Knightsbridge PAT1300W Setup guide

SAFETY AND INSTALLATION INSTRUCTIONS
120106-SM
HELPLINE:
• T: 01933 673 144
• F: 01933 678 083
• E: [email protected]
Visit our website:
www.eterna-lighting.co.uk
LAMP REPLACEMENT:
1. Unplug or switch off the electricity at the mains.
2. Release the front cover screws.
3. Remove and replace lamp. Use a soft cloth; do not touch with bare fingers.
4. Refit front cover, ensure gasket is in position and tighten screws.
REPLACEMENT LAMP TYPE:
Wattage: 1300W
Supply Voltage: 240V
Size: 255mm
Type: R7 IR Ruby Halogen
EVENTUALLY, YOU MAY WANT TO REPLACE THIS LIGHT FITTING:
When your product comes to the end of its life or you choose to update or upgrade it by replacing
it, please do not dispose of it with your normal household waste and please recycle where facilities
exist. When you need to dispose of this fitting you can check with your retailer or local authority
for suitable options. New regulations require the recycling of Waste from Electrical and Electronic
Equipment (European “WEEE Directive” effective August 2005—UK WEEE Regulations effective 2nd
January 2007). Environment Agency Registered Producer: WEE/GA0248QZ.
Model:
PAT1300W
1300W WALL MOUNTED PATIO HEATER
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE USING YOUR NEW FITTING
PLEASE RETAIN FOR FUTURE REFERENCE
Pack contents:
1 x heater c/w 5m mains
lead with 3-pin plug
1 x mounting bracket
1 x bolt
1 x locknut
IP54
1m

General Information & Cleaning: Installation:
READ THIS FIRST:
Check the pack and make sure you have all of
the parts listed on the front of this booklet. If
not, contact the outlet where you bought this
product.
This product contains glass, care must be taken
when assembling, fitting or handling to prevent
personal injury or damage to the product.
This product must be installed by a competent
person in accordance with the current building
and IEE wiring regulations.
As the buyer, installer and/or user of this product
it is your own responsibility to ensure that this
fitting is fit for the purpose for which you have
intended it. Eterna Lighting cannot accept any
liability for loss, damage or premature failure
resulting from inappropriate use.
If in any doubt, consult a qualified electrician.
This product is designed and constructed
according to the principles of the appropriate
British Standard and is intended for normal
domestic service. Using this heater in any other
environments may result in a shortened working
life.
The heater lamps supplied with this fitting are
consumable parts and therefore may be outside
of any warranty offered.
Do not use the fitting without the safety shield
fitted and replace the safety shield if it is cracked
or broken.
When replacing the heater lamp, do not touch
with bare fingers, grip the lamp with a tissue or
clean soft cloth.
This unit is suitable for indoor and outdoor use.
This product is suitable for installation on
surfaces with normal flammability e.g. wood,
plasterboard and masonry. It is not suitable
for use on highly flammable surfaces (e.g.
polystyrene, textiles).
Before making fixing hole(s), check that
there are no obstructions hidden beneath the
mounting surface such as pipes or cables.
Make sure that the fixings are strong enough to
support the considerable weight of the fitting
and hold it rigidly.
The heater must be positioned so that there is
at least 1.0m between the heater and any other
surfaces.
When choosing the location for your new heater,
ensure that the fixings will be anchored in a solid
surface e.g. concrete, brick or a joist—do not fix
directly onto panelling, cladding, plasterboard
etc. Always use the supplied baskets where
possible.
This product must be connected to earth
termination.
WARNING! This product becomes hot!
This product is not intended to be used by
children and persons with sensory, physical
and/or mental impairments that would prevent
them from using it safely.
Small children should be supervised to ensure
that they do not play with this appliance.
IMPORTANT— Do not cover or obstruct your
patio heater.
Always switch off at the socket and remove the
plug before changing the heater lamp.
The plug is fitted with a 13Amp fuse. When
replacing, use only a 13Amp fuse approved
to BS1362 and carrying the relevant approval
mark. Never use the plug with the fuse bypassed
or omitted. If the external flexible cable of
this heater is damaged it shall be exclusively
replaced by a service agent or similar qualified
engineer.
If in doubt, consult a qualified electrician
CLEANING:
Disconnect the power and clean the exterior
only of this fitting with a moist (not wet) cloth.
Do not use any chemical or abrasive cleaners.
INSTALLATION:
Choose the location for your new patio heater
giving consideration to the points above.
1. Use the mounting bracket to mark the position
of fixing, use a spirit level to ensure it is fixed
level.
2. Drill the wall at marked positions & fix
the bracket using appropriate fixings (not
supplied).
3. Using the bolt and locknut, secure heater/
tilting bracket onto the wall bracket previously
fixed.
4. Adjust/secure the angle of the heater
to provide heat to the desired area by
unscrewing/tightening the locknut of the
tilting bracket assembly.
5. Ensure that you meet the minimum distance
of 1 metre from lighted objects.
6. Ensure that the mains cable does not cause a
trip hazard.
7. Insert the plug into a suitable mains supply
socket and switch on the power. If the socket
or extension lead is situated outdoors it must
be the correct IP rated type.
CAUTION:
DO NOT TOUCH THE HEATER OR ADJUST
ITS POSITION UNLESS THE POWER IS
DISCONNECTED AND IT HAS COOLED DOWN
