Kodak DryView 8100 User manual

7 X 9 inside cover
User Guide
Kodak DryView 8100 Laser Imager
8754020
96-0000-0197-2
3/00 Rev. B

Safety, EMC, and CE Marking Compliance
i
2000 March Rev. B 8754020
Safety, EMC, and CE Marking Compliance
Read and understand all instructions before using.
For a translation of the following warnings, please refer to the applicable safety
addendum listed below:
DryView 8100 Imager User Guide Safety Addendum (Polish) 74-0500-5507-3
DryView 8100 Imager User Guide Safety Addendum (Hebrew) 74-0500-5508-1
DryView 8100 Imager User Guide Safety Addendum (Korean) 74-0500-5509-9
!WARNING
This equipment is operated with hazardous voltage which can shock,
burn, or cause death.
Remove wall plug before servicing equipment. Never pull on cord to remove from
outlet. Grasp plug and pull to disconnect.
Do not operate equipment with a damaged power cord.
Do not use an extension cord to power this equipment.
Use only the power cord supplied with this equipment.
Position the power cord so it will not be tripped over or pulled.
Connect this equipment to a grounded outlet.
!WARNING
This equipment contains moving parts that may be accessible to the user. Loose
clothing, jewelry, or long hair may cause minor personal injury or damage to the
equipment. Do not operate equipment with the covers open. Do not operate
equipment with any of the safety interlocks overridden.
!WARNING
This equipment is not contained in a sealed cabinet. Therefore it must not be used in
locations where it can come in contact with liquids, including bodily fluids.
!WARNING
For continued protection against fire, replace fuses only with fuses of the same type
and rating.

DryView 8100 Laser Imager User Guide
ii 8754020 2000 March Rev.B
Read and understand all instructions before using.
!CAUTION
Do not use in the presence of flammable anesthetics, oxygen or nitrous oxide. This
equipment does not have a gas sealed electronics enclosure and could ignite any
flammable or explosive gases present in its environment.
!CAUTION
This equipment is intended to connect to other medical devices. Installation and
service maintenance are to be performed only by qualified service personnel. The
laser in the equipment is not a patient device. Therefore the equipment must be
installed no closer than 1.83 meters from a patient bed or chair.
!CAUTION
Do not substitute or modify any part of this equipment without approval of Eastman
Kodak Company.
!CAUTION
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. Those limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

Safety, EMC, and CE Marking Compliance
iii
2000 March Rev. B 8754020
Read and understand all instructions before using.
!CAUTION
General External Cleaning: This equipment may be cleaned with a damp cloth
using water with mild detergent, or commercial electronic equipment cleaner.
8100–38L

DryView 8100 Laser Imager User Guide
iv 8754020 2000 March Rev.B
Read and understand all instructions before using.
!DANGER
The equipment employs a 50 milliwatt laser. Laser radiation may be present when
the machine operates without the rear cover installed.
Use of controls or adjustments, or performance of procedures other than those
specified herein, may result in eye damage.
The rear cover shall be removed by authorized service personnel only.
6E7000 Rev. A
Class 1 Laser
Laser de catégorie 1
Laser-Klasse 1
Laser di Classe 1
Klass 1 Laser
Bypassing interlocks (other than the Service Interlock above)
will allow the system to run with the laser energized.
Exposure to laser light may result in permanent eye damage.
DANGER

Safety, EMC, and CE Marking Compliance
v
2000 March Rev. B 8754020
Read and understand all instructions before using.

DryView 8100 Laser Imager User Guide
vi 8754020 2000 March Rev.B
This equipment has been tested for and complies with the following Safety and
Emission Standards. Certificates of Compliance and Declarations of Conformity
have been issued as shown below.
Safety:
Canada:
C22.2 NO 950-95–CAN/CSA Safety for Information Technology Equipment,
Including Electrical Business Equipment
C22.2 NO 601.1–M90–CAN/CSA Medical Electrical Equipment –Part 1:
General Requirements for Safety
Europe:
EN60950: Safety of Information Technology Equipment, Including Electrical
Business Equipment (IEC 60950 : 1991, Modified) (Includes Amendment A1 and
A2: 1993)
EN60601–1–1: Medical electrical equipment –Part 1: General requirements for
safety –Section 1: Collateral standard: Safety requirements for medical electrical
systems
EN60825–1: Safety of laser products –Part 1: Equipment classification,
requirements and user’s guide
U.S.A.:
UL 1950: Safety of Information Technology Equipment, Including Electrical
Business Equipment DOD (Bi–National Standard) with UL 2601–1 Medical
Electrical Equipment, Part 1: General Requirements for Safety
21CFR1040.10 Class I: FDA CDRH Code of Federal Regulations Title 21,
Volume 8, Food and Drugs, Part 1040 Performance Standards For
Light–Emitting Products, Section 10 Laser Products
FDA Premarket Notification 510(K): Regulatory Requirements For Medical
Devices
Rest of World:
IEC 950: Safety of information technology equipment
IEC 60601–1–1: Medical electrical equipment –Part 1: General requirements for
safety –Section 1: Collateral standard: Safety requirements for medical electrical
systems
IEC 60825–1: Safety of laser products –Part 1: Equipment classification,
requirements and user’s guide

Safety, EMC, and CE Marking Compliance
vii
2000 March Rev. B 8754020
EMC:
Canada:
CAN/CSA–C108.6–M91 Class A: Limits and Methods of Measurement of
Electromagnetic Disturbance Characteristics of Industrial, Scientific and Medical
(ISM) Radio–Frequency Equipment
Europe:
EN55022 (CISPR 22) Class B Group 1: Limits and Methods of Measurement of
Radio Interference Characteristics of Information Technology Equipment
EN61000–3–2 (IEC 1000–3–2): Electromagnetic compatibility (EMC) –Part 3:
Limits –Section 2: Limits for harmonic current emissions (equipment input
current <= 16 per phase)
EN 61000–4–2 (IEC 1000–4–2): Electromagnetic compatibility (EMC) –Part 4:
Testing and measurement techniques –Section 2: Electrostatic discharge
immunity test. Basic EMC Publication
EN 61000–4–3 (IEC 1000–4–3): Electromagnetic compatibility (EMC) –Part 4:
Testing and measurement techniques –Section 3: Radiated, radio–frequency,
electromagnetic field immunity test
EN 61000–4–4 (IEC 1000–4–4): Electromagnetic compatibility (EMC) –Part 4:
Testing and measurement techniques –Section 4: Electrical fast transient/burst
immunity test. Basic EMC Publication
EN 61000–4–5 (IEC 1000–4–5): Electromagnetic compatibility (EMC) –Part 4:
Testing and measurement techniques –Section 5: Surge immunity test
EN 61000–4–6 (IEC 1000–4–6): Electromagnetic compatibility (EMC) –Part 4:
Testing and measurement techniques –Section 6: Immunity to conducted
disturbances, induced by radio–frequency fields
EN 61000–4–11 (IEC 1000–4–11): Electromagnetic compatibility (EMC) –Part 4:
Testing and measuring techniques –Section 11: Voltage dips, short interruptions
and voltage variations immunity tests
U.S.A.:
FCC Rules and Regulations, Title 47, Part 15, Subpart B, Class B: Radio
frequency devices: Unintentional Radiators
Rest of World:
CISPR 22 Class B Group 1: Limits and Methods of Measurement of Radio
Interference Characteristics of Information Technology Equipment

DryView 8100 Laser Imager User Guide
viii 8754020 2000 March Rev.B
EU Directives:
73/23/EEC Council Directive on the Harmonization of the Laws of Member
States Relating to Electrical Equipment Designed for Use within Certain Voltage
Limits
89/336/EEC Council Directive on the Approximation of the Laws of the Member
States Relating to Electromagnetic Compatibility
93/42/EEC Council Directive Concerning Medical Devices
CE Marking:
Documents concerning the conformance of this product to Council Directive
93/42/EEC of 14 June 1993 concerning Medical Devices can be obtained from the
Eastman Kodak Health Imaging Systems European Representative at:
Kodak AG
Quality Services
Product Safety
70323 Stuttgart
Germany
Phone: ++49 711 406 2993
Fax: ++49 711 406 3513
DOC:
This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la Classe A respecte toutes les exigences du Règlement
sur le matérial brouilleur du Canada.

Table of Contents
ix
2000 March Rev. B 8754020
PLEASE NOTE The information contained herein is based on the experience
and knowledge relating to the subject matter gained by Eastman
Kodak Company prior to publication.
No patent license is granted by this information.
Eastman Kodak Company reserves the right to change this
information without notice and makes no warranty, express or
implied, with respect to this information. Kodak shall not be liable
for any loss or damage, including consequential or special
damages, resulting from the use of this information, even if loss
or damage is caused by Kodak’s negligence or other fault.
Table of Contents
Description Page
Safety, EMC, and CE Marking Compliance i. . . . . . . . . . . .
Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introducing the Kodak DryView 8100 Laser Imager 1-1. . .
System Configurations 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
DryView 8100 Laser Imager 1-2. . . . . . . . . . . . . . . . . . . .
Dryview 8100 PACS Link Laser Imager 1-2. . . . . . . . . .
Keypad Features 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How the DryView 8100 Laser Imager Works 1-4. . . . . . . . .
Automatic Image Quality Control 1-4. . . . . . . . . . . . . . . . . . .
Manual Mode of Operation 1-4. . . . . . . . . . . . . . . . . . . . . . . . .
How This Manual is Organized 1-6. . . . . . . . . . . . . . . . . . . . .
Controls and Indicators 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main Cabinet Controls and Indicators 2-1. . . . . . . . . . . . . . .
Local Panel Functions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation and Maintenance 3-1. . . . . . . . . . . . . . . . . . . . . . . . .
System Power Up 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Methods for Acquiring and Printing Images 3-2. . . . . . . . . .
Methods for Adjusting Image Density and Contrast 3-2. . .
Adjusting Density from the Local Panel 3-3. . . . . . . . . . . . . .
Adjusting Contrast from the Local Panel 3-4. . . . . . . . . . . . .

DryView 8100 Laser Imager User Guide
x8754020 2000 March Rev. B
Description Page
Producing a Calibration Test Print 3-4. . . . . . . . . . . . . . . . . . .
Operating in Manual Mode 3-5. . . . . . . . . . . . . . . . . . . . . . . . .
Opening the Front Door Via the Local Panel 3-6. . . . . . . . .
Opening the Front Door Manually 3-7. . . . . . . . . . . . . . . . . . .
Opening and Closing the Upper Hood 3-8. . . . . . . . . . . . . . .
Loading/Unloading Film 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the Charcoal Filter 3-11. . . . . . . . . . . . . . . . . . . . . .
Using the DryView V2 Keypad 4-1. . . . . . . . . . . . . . . . . . . . . . .
DryView V2 Keypad Controls 4-1. . . . . . . . . . . . . . . . . . . . . .
DryView V2 Keypad –Main Menu 4-2. . . . . . . . . . . . . . . . . .
DryView V2 Keypad –Format Menu 4-3. . . . . . . . . . . . . . . .
DryView V2 Keypad –Imager Menu 4-4. . . . . . . . . . . . . . . .
DryView V2 Keypad –Keypad Menu 4-6. . . . . . . . . . . . . . .
Using the Keypad to Format/Acquire/Print 4-8. . . . . . . . . . .
Selecting Auto Print or Auto Format Mode 4-10. . . . . . . . . . .
Using the Keypad to Adjust Image Density 4-11. . . . . . . . . . .
Using the Keypad to Adjust Image Contrast 4-12. . . . . . . . . .
Using the Keypad to Erase Stored Images 4-13. . . . . . . . . . .
DryView V2 Keypad Error Message Table 4-14. . . . . . . . . . .
Troubleshooting 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operator Troubleshooting 5-1. . . . . . . . . . . . . . . . . . . . . . . . . .
Local Panel Message Types 5-1. . . . . . . . . . . . . . . . . . . . . . .
Status Information 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Error Messages or Notices 5-1. . . . . . . . . . . . . . . . . . . . .
Local Panel Status Messages 5-2. . . . . . . . . . . . . . . . . . . . . .
Local Panel Error Messages 5-4. . . . . . . . . . . . . . . . . . . . . . .
Film Drive Problems 5-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Film Pickup Problems in Area 1 5-11. . . . . . . . . . . . . . . . . . . .
Removing Film Jams from Area 2 5-12. . . . . . . . . . . . . . . . . . .
Removing Film Jams from Area 3 5-13. . . . . . . . . . . . . . . . . . .
Removing Film Jams from Area 4 5-14. . . . . . . . . . . . . . . . . . .

Table of Contents
xi
2000 March Rev. B 8754020
Description Page
Removing Film Jams from Area 5 5-16. . . . . . . . . . . . . . . . . . .
Manually Closing the Film Cartridge 5-17. . . . . . . . . . . . . . . . .
Calling for Support 5-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Environment 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Environmental Effects 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Environment 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Film Size 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Film Throughput 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Host Control 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DryView V2 Keypad 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Agency Compliance 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Information 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Description 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spectral Sensitivity 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Image Quality 7-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Image Quality Control 7-2. . . . . . . . . . . . . . . . . . .
Less Impact on the Environment 7-3. . . . . . . . . . . . . . . . . . .
Storage and Handling of Undeveloped Film 7-3. . . . . . . . . .
Handling of Developed Film 7-4. . . . . . . . . . . . . . . . . . . . . . . .
Archivability of Developed Film 7-4. . . . . . . . . . . . . . . . . . . . .
Exposure to Moisture 7-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odor Dissipation 7-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heat Dissipation 7-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Film Recycling 7-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT NOTICE TO PURCHASER 7-6. . . . . . . . . . . .

DryView 8100 Laser Imager User Guide
xii 8754020 2000 March Rev. B
BLANK PAGE

Introduction
1-1
2000 March Rev. B 8754020
Introduction
Introducing the Kodak DryView 8100 Laser Imager
The DryView 8100 Laser Imager is a continuous tone laser imager with an internal
photothermographic film developer. Heat, rather than photo chemicals, is used to
develop the film. The imager can be connected to and print images from a variety of
medical image source devices such as CT scanners or Ultrasound. It can also be
connected to a DICOM medical image network via the PACS Link 9410 Acquisition
System.
The DryView 8100 Laser Imager uses 14 inch x 17 inch (35 cm x 43 cm) DryView
Laser Imaging Film, which is packaged in 125-sheet Kodak Instant Daylight Load
Film Cartridges.
A DryView V2 Keypad can be used to control the imager, or the system can be
controlled from the host modality. A footswitch is also available, providing an optional
method of acquiring images for printing.
Figure 1-1. DryView 8100 Laser Imager

DryView 8100 Laser Imager User Guide
1-2 8754020 2000 March Rev. B
System Configurations
The DryView 8100 Laser Imager can be used in two system configurations. The key
features of these are described below.
DryView 8100 Laser Imager
The imager connects directly to up to three image source devices. (The standard
unit has one input, but it can be upgraded for additional inputs.)
Copper cables are used for connections to the source imaging device and
keypad.
The operator controls image acquisition and printing from either a keypad or a
console on the host source imaging device.
Dryview 8100 PACS Link Laser Imager
The imager connects to a DICOM medical image network via a PACS Link
Interface.
The imager prints images sent from image source devices or archiving stations
connected to the DICOM network.

Introduction
1-3
2000 March Rev. B 8754020
Keypad Features
The table below lists the features provided by the DryView V2 Keypad.
Feature DryView
V2 Keypad
Format Select Yes*
Multiple Copies Setting Yes
Sequential Image Acquire Yes
Random Image Acquire Yes
Sequential Image Erase No
Random Image Erase Yes
Move Acquired Image No
Print Yes
Stop Print No
Density or Dmax Setting Yes**
Contrast Setting Yes**
Print Density Test Yes**
Print Contrast Test Yes**
Smooth/Sharp Select Yes
Image Polarity Select Yes
Image Framing Select No
Auto-Print Select Yes
Auto-Format Select Yes
Alarm Volume Setting Yes
* Available image formats include:
From DryView V2 Keypad: 1:1, 2:1, 4:1, 6:1, 9:1, 12:1, 15:1, 16:1, and 20:1.
From host console: Same as for the DryView V2 Keypad, plus 24:1.
** Can also be set at the imager’s Local Panel.

DryView 8100 Laser Imager User Guide
1-4 8754020 2000 March Rev. B
How the DryView 8100 Laser Imager Works
Using the keypad or host console, the operator acquires an image from the
image source device. The image is stored on a hard disk in the imager.
Using the keypad or host console, the operator prints the image.
The following sequence occurs each time the operator issues a print command. The
step numbers refer to the circled numbers in Figure 1-2. The dashed lines in the
illustration indicate the film path.
1. Suction cups lift a single sheet of film out of the supply cartridge and route it into
the film feed rollers.
2. The film feed rollers move the film down to the platen rollers.
3. The platen rollers drive the film into the exposure module platen.
4. A moving laser beam writes the image onto film, which is held stationary in the
platen.
5. The platen rollers reverse direction and move the exposed film up through the
vertical transport area.
6. Transport rollers drive the film onto the processor drum.
7. The heated processor drum develops the film as it passes over the drum.
8. Rollers move the developed film from the processor drum, through the
densitometer (see the next paragraph), and onto the receive tray.
Automatic Image Quality Control
The built-in densitometer is a key element in the Automatic Image Quality Control
(AIQC) process. AIQC allows the imager to automatically adjust processing
parameters to ensure optimum image quality. The imager adjusts these parameters
each time it prints a calibration film. A calibration film is printed whenever:
The DryView 8100 Laser imager is powered on.
A calibration film is requested from the Local Panel.
The imager has not been used for 7 days, and a print is requested.
Manual Mode of Operation
The imager can be operated in a “manual”mode, without AIQC. Use of this mode is
explained in Section 3 of this manual.

Introduction
1-5
2000 March Rev. B 8754020
Vertical
Transport
Area
Receive Tray
Film
Supply
Cartridge
Exposure
Module
Film
Processor
Drum
1
2
3
4
8
8100–49C
Suction
Cups
Film Feed
Rollers
Densitometer
Transport
Rollers
Platen
Rollers
Laser
Beam
5
6
7
Figure 1-2. Print Sequence

DryView 8100 Laser Imager User Guide
1-6 8754020 2000 March Rev. B
How This Manual is Organized
The remainder of this manual is organized as follows:
Section 2 describes operator controls and indicators on the main cabinet,
including the Local Panel.
Section 3 provides general procedures for operating and maintaining the system.
(It does not include instructions for using the keypad. These are provided in
Section 4.)
Section 4 provides instructions for using the DryView V2 Keypad, including:
descriptions of keypad controls, procedures for operating the imager from the
keypad, and keypad error messages.
Section 5 includes system troubleshooting procedures.
Section 6 provides system specifications.
Section 7 includes technical information about DryView 8100 Laser Imaging
Film.

Controls and Indicators
2-1
2000 March Rev. B 8754020
Controls and Indicators
Main Cabinet Controls and Indicators
This section describes the operator controls on the DryView 8100 Laser Imager
cabinet, focusing on the Local Panel. For keypad functions, refer to Section 4.
The numbered descriptions below correspond to the circled numbers in Figure 2-1.
1. Local Panel –Includes a message display, status indicator lights, and
pushbutton controls. The Local Panel is described in greater detail on the
following pages.
2. Power Switch –Controls power to the imager. (On rear of cabinet.)
3. Front Door –Accesses the film cartridge.
4. Upper Hood - Accesses upper assemblies.
5. Receive Tray –Collects developed film.
6. Floppy Disk Drive –Used to update the imager internal software.
2
4
3
5
68100–27C
1
Figure 2-1. DRYVIEW 8100 Laser Imager –Controls and Indicators
