To avoid damaging the hose reel (A), always hold on to air hose (B) while it is
rewinding.
1. To extend air hose (B), slowly extend air hose to desired length. The hose reel will
make a “clicking” sound as the hose is pulled out. The clicking sound you hear is
the drum locking into place so it will not retract when you let go of the air hose. It
may be necessary to pull air hose beyond desired length to keep it from
automatically retracting.
OPERATING INSTRUCTIONS
CARE AND MAINTENANCE
Always operate the product with care by following the operating instructions.
NOTE
TROUBLESHOOTING
If you have any questions regarding the product, please call customer service at
888-3KOBALT, 8:00 a.m.- 8:00 p.m. EST, Monday-Sunday. You could also contact
2. To retract, slowly pull air hose (B) until clicking stops. While holding the air hose,
let the hose automatically draw back until the bumper (I) stops against the hose
guide (H).
PROBLEM CORRECTIVE ACTIONPOSSIBLE CAUSE 1. Adjust roller bracket in the
best angle/position.
2. Replace roller bracket.
Air hose cannot be
pulled smoothly or
blocks.
1.
Roller bracket is not adjusted
in the best angle/position.
2. Roller bracket is damaged.
8
Air hose will not
retract smoothly.
Air hose will not
retract all the way.
2. Roller bracket is damaged.
1. Not enough tension on the
coil spring.
1. Adjust roller bracket in the
best angle/position.
2. Replace roller bracket.
1.
Roller bracket is not adjusted
in the best angle/position.
Pull out approximately 6-ft of
hose, and lock hose in place.
Remove the bumper (H) from
the hose and slide the hose out
of hose gudie (G) so the hose is
hanging loose.
A.To increase tension, wrap the
loose hose one time around the
reel drum.
B.To decrease tension, unwrap
the hose one time from the drum.
- Run the hose back through the
hose gudie (G) and reattach
the hose stopper.
- Pull the hose out several feet
to check the tension.
