1 Choosing a Connection Type
Make sure you completed the steps in the Start Here instructions. Then choose one of the following
connection types for your printer, and see the corresponding chapter for instructions.
NOTE:
• You can change your connection type later. See the chapter Configuring Your Printer in the
Extended User Guide.
• For additional networking information or troubleshooting, go to
www.kodak.com/go/inkjetnetworking.
Wireless (Wi-Fi) connection
Ethernet connection
To connect your printer to a wireless network, see Setting Up the Wireless (Wi-Fi)
Connection, page 2.
To connect your printer to a wired network using an Ethernet cable, see Setting Up the
Ethernet Connection, page 4.
MSSD/HCMMC
Rotate
BackHome

www.kodak.com/go/aiosupport 2
2 Setting Up the Wireless (Wi-Fi) Connection
Before you connect, you need to:
• Have a functional 802.11 wireless network. Kodak recommends that you use a wireless access point, most
commonly a router, that uses Dynamic Host Configuration Protocol (DHCP).
• Determine whether your wireless router supports Wi-Fi Protected Setup (WPS).
• Temporarily disable your firewall until the printer is successfully installed and communicating.
IMPORTANT: If you are unsure of how your network is configured, contact your Internet service provider or your
network administrator for assistance.
Using the LCD keyboard
There are two types of keyboards.
On the control panel (both types of keyboards), press , , or to select the letters and numbers,
using the correct uppercase and lowercase letters. Press OK after each character. When you are done, select
DONE, then press OK.
Connecting to a non-WPS wireless router
To connect your printer to your wireless network, you need to know the network name, which is also called the
Service Set Identifier (SSID). You can obtain your network name from the wireless router. See the
manufacturer’s documentation for more information.
If your network has security enabled, you also need to know the security string, which may be a Wired
Equivalent Privacy (WEP) key or a Wi-Fi Protected Access (WPA/WPA2) passphrase or password.
Record your network information in the spaces below, using the correct uppercase and lowercase letters.
Network Name (SSID): __________________________________________________________________________
Security String: _________________________________________________________________________________
1. Press Home.
2. Press to select Network Settings, then press OK.
3. With WiFi Setup Wizard selected, press OK.
The printer searches for available wireless networks within range, then displays the list in order of signal
strength. If there are more networks than can be shown on the LCD, a (page down) symbol appears in
the bottom right of the display. If you don’t see your network in the list, or if you want to change your
network, select Rescan for Wireless Networks, then press OK.
•To change from uppercase to
lowercase, select abc/123,
then press OK.
• To change from lowercase to
uppercase, select ABC/123,
then press OK.
•To enter punctuation or
symbols, select !@#, then press
OK.
Use the arrow
keys to select the
letters, numbers,
and symbols.

Setting Up the Wireless (Wi-Fi) Connection
3www.kodak.com/go/aiosupport
4. If the name of your network is:
5. If your network has security enabled, use the LCD keyboard to enter your security string.
6. When the confirmation message appears, press OK.
If the printer is successfully connected, the Wi-Fi status light should be on.
If you are unable to connect your printer, go to www.kodak.com/go/inkjetnetworking.
7. When the printer is successfully connected, install the KODAK All-in-One Printer Software on your
computer. Follow the on-screen instructions to complete your setup.
Connecting to a WPS wireless router
1. Press Home.
2. Press to select Network Settings, then press OK.
3. With WiFi Setup Wizard selected, press OK.
NOTE: The Wi-Fi radio turns on automatically when you select Wi-Fi Setup Wizard.
4. With WPS Connect selected, press OK.
5. Select one of these two methods of connecting:
IMPORTANT: Before you press OK on the printer, make sure you know where the router's button is, or where to
enter the generated PIN. If necessary, consult your Internet service provider or router
manufacturer’s documentation for more information.
6. When the confirmation message appears, press OK.
If the printer is successfully connected, the Wi-Fi status light should be on.
If you are unable to connect your printer, go to www.kodak.com/go/inkjetnetworking.
7. When the printer is successfully connected, install the KODAK All-in-One Printer Software on your
computer. Follow the on-screen instructions to complete your setup.
Listed Not Listed
Press to select your
network, then press
OK.
Make sure your wireless router is turned on and within range. If your wireless
router does not broadcast its SSID:
a. Press to select Unlisted network, then press OK.
b. Use the LCD keyboard to enter your network name.
c. Select WEP or WPA/WPA2 as required for your network's security
setup, then press OK.
Pressing a Button Entering a PIN
a. With Push Button Configuration selected, press OK.
b. Press or select the WPS button for your wireless router.
NOTE: You will have two minutes to press or select the
WPS button. It may be a button on the device or a
virtual button in the device’s software.
a. Press to select Generate WPS
PIN, then press OK.
b. In your wireless router’s software,
locate the PIN screen.
c. Enter the PIN you received from the
LCD into the PIN screen.

www.kodak.com/go/aiosupport 4
3 Setting Up the Ethernet Connection
Before you connect, you need to:
• Have a functional Ethernet network that includes a router, switch, or hub with an Ethernet port.
• Have a Category 5 (or higher) Ethernet cable.
• Temporarily disable your firewall until the printer is successfully installed and communicating.
Connecting to an Ethernet network
1. Connect the Ethernet cable into the Ethernet port on the back of the printer.
2. Connect the other end of the Ethernet cable into an available Ethernet port on your router, switch, or hub.
3. Install the KODAK All-in-One Printer Software on your computer. Follow the on-screen instructions to
complete your setup.
