Kobalt SGY-AIR161 User manual

ITEM #0002174
MODEL #SGY-AIR161
50-PIECE AIR TOOL KIT
Français p. 32
Español p. 64
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-888-3KOBALT (1-888-356-2258),
8:00 a.m. - 8:00 p.m., EST, Monday - Friday.
1
KOBALT® and the K & Design® are registered
trademarks of LF, LLC.All rights reserved.
PLUGS
SPORTS
NEEDLES
SAFETY
NOZZLE
TAPERED
NOZZLE
RUBBER
NOZZLE GRINDING STONES
WRENCHES
OIL BOTTLE
TAPE SEAL
1/2” 7/16” BITS HOLDER 3/8” TO 1/2”
ADAPTOR
EXTENSION BAR
1” 7/8” 11/16” 9/16”
BITS
50-PSI GAUGE
DUAL TIRE CHUCK
CHISELS
HAMMER
BLOW GUN
ROTARY TOOL
IMPACT
RATCHET

TABLE OF CONTENTS
2
Safety Information ............................................................................................... 3
Package Contents ............................................................................................... 9
Preparation .......................................................................................................... 12
Assembly Instructions .......................................................................................... 12
Operating Instructions ........................................................................................ 20
Care and Maintenance ....................................................................................... 26
Troubleshooting .................................................................................................. 27
Warranty ............................................................................................................. 27
Parts List ............................................................................................................. 28
IMPORTANT: To operate correctly, this tool requires airflow that is at least 6 cubic feet per minute (CFM),
4.5 CFM, 4 CFM, at 90 pounds per square inch (PSI). Check the specifications of your air compressor to be
sure that it can support both the minimum CFM and PSI required. An air hose may cause up to 15 PSI drop
in pressure, so you may need to set the output higher to maintain the required pressure at the tool.
333
IMPORTANT : Cet outil nécessite un débit d’air d’au moins 6 pi par minute, 4,5 pi par minute, 4 pi par
minute à une pression de 90 PSI. Vérifiez les spécifications de votre compresseur d’air afin de vous assurer
3
qu’il satisfait aux exigences minimales (pi /min et PSI). L’utilisation d’un tuyau à air peut entraîner une chute
de pression de jusqu’à 15 PSI. Il peut donc s’avérer nécessaire d’augmenter la pression afin de maintenir
un niveau adéquat.
IMPORTANTE: Para funcionar de manera correcta, esta herramienta requiere un flujo de aire de por lo
menos 6 pies cúbicos por minutos (CFM por sus siglas en inglés), 4,5 CFM, 4 CFM para 90 libras por
pulgada cuadrada (PSI, por sus siglas en inglés). Revise las especificaciones de su compresora de aire
para asegurarse de que puede soportar tanto los CFM como las PSI mínimas requeridas. Una manguera
de aire comprimido puede causar una caída de hasta 15 PSI en la presión, de manera que puede necesitar
configurar la potencia más alta para mantener la presión requerida en la herramienta.

3
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate
or install the product.
Improper operation or maintenance of this product could result in serious injury and
property damage. Read and understand all warnings and operation instructions
before using this equipment. When using air tools, basic safety precautions should
always be followed to reduce the risk of personal injury.
WARNING
Some dust created by power sanding, sawing, grinding, drilling and other related
activities contains chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. A listing of chemicals can be obtained from
www.oehha.ca.gov under proposition 65. Some examples of these chemicals are:
Lead from lead-based paints
Crystalline silica from bricks, cement and other masonry products
Arsenic and chromium from chemically-treated lumber
Users of these tools should review the chemical composition of the work surface
and any products in conjunction with the operation of these tools for any such
chemicals prior to engaging in any activity that creates dust and/or microscopic
particles.
Users should obtain the material safety data sheets from all identified chemicals,
either from the manufacturer or their employer, and proceed to study, understand,
and follow all instructions and warnings for exposure to such chemicals. Your risk
from these exposures varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals, work in a well-ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
WARNING
This product contains one or more chemicals known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands after
handling.
WARNING

RISK OF EYE OR HEAD INJURY
WHAT COULD HAPPEN HOW TO PREVENT IT
Air powered equipment and power tools
are capable of propelling materials such
as fasteners, metal chips, sawdust and
other debris at high speed which could
result in serious eye injury.
Compressed air can be hazardous. The
air system can cause injury to soft
tissue areas such as eyes, ears, etc.
Particles or objects propelled by the
stream can cause injury.
Tool attachments can become loose or
break and fly apart propelling particles
at the operator and others in the work
area.
WARNING
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
Abrasive tools such as sanders and
grinders, rotating tools such as drills,
and impact tools such as nailers,
staplers, wrenches, hammers and
reciprocating saws are capable of
generating sparks, which could result in
ignition of flammable materials.
Exceeding the maximum pressure
rating of tools or accessories could
cause an explosion resulting in
serious injury.
RISK OF FIRE OR EXPLOSION
Never operate tools near flammable
substances such as gasoline, naphtha,
cleaning solvents, etc.
Work in a clean, well-ventilated area
free of combustible materials.
Never use oxygen, carbon dioxide or
other bottled gases as a power source
for air tools.
Use compressed air regulated to a
maximum pressure at or below the
rated pressure of any attachments.
Never connect to an air source that is
capable of exceeding 200 psi.
Always verify prior to using the tools
that the air source has been adjusted
to the rated air pressure range.
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF LOSS OF HEARING
Always wear ANSI S3.19 hearing
protection.
Long term exposure to noise produced
from the operation of air tools can lead
to permanent hearing loss.
4
Always wear ANSI approved Z87.1
safety glasses with side shields.
Never leave operating tool unattended.
Disconnect air hose when tool is not
in use.
For additional protection use an
approved face shield in addition to
safety glasses.
Make sure that any attachments are
securely assembled.

WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
INHALATION HAZARD
Always wear properly fitting facemask
or respirator when using such tools.
Always work in a clean, dry,
well-ventilated area.
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF INJURY
A tool left unattended, or with the air
hose attached, can be activated by
unauthorized persons leading to
their injury or injury to others.
Air tools can propel fasteners or other
materials throughout the work area.
A wrench or a key that is left attached to
a rotating part of the tool increases the
risk of personal injury.
Using inflator nozzles for duster
applications can cause serious injury.
Air tools can become activated by
accident during maintenance or tool
changes.
Air tools can cause the workpiece to
move upon contact, leading to injury.
Remove air hose when tool is not in
use and store tool in secure location
away from reach of children and
untrained users.
Use only parts, fasteners and accessories
recommended by the manufacturer.
Keep work area clean and free of
clutter. Keep children and others away
from tool while it is in operation.
Keep work area well lit.
Remove adjusting keys and wrenches
before turning the tool on.
DO NOT use inflator nozzles for duster
applications.
Remove air hose to lubricate or add
grinding attachments, impact sockets,
chisels, etc. to the tool.
Never carry the tool by hose.
Avoid unintentional starting. Don't carry
hooked-up tool with finger on trigger.
Only an authorized service
representative should do repair servicing.
Use clamps or other devices to prevent
movement.
5
Abrasive tools, such as grinders,
sanders and cut-off tools generate dust
and abrasive materials, which can be
harmful to human lungs and respiratory
system.
Some materials such as adhesives and
tar contain chemicals whose vapors
could cause serious injury with
prolonged exposure.

Loss of control of the tool can lead to
injury to self or others.
Poor quality, improper or damaged tools
and attachments can fly apart during
operation, propelling particles
throughout the work area causing
serious injury.
Improperly maintained tools and
accessories can cause serious injury.
There is a risk of bursting if the tool is
damaged.
Use only accessories identified by the
manufacturer to be used with specific
tools.
Never use tool while using drugs or
alcohol.
Don't overreach. Keep proper footing
and balance.
Keep handles dry, clean and free from
oil/grease.
Stay alert. Watch what you are doing.
Use common sense. Do not operate
tool when you are tired.
Always use tool attachments rated for
the speed of the power tool.
Never use tools, which have been
dropped, impacted or damaged by use.
Use only impact grade sockets on an
impact wrench.
Do not apply excessive force to the tool;
let the tool perform the work.
Maintain the tool and accessories
with care.
Keep the tool clean. A properly
maintained tool reduces the risk of
binding and is easier to control.
Check for misalignment or binding of
moving parts, breakage of parts and
any other condition that affects the
tool's operation. If damaged, have the
tool serviced before using.
Use of an accessory not intended for
use with the specific tools increases the
risk of injury to persons.
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF INJURY
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF ELECTRIC SHOCK
Using air tools to attach electrical wiring
can result in electrocution or death.
This tool is not provided with an
insulated gripping surface. Contact with
a “live” wire will also make exposed
metal parts of the tool “live” and can
result in electrocution or death.
Never use tools to attach electrical
wiring while energized.
Avoid body contact with grounded
surfaces such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your
body is grounded.
6

Tools which contain moving elements,
or drive other moving parts, such as
grinding accessories, sockets, chisels,
etc., can become entangled in hair,
clothing, jewelry and other loose
objects, resulting in severe injury.
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF ENTANGLEMENT
Never wear loose fitting clothes or
apparel that contains loose straps or
ties, etc., which could become
entangled in moving parts of the tools.
Remove any jewelry, watches,
identifications, bracelets, necklaces,
etc., which might become caught by
the tool.
Keep hands away from moving parts.
Tie up or cover long hair.
Always wear proper fitting clothing and
other safety equipment when using
the tool.
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF CUT OR BURNS
Keep the working part of the tool away
from hands and body.
Tools that impact, rotate, chisel, etc. are
capable of causing serious injury.
7
WHAT COULD HAPPEN HOW TO PREVENT IT
WARNING
RISK OF ELECTRIC SHOCK
Air tool accessories such as impact
sockets, chisels and grinding stones
that come into contact with hidden
electrical wiring could cause
electrocution or death.
Thoroughly investigate the workpiece
for possible hidden wiring before
performing work.

PRODUCT SPECIFICATIONS
3/8 IN. AIR RATCHET WRENCH
SPECIFICATIONS
3/8 IN.
160 RPM +/- 10%
60 FT.-LBS.
4.5 CFM
1/4 IN. NPT
3/8 IN.
90 PSI
COMPONENT
SQUARE DRIVE
FREE SPEED
MAXIMUM TORQUE
AVERAGEAIR CONSUMPTION
AIR INLET
AIR HOSE
WORKING PRESSURE
AIR HAMMER
1/4 IN. AIR ROTARY TOOL
SPECIFICATIONS
0.401 IN.
1.6 IN.
4,500 B.P.M. +/- 10%
4.5 CFM
1/4 IN. NPT
3/8 IN.
90 PSI
COMPONENT
CHISEL SHANK DIAMETER
STROKE LENGTH
BLOW PER MINUTE
AVERAGEAIR CONSUMPTION
AIR INLET
AIR HOSE
WORKING PRESSURE
SPECIFICATIONS
1/4 IN.
25,000 RPM +/- 10%
4 CFM
1/4 IN. NPT
3/8 IN.
90 PSI
COMPONENT
COLLET
FREE SPEED
AVERAGEAIR CONSUMPTION
AIR INLET
AIR HOSE
WORKING PRESSURE
1/2 IN. AIR IMPACT WRENCH
SPECIFICATIONS
1/2 IN.
7,200 RPM +/- 10%
350 FT.-LBS.
6 CFM
1/4 IN. NPT
3/8 IN.
90 PSI
COMPONENT
SQUARE DRIVE
FREE SPEED
MAXIMUM TORQUE
AVERAGEAIR CONSUMPTION
AIR INLET
AIR HOSE
WORKING PRESSURE
8

PACKAGE CONTENTS
PLUGS
SPORTS
NEEDLES
SAFETY
NOZZLE
TAPERED
NOZZLE
RUBBER
NOZZLE GRINDING STONES
WRENCHES
OIL BOTTLE
TAPE SEAL
1/2” 7/16” BITS HOLDER 3/8” TO 1/2”
ADAPTOR
EXTENSION BAR
1” 7/8” 11/16” 9/16”
BITS
50-PSI GAUGE
DUAL TIRE CHUCK
CHISELS
HAMMER
BLOW GUN
ROTARY TOOL
IMPACT
RATCHET
UP
N
Y
O
L
M
K
TQ R
S
V
W
X
J
I
H
G
C
E
D
A
B
F
DESCRIPTION
1/2 in. Impact Wrench
3/8 in. Ratchet Wrench
Air Hammer
1/4 in. Rotary Tool
Blow Gun
Spring Retainer
3 in. Extension Bar
3/8 in. to 1/2 in. Adapter
Bit Holder
1/2 in. Dr. Impact Socket
Chisel
50-PSI Tire Gauge
Dual Tire Chuck
Screwdriver Bit
Bit Base
Grinding Stone
Rubber Nozzle
Tapered Nozzle
Safety Nozzle
Sports Needle
Male Plug
Female Plug
Wrench
Oil Bottle
Seal Tape
Case
QTY.
1
1
1
1
1
1
1
1
1
6
2
1
1
10
1
5
1
1
1
2
5
1
2
1
1
1
PAR T
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
9
Z

PACKAGE CONTENTS
DESCRIPTION
1/2 in. Impact Wrench
Anvil
Trigger
Switch
Air Inlet
QUANTITY
1
1
1
1
1
PAR T
A1
B1
C1
D1
E1
A1
B1
C1
D1
E1
1/2 IN. AIR IMPACT WRENCH
DESCRIPTION
3/8 in. Air Ratchet Wrench
Anvil
F/R Knob
Trigger
Air Regulator
Exhaust Deflector
Air Inlet
Steel Ball Indicator
QUANTITY
1
1
1
1
1
1
1
1
PAR T
A2
B2
C2
D2
E2
F2
G2
H2
B2
C2
D2
A2
E2
G2
H2
F2
3/8 IN. AIR RATCHET WRENCH
10

PACKAGE CONTENTS
DESCRIPTION
Air Hammer
Spring Retainer
Chisel
Trigger
Cylinder
Air Inlet
QUANTITY
1
1
2
1
1
1
PAR T
A3
B3
C3
D3
E3
F3
A3
B3
C3
D3
E3
F3
DESCRIPTION
1/4 in. Air Rotary Tool
Collet Jacket
Collet Holder
Collet
Trigger
Lever
Air Regulator
Exhaust Deflector
Steel Ball Indicator
Air Inlet
QUANTITY
1
1
1
1
1
1
1
1
1
1
PAR T
A4
B4
C4
D4
E4
F4
G4
H4
I4
J4
A4
B4 C4
D4
G4
E4
F4
I4
H4
J4
AIR HAMMER
1/4 IN. AIR ROTARY TOOL
11

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list above. If any part is missing or damaged, do not
attempt to assemble the product.
Estimated Assembly Time: 5-10 minutes
Tools Required for Assembly (not included): Adjustable wrench
ASSEMBLY INSTRUCTIONS
2
1
1. Remove the air inlet protective cap from the
air inlet (E1).
2. Mount a male plug by hand into the air
inlet (E1).
NOTE Use thread sealant tape on the male plug
and tighten it with a wrench (not included) for
airtight connection. Do not overtighten.
1/2 IN. AIR IMPACT WRENCH
12

3
3. Place 2 - 3 drops of air tool oil into the male
plug before each use.
ASSEMBLY INSTRUCTIONS
5
4
4. Choose the correct impact socket as needed
and mount it onto the anvil (B1).
5. If longer reach is necessary, use the extension
bar and then mount impact socket onto the bar.
Only use impact sockets that have an RPM
rating equal to or greater than the tool itself.
WARNING
13

6
6. Connect air supply hose to the male plug. Set
the working pressure at 90 PSI for best tool
performance.
NOTE Working pressure refers to the air line
pressure set to tool when tool is under working
conditions.
ASSEMBLY INSTRUCTIONS
14
2
1
1. Remove the air inlet protective cap from the
air inlet (G2).
2. Mount a male plug by hand into the air
inlet (G2).
NOTE Use thread sealant tape on the male plug
and tighten it with a wrench (not included) for
airtight connection. Do not overtighten.
3/8 IN. AIR RATCHET WRENCH

3
3. Place 2 - 3 drops of air tool oil into the male
plug before each use.
5
4
4. Mount the 3/8 in. to 1/2 in. adapter onto the
anvil (B2) if necessary, and then choose the
correct impact socket as needed and mount it
onto the adapter.
Only use impact sockets that have an RPM
rating equal to or greater than the tool itself.
WARNING
5. Connect air supply hose to the male plug. Set
the working pressure at 90 PSI for best tool
performance.
NOTE Working pressure refers to the air line
pressure set to tool when tool is under working
conditions.
ASSEMBLY INSTRUCTIONS
15

2
3
1
2. Mount a male plug by hand into the air
inlet (F3).
3. Place 2 - 3 drops of air tool oil into the male
plug before each use.
NOTE Use thread sealant tape on the male plug
and tighten it with a wrench (not included) for
airtight connection. Do not overtighten.
1. Remove the air inlet protective cap from the
air inlet (F3).
ASSEMBLY INSTRUCTIONS
AIR HAMMER
16

5
C3
4
6
4. Insert a chisel (C3) into the opening of
cylinder (E3).
5. Screw the spring retainer (B3) onto the
cylinder (E3) and firmly secure it.
6. Connect air supply hose to the male plug. Set
the working pressure at 90 PSI for best tool
performance.
NOTE Working pressure refers to the air line
pressure set to tool when tool is under working
conditions.
ASSEMBLY INSTRUCTIONS
17

ASSEMBLY INSTRUCTIONS
2
3
1
1. Remove the air inlet protective cap from the
air inlet (J4).
2. Mount a male plug by hand into the
air inlet (J4).
3. Place 2-3 drops of air tool oil into the male
plug before each use.
NOTE Use thread sealant tape on the male plug
and tighten it with a wrench (not included) for
airtight connection. Do not overtighten.
1/4 IN. AIR ROTARY TOOL
18

4
5
6
ASSEMBLY INSTRUCTIONS
4. Loosen the collet jacket (B4) counterclockwise
by hand or with the large wrench while holding
the small wrench on the flats of the
collet holder (C4).
5. Insert a grinding accessory like a grinding
stone into the collet (D4).
6. Tighten the collet jacket (B4) clockwise with
large wrench while holding the small wrench
on the flats of the collet holder (C4). Make sure
that the grinding stone is installed securely
and tightly.
Only use grinding accessories that have an RPM
rating equal to or greater than the tool itself.
WARNING
19

ASSEMBLY INSTRUCTIONS
7
7. Connect air supply hose to the male plug. Set
the working pressure at 90 PSI for best tool
performance.
NOTE Working pressure refers to the air line
pressure set to tool when tool is under working
conditions.
1
1. How to install/tighten threaded fasteners.
Push the switch (D1) forward and have the
arrow on the switch (D1) pointing at either of
the settings 1, 2, 3 as shown. Press the trigger
(C1). The tool anvil (B1) runs clockwise.
2
2. How to remove/loosen threaded fasteners.
Push the switch (D1) backward and have the
arrow on the switch (D1) pointing at “R” position
as shown. Press the trigger (C1). The tool anvil
(B1) runs counterclockwise.
OPERATING INSTRUCTIONS
1/2 IN. AIR IMPACT WRENCH
20
