KMART EssentialHome 6970107991638 User manual

IVYER

P 5P 4
16-Shelves 17-Lower Back Panel 18-Upper Back Panel
Qty: 2 PCS Qty: 2 PCS Qty: 1 PC
19-Pull-out Deck A-Cam Bolt B-Large Cam Lock
Qty: 1 PC Qty: 16 PCS Qty: 8 PCS
C-Small Cam Lock D-Wood Dowel E-Long Allen Bolt
Qty: 8 PCS Qty: 16 PCS Qty: 12 PCS
F-Tank Nut G-Long Flat-Head Screw H-Door Hinge
Qty: 8 PCS Qty: 16 PCS Qty: 4 PCS
I-Medium Flat-Head Screw J-Drawer Handle K-Short Flat-Head Screw
Qty: 16 PCS Qty: 2 PCS Qty: 4 PCS
PARTS & HARDWARE LIST
L-Lock Caster M-Swivel Caster N-Pan Head Screw
Qty: 2 PCS Qty: 2 PCS Qty: 16 PCS
O-Door Knob P-Pan Head Bolt Q-Allen Wrench
Qty: 2 PCS Qty: 2 PCS Qty: 1 PC
R-Shelf Pin
Qty: 8 PCS
PARTS & HARDWARE LIST

P 11P 10
%['[
%
'
'


STEP #9
STEP #10
Attach Upper Vertical Divider (7) to frame
as shown, using Wood Dowels (D), and
Large Cam Locks (B).
Slide in Upper Back Panel (18) along the grooves as shown.
ASSEMBLY INSTRUCTIONS
&[
*[
;
&
%
%['[
'
'
'
'
%
*
*






STEP #11
STEP #12
Attach Top Panel (1) using Wood
Dowels (D), Large Cam Locks (B).
Assemble the drawers by following the figures below.
ASSEMBLY INSTRUCTIONS

P 13P 12


5[
5
STEP #13
STEP #14
Push in Shelf Pins (R) as shown,
be sure to align each shelf pin
at the same height level, then
put Shelves (16) into place.
DRAWER ASSEMBLY:
Pull out tracks and
ball arrays as far as
possible. Gently insert
bayonets into tracks
and move back and
forth until they move
smoothly.
ASSEMBLY INSTRUCTIONS
PULL-OUT TRAY
ASSEMBLY:
Push in ball arrays
as much as possible.
Gently insert bayonets
into tracks and move
back and forth until
they move smoothly.
+[,[2[3[
2
3
,
+


STEP #15
STEP #16
See next page for door hinge adjustment.
Attach Door Hinges
(H) to Door Panels (8)
using Medium Flat Head
Screws (I). Attach the
doors to the cart and
secure with Medium Flat
Head Screws (I).
Install Door Knobs (O) to
door panels as shown,
using Pan Head Bolts (P).
The kitchen cart is now ready for use.
ASSEMBLY INSTRUCTIONS
