Kodiak KCH3100BE1 User manual

KODIAK HD BELT DRIVE
PRESSURE WASHER
OWNER’S MANUAL
Overview & Warnings
Safety Precautions
Assembly Instructions
Operating Instructions
Using the Accessories
Working with Detergent
Shutdown Instructions
Storage, Winterization & Transport
Basic Maintenance
Troubleshooting
Warranty Information
2.
3.
5.
6.
7.
8.
9.
10.
10.
12.
14.
IMPORTANT: Do not operate this equipment until you have read and understand all
of the enclosed Owner’s Manuals. Carefully read all Warnings, Safety Precautions,
Assembly and Operating Instructions, Maintenance and Storage information.
CUSTOMER SERVICE HOTLINE:
1-888-881-6667
Visit our website:
www.dynablast.ca

2
MACHINE OVERVIEW
WARNING!
Note: Check for visible shipping damage. Shipping damage will cause problems in the operation of this unit.
Contact the Customer Service Hotline immediately if parts are missing or damaged. DO NOT return this
product to the Dealer.
Never aim water spray at persons, animals, electrical devices or the machine itself.
Never touch water spray.
Never use hot water.
Never operate pressure washer without the water turned on.
Never drink alcohol or use drugs while operating this equipment.
Never allow the pressure washer to freeze.
Always wear safety glasses and protective clothing.
Always ensure that you have read and understand all of the enclosed Owner’s Manuals before operating
this equipment.
ITEM DESCRIPTION
Nozzle Connector
Spray Lance
Gun with Safety-Lock
High-Pressure Hose
Reversible Cart Handle
Spray Nozzles
Unloader
Belt Guard
Water Inlet
Water Outlet
Front Guard
Pump
Pump Oil Dipstick
Motor
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
7
9
11
10
12
13
6
8
14

3
SAFETY OVERVIEW
This unit was designed for specic applications. It should
not be modied or used for any application other than
that for which it was designed.
The Owner’s Manual is an essential part of the pressure
washer and should be kept in a safe place for future
reference. If you sell the pressure washer, all manuals
should be provided to the new owner. Read this manual
carefully before using the product – know your equipment.
Save these instructions. The Owner’s Manual should
remain with the unit at all times.
SAFETY PRECAUTIONS
The following safety precautions are essential for the safe
operation of your pressure washer. Make sure anyone
who may be using the pressure washer is familiar with
these important safety and equipment precautions.
If safety precautions are overlooked or ignored, personal
injury or property damage may occur. Always heed
these precautions as they are essential when using any
mechanical equipment.
1. Ensure the unit is off and secured in a position to
limit movement before transport.
2. High-pressure spray can be dangerous if subject
to misuse. DO NOT direct the water spray
at persons, animals, electrical devices or the
machine itself.
3. Never touch the water spray.
4. Never hold on to the hose or ttings while operating
the pressure washer.
5. Keep operating area clear of all persons. To reduce
the risk of injury, DO NOT operate the machine
near children.
6. Keep work area free of obstacles. Remove loose
objects from spray path. Secure light objects to be
cleaned.
7. Always use both hands during operation to maintain
complete control of the gun/lance assembly. Expect
it to kick back when the gun is triggered.
8. Always engage the gun safety-lock when not
spraying to prevent accidental triggering.
9. Always wear protective clothing and safety glasses.
Protect your eyes and skin from contact with
sprayed materials.
10. Stay alert – watch what you are doing.
11. DO NOT operate the product when fatigued or
under the inuence of alcohol or drugs.
12. Learn how to stop the machine and release
pressure quickly. Be thoroughly familiar with the
controls.
13. Outlets with a third prong ground are required. DO
NOT use without grounded prong.
14. If replacement of the plug or cord is needed, use
only identical replacement parts.
15. Check power cords before using. DO NOT use
damaged cords as that could reduce machine
performance or cause fatal electric shock.
16. To reduce the risk of electrocution, keep all
connections dry and off the ground. DO NOT touch
the plug or outlet with wet hands.
17. DO NOT pull on the cord to disconnect from an
outlet. Never carry your pressure washer by the
cord.
18. To prevent damage, the cord should not be crushed,
placed next to sharp objects or near a heat source.
19. Avoid accidental starts. Move switch on unit to OFF
position before connecting or disconnecting cord to
electrical outlets.
20. Disconnect the plug from the outlet when not in use,
prior to detaching the high-pressure hose and/or
servicing.
21. Parts of the motor get extremely hot during
operation. Never touch the motor while it is hot or
running; allow motor to cool down and avoid injury.
22. DO NOT allow the hose to touch any part of the
motor while it is running or hot. A hot motor could
melt through the hose.
23. Work in a well-ventilated area. The pressure
washer should not be used in areas where gas
vapors may be present. A spark could cause an
explosion or re.
24. To allow free air circulation, DO NOT cover the
pressure washer during operation.
25. DO NOT over reach or stand on an unstable
support. Keep good footing and balance at all
times when using this equipment.
26. The narrow pencil-point spray is very powerful. It
is NOT recommended for use on painted surfaces,
wood surfaces or items attached with an adhesive
backing.
27. Only use pressure washer detergent with this product.
Carefully observe all instruction and warnings before
using detergents.
28. DO NOT use this machine to spray chemicals, acids,
solvents, insecticides or any ammable material.
These products can cause physical injuries to the
operator and irreversible damage to the unit.
29. DO NOT allow your pressure washer to freeze
during the colder months. Damage as a result of
freezing will void the warranty.
30. Prior to starting the pressure washer in cold
weather, be sure that ice has not formed in any part
of the equipment.
31. Never tie knots or kink the high-pressure hose as
damage could result. DO NOT operate the unit if
the high-pressure hose is damaged.
32. The gun safey Lock PREVENTS the trigger from
accidentally being engaged. This safety feature
DOES NOT lock the trigger in the ON position.
IMPORTANT: Your pressure washer operates at uid
pressures and velocities high enough to penetrate
human and animal esh, which could result in serious
injury or loss of life. Leaks caused by loose ttings,
damaged or worn hoses can result in Injection Injuries.
WARNING: DO NOT treat uid injections as a simple
injury. Fluid injection is very serious. See a physician
immediately.
WARNING: Some chemicals or detergents may be
harmful if inhaled or ingested, causing severe nausea,
fainting or poisoning.
ONLY OPERATE THE PRESSURE
WASHER OUTSIDE!
IMPORTANT SAFETY PRECAUTIONS

4
GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction
or break-down, grounding provides a path of least
resistance for the electric current to reduce the risk of
electric shock. This product is equipped with a cord that
includes a grounding plug. You must make sure that the
plug is inserted into an outlet that is properly installed
and grounded in accordance with all local codes and
ordinances.
Warning: Improper connection can result in a risk
of electrocution. Check with a licensed electrician if
you are unsure as to whether the outlet is properly
grounded.
DO NOT modify the plug provided with the unit; if it
will not t the outlet, a have a proper outlet installed
by a licensed electrician. Do not use any type of
adaptor with this product.
EXTENSION CORDS
Extension cords are NOT recommended for this
product. If an extension cord must be used, the
following requirements must be met:
• 14-3 gauge minimum wire size up to 25 ft. cord. (120V)
• 12-3 gauge minimum wire size up to 50 ft. cord. (120V)
• 10-3 gauge minimum wire size up to 50 ft. cord. (240V)
• Use only 3-wire extension cords that have 3-prong
grounding type plugs and 3-pole cord connectors that
accept the plug from the unit.
Use only extension cords that are intended for outdoor
use. These extension cords are identied by the
marking “Acceptable for use with outdoor appliances;
store indoors while not in use.” Only use extension
cords with a rating no less than that of the rating of
the product. Do not use damaged extension cords.
Examine the extension cord before using and replace
if damaged.
Do not abuse the extension cord and do not yank on
any cord to disconnect. Keep cord away from heat
and sharp edges. Always disconnect the extension cord
from the receptacle before disconnecting the product
from the extension cord. If you are using an extension
cord, it should always be completely unwound.
SAFETY PRECAUTIONS (CONT’D)
33. Securely connect the discharge lines before starting
the pump. An insecurely connected line may cause
personal injury and/or property damage.
34. To avoid serious injury and damage to the unit DO NOT
operate this pressure washer with any components
rated less than the pressure rated for each model (i.e.:
spray guns, hoses, hose couplings, etc...)
35. DO NOT allow the pressure washer to run for
more than 3 minutes with the gun closed and motor
running. Prolonged operation in bypass mode can
result in damage to the pump.
36. Shut the motor OFF if you are not using the pressure
washer.
CAUTION: The pressure has been preset by the
manufacturer. DO NOT attempt to adjust the pressure
higher than its factory setting. Doing so will damage the
pump, void the warranty and could result in personal
injury or damage.
CAUTION: This machine has been designed for use with
pressure washer detergents only.
WATER SUPPLY (Cold Water Only)
This pressure washer must only be used with clean water;
use of unltered water or corrosive chemicals will damage
the pressure washer.
1. The supply hose should be at least 5/8” in diameter.
2. The water supply much be at least twice to the ow
rate of the pressure washer. (GPM)
3. The water supply pressure must be a minimum of
20psi and must not exceed 120psi.
4. The water supply temperature must not exceed
40˚C/104˚F.
5. Never use the pressure washer to draw in water
contaminated with solvents, e.g. paint thinners,
gasoline, oil, etc.
6. Always prevent debris from being drawn into the
unit by using a clean water source.
7. Calcium build-up due to hard water is NOT covered
by the warranty.
IMPORTANT SAFETY PRECAUTIONS (CONT’D)

5
STEP 6
Pull back the collar on the lance
socket to insert a nozzle. Release
collar.
STEP 5
Pull back the collar on the high-
pressure hose socket to connect to
the spray gun. Release collar.
STEP 4
Wrap the threads of the lance
with Teon Tape provided.
Thread lance into spray gun.
NOTE: Check for visible shipping damage. Shipping damage will cause problems in the operation of this unit. Contact
the Customer Service Hotline immediately if there are missing or damaged parts.
DO NOT return this product to the Dealer!
CAUTION: If the spray nozzle is
not securely locked into place,
it could be ejected under high-
pressure when operating the gun,
possible causing injury and/or
damage. Poorly mounted nozzles
can become projectile. Ensure that
the connection is securely made.
CAUTION: The vented yellow plug/dipstick must be installed. Failure to install the yellow plug/ dipstick will damage
the pump and void the warranty.
NOTE: This product features an innovative reversible handle which allows the user the option of high cart or low cart
conguration by simply switching handles from one side to the other.
STEP 7
Connect the garden hose to the
INLET. Hand tighten.
STEP 1
Determine desired position and
attach handle to the frame. Insert
bolts and tighten with hardware
provided.
STEP 3
Install the provided vented yellow
plug/dipstick.
STEP 2
Remove the red shipping plug
from the pump crankcase.
STEP 8
Connect the high-pressure hose to
the OUTLET. Pull back the collar
on the socket.
ASSSEMBLY INSTRUCTIONS

6
STEP 4
Connect electrical cord to a
properly grounded outlet.
OPERATING INSTRUCTIONS
STEP 3
Continue to squeeze gun trigger
until a steady stream of water
ows from the nozzle before
releasing the trigger.
STEP 2
Release the gun safety-lock and
squeeze gun trigger.
STEP 1
Connect the garden hose to the
water supply and turn ON water
full force.
WARNING: Operating unit without
water can damage seals and void
the warranty. Always trigger gun
until steady stream of water ows
from the nozzle to ensure unit is
receiving water correctly before
starting the motor.
CAUTION: Always shutdown the
pressure washer when it is not in
use. Please refer to the shutdown
instructions on page 9 for more
details.
STEP 5
Start motor. Refer to the Motor
Owner’s Manual.

7
CAUTION: The red nozzle (0˚) is very aggressive. For most
cleaning applications, the at spray nozzles (15˚, 25˚, and
40˚) should be used to avoid damage to the surface being
sprayed.
NOTE: The intensity of the spray increases as you move the
nozzle closer to the surface.
Additional accessories available for your pressure washer
include the following:
Hose Reel Kit Part Number: CC2HRKIT
Rotary Nozzles Kits:
NOTE: Your dealer carries a complete line of accessories
that compliments your pressure washer and maximizes its
usage.
USING THE ACCESSORIES
This nozzle produces a high-pressure at
spray (15˚) suitable for cleaning concrete,
brick & other porous surfaces.
YELLOW:
This nozzle produces a high-pressure
pencil-point spray (0˚) ideal for removing
stubborn dirt.
RED:
This nozzle produces a high-pressure at
spray (25˚) suitable for cleaning painted
surfaces, wood, siding and fences.
This nozzle produces a wide, high-
pressure, at spray (40 ˚) suitable for
cleaning windows and screens .
GREEN:
WHITE
This nozzle produces a low-pressure
spray that must be used for application
of detergents.
BLACK:
CAUTION: Your pressure washer operates at uid pressures and velocities high enough to cause property damage.
Before cleaning any surface, choose an inconspicuous area to test spray pattern and distance for maximum cleaning
results. If painted surfaces are peeling or chipping, use extreme caution as pressure washer may remove the loose paint
from the surface.
CHANGING NOZZLES
CAUTION: When installing or changing a spray nozzle,
always do so with the water turned OFF at the source and
the motor turned OFF.
CAUTION: When inserting or removing the spray nozzles
from the rubber grommet (located on the handle) use
a twisting motion so that the rubber grommet does not
disengage from the grommet hole.
QUICK-CONNECT NOZZLES
Five colour-coded quick-connect nozzles are included with
the pressure washer.
STEP 1
Discharge residual pressure by pressing and holding the
gun trigger until no water comes out of the nozzle.
STEP 2
Release the gun trigger and engage the gun safety-lock.
STEP 3
Pull back the collar on the lance socket to insert one of
the nozzles.
STEP 4
Release the collar and pull sharply on the connection to
ensure it is secure.
Nozzle Kit Part
Number
Compatible
HD Model
RNOZKITUR16055 KCH3100BE1
KCH3100BET1
RNOZKITUR2504 KCH2150BE1
KCH2150BET1
RNOZKITUR25045 KCH3150BE1
KCH3150BET1
RNOZKITUR2505
KCH4200BE1
KCH4200BET1
KCH4200BET3D
RNOZKITUR25035
KCH3250BE1
KCH3250BET1
KCH3250BET3D

8
IMPORTANT: When you have nished using detergent,
always follow the Cleanup Instructions. Failure to clean
properly will cause the injection system to become
clogged and inoperable.
CAUTION: This machine has been designed for use
with pressure washer detergents only. The use of other
detergents or chemicals may affect the operation of
the machine and will void the warranty.
NOTE: To apply detergent, the black coloured
detergent nozzle must be used to activate the low-
pressure detergent injection system.
DETERGENT OVERVIEW
To enhance the efciency of the pressure washer,
sometimes it is necessary to use detergents to help
loosen tough dirt and grime.
WARNING!
• Never use bleach, chlorine products and other
corrosive chemicals
• Never use liquids containing solvents (i.e. paint
thinners, gasoline, oils)
• Never use tri-sodium phosphate products
• Never use ammonia products
• Never use acid-based products
These products can cause physical injuries to the
operator and irreversible damage to the machine
and/or damage the surface being cleaned.
STEP 1
Place the suction hose into a container of pressure washer
detergent.
STEP 2
Pull back the collar on the spray lance to insert the
detergent nozzle. (see page 7)
STEP 1
Insert detergent suction tube into a clean container (not
supplied) with one gallon (4L) of fresh water.
STEP 2
Pull back the collar on the spray lance to insert the
detergent nozzle (see page 7).
STEP 3
Turn the adjustment knob counter-clockwise to open and
meter the desired amount of chemical injection.
STEP 4
With the motor running, depress the gun trigger to apply
detergent to the work area, DO NOT allow detergent
to dry.
STEP 5
After applying detergent, turn adjustable knob clockwise
to close off the detergent chemical injector.
STEP 6
Release the gun trigger and attach one of the high-
pressure nozzles.
STEP 3
Turn the adjustment knob counter-clockwise to open and
meter the desired amount of chemical injection.
STEP 4
With the motor running, press and hold the gun trigger for
one minute or until the container of fresh water is empty.
STEP 5
After siphoning the water, turn adjustable knob clockwise to
close off the detergent chemical injector.
STEP 6
Release the gun trigger and attach one of the high-
pressure nozzles.
DETERGENT APPLICATION
CLEANUP INSTRUCTIONS
WORKING WITH DETERGENT

9
CAUTION: Never allow the pressure washer to run for
more than 3 minutes with the gun closed and the motor
running. Prolonged operation in bypass mode can result
in damage to the pump.
NOTE: Always shut the motor OFF and engage the gun
safety-lock when the pressure washer is not in use.
CAUTION: Failure to discharge the residual pressure could result in personal
injury due to discharge of high-pressure water.
STEP 3
Turn OFF the water supply.
STEP 1
Turn motor switch off.
STEP 2
Unplug power cord from outlet.
STEP 6
Disconnect the garden hose from
the water INLET.
STEP 5
Disconnect the high-pressure hose
from the water OUTLET.
STEP 4
Discharge residual pressure by
pressing and holding the gun
trigger until no water comes out
the nozzle.
STEP 7
Engage the safety-lock.
THERMAL PROTECTION VALVE
Your pressure washer is equipped with a thermal protection valve, located at the base of the pump. If the motor is left
running for an extended period of time with the gun closed, the pressure washer will vent water into the atmosphere
through this valve. This will protect against accidental situations but is not designed for repetitive venting.
SHUTDOWN INSTRUCTIONS

10
STORANGE, WINTERIZING & TRANSPORT
STORAGE
CAUTION: Always follow the proper Shutdown
Instructions on page 9 before storing the pressure
washer or accessories. For your own safety, be sure to
turn the motor OFF and discharge the residual pressure
(see page 9.)
Always store your pressure washer in a location where
the temperature will NOT fall below 0˚C. Store the
machine and accessories in a dry place, protected from
freezing. The machine should NOT be placed near an
open ame i.e. furnace, hot water heater, etc.
TRANSPORT
Before transport, make sure that the unit is not under
pressure and that the unit is in a secure and upright
position.
WINTERIZING
Always store your pressure washer in a location where
the temperature will NOT fall below 0˚C.
If you must store your pressure washer in a location
where the temperature is below 0˚C, you can minimize
the chance of damage to your machine by utilizing the
following procedure:
1. Turn Motor switch OFF
2. Shut off water supply and relieve pressure in the
spray gun by depressing the trigger.
3. Disconnect the garden hose from the unit, but
leave the high-pressure hose connected.
4. Connect a short hose (not supplied) to the water
inlet of the pressure washer.
5. Place the other end of this hose into a container
of plumbing anti-freeze.
6. Start the motor to circulate the plumbing anti-
freeze in the pump.
7. Press and hold the gun trigger until the uid comes
out the nozzle. Turn the motor OFF immediately.
8. Discharge residual pressure by pressing and
holding the gun trigger, then disconnect the high-
pressure hose.
The plumbing anti-freeze will help protect against
freezing during storage and help prevent the pistons
from sticking.
BASIC MAINTENANCE
IMPORTANT: Always follow the Shutdown Instructions on page 9 before working on the pressure washer or the
accessories. For your own safety, be sure to turn the motor OFF and discharge the residual pressure (see page 9)
before carrying out any maintenance.
WARNING! The pressure washer pump is
susceptible to permanent damage if frozen.
Damage as a result of the unit freezing is NOT
covered by the warranty.
NOZZLE
Clogging of the nozzle causes pump pressure to pulsate
and a distorted spray pattern can result.
Cleaning is immediately required with unit turned OFF.
CAUTION: Failure to discharge the residual pressure
could result in personal injury due to discharge of high-
pressure water.
Step 1: Disconnect the nozzle from the lance.
Step 2: Flush the nozzle backwards with water.
Step 3: Reconnect the nozzle to the lance.
Restart the pressure washer and depress the trigger on the
spray gun. If the nozzle is still plugged, repeat steps 1
through 3.
CONNECTIONS
Connections on hoses, the gun and spray lance should be
cleaned regularly.
COOLING SYSTEM
The air vents, located in and around the pressure washer,
must be kept clean and free of any obstructions to ensure
proper air-cooling of the motor during operation.

11
BASIC MAINTENANCE (CONT’D)
WATER SCREEN
CAUTION: If the screen is not kept clean, the ow of
water to the pressure washer will be restricted and the
pump maybe damaged.
The pressure washer is equipped with a water inlet screen
to protect the pump. Clogging of the water screen will
restrict ow of water. Cleaning is immediately required
with unit turned OFF.
1. Disconnect the garden hose from the INLET.
2. Remove the water screen from the INLET.
3. Clean screen under warm water.
4. Replace screen immediately to prevent any foreign
matter from entering the pump.
5. Reconnect the garden hose to the INLET.
CAUTION: Do not damage the screen while removing
or cleaning. Any foreign particles entering the pump will
damage the unit.
Please refer to the Motor Owner’s Manual for details on
maintenance of the motor.
WARNING: Improperly maintaining the motor, or failure
to correct a problem before operation can cause a
malfunction in which you can be seriously hurt or killed.
PUMP OIL CHANGE
NOTE: Check the pump before every use as well as the
system components. Check pump oil level daily. The pump
of the pressure washer will require an oil change once a
season or after the rst 50 hours of operation and then
every 50 hours after that. Use only 15W40 HD Motor
Oil in the pump. The pump also contains an oil sight glass
and dipstick.
STEP 1
Use a socket wrench to remove the drain plug located on
the side of the pump.
STEP 2
Drain the oil into a suitable container. Please dispose of
oil properly.
STEP 3
Replace the oil drain plug securely.
STEP 4
Remove the yellow oil ll plug from pump.
STEP 5
Add oil (15W40 HD Motor Oil) until the oil level is
halfway up the oil sight glass.
STEP 6
Replace the yellow oil ll plug securely.

12
TROUBLESHOOTING
IMPORTANT: Always follow the Shutdown Instructions (see page 9) before working on the unit or the accessories.
Always discharge residual pressure and turn the motor OFF.
SYMPTOM POSSIBLE CAUSE SOLUTION
Motor will not
start
On/Off switch is in the “OFF”
position
Turn switch to the “ON” (I) position.
Power cord is not plugged in. Plug in the power cord.
Extension cord is too long.
Extension cord is damaged.
Extension cord is not proper
gauge.
Replace extension cord with either
a 25 ft. 14-gauge cord or
a 50 ft. 12-guage cord.
See Extension Cord section on page 4.
Electrical outlet does not
supply adequate power.
Check that the circuit is rated for 15 amps.
Overload Cutout tripped. Wait 2-3 minutes before restarting.
Trigger not operating Call Customer Service hotline.
Circuit breaker
trips or fuse
blown in fuse
box.
Circuit overload. Check that the circuit is rated for 15 amps.
Disconnect all other loads on the circuit.
Motor is
running, but
pump is not
delivering
maximum
pressure.
Water supply is restricted. Open water faucet fully. Check the garden hose for kinks,
leaks and blockages.
Worn or broken motor key. See dealer.
Diameter of garden hose is
too small.
Use a minimum 5/8” diameter garden hose.
Water inlet screen clogged. Remove screen and clean (see page 10).
Nozzle obstructed. Clean nozzle (see page 10).
Incorrect cleaning nozzle is
installed.
Install the correct nozzle for the cleaning application. (see
page 7).
Unit has been stored in
freezing temperatures.
Thaw out unit completely, including hose, gun and wand.
Output
pressure
varies
between high
and low.
Water supply is restricted. Open water faucet fully. Check garden hose for kinks,
leaks and blockages.
Pump is sucking air. Check that hoses and ttings are airtight. Turn off machine
and purge the pump by squeezing the gun trigger until a
steady ow of water emerges through the nozzle.
Water inlet screen clogged. Remove screen and clean (see page 10).
Nozzle obstructed. Clean nozzle (see page 10).
Calcied gun, hose or spray
lance.
Run distilled vinegar through machine.
Leaks downstream of
unloader
Check for leaks downstream of the unloader valve. If no
leaks, unloader may have to be serviced.

13
IMPORTANT: Always follow the Shutdown Instructions (see page 9) before working on the unit or the accessories.
Always discharge residual pressure and turn the motor OFF.
SYMPTOM POSSIBLE CAUSE SOLUTION
Garden hose
connection
leaks.
Loose ttings. Tighten or replace ttings.
Missing or worn rubber
washer.
Insert new washer.
Gun/lance
assembly or
spray lance
leaks.
Spray lance not attached
properly.
Ensure the spray lance is connected properly. Hand tighten
the connection.
Broken O-Ring. Call Customer Service Hotline to order a replacement
O-Ring.
No detergent. Black-coloured detergent
nozzle not attached.
Attach the black-coloured detergent nozzle (see page 7).
Adjustable detergent knob in
closed position.
Open adjustable detergent knob (see page 8).
Detergent suction tube not
properly attached.
Check connection.
Filter on detergent suction
tube is clogged.
Run warm water through lter to remove debris.
Detergent suction tube
damaged or blocked.
Remove obstruction or replace detergent suction tube.
Nozzle obstructed. Clean nozzle (see page 10).
Detergent container empty. Replace detergent container.
Water leaking. Loose ttings. Check that all ttings are tight.
Water or oil
leaking from
bottom of unit.
Loose ttings. Check that all ttings are tight.
A small amount of leakage is
normal.
Excessive leaking may
indicate water seals are
damaged or worn.
If excessive leaking occurs, call Customer Service Hotline.
Pump is noisy. Pump is sucking air. Check that hoses and ttings are airtight.
Turn off machine and purge pump by squeezing gun
trigger until a steady ow of water emerges through the
nozzle.
Trigger will
not move.
Gun safety-lock engaged. Release safety lock.
CUSTOMER SERVICE HOTLINE:
1-888-881-6667
Visit our website:
www.dynablast.ca
If you encounter any difculties
not listed above, please contact
the Customer Service Hotline.
TROUBLESHOOTING (CONT’D)

14
WARRANTY INFORMATION
PRESSURE WASHER WARRANTY
This product is warranted to be free from defects in materials and workmanship under normal use and service for a
period of one year from the date of purchase when operated and maintained in accordance with the Maintenance
and Operating Instructions supplied with the unit. Hoses, spray lances and other accessories are warranted for 30 days.
Warranty period commences on the date of purchase.
The warranty herein is expressly conditioned upon the customer’s compliance with all precautions and instructions
contained in the Owner’s Manual.
If the machine is still under warranty, the customer has a valid receipt, and the machine meets the warranty criteria, then
the repair will be made at no charge to the customer. Units and parts should be returned at the customer’s expense to
the nearest Authorized Service Centre. Include original purchase receipt with and claim, making sure to keep a copy
for your les. Be sure to pack the unit in a strong carton and pad tightly to avoid damage. Damage in transit is NOT
covered by warranty.
Warranty is void if any devices or accessories other than those distributed or recommended by Kodiak are attached to
or connected with the equipment in such a manner that the original factory construction is altered.
Warranty is void if repairs are attempted by anyone other than an Authorized Service Centre. In the event that a
difculty develops with the product, you should contact the nearest Authorized Service Centre. Only these locations are
authorized to make repairs to the product or affect the replacement of defective parts, which will be done at no charge
within a reasonable amount of time after receipt of the product.
This warranty shall not apply to any problem which is due to misuse, neglect, accident, abuse, improper handling,
freezing, normal wear and tear, use of improper detergents/ chemicals, or non-compliance with precautions and
instructions contained in the Owner’s Manual. This warranty is non-transferable.
The liability of John Brooks Company Limited is limited to repair of the product and/or replacement of parts, and
is given to the purchaser in lieu of all other remedies including incidental and consequential charges. There are no
expressed warranties other than those specied herein.
PUMP WARRANTY - 5 YEARS
ELECTRIC MOTOR WARRANTIES
TECHTOP - Techtop electric motors are covered by the manufacturer by a period of 18 months. If you experience any
problems with your Techtop electric motor, please contact the manufacturer, www.techtopcanada.com.
BALDOR - Baldor electric motors are covered by the manufacturer by a period of one year. If you experience any
problems with your Baldor electric motor, please call the manufacturer, www.baldor.com.
CUSTOMER SERVICE HOTLINE:
1-888-881-6667
Visit our website:
www.dynablast.ca
