Kobold BVB-1101 User manual

Operating Instructions
for
Manifold Valves for Multiple Installation
for Lubricating Oil Circuits
Model: BVB

BVB
page 2 BVB K02/0822
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 3
3.Instrument Inspection .................................................................................... 3
4.Regulation Use ............................................................................................. 3
5.Operating Principle ........................................................................................ 4
6.Mechanical Connection ................................................................................. 4
7.Technical Information .................................................................................... 5
8.Order Codes ................................................................................................. 5
9.Dimensions ................................................................................................... 6
10.Disposal ........................................................................................................ 7
11.EU Declaration of Conformance ................................................................... 8
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

BVB
BVB K02/0822 page 3
2. Note
Please read these operating instructions before unpacking and putting the unit
into operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
The devices are only to be used, maintained and serviced by persons familiar
with these operating instructions and in accordance with local regulations
applying to Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC-machine guidelines.
as per PED 2014/68/EU
In acc. with Article 4 Paragraph (3), "Sound Engineering Practice", of the
PED 2014/68/EU no CE mark.
Diagram 8, Pipe, Group 1 dangerous fluids
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of
the delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Manifold Valves for Lubricating Oil Circuits: Model: BVB
4. Regulation Use
Any use of the Manifold Valves, model: BVB, which exceeds the manufacturer’s
specifications, may invalidate its warranty. Therefore, any resulting damage is not
the responsibility of the manufacturer. The user assumes all risk for such usage.

BVB
page 4 BVB K02/0822
5. Operating Principle
For centralised flow measurement and switching, for example, with lubricating oil
circuits we recommend the KOBOLD manifold valves for multiple device
installation.
A group of manifolds from one to 8 pcs. can be assembled with the flowmeters.
The max. flow of each group does not exceed 24 l/min.
Design
6. Mechanical Connection
Before installation
 Remove all packing materials and transport retainers and ensure that no such
materials remain in the device.
 Make sure that the maximum operating pressure and temperature of the
device are not exceeded. (see section 7 Technical Information)
 Mount the manifold in the pipe.
 Avoid water hammer in the measuring tube e.g. caused through a very quick
shut off the flow.
 If possible, check directly after mechanical installation that the connection
thread to pipe is fully sealed.
 Avoid the mounting of the flowswitches in magnetic fields.

BVB
BVB K02/0822 page 5
7. Technical Information
Housing: Aluminium, anodized
Process connection: G 1/2 IG (BVB)
Please specify whether for model VKG or VKM
Max. flow rate: 24 l/min. per group
Seal: Buna N
Max. temperature: 100 °C
Max. pressure: PN 64
(Please compare with the max. pressure allowed for
flowmeter/-switch)
kv-value: 0.5 bar at 9.5l/min water
1 bar at 14 l/min. water
2 bar at 20 l/min. water
8. Order Codes
Order Details (Example: BVB-1101)
Order number Version
BVB-1101 1 manifold valve
BVB-1102 2- fold manifold valve
BVB-1103 3- fold manifold valve
BVB-1104 4- fold manifold valve
BVB-1105 5- fold manifold valve
BVB-1106 6- fold manifold valve
BVB-1107 7- fold manifold valve
BVB-1108 8- fold manifold valve
Please order the necessary flow meters separately and mention if the units must
be assembled together.
Example:
Item 1 BVB – 1102 x 1 piece
Item 2 VKG – 2104 RO R 15 x 2 pieces

BVB
page 6 BVB K02/0822
9. Dimensions

BVB
BVB K02/0822 page 7
10. Disposal
Note!
 Avoid environmental damage caused by media-contaminated parts
 Dispose of the device and packaging in an environmentally friendly
manner
 Comply with applicable national and international disposal regulations and
environmental regulations.
Batteries
Batteries containing pollutants are marked with a sign consisting of a crossed-out
garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal that
is decisive for the classification as containing pollutants:
Cd1 Hg2 Pb3 Li4
1. „Cd" stands for cadmium
2. „Hg" stands for mercury
3. „Pb" stands for lead
4. „Li" stands for lithium
Electrical and electronic equipment

BVB
page 8 BVB K02/0822
11. EU Declaration of Conformance
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Manifold Valves for Multiple Installation for Lubricating Oil Circuits
Model: BVB-…
to which this declaration relates is in conformity with the standards noted below:
EN IEC 63000:2018 Technical documentation for the assessment of electrical
and electronic products with respect to the restriction of hazardous substances
Also, the following EC guidelines are fulfilled:
2011/65/EU RoHS (category 9)
2015/863/EU Delegated Directive (RoHS III)
Hofheim, 31 March 2022
H. Volz M. Wenzel
General Manager Proxy Holder
