Kobold DF KL Series User manual

Operating Instructions
for
Evaluation Electronics
Model: ZED-K
and DF-…KLxxx

ZED-K
page 2 ZED-K K11/0523
1.Contents
1. Contents........................................................................................................2
2. Note ..............................................................................................................3
3. Instrument Inspection....................................................................................3
4. Regulation Use .............................................................................................3
5. Operating Principle........................................................................................4
6. Electrical Connection ....................................................................................5
6.1 ZED-K field housing and control panel installation...............................5
6.2 DF-…KLxxx, cable connection.............................................................5
6.3 Connection example............................................................................6
7. Operation and Menu Structure......................................................................7
7.1 General................................................................................................7
7.2 Function of the control keys.................................................................7
7.3 Character explanation for main menu..................................................9
7.4 General settings...................................................................................9
7.5 Flow, analogue output and relay S1 ..................................................11
7.6 Relay S2............................................................................................13
7.7 User alignment and service-settings..................................................14
7.8 Error report ........................................................................................16
8. Relay Functions ..........................................................................................17
8.1 Switching characteristic limit value ....................................................17
8.2 Switching characteristic window ........................................................17
9. Technical Information..................................................................................18
10. Order Codes ...............................................................................................18
11. Dimensions .................................................................................................18
12. Disposal......................................................................................................19
13. EU Declaration of Conformance .................................................................20
14. UK Declaration of Conformity......................................................................21
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

ZED-K
ZED-K K11/0523 page 3
2.Note
Please read these operating instructions before unpacking and putting the unit
into operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for
currently manufactured version of our products. Due to technical changes, the
instruction manuals available online may not always correspond to the product
version you have purchased. If you need an instruction manual that corresponds
to the purchased product version, you can request it from us free of charge by
email ([e-mail]) in PDF format, specifying the relevant invoice
number and serial number. If you wish, the operating instructions can also be
sent to you by post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar
with these operating instructions and in accordance with local regulations
applying to Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC-machine guidelines.
3.Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of
the delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
•Electronics for measuring and monitoring model: ZED-K and DF-…KLxxx
4.Regulation Use
Any use of the Evaluation Electronics, model: ZED-K and DF-..KLxxx, which
exceeds the manufacturer’s specification, may invalidate its warranty. Therefore,
any resulting damage is not the responsibility of the manufacturer. The user
assumes all risk for such usage.

ZED-K
page 4 ZED-K K11/0523
5.Operating Principle
The evaluation unit changes the frequency signal of the pickup into a flow
reading and into a scalable analogue signal.
The top display line of the double-spaced display shows the flow value with
measuring unit and the bottom line a bargraph indicator proportional to the
measuring value.
The two relays with floating output changeover contacts continuously monitor
the flow values. Switching point, hysteresis, a window point, and switch on or off
delay can be set separately for each relay. The switching points can also be set
directly by using the control keys without having to change over into the menu. A
red LED indicates the switching status.
The analogue output is optionally available as current output with 0(4)...20 mA
or as voltage output with 0...10 V. The menu languages can be switched
between German or English. If used where the flow readings change rapidly, the
display can be pacified and the analogue reading averaged by switching on
some software.
A MIN/MAX reading memory determines the extreme readings of the flow. The
display of the readings and the resetting are achieved by using the keys without
having to change into the menu. Resetting by using the keys can also be
blocked.
The set parameters can be protected against unauthorized alteration by using a
password function.

ZED-K
ZED-K K11/0523 page 5
6.Electrical Connection
6.1 ZED-K field housing and control panel installation
*) Don’t connect the clamp!
6.2 DF-…KLxxx, cable connection
Wire number ZED-K electronics
1 +24 VDC
2
GND
3
4-20 mA / 0-10 V
4
GND
5
S1 N/O
6
S1 COM
7
S1 N/C
8
S2 N/O
9
S2 COM
10
S2 N/C
*) Don’t connect the wire!

ZED-K
page 6 ZED-K K11/0523
6.3 Connection example
PNP-Sensor NPN-Sensor
Namur-Sensor

ZED-K
ZED-K K11/0523 page 7
7. Operation and Menu Structure
7.1 General
Only the menu items of which the lines are marked in the selection matrix (in the
right position) in grey colour, are available in the respective instrument version.
Italic written values in the menu structure are blinking in the display, if
they have been chosen for any input.
The parameter can only be changed, if the security code has been
entered correctly! The message „locked“ will appear if the input has
not been activated.
7.2 Function of the control keys
Operating mode >Measure< :
- Press briefly: a) Display total quantity, then
Display corresponding scale unit or
b) Reset status reports.
- Press for 3 sec: Switch to operating mode >Parameterise<.
- Press briefly: Display min. flow value (MIN value memory).
- Press for 3 sec: Enter switching point for Relay S1 s1SPoint
(only if parameter SPdirect is set to “yes”).
- Press briefly: Display max. flow value (MAX value memory).
- Press for 3 sec: Enter switching point for Relay S2 s2SPoint
(only when parameter SPdirect is switched to “yes”).
PGM
ENTER

ZED-K
page 8 ZED-K K11/0523
Press for 3 sec: Sets min. and max. value memory to flow value
(only when parameter fMMReDir is switched to “yes”).
Operating mode >Parameterize<:
- Press briefly: a) Open parameter group or
b) Change parameter (go lower in menu level) or
c) Adopt value input.
- Press for 3 sec: Abort input and go back one
menu level.
- Press briefly: a) Select parameter group or parameter or
b) Reduce selected number by 1 or
c) Select list value (e.g.... L/m, L/h, m3/m, ...).
- Press briefly: a) Select parameter group or parameter or
b) Increase selected number by 1 or
c) Select list value (e.g.... m3/m, L/h, L/m, ...).
Note: If no button is pressed for 20 seconds during parameterising, the
instrument automatically switches back into >measuring< mode.
+
PGM
ENTER

ZED-K
ZED-K K11/0523 page 9
7.3 Character explanation for main menu
( e) -Button press shortly.
( E) -Button press and hold for approx. 3 seconds.
(▼) -Button press shortly.
(▲) -Button press shortly.
7.4 General settings
PGM
ENTER
PGM
ENTER

ZED-K
page 10 ZED-K K11/0523
GENERAL SETTINGS
Menu Item Parameter / Function Explanation / Values / Other
Language Select menu language German or English
fUnitFS * Measuring unit for flow
measurement
mL/s, mL/m, L/s, L/m, L/h, m3/m, m3/h,
GPM, GPH, UU/s, UU/m, UU/h
fValueFS * Maximum measuring range value
for flow measurement
Range = 0,00...99,9..._100...9999
fMinVal * Minimum measuring range value
for flow measurement
Basis is fValueFS and fUnitFS
If the level drops below this, the flow indicator goes to 0.
fPls/rev* Impulse per sensor wheel
revolution
Number of impulses per revolution of the sensor wheel or the like
Necessary for long-term period averaging if the readings per revolution vary.
The function is switched off when the input value is 1.
fJumpVD* Flow switch value for attenuation
cut-off
Value in %, basis is fValueFS and fUnitFS.
Attenuation does not function if the switch value is 0%.
fOverflV * Flow overflow value (overflow)
Value in %, basis is fValueFS and fUnitFS.
If exceeded, an M100 report is generated and faded in, alternating
with the flow indicator.
The report is saved and can be reset by briefly pressing the
PGM key.
fFactor Select pulse ration
Selection of works calibration or user calibration.
(only for devices Model DF-...ZLxxx and Model-...ExxR)
UserUnit. Special volume unit
Customer-specific special unit UU.
The value entered corresponds to the number of litres of the special unit, e.g.
in the case of the unit Barrel the factor would for example be 115.6271.
SPdirect Activation of direct input switching
point
yes: Direct input of switching points s1SPoint and
s2SPoint is possible using the keys (default).
no: The switching points can only be set in the menu .
*) Only for ZED devices: Device-specific parameter, is only visible after activation in the SecCode menu item in the SERVICE
menu group, and can be changed.

ZED-K
ZED-K K11/0523 page 11
7.5 Flow, analogue output and relay S1

ZED-K
page 12 ZED-K K11/0523
FLOW
Menu Item
Parameter / Function
Explanation / Values / Other
fUnit Unit of flow indicator
mL/s, mL/m, L/s, L/m, L/h, m3/m, m3/h,
GPM, GPH, UU/s, UU/m, UU/h
fDamping Attenuation of reading fluctuations in the flow indicator
The attenuation pacifies the flow indicator.
The attenuation value is the approximate equivalent of the setting time
of the display value to c. 90% of a measured value jump in seconds.
(Parameter is blocked at DF-...ZLxxx devices).
fMMReDir Reset the Min/Max flow value directly using the keys,
without using the menu
yes: direct resetting of the Min/Max value memory by simultaneously
pressing (3 sec) the (+) and (-) keys (default).
no: memory reset only possible with fMMRST.
fMMRST Reset the Min/Max flow value memory of the flow
indicator
yes: Resets Min / Max value memory for the flow
no: No action.
ANALOGUE OUTPUT
Menu Item
Parameter / Function
Explanation / Values / Other
aLIFE 0 Select Life Zero
Offset at power output: 0 mA or 4 mA
at 0-10 V
≙
0 mA →0 V and 4 mA → 2 V
aLowFlow Flow reading at 0/4 mA or 0/2 V
Lower flow reading of gauged output range,
value has the same unit as the flow indicator
aHighFlo Flow reading at 20 mA or 10 V
Upper flow reading of gauged output range,
value has the same unit as the flow indicator
RELAY S1
Menu Item
Parameter / Function
Explanation / Values / Other
s1Char. Relay1 Switch characteristic
Limit: Monitoring a reading (s1SPoint).
Window: Monitoring an adjustable measuring range
(s1SPoint...s1Fpunkt).
s1Logic Relay1 Switch logic
normal: Relay 1 activated when the limit value is exceeded.
invers: Relay 1 drops out when the limit value is exceeded.
s1SPoint Relay1 Switchpoint Reading is in the same units as the flow indicator.
s1Hyste Relay1 Hysteresis Reading is in the same units as the flow indicator.
s1FPoint Relay1 Windowpoint
Reading is in the same units as the flow indicator.
(only if s1Char. is set to Window )
s1SDelay Relay1 Switch delay
Delays the switching of the relay when the limit value is exceeded.
Range:_ 0,0...99,9 sec
s1RDelay Relay1 Reset delay
Delays the switching of the relay when the limit value is undershot.
Range:_ 0,0...99,9 sec

ZED-K
ZED-K K11/0523 page 13
7.6 Relay S2
RELAY S2
Menu Item
Parameter / Function
Explanation / Values / Other
s2Char. Relay2 Switch characteristic
Limit: Monitoring a reading (s2SPoint).
Window: Monitoring an adjustable measuring range
(s2SPoint...s12punkt).
s2Logic Relay2 Switch logic
normal: Relay 2 activated when the limit value is exceeded.
invers: Relay 2 drops out when the limit value is exceeded.
s2SPoint Relay2 Switchpoint Reading is in the same units as the flow indicator.
s2Hyste Relay2 Hysteresis Reading is in the same units as the flow indicator.
s2FPoint Relay2 Window point
Reading is in the same units as the flow indicator.
(only if s2Char. Is set to Window )
s2SDelay Relay2 Switch delay
Delays the switching of the relay when the limit value is exceeded.
Range:_ 0,0...99,9 sec
s2RDelay Relay2 Reset delay
Delays the switching of the relay when the limit value is undershot.
Range:_ 0,0...99,9 sec

ZED-K
page 14 ZED-K K11/0523
7.7 User alignment and service-settings

ZED-K
ZED-K K11/0523 page 15
USER CALIBRATION
Menu Item
Function / Description
CAL Freq* Calibrate by entering frequency and flow.
In the menu item CAL Freq the bottom line always shows the current pulse value of the
User calibration.
Calibration process:
a) FlowVal Enter nominal flow value of the sensor. > (e) press >
b) FlowUnit Enter unit for flow value. > (e) press >
c) Freq.Val. Enter nominal frequency > finish with (e).
The new pulse value of the User calibration is calculated from these three values and saved
as user calibration for the flow measurement, e.g. 20.2757 pls./litre.
CAL Vol. Calibration process using impulse counting and volume input (cc procedure).
In the menu item CAL Vol. the bottom line always shows the current pulse value of the
User calibration.
Calibration process:
a) PulseCnt measures number of impulses
(e) press > start counter (impulses are counted) > (e) press > stops counter.
b) Vol.Val Enter measured volume value > (e) press.
c) Vol.Unit Enter unit for volume value > finish with (e).
The pulse value of the User calibration is calculated from these three values and is saved as
the user calibration for the flow measurement, e.g. 3900,5 pls./L.
*) CAL Freq – Only possible with ZED devices.
Note: With ZED devices it is necessary to enable the device-specific
parameter input in the menu Item SecCode in the menu SERVICE in order
to activate the CAL-USER function.
Note: If the new pulse ratio will be used for measurement, than the menu
item fFaktor in the menu group General Settings must be setted to USER
calibration.

ZED-K
page 16 ZED-K K11/0523
SERVICE
Menu Item
Function
Explanation / Values / Other
SecCode
Input
Enter security code Input of 4-digit security code
and enablement of the parameter change.
The following codes have been defined:
3461 – General menu release
6571 – Activates the device-specific
parameters (only ZED and measuring unit as
compact version)
SecCode
change
Change security code Define or change security code for the first time or
change.
If no code ( = 0000) has been set, then the
parameter values set are unsecured!
Save Prm Save parameter record Save current settings
Load Prm Load parameter record Restore saved settings (reload).
Restore
Default
Reset to works default
settings
Load initial setting with password 2541.
ATTENTION: For ZED-devices the device-specific
parameters will be overwritten. An adjustment
provided by the customer will be lost in the process.
7.8 Error report
Error code
Reason
Reset
E102 User unit may not be ≤0 Correct parameter
E142 Distance between upper and lower analogue value
too small (based on the actual flow) Correct parameter
E 161 Value is greater than maximum measuring range
value. Correct parameter
E162 Hysteresis too large Correct parameter
E 163 Window point is lower than switching point. Correct parameter
E242 Frequency must be between 0,2 and 2000 Hz Correct parameter
E245 Calculated pulse value out of valid range Correct parameter
E300 Error memory value of totalising/part counter Keep ▲+ ▼pressed about
20 seconds
M100 Overflow
Acknowledge with PGM
button
#### Value does not fit in the display
Choose suitable measuring
unit

ZED-K
ZED-K K11/0523 page 17
8.Relay Functions
8.1 Switching characteristic limit value
MV
REL Sx
sxSPoint
sxSPoint
- sxHyste
8.2 Switching characteristic window
MV
REL Sx
sxSPoint
sxSPoint
- sxHyste
sxFPoint
sxFPoint
+ sxHyste

ZED-K
page 18 ZED-K K11/0523
9.Technical Information
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
10. Order Codes
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
11. Dimensions
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com

ZED-K
ZED-K K11/0523 page 19
12. Disposal
Note!
•Avoid environmental damage caused by media-contaminated parts
•Dispose of the device and packaging in an environmentally friendly
manner
•Comply with applicable national and international disposal regulations
and environmental regulations.
Batteries
Batteries containing pollutants are marked with a sign consisting of a crossed-
out garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal
that is decisive for the classification as containing pollutants:
Cd1Hg2Pb3Li4
1. „Cd" stands for cadmium
2. „Hg" stands for mercury
3. „Pb" stands for lead
4. „Li" stands for lithium
Electrical and electronic equipment

ZED-K
page 20 ZED-K K11/0523
13. EU Declaration of Conformance
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Evaluation Electronics Model: ZED-K and model: DF-…KLxxx
to which this declaration relates is in conformity with the standards noted below:
EN IEC 61326-1:2021
Electrical equipment for control and instrumentation technology and laboratory
use – EMC-requirements, industrial area (measurement of interference immunity
to HF fields up to 1 GHz)
EN 61010-1:2010 + A1:2019 + A1:2019/AC:2019
Safety requirements for electrical measuring-, control- and laboratory
instruments.
EN 60529:2014
Protection type housing (IP-Code)
EN IEC 63000:2018 Technical documentation for the assessment of electrical
and electronic products with respect to the restriction of hazardous substances
Also, the following EC guidelines are fulfilled:
2014/30/EU EMC Directive
2014/35/EU Low Voltage Directive
2011/65/EURoHS (category 9)
2015/863/EU Delegated Directive (RoHS III)
Hofheim, 05 May 2023
H. Volz M. Wenzel
General Manager Proxy Holder
