Kobold NBK-RPVC User manual

Operating Instructions
for
Bypass Magnetic Switch
Model: NBK-RPVC

NBK-RPVC
page 2 NBK-RPVC K01/0723
We don’t accept warranty and liability claims neither upon this publication nor in
case of improper treatment of the described products.
The document may contain technical inaccuracies and typographical errors. The
content will be revised on a regular basis. These changes will be implemented in
later versions. The described products can be improved and changed at any time
without prior notice.
© Copyright
All rights reserved.
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 4
3.Instrument Inspection .................................................................................... 4
4.Regulation Use ............................................................................................. 4
5.Operating Principle ........................................................................................ 5
6.Safety ............................................................................................................ 6
6.1Proper intended use ............................................................................ 6
6.2Improper use ........................................................................................ 6
6.3Responsibility of the operator .............................................................. 7
6.4Personnel qualification ......................................................................... 7
6.5Personal safety equipment .................................................................. 7
7.Commissioning, operation ............................................................................. 8
7.1Mounting preparations ......................................................................... 8
7.2Mounting .............................................................................................. 8
7.3Mounting the Magnetic Switch on magnetic indicator .......................... 9
8.Electrical connection ................................................................................... 10
8.1Commissioning .................................................................................. 11
9.Faults .......................................................................................................... 12
10.Maintenance and cleaning .......................................................................... 13
10.1Maintenance ...................................................................................... 13
10.2Cleaning ............................................................................................. 13
11.Disassembly ................................................................................................ 14
12.Technical Information .................................................................................. 14
13.Order Codes ............................................................................................... 14
14.Dimensions ................................................................................................. 14
15.Disposal ...................................................................................................... 15
16.EU Declaration of Conformance ................................................................. 16

NBK-RPVC
NBK-RPVC K01/0723 page 3
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

NBK-RPVC
page 4 NBK-RPVC K01/0723
2. Note
Please read these operating instructions before unpacking and putting the unit into
operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar with
these operating instructions and in accordance with local regulations applying to
Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC machinery directive.
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of the
delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Bypass Magnetic Switch model: NBK-RPVC
4. Regulation Use
Any use of the device, which exceeds the manufacturer’s specification, may
invalidate its warranty. Therefore, any resulting damage is not the responsibility of
the manufacturer. The user assumes all risk for such usage.

NBK-RPVC
NBK-RPVC K01/0723 page 5
5. Operating Principle
Bypass magnetic switches are non-contact switches. They are mainly made of a
switch housing with a built-in reed contact, proximity switch or rotational switch.
They are triggered by the magnetic field of a permanent magnet.
The Bypass magnetic switches are used to provide a switching function at a pre-
determined level in connection with Kobold bypass level indicators of type NBK-16
or comparable products. For this, one or several switches can be mounted on the
level indicator
Note:
Magnetic Switches and bypass level indicators with built-in float are de-
signed for each other and ensure reliable functioning and trouble-free
operation.
When mounting on level indicators of other manufacturers, malfunctions can
occur due to a different arrangement of the magnetic fields.

NBK-RPVC
page 6 NBK-RPVC K01/0723
6. Safety
6.1 Proper intended use
The Bypass magnetic switches are solely intended for monitoring the liquid level of
fluids. The area of use is based on the technical performance limits and materials.
 The fluids must not be contaminated nor contain coarse particles nor tend
to crystallize. It must be ensured that the magnetic switch materials that
come into contact with the media are sufficiently resistant to the monitored
medium. Not suitable for dispersion, abrasive fluids, highly viscous media
and paints.
 Compliance with the usage conditions specified in the operating instructions
is required.
 Do not operate the unit in direct proximity of ferro-magnetic environments
(distance min. 50mm).
 Do not operate the unit in direct proximity of strong electromagnetic fields or
in direct proximity of facilities that can be impacted by magnetic fields
(distance min. 1m).
 The magnetic switches may not be subjected to strong mechanical stresses
(impact, bending, vibrations). The unit is exclusively de-signed and
constructed for the intended use described here and may only be used
accordingly.
 The switching points of the magnetic switch cannot be adjusted.
 These instructions are intended for technicians who execute the installation
and calibration.
 Compliance with the relevant safety regulations for the use is re-quired.
 Compliance with the technical specifications in these operating instructions
is required. Improper use or operation of the unit outside the technical
specifications requires immediate shut-down and inspection by an
authorized Kobold service technician.
6.2 Improper use
Any use that exceeds the technical performance thresholds or that is in-compatible
with the materials is considered improper use.
WARNING!
Injury due to improper use
Improper use of the unit can result in hazardous situations and injuries.
 Do not modify the unit without authorization
 Do not use the unit in potentially explosive areas.
Any use beyond the proper intended use or any other use is considered improper
use.
Do not use this unit in safety or emergency off equipment.

NBK-RPVC
NBK-RPVC K01/0723 page 7
6.3 Responsibility of the operator
The unit is used in the industrial sector. The operator is therefore subject to
statutory obligations with respect to occupational safety.
In order to safely work on the unit, the operator must ensure
 the operating personnel is regularly trained in all matters pertaining to
occupational safety, first aid and environmental conservation and is familiar
with the operating instructions and, in particular, the safety instructions
contained therein
 the unit is suitable for the application in accordance with the proper intended
use (check for improper use).
After check, improper use is excluded.
6.4 Personnel qualification
WARNING!
Risk of injury due to insufficient qualifications
Improper use can result in significant personal injury and property damages.
 The activities described in these operating instructions may only be
performed by specialist technicians with the following qualifications.
Specialist personnel
The specialist personnel authorized by the operator is capable of executing the
described work and autonomously detect potential hazards due their technical
training, knowledge of measuring and control technology and their experience and
knowledge of country-specific regulations, applicable standards and guidelines.
6.5 Personal safety equipment
The personal safety equipment serves to protect the technicians against hazards
that might impact the safety or health while working. When executing the various
tasks on and with the unit, the technicians must wear personal safety equipment.
Comply with warning signs posted in the work area regarding personal safety
equipment!
The required personal safety equipment must be provided by the operator.

NBK-RPVC
page 8 NBK-RPVC K01/0723
7. Commissioning, operation
Comply with all of the instructions on the packaging pertaining to removing the
transport locks.
Remove the magnetic switch from the packaging carefully!
When unpacking, check all parts for external damage.
Functional test before assembly:
The functional test is carried out to determine the proper functioning of the
switching contacts. You should disconnect the power connection between the
control and the switch before the test. You can determine the switching condition
e.g. with a continuity tester. You can carry out the functional test by actuating the
contact with a permanent magnet with a radial magnetic field in the switching area.
For this, you should move the magnet alongside the Magnetic Switch from the
bottom towards the top. When doing so, the contact should switch over. Afterwards,
you should move the magnet again from the top towards the bottom. The contact
is falling back into its initial position. Instead of the magnet, you can also use the
built-in float of the bypass level indicator.
During the functional test, unintentional processes can be triggered off in
the downstream control. Risk of physical injuries and property damage.
Competent technical staff only should connect and disconnect power lines.
Do not operate Magnetic Switches in the immediate proximity of powerful
electromagnetic fields (distance should be at least 1m).
Do not expose Magnetic Switches to strong mechanical loads.
7.1 Mounting preparations
Ensure the sealing surface of the container or the NBK-RPVC is clean and has no
mechanical damage.
7.2 Mounting
Before mounting in an aggressive environment, you should ensure that the
Magnetic Switch's case is resistant to it accordingly. When choosing the place for
mounting, you should take into account the system of protection of the used switch.
Magnetic Switches, which have been supplied together with Kobold bypass level
indicators, are preassembled already and should just be adjusted to the desired
switching height only.
Mounting occurs on magnetic roller indicator (model BMD) on bypass level
indicator (model BNA) or directly with tightening straps.
Type Description (Switch, housing) Attachment
with T-slot
Attachment with
tightening straps
NBK-
RPVC
Reed, aluminium case, cable outlet X X

NBK-RPVC
NBK-RPVC K01/0723 page 9
7.3 Mounting the Magnetic Switch on magnetic indicator
The Magnetic Switches will be mounted on the magnetic roller level indicator of
the bypass level indicator by means of t-slot stones.
1. Insert the t-slot block(s) into the slot of the magnetic roller indicator from top or
bottom.Unscrew the fastening screws at the Magnetic Switch with a hexagon
socket screw key WAF 3 mm by about one turn.
2. Insert the t-slot block(s) into the slot of the magnetic roller indicator from top or
bottom.
3. Shift the Magnetic Switch to the level of the desired switching point and fasten
it by tightening the screws (the switching point is marked).
The Magnetic Switches can be mounted on both sides of the magnetic roller level
indicators optionally. For this, you should mount the t-slot block on the switch's
opposite side. The assembly at works is done on the by-pass level indicator's right
side.
When mounting several Magnetic Switches on the bypass level indicator, we
recommend mounting them on both sides of the magnetic roller indicator alternately.
Thus, it is ensured that any desired switching height can be adjusted.
7.3.1 Mounting of Magnetic Switch with tightening straps
1. Open the fixing band by loosening the adjustment screw.
2. Slide the fixing band through the opening on the magnetic switch
3. Attach the fixing band to the bypass chamber and tighten via adjustment
screw, so that the magnetic switch can still be moved.
4. Slide the magnetic switch to the desired switching height and fix into position
by tightening the screw. (The switch point is marked).
Note!
1. When mounting, please pay attention to that the cable entry faces
downwards. In order to ensure a safe switching function, the Magnetic
Switch's case should sit close to the bypass pipe.
2. The Magnetic Switches do only work in the area between the by-pass
level indicator's process connections. We cannot guarantee a safe
functioning if a switching point is set outside that area.

NBK-RPVC
page 10 NBK-RPVC K01/0723
8. Electrical connection
The electrical connection must be established in accordance with the application
construction regulations in the country of installation and may only be performed
by specialist personnel.
The connection should be carried out pursuant to the connection diagram with at
least 3 x 0,75mm² according to the desired switching function. When selecting the
cable, please pay attention to that it is suitable for the planned area of application
(temperature, weather influences, aggressive atmosphere etc.).
Protection Class II
Warning!
The operation of the Magnetic Switches at inductive or capacitive load can
result in the destruction of the reed contact. This can lead to a malfunction
of the downstream control and to physical injury or property damage.
With inductive load, please protect the Magnetic Switches by wiring with a RC
module (see appendix) or with a shunt diode. The use of varistors protective
wiring is not permitted for the reed contact can be destroyed by occur-ring peaks.
With capacitive load, line lengths above 50m, or connection to process control
systems with capacitive input a protective resistor of 22 Ω should be connected in
series to the to limit the peak current.

NBK-RPVC
NBK-RPVC K01/0723 page 11
RC modules for switch protection
Depending on the operating voltage, RC modules should only be used in
accordance with the table below.
Other RC modules that those listed here will result in the destruction of the Reed
switch.
For reed contacts from 10 - 40 VA
V
olta
g
e Resistance Capacit
y
A
C 24 V 100 Ω 0,33 µF
A
C 48 V 220 Ω 0,33 µF
A
C 115 V 470 Ω 0,33 µF
A
C 230 V 1500 Ω 0,33 µF
For reed contacts from 40 - 100 VA
V
olta
g
e Resistance Capacit
y
A
C 24 V 47 Ω 0,33 µF
A
C 48 V 100 Ω 0,33 µF
A
C 115 V 470 Ω 0,33 µF
A
C 230 V 1000 Ω 0,33 µF
8.1 Commissioning
You should set the Magnetic Switches to their defined initial state before putting
them into operation. For this, you should push the bypass level indicator's float
inside the pipe slowly from the bottom towards the top and afterwards to the bottom
again. If this is not possible anymore, you may even pass the float alongside the
Magnetic Switch from the bottom to-wards the top and afterwards to the bottom
again. Pay attention to the identification „top“ at the float.
When retrofitting Magnetic Switches, you should set these to their defined initial
state in the same way. If a float is not available, you may even use a permanent
magnet of any radial polarity for this procedure.
Due to the bistable switching behaviour of the Magnetic Switches, a de-fined initial
state before putting them into service is mandatory. Otherwise, there is a risk that
a defective switching function is triggered off in the downstream control through a
false contact position upon initial start-up.
Adjustment of the Magnetic Switch
Unscrew the fastening screw(s) and shift the Magnetic Switch to the level of the
desired switching point.
Tighten the fastening screw again afterwards.

NBK-RPVC
page 12 NBK-RPVC K01/0723
9. Faults
The most frequent root causes and required countermeasures are listed in the
following table.
Fault Cause Measure
Bypass magnetic switch
cannot be mounted at
the in-tended position on
the B
y
pass
Collision with other
attachments
Modification of the
attachments or return
shipment to the factory
No or undefined
switching function
Electrical connection
incorrect
See chapter 8
Reed contact defective Return shipment to
factor
y
Incorrect switching
function
Change terminal
assi
g
nment
Switching position in-
correct
New positioning of the
NB
K
-RPVC
Ra
gg
ed cable Return shipment to
factory
Switch are not triggered
b
y
the float ma
g
-net
CAUTION!
Bodily injuries, property and environmental damages If faults cannot be
rectified with the help of the listed measures, immediately shut the unit off.
 Ensure the pressure is switched off and secure the unit against
unintentionally being switched on.
 Contact the manufacturer.

NBK-RPVC
NBK-RPVC K01/0723 page 13
10. Maintenance and cleaning
10.1 Maintenance
Bypass magnetic switches Type NBK-RPVC do not require maintenance if
operated properly.
The switches should be repaired by the manufacturer or by persons authorized by
the manufacturer only. You should observe the international and national
regulations regarding the implementation of the repair. Please use Kobold spare
parts only, for otherwise the conformity with the approval of the type of protection
cannot be guaranteed.
DANGER!
When working on containers, there is a risk of poisoning or suffocation.
Work may only be performed using suitable personal safety equipment (e.g.
respiratory protection, protective clothing, etc.).
NOTICE!
Fault-free functionality of the magnetic switch can only be guaranteed if
original Kobold accessories and spare parts are used.
10.2 Cleaning
CAUTION!
Bodily injuries, property and environmental damages Improper cleaning
may result in bodily injuries, property and environmental damages.
Measurement material residues in the disassembled unit can result in risks
to persons, the environment and equipment.
 Flush and clean the disassembled unit.
 Implement sufficient precautionary measures.
 Prior to cleaning the unit, properly disconnect it from the process and
the power supply.
 Carefully clean the unit with a damp cloth.
 Do not let electrical connections come into contact with moisture!
CAUTION!
Property damage
Improper cleaning will damage the unit!
 Do not use any aggressive cleaning agents.
 Do not use any hard or sharp objects for cleaning.

NBK-RPVC
page 14 NBK-RPVC K01/0723
11. Disassembly
Only disassemble the measuring unit when it has been disconnected from the
pressure and voltage!
If necessary, the container must be relaxed.
12. Technical Information
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
13. Order Codes
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
14. Dimensions
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com

NBK-RPVC
NBK-RPVC K01/0723 page 15
15. Disposal
Note!
 Avoid environmental damage caused by media-contaminated parts
 Dispose of the device and packaging in an environmentally friendly manner
 Comply with applicable national and international disposal regulations and
environmental regulations.
Batteries
Batteries containing pollutants are marked with a sign consisting of a crossed-out
garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal that
is decisive for the classification as containing pollutants:
Cd1 Hg2 Pb3 Li4
1. „Cd" stands for cadmium
2. „Hg" stands for mercury
3. „Pb" stands for lead
4. „Li" stands for lithium
Electrical and electronic equipment

NBK-RPVC
page 16 NBK-RPVC K01/0723
16. EU Declaration of Conformance
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Bypass Magnetic Switch Model: NBK-RPVC
to which this declaration relates is in conformity with the following EU directives
stated below:
2014/35/EU Low Voltage Directive
2011/65/EU RoHS (category 9)
Also, the following standards are fulfilled:
EN 61010-1:2010 + A1:2019 + A1:2019/AC:2019 Safety requirements for
electrical equipment for measurement, control and laboratory use - Part 1:
General requirements
EN IEC 63000:2018 Technical documentation for the assessment of electrical
and electronic products with respect to the restriction of hazardous substances
Hofheim, 16 August 2023
H. Volz J. Burke
General Manager Compliance Manager
