DIAGNOSTICS
for the
Kodak X-Omat 5000 RA PROCESSOR
H148_0004GA

2 January 1996 – 5B6342
PLEASE NOTE The information contained herein is based on the experience and knowledge relating to the
subject matter gained by Eastman Kodak Company prior to publication.
No patent license is granted by this information.
Eastman Kodak Company reserves the right to change this information without notice, and
makes no warranty, express or implied, with respect to this information. Kodak shall not be liable
for any loss or damage, including consequential or special damages, resulting from any use of
this information, even if loss or damage is caused by Kodak’s negligence or other fault.
This equipment includes parts and assemblies sensitive to damage from electrostatic
discharge. Use caution to prevent damage during all service procedures.
Description Page
Table of Contents
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
All Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fatal Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Non-Fatal Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mechanical Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Transport Malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Artifacts and Wrong Film Densities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Wet Films . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Solution Levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Internal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Accessing the Internal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
D1 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
D2 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
D3 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Diagnostic Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
D1 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
D2 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
D3 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Flowcharts for the Internal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Printing Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
SOLID STATE RELAYS (SSR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Possible Malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Checking the LOAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Checking the SSR and the 5000 BOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Publication History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Error Codes
5B6342 – January 1996 3
Section 1: Error Codes
Introduction
Overview The software on the 5000 MICROPROCESSOR BOARD controls and monitors the operation
of the PROCESSOR and continually checks for errors. When an error occurs, a description of
the error is displayed on the DISPLAY PANEL.
When 2 or more errors occur together, all the errors are displayed, but only 1 error is visible on
the DISPLAY PANEL at a time. The error with the highest priority is displayed first. You can
scroll through the list to view the other errors.
An error log on the 5000 BOARD records the last 100 errors that have occurred and the
number of times each error has occurred.
3 types of errors can occur:
• Fatal
• Non-Fatal
• Warning
Fatal and
Non-Fatal Errors Only qualified service personnel should repair both fatal and non-fatal errors. • Most fatal errors prevent optimum film processing.
• Most non-fatal errors do not prevent optimum film processing.
Important
When you service a PROCESSOR with a fatal or non-fatal error and you check an electrical
component or BOARD, also check all the:
• connections and CABLES for the component or BOARD
• voltages from the POWER SUPPLY for the component or BOARD
Warning Errors Operators can repair warning errors. Normally, you can feed film into a PROCESSOR when a
warning error is displayed.
READY LED If any error prevents optimum film processing, the READY LED will de-energize. When the
LED de-energizes, you can feed film into the PROCESSOR but the image quality may not be
correct. Kodak recommends that you do not process film when the LED is de-energized.

DIAGNOSTICS
4 January 1996 – 5B6342
All Errors
Important
When you check an electrical component or BOARD, also check all the:
• connections and CABLES for the component or BOARD
• voltages from the POWER SUPPLY for the component or BOARD
When you check a SOLID STATE RELAY, use the tests in the Appendix to determine the source of the malfunction.
Possible damage from electrostatic discharge.
ESD
Fatal Errors
Code Description Possible Malfunction Action
E001 Microcontroller error 5000 BOARD Install a new BOARD.
E002 Dryer over maximum
temperature
Note
The maximum temperature
is 79°C (175°F).
Normally, the DRYER AC
OVERTEMPERATURE
THERMOSTAT opens
before the DRYER reaches
this temperature.
DRYER BLOWER When the DRYER HEATER energizes,
the DRYER BLOWER should energize.
Check:
• RELAY K1
• DRYER BLOWER
DRYER THERMISTOR Check that the resistance at 25°C (77°F)
is approximately 10 KW.
SOLID STATE RELAY U1 that
controls the DRYER HEATER Check U1.
5000 BOARD Install a new BOARD.
E003 Loss of film accumulator
data link No communication with the 6000 BOARD De-energize and energize the PROCESSOR to automatically reset the:
• MICROPROCESSOR on the 5000
BOARD
• MICROPROCESSOR on the 6000
BOARD
BOOT PROM U6018 on the
6000 BOARD Install a new U6018.
6000 BOARD Install a new BOARD.
5000 BOARD Install a new BOARD.
E004 Inoperative transport See E041.
E007 Developer thermistor
failure The DEVELOPER HEATER is disabled when this error occurs.
DEVELOPER THERMISTOR Install a new THERMISTOR.
E008 Fixer thermistor failure The FIXER HEATER is disabled when this error occurs.
FIXER THERMISTOR Install a new THERMISTOR.
E009 Dryer thermistor failure The DRYER HEATER is disabled when this error occurs.
DRYER THERMISTOR Install a new THERMISTOR.
E010 Analog-to-digital converter
failure All 3 HEATERS are disabled when this error occurs.
5000 BOARD Install a new BOARD.

Error Codes
5B6342 – January 1996 5
E011 Developer heater failure This error occurs when the 8000 CURRENT SENSE BOARD detects no
current through the DEVELOPER HEATER.
When the temperature of the
developer solution is too high,
the DEVELOPER HEATER
OVERTEMPERATURE
THERMOSTAT will open. The
THERMOSTAT will reset
automatically when the solution
cools.
Determine the cause for the high
developer temperature, and repair the
problem.
No continuity for the
DEVELOPER HEATER After the HEATER cools, check the continuity. If necessary, install a new
HEATER.
The 5000 BOARD does not
energize the RELAY K5004 on
the 5000 BOARD.
Check that the LED DS9 on the 5000
BOARD is energized.
If necessary, install a new BOARD.
SOLID STATE RELAY U2 that
controls the DEVELOPER
HEATER
Check U2.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U2.
Check that LED DS4 on the 5000
BOARD is energized.
If necessary, install a new BOARD.
8000 BOARD Install a new BOARD.
E012 Fixer heater failure This error occurs when the 8000 CURRENT SENSE BOARD detects no
current through the FIXER HEATER.
When the temperature of the
fixer solution is too high, the
FIXER HEATER
OVERTEMPERATURE
THERMOSTAT will open. The
THERMOSTAT will reset
automatically when the solution
cools.
Determine the cause for the high fixer
temperature, and repair the problem.
No continuity for the FIXER
HEATER After the HEATER cools, check the continuity. If necessary, install a new
HEATER.
SOLID STATE RELAY U5 that
controls the FIXER HEATER Install a new U5.
The 5000 BOARD does not
energize the RELAY K5004 on
the 5000 BOARD.
Check that the LED DS9 on the 5000
BOARD is energized.
If necessary, install a new BOARD.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U5.
Check that LED DS1 on the 5000
BOARD is energized.
If necessary, install a new BOARD.
8000 BOARD Install a new BOARD.
Code Description Possible Malfunction Action

DIAGNOSTICS
6 January 1996 – 5B6342
E013 Level sensor circuit failure This error occurs when the level sensor circuit on the 5000 BOARD
malfunctions. The following parts are disabled:
• DEVELOPER and FIXER REPLENISHMENT PUMPS
• RECIRCULATION PUMP
The temperature control for the fixer and developer is disabled.
5000 BOARD Install a new BOARD.
E014 Invalid program software E014 is displayed on the DEVELOPER TEMPERATURE DISPLAY. This
error disables all subsystems, except communications.
The main program software in
the EEPROM on the 5000
BOARD
Download new software.
E015 Invalid bootstrap software The bootstrap software for the
PROM U5006 on the 5000
BOARD
Install a new U5006.
E016 Invalid film accumulator
software This error does not disable any subsystems. The PROCESSOR will remain in the standby mode until the FILM DETECTOR SWITCHES actuate. These
SWITCHES provide information about the length of the film. Because the
6000 BOARD does not operate correctly, the PROCESSOR uses the
information from the SWITCHES to determine the replenishment rate.
The main program software in
the EEPROM on the 6000
BOARD
Download new software.
Code Description Possible Malfunction Action

Error Codes
5B6342 – January 1996 7
Non-Fatal Errors
Code Description Possible Malfunction Action
E032 Developer tank fill
error This error will occur if the: • DEVELOPER TANK:
– does not fill in 2 minutes in normal operation
– does not fill in 10 minutes in the Tank Fill Mode
– is empty and the operator does not select the Tank Fill Mode
• REPLENISHER TANK is empty.
• REPLENISHMENT HOSE has:
– an obstruction
– a kink
– an air bubble
• TANKS of the PROCESSOR are filled with water during the initial installation
.
The following parts will be disabled:
• DEVELOPER REPLENISHMENT PUMP
• RECIRCULATION PUMP
• temperature control for the fixer and developer
To prevent the error from occurring during the initial installation:
• Add 240 mL (8 fl oz) of developer to the DEVELOPER TANK before you fill
the PROCESSOR with water.
• Energize the RECIRCULATION PUMP to move the developer and remove
any air bubbles. Use the diagnostics to energize the PUMP.
LEVEL PROBES Clean and check the PROBES.
The solution level in the
REPLENISHER TANK is low. Mix new developer solution.
Solution does not flow through the
HOSES between the
REPLENISHMENT TANK and the
REPLENISHMENT PUMP.
Check that the:
• HOSE CLAMPS are tight.
• HOSES:
– are round and opened
– have no obstructions or air bubbles
The DEVELOPER DRAIN VALVE
is opened. Close the VALVE.
SOLID STATE RELAY U3 that
controls the DEVELOPER
REPLENISHMENT PUMP
Check U3.
POPPET VALVES in the
DEVELOPER REPLENISHMENT
PUMP
Clean and check the VALVES.
DEVELOPER REPLENISHMENT
PUMP Check the REPLENISHMENT PUMP MOTOR B3.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U3.
Check that LED DS3 on the 5000 BOARD
is energized.
If necessary, install a new BOARD.

DIAGNOSTICS
8 January 1996 – 5B6342
Code Description Possible Malfunction Action
E033 Fixer tank fill error This error will occur if the:
• FIXER TANK
– does not fill in 2 minutes in normal operation
– does not fill in 10 minutes in the Tank Fill Mode
– is empty and the operator does not select the Tank Fill Mode
• REPLENISHMENT TANK is empty.
• REPLENISHMENT HOSE has:
– an obstruction
– a kink
– an air bubble
• TANKS of the PROCESSOR are filled with water during the initial installation
.
The following parts will be disabled:
• FIXER REPLENISHMENT PUMP
• RECIRCULATION PUMP
• temperature control for the fixer and developer
To prevent the error from occuring during the initial installation:
• Add 240 mL (8 fl oz) of fixer to the FIXER TANK before you fill the
PROCESSOR with water.
• Energize the RECIRCULATION PUMP to move the fixer and remove any air
bubbles. Use the diagnostics to energize the PUMP.
LEVEL PROBES Clean and check the PROBES.
The solution level in the
REPLENISHER TANK is low. Mix new fixer solution.
Solution does not flow through the
HOSES between the
REPLENISHMENT TANK and the
REPLENISHMENT PUMP.
Check that the:
• HOSE CLAMPS are tight.
• HOSES:
– are round and opened
– have no obstructions or air bubbles
The FIXER DRAIN VALVE is
opened. Close the VALVE.
SOLID STATE RELAY U4 that
controls the FIXER
REPLENISHMENT PUMP
Check U4.
POPPET VALVES in the FIXER
REPLENISHMENT PUMP Clean and check the VALVES.
FIXER REPLENISHMENT PUMP Check the REPLENISHMENT PUMP
MOTOR B4.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U4.
Check that LED DS2 on the 5000 BOARD
is energized.
If necessary, install a new BOARD.

Error Codes
5B6342 – January 1996 9
Code Description Possible Malfunction Action
E038 Loss of developer
cooling ability Water does not enter the WASH TANK. Check: • that water is supplied to the
PROCESSOR
– The water supply is turned on.
– The FILTER is clean.
• WASH WATER SOLENOID L1
– The operation is correct.
– The SCREEN has no obstructions.
• COOLING/DRAIN SOLENOID L2
The temperature of the water
entering the WASH TANK is too
hot.
Decrease the temperature of the water
supply. The wash water must be a
minimum of 5.5°C (10°F) below the setpoint
of the developer.
HEAT EXCHANGER in the
DEVELOPER TANK Remove any obstructions from the EXCHANGER.
The 5000 BOARD does not
energize the SOLENOID L1 or
de-energize the SOLENOID L2.
Check for 24 V DC at TERMINALS 1 and 2
on the WASH WATER SOLENOID L1.
Check that 24 V DC is not present at
TERMINALS 1 and 2 for the
COOLING/DRAIN SOLENOID L2.
If necessary, install a new BOARD.
RECIRCULATION PUMP Check the RECIRCULATION PUMP
MOTOR B5. If necessary, install a new
PUMP.
E040 Loss of dryer heating
ability A PANEL is not installed. Install the PANEL.
DRYER OVERTEMPERATURE
THERMOSTAT Reset the THERMOSTAT. If the THERMOSTATopensagain,determinethe
cause of the high temperature. If you
cannot determine the cause of the problem,
install a new THERMOSTAT.
SOLID STATE RELAY U1 that
controls the DRYER HEATER Check U1.
No continuity for the DRYER
HEATER Check that the resistance at 25°C (77°F) is approximately 18 W.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U1.
Check that LED DS5 on the 5000 BOARD
is energized.
If necessary, install a new BOARD.

DIAGNOSTICS
10 January 1996 – 5B6342
Code Description Possible Malfunction Action
E041 Loss of transport speed control
Note
This error occurs when the
transport speed is adjusted for
10 seconds and the speed is
not within 7.6 cm/min (3 in./min)
of the setpoint.
When the PROCESSOR operates normally:
• The supply voltage from the +24 V POWER SUPPLY PS3 to the
PCOM and +24 V TERMINALS of the DRIVE MOTOR
CONTROLLER A4 is 24 V DC.
• The control voltage to TERMINALS 4 and 6 on the DRIVE MOTOR
CONTROLLER A4 is approximately:
– 0.85 V DC for the Extended Speed
– 1.55 V DC for the Standard Speed
– 2.25 V DC for the Rapid Speed
– 3.00 V DC for the K/RA Speed
• Feedback pulses from the DRIVE MOTOR CONTROLLER A4 at
Test Point MOTFB on the 5000 BOARD indicate the speed of the
DRIVE MOTOR.
If the transport operates slower than the set speed, the
MICROPROCESSOR increases the control voltage approximately
25 mV every second at TERMINALS 4 and 6 on the DRIVE MOTOR
CONTROLLER A4. If the voltage reaches 5 V DC, the
MICROPROCESSOR stops increasing the voltage. When you check
the voltage, if it is:
• 5 V DC, check for mechanical malfunctions.
• 0, check the wiring and the CONNECTOR.
5000 BOARD If the control voltage is not correct at
TERMINALS 4 and 6 of the DRIVE MOTOR
CONTROLLER A4, install a new BOARD.
DC DRIVE MOTOR B6 or
DRIVE MOTOR
CONTROLLER A4
If B6 operates, but no pulses occur at Test
Point MOTFB on the 5000 BOARD or if the
supply voltage and the control voltage to the
CONTROLLER are not correct, check:
• B6
•A4
E042 Loss of accessory data link Loose connections Check all connections between any
accessory and the PROCESSOR.
5000 BOARD Install a new BOARD.
2000 BOARD Install a new BOARD.
E045 Display data link error CABLES between the
3000 and 5000 BOARD Check the CABLES.

Error Codes
5B6342 – January 1996 11
Warnings
Error
Code Error Description Possible Malfunction Action
E128 Top cover not in
place When this error occurs, the following functions are disabled: • film transport
• film accumulation
The TOP COVER is opened. Close the TOP COVER.
INTERLOCKSWITCHESS3
and S4
• MAGNETS
Check S3 and S4. If necessary, install a new
SWITCH or MAGNET.
7000 BOARD Install a new BOARD.
E129 Tankscurrentlybeing
filled When this error occurs, • the following functions are disabled:
– film transport
– film accumulation
• the following parts are disabled:
– RECIRCULATION PUMP
– 3 HEATERS
None None. This message will clear automatically.
E130 Replenish pumps
disabled None Use the KEYPAD to select either Automatic or Flooded Replenishment to enable the PUMPS.
E132 Developer under set
temperature None None. This message will clear automatically when the developer reaches the setpoint temperature.
E133 Developer over set
temperature None None. This message will clear automatically when the developer reaches the setpoint temperature.
E134 Dryer under set
temperature None None. This message will clear automatically when the DRYER reaches the setpoint temperature.
E137 Film accumulator
LED error 6000 BOARD Check that no chemical deposits are on the PROTECTIVE COVER for the BOARD.
De-energize and energize the PROCESSOR to
reset the:
• MICROPROCESSOR on the 5000 BOARD
• MICROPROCESSOR on the 6000 BOARD
Check the BOARD. Use the internal diagnostics. If
necessary, install a new BOARD.
E141 Low developer tank
level When this error occurs, the: • RECIRCULATION PUMP is disabled
• temperature control for the fixer and developer is disabled
None None. This error will clear automatically when the
developer solution reaches the correct level.
E142 Low fixer tank level When this error occurs, the:
• RECIRCULATION PUMP is disabled
• temperature control for the fixer and developer is disabled
None None. This error will clear automatically when the
fixer solution reaches the correct level.

DIAGNOSTICS
12 January 1996 – 5B6342

Mechanical Diagnostics
5B6342 – January 1996 13
Section 2: Mechanical Diagnostics
Transport Malfunction
Possible Cause Check
RACK and CROSSOVER
ASSEMBLIES RACK and CROSSOVER ASSEMBLIES: correct positions
seated correctly
• squareness
– SeetheAdjustmentsandReplacements,Publication No.5B6340,
RACKS and CROSSOVERS.
Adjusting the Squareness of the CROSSOVERS
Adjusting the Squareness of the RACKS
• cleaned completely
– See the Preventive Maintenance, Publication No. 5B6747.
CROSSOVER TROUGHS
• correct positions
ROLLER ASSEMBLIES ROLLERS
• correct positions
• rotate freely
• GUDGEONS
– no damage
– If necessary, install new ROLLERS.
GEARS, SPROCKETS, and IDLERS
• engage correctly
• not broken or worn
BEARINGS
• no wear
SPRINGS and E-RINGS
• not broken or missing
RACK ASSEMBLY
• DRIVE CHAIN
– tension
DRYER AIR TUBE BAFFLES
• installed
Temperature setting of the DRYER
lowest possible setting to provide the best image quality
•
DRYER ROLLERS and AIR TUBES
• seated correctly
DRYER BELT
• moves correctly
TOP COVER TOP COVER
• closed

DIAGNOSTICS
14 January 1996 – 5B6342
Artifacts and Wrong Film Densities
Possible Cause Check
Replenishment system Replenishment rates
• correct setting
HOSES
• opened and round
• no obstructions or air bubbles
HOSE CLAMPS
• tight
REPLENISHMENT PUMP
• operation
• calibration
Replenishment chemicals
• Change any chemicals that are:
– not mixed correctly
– exhausted
– contaminated
Note
When you mix chemicals:
• Mix a maximum of a 2-week supply of the DEVELOPER
RELENISHER.
• Follow all directions for mixing chemicals and solutions.
• Use a SPLASH GUARD and DRIP TRAY when you remove the
FIXER RACK from the PROCESSOR to prevent contamination of the
developer.
DEVELOPER and FIXER TANKS
• DRAIN VALVES
– completely closed
Recirculation system DEVELOPER and RECIRCULATION HOSES
• ORIFICES
– no obstructions
DEVELOPER FILTER
• If necessary, install a new FILTER.
Movement of the solutions at the surface of the PROCESSOR TANKS
when you enrgize the PROCESSOR and the TANKS are full.
• If the solutions do not move, check that the:
– HOSES have no obstructions or air bubbles in the recirculation
system
– RECIRCULATION PUMP operates
– DEVELOPER FILTER is clean and in the correct position

Mechanical Diagnostics
5B6342 – January 1996 15
RACK and CROSSOVER
ASSEMBLIES RACKS and CROSSOVERS • correct position
• seated correctly
• cleaned completely
– See the Preventive Maintenance, Publication No. 5B6747.
CROSSOVER TROUGHS and EVAPORATION COVERS
• correct position
• TROUGHS
– clean
• TROUGH DRAINS
– no obstructions
• CROSSOVER YOKE
– correct position
ROLLERS ROLLERS
• clean and not scratched
• correct position
• rotate freely
• GUDGEONS
– no damage
– If necessary, install new ROLLERS.
DETECTOR ROLLERS
• clean
GEARS, SPROCKETS, and IDLERS
• engage correctly
• no wear
BEARINGS
• no wear
SPRINGS
• not broken or missing
DEVELOPER and FIXER RACK ASSEMBLIES
• ROLLER SPROCKETS
– engage correctly
• DRIVE CHAINS
– correct adjustment of the tension
Possible Cause Check

DIAGNOSTICS
16 January 1996 – 5B6342
Drying system DRYER AIR TUBES
• clean
– If necessary, use a BOTTLE BRUSH and water to clean the
TUBES and SLOTS in the TUBES.
• BAFFLES
– installed
Temperature setting of the DRYER
• lowest possible setting to provide the best image quality
• exhaust for the PROCESSOR
– meets the specifications
– See the Site Specifications, Publication No. 5B6338.
Wrong water temperature Temperature of the water
• 4.5 - 29.5˚C (40 - 85˚F)
Wash water WASH TANK and CROSSOVER TROUGH
• Water flows into these parts
COVERS and PANELS TOP COVER
• closed
ACCESS PANEL
• installed
EVAPORATION COVERS
correct position
•
Ventilation system Exhaust for the PROCESSOR
• meets the specifications
• See the Site Specifications, Publication No. 5B6338.
• Internal EXHAUST FAN operates correctly
External EXHAUST HOSE
• connected from the AIR EXHAUST on the PROCESSOR to the
BUILDING EXHAUST
Internal EXHAUST HOSE
• connected from the internal EXHAUST FAN to the AIR EXHAUST
Possible Cause Check

Mechanical Diagnostics
5B6342 – January 1996 17
Wet Films
Possible Cause Check
Film and chemicals are not
compatible. Film • compatible with the selected cycle
Replenishment system Replenishment rates
• correct setting
HOSES
• opened and round
• no obstructions or air bubbles
HOSE CLAMPS
• tight
REPLENISHMENT PUMP
• operation
• calibration
Replenishment chemicals
• Change any chemicals that are:
– not mixed correctly
– exhausted
– contaminated
Note
When you mix chemicals:
• Mix a maximum of a 2-week supply of the DEVELOPER RELENISHER.
• Follow all directions for mixing chemicals and solutions.
• Use a SPLASH GUARD and DRIP TRAY when you remove the FIXER
RACK from the PROCESSOR to prevent contamination of the developer.
REPLENISHMENT TANKS
• quantity of solution
DEVELOPER and FIXER TANKS
• DRAIN VALVES
– completely closed
Recirculation system Movement of the solutions at the surface of the PROCESSOR TANKS when
you energize the PROCESSOR and the TANKS are full.
• If the solutions do not move, check that the:
– HOSES have no obstructions or air bubbles in the recirculation system
– RECIRCULATION PUMP operates
– DEVELOPER FILTER is clean and in the correct position

DIAGNOSTICS
18 January 1996 – 5B6342
Drying system DRYER AIR TUBES
• clean
– Ifnecessary, use a BOTTLE BRUSH andwaterto clean the TUBES and
SLOTS in the TUBES.
• BAFFLES
– installed
DRYER
• lowest possible temperature to provide the best image quality
DRYER AIR EXHAUST
• no obstructions
• installed correctly
– If necessary, see the Installation Instructions, Publication No. 5B6339.
DRYER HEATER
• operates correctly
DRYER ROLLERS and AIR TUBES
• seated correctly
Wash water Water
• input to the WASH TANK
• temperature
• input to the CROSSOVER TROUGHS
– is connected
RACK and CROSSOVER
ASSEMBLIES WASH RACK • SQUEEGEE ROLLERS
– clean
– good condition
SPRINGS
• not broken or missing
SQUEEGEE ASSEMBLY
• operates correctly
• ROLLERS
– clean
– good condition
• SPRINGS
– correct tension
YOKE and CROSSOVER TROUGHS
• installed correctly
CROSSOVER TROUGHS
holes are
• opened
– Ifnecessary,clean the holestopreventanoverflow of thewaterfromthe
TROUGHS into the DEVELOPER and FIXER TANKS.
Possible Cause Check

Mechanical Diagnostics
5B6342 – January 1996 19
Solution Levels
Possible Cause Check
Replenishment system Replenishment rates
• correct setting
HOSES
• opened and round
• no obstructions or air bubbles
REPLENISHMENT PUMP
• operation
• calibration
REPLENISHMENT TANKS
• quantity of solution
POPPET VALVES
• clean
• no damage
DEVELOPER and FIXER TANKS
• DRAIN VALVES
– no leakage
CROSSOVER TROUGHS
• correct positions
• TROUGHS
– clean
• TROUGH DRAINS
– no obstructions

DIAGNOSTICS
20 January 1996 – 5B6342
