Kodiak Swag User manual

1
Swag Tent and
Sleeping Pad
Owner’s Manual
For Model 8101
Important! For safe and proper assembly, use, and care read and follow all
instructions. Everyone who uses this tent should first read this manual.
1015

2
No Fire
This tent is flammable. Keep all flame and heat sources away from the tent fabric.
Never place a stove, campfire, or any other flame source in or near your tent. Never
use, light, or refuel a stove, lantern, heater, or any other heat source inside your tent.
Death by carbon monoxide poisoning and/or serious burns are possible.
Ventilation
Maintain adequate ventilation inside your tent at all times. Death by suffocation is
possible.
Anchor
This tent is not free-standing. If not properly anchored it will collapse. Anchor your tent
properly at all times to reduce the risk of loss or injury to the tent or occupants.
Campsite Choice
Carefully consider the possibility of falling rocks or tree limbs, lightning strikes, flash
floods, avalanches, strong winds, and other objective hazards when choosing a
campsite to reduce the risk of loss or injury to the tent or occupants.
Children
Do not leave children unattended inside a tent or camp. Do not allow children to
assemble or disassemble the tent. Do not allow children to remain closed-up in a tent
on hot days. Failure to follow these warnings may result in injury and/or death.
Kodiak Canvas
Limited Lifetime Warranty
This product is warranted, to the original purchaser, to be free of defects in materials and workmanship for
as long as you own the product. This product is made with quality materials and expert workmanship, but is not
indestructible. This warranty does not cover damage attributed to or resulting from normal wear and tear (e.g.
exhausted zippers), natural hazards (e.g. weather, animals), abuse (e.g. mold, mildew, burns, ultraviolet), or
alterations or modifications of any kind. If your product is found defective, we will repair or replace it free of charge.
Charges for shipping your product to Kodiak Canvas will be your responsibility. We reserve the right to make
substitutions if parts are unavailable or obsolete. If your product needs repair beyond what is covered under warranty,
we will provide parts and service at a reasonable charge.
This warranty gives you, the original purchaser, specific legal rights. You may also have other rights which
vary from state to state. Do not return your product until you have received authorization and instruction to
do so.

3
Component Checklist
● Identify all components and make sure they are in good condition and working order.
Qty
Item
1
Tent Body
1
Foam Mattress Pad w/ fabric cover
1
Large Support Pole (A)
1
Medium Support Pole (B)
1
Small Support Pole (C)
7
Tent Stakes (D)
1
Zippered Storage Bag
1
Doormat
3
Guy Ropes (E)

4
Before You Set Out
● It is recommended that you assemble this tent at home at least once before your trip to familiarize
yourself with the process, and make sure your tent is in good order.
● After initial set-up it is recommended that you spray the tent lightly with water and allow it to dry
completely.Thisseasonsthecanvas.Thewatercausesthecanvas toshrink slightly,closingneedle
holes where the canvas was stitched. This process is onlyrequired once. Before you do this, first
remove the mattress pad.
Waterproofing
Kodiak Canvas tents are made with Hydra-Shied™canvas that features superb water repellency.
However, not all tents are completely waterproof out of the box. On occasion a new tent will experience
some leaking. Over the life of the tent, occasional, waterproofing maintenance will be required. If leaking
occurs, it is an easy fix. Treat the affected area with a SILICONE based waterproofing such as Kiwi Camp
Dry®. This should absolutely take care of any leaks, and you should seldom have to re-treat. Caution: Do
not use other types of waterproofing such as Canvak® on this Hydra-Shield™ canvas, as it could affect
the breathability of the canvas. When properly sealed, your expectation should be that a Kodiak Canvas
tent will be completely dry inside, even during drenching rains.
Assembly
Caution: The use of protective eyewear is recommended during assembly.
STEP 1: Stake the Tent
Stake each of the tent’s four corners, making sure that the tent is taut and square.
Tips:
 Drive in stakes with the tip angling toward the tent. Secure hooks on the end of the stakes over the
corner rings.
STEP 2: Assemble the Frame
1) Join the Aluminum support poles. The large pole is for the head of the tent. The medium pole is for the
middle. The small support pole is for the foot of the tent.
2) Pass the small support pole through the sleeve at the foot of the tent. Insert the ends of the pole into the
lock pins on each of the corners. Clip the black plastic hooks onto the pole.

5
3) Repeat 2 above with the large support pole at the head of the tent.
4) The middle support pole is secured on the inside. Locate the lock pins on the inside middle of the tent
on the floor. Caution: Grasp pole firmly as it is placed under tension. It could spring loose.
Insert the ends of the middle support poles into the lock pins. Use the Velcro-like tabs on the lower
sides of the tent, and also on the screen mesh cover, to secure the middle support pole into place.
5) Securely tie a guy rope to the grommets at the head and foot of the tent. Stake out these guy ropes and
adjust until taut. Do not over tighten or this could make it difficult to open and close zippers.
6) Optional: The third guy rope can be used to hold a side of the top cover out for added air flow. To do
this tie the guy rope to the small loop in the corner (see image above).
7) The doormat is handy to step onto, or sit on while taking off your shoes. If rain is expected tuck your
shoes underneath to keep them dry. Attach it by inserting the T-buttons on the mat into the small loops
on the side of the tent.
Special Features
● Small storage pocket at the head corner. Great place to keep keys or small flashlight.
● Zippered windows at head and foot. Use to regulate airflow.
● Removable mattress pad cover. Can be removed to hand wash and hang dry.

6
Taking Down and Storing the Tent
STEP 1: Clean and Dry
1) Sweep out any dirt.
2) Empty all storage pockets.
3) Allow tent and mattress pad to dry completely! Remove the mattress pad. Zip open and allow tent to air
out and dry inside and out. Replace the mattress pad when completely dry.
STEP 2: Collapse Tent
1) Remove the tent stakes by pulling the stakes, not the tent. Pulling the tent could cause damage to your
tent.
2) Remove all poles and collapse tent. Caution: Grasp poles firmly they are under tension and could
spring loose. Insert the poles in the storage sleeve at the inside head of the tent.
CAUTION
VERY IMPORTANT—Your tent must be completely dry, inside and out, before
storage! Your tent maybe damp from condensation even if there has been no
rain. Storing a wet or damp tent, even for a short time, can ruin it and void the
warranty. This causes mold that will cause a bad odor, stain and deteriorate
the canvas and its water repellency.
If you must take the tent down while still wet or damp, loosely roll it for
transport. After transport, immediately unroll and set up or hang out to dry
thoroughly before long-term storage.

7
3) Roll the tent from head to foot. Use the cinch straps at the foot to secure the rolled swag. Tip: No need
to remove your blanket or sleeping bag. Just roll it up inside the swag. The straps are oversized for this
purpose. For long term storage, don’t leave the cinch straps too tight or you may get some permanent
compression on the mattress pad.
Tip for zippered storage bag: Rather than lifting the rolled tent into the storage bag, place the storage
bag over the rolled tent, and then flip it over so zipper is upright, then zip.
Care
● VERY IMPORTANT—Your tent must be completely dry before storage! STORING A WET OR DAMP
TENT, EVEN FOR A SHORT TIME, CAN RUIN IT AND WILL VOID THEWARRANTY.
● To clean tent, hose down with water and wipe with a cloth. Soaps and detergents can damage the
water-repellant treatment of the canvas.
● Do not spray insecticides or bug repellant directly on the canvas. This may damage the water-repellant
treatment.
● For long-term storage, store in a cool dry location that is not exposed to direct sunlight.
● This tentis equipped with quality zippers. Toprolong zipper life,do not grind the zippers around
corners. If needed pull the canvas, windows or doors to help zippers glide smoothly. Keep them clean
from dirt.
● The canvas on your tent has a special Hydra-Shield™ treatment that is watertight yet breathable. You
should rarely, if ever have to retreat the canvas. If you do need to spot treat the canvas for water
repellency, use a silicone based repellent such as Kiwi Camp Dry®. Other treatments will clog the tiny
holes in the canvas eliminating its breathability.
● Forextended usesituations (more thanthreeconsecutiveweeks)seeExtendedUseCare
instructions at www.KodiakCanvas.com.
Other Notes
● Condensation inside the tent is affected by the difference between inside and outside temperatures,
and humidity. Condensation can be reduced by venting your tent. Condensation between the floor and a
sleeping mat can be reduced byplacing a ground cloth underneath the tent.
● Some slight irregularities are normal with 100% cotton canvas and will not affect the performance of
your tent.

8
● Use your Kodiak Canvas Swag tent on the ground, in the bed of a pickup, or on a compatible
85x40 inch cot. When using with a cot, secure the corners of the tent to the cot with tie cord, or
Velcro straps (sold separately).
Weappreciate your business. Thank you for purchasing a Kodiak Canvas™ tent. We put our pride into
the design and manufacturing of this product. It is the best of its kind available. We wish you safe and
happy camping. Please tell your friends about us.
Find info, accessories, replacement parts and
other products at: www.KodiakCanvas.com
© Kodiak Canvas. Layton, UT USA Made in China
