Kogan KALED423DSMTZA User manual

.$/(''607=$
USER MANUAL

SMART TV Application Features
1- Android 4.2 dual-core smart TV 5- MHL
2- Network Connection( ired/ ireless/PPPOE/ LAN) 6- Application Installation
3- DLNA 7- Google Play Store
4- Home Share 8- USB 3.0
1. Android 4.2 Dual Core Smart TV
Equipped with a dual-core processor, the latest CPU (1.2G) and a Mali400
Quad Core GPU, this Smart TV contains a robust system configuration
designed to run the newest software applications.
You can enjoy your favourite applications, downloads, internet content and
human-computer interaction (such as Surfing the eb, SNS Social Network,
Online Video Playback, Online Video Chat and creating a home
entertainment centre between the TV and your portable devices.)
This TV also has wireless Mouse and wireless Keyboard support when you
plug the receiver into the USB port on the TV.

SMART TV Android 4.2 Launcher Introduction
1 Add to home screen. (Add apps to the home page)
2 All Apps
3 Change Wallpaper
4 Search
5 Settings
6 Mass Storage (USB/SD/TF)
7 Network (Wireless/WLAN)
8 Source Window (TV/DTV/ATV/AV/HDMI/YPbPr/VGA)
9 Application at home page.
10 Search
11 HOME page
12/13/14 Other pages

2. NETWORK CONNECTION (Wired/Wireless/PPPOE/WLAN HP)
The instant network page gives you quick and easy access to information via
the internet.
CABLE NETWORK
WIRELESS NETWORK

PPPOE
PPPOE is point-to-point protocol over ethernet. For detailed operations
please contact your Internet Service Provider.
WLAN HP (Hotspot)

3. DLNA
DLNA is the Digital Living Network Alliance, which lets you enjoy your music,
photos and videos anywhere, anytime.
Note: 1 Make sure your devices (PC, Smartphone, iPad etc..) have a
DLNA compatible program installed.
2 Ensure your devices and the TV is in the same local area
network.
3 Share the video/music/picture on your devices via DLNA.
OPERATION

4. HOME SHARE
Easily browse the internet or receive data from your home smart devices.
Your PC, NAS, Router with USB together with your TV creates a whole new
home entertainment centre.
To enjoy Home Share, you need to access the internet first. Please refer to
wireless connection information to connect to your network.
Operation
5. MHL
MHL is Mobile High-Definition Link. It utilizes established connectors and
features a single cable with a 5-pin interface. It supports 1080p HD video and
digital audio, and simultaneously provides power to the mobile device. It
also enables the TV remote control to control the mobile phone and access
its contents.
NOTE: MHL cable and a portable device that supports MHL is required
for this function. MHL is only available for HDMI1 mode.
Operation

6. APPLICATIONS INSTALLATION
Note: You can download applications from the Google Play Store or
from other online stores directly if your TV has these stores installed, or
you can install applications from USB/SD/TF which contains the
suitable .apk software.
For USB/SD/TF installation:
7. GOOGLE PLAY STORE
The Google Play Store is an online store for Google by Android devices. You
can select your favourite from 450,000+ apps, millions of songs and books,
plus thousands of movies.
Note: Some applications you can download from the Google Play Store
may not be compatible with this TV. Please check that the application is
compatible with the TV. We suggest that you are best to install
applications from the local app store.
8. USB 3.0
The newly upgraded USB 3.0 brings ultra-high bandwidth and high-speed
transmission of data. The USB3 interface on the TV is for USB 3.0 usage.

The screen and cabinet get warm when the TV
is in use. This is not a malfunction.In case of
smoke, strange noise or strange smell from the
unit:
· Turn off the power switch immediately;
· Disconnect the power plug from the power
outlet;
· Contact your dealer or service centre. Never attempt to make repairs
yourself because this could be dangerous.
High Voltage
Do not open
Risk of electronic shock, do not open.
Do not attempt to service this product yourself
as opening or removing covers may expose
you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
CAUTION
Important Safety Instructions
Important Safety Instructions and Maintenance
Never push objects of any kind into the set
through the cabinet slots as they may touch
dangerous voltage points or short-circuit parts that
could result in a fire or electric shock. Never spill
liquid of any kind on the set. Use special caution
in households where children are present. The apparatus is not suitable for children
under 3-year to operate.
To reduce the risk of fire or electric shock, do not
expose this product to rain or moisture.
The apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
1
If the following problems occur:
Turn off the TV set and unplug the AC power cord
immediately if any of the following problems occur.
Ask your dealer or service centre to have it checked
by qualified service personnel
When:
- AC power cord is damaged.
- Poor fitting of AC power outlet.
- TV set is damaged by being dropped, hit or having something thrown at it.
- Any liquid or solid object falls through openings in the cabinet.
Do not overload wall outlets, extension cords or
adaptors beyond their capacity, this can result in
fire or electrical shock.
Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords at plug end, adaptors
and the point where they exit from the appliance. The mains plug is used as the
disconnect device. It shall remain readily accessible and should not be obstructed
during intended use. Make sure to plug the power cord in until it is firmly inserted.
When removing the power cord, make sure to hold the power plug when pulling the
plug from the outlet, do not pull the plug out by the wire. NEVER touch the plug or
power cord with wet hands. To disconnect the apparatus from the mains power, the
plug must be pulled out from the mains socket, therefore make sure the mains plug
is always easily accessible.

Important Safety Instructions and Maintenance
Important Safety Instructions
When not in use
If you will not be using the TV set for several days, the
TV set should be disconnected from the AC mains for
environmental and safety reasons. As the TV set is not
disconnected from the AC power when the TV is turned
off at the standby switch, pull the plug from the AC power
outlet to disconnect the TV completely. However, some
TV sets may have features that require the TV set to be
left in standby to function correctly. In the case of lightning,
unplug the TV set from the outlet immediately. Never
touch the antenna wire during lightning.
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact
with them might be fatal.Ensuring the television is not
overhanging the edge of the supporting furniture.
Installation
The ventilation should not be impeded by covering the
ventilation opening with items, such as newspapers,
tablecloths, curtains, etc.
At least 10 cm space should be left around the
apparatus for sufficient ventilation.
The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
Place the apparatus in such a position that the screen
is not exposed to direct sunlight. It is best to have soft
indirect lighting while watching and avoid
and reflection from the screen as
these may cause eye fatigue.
Keep the TV set away from any equipment emitting
electromagnetic radiation.
completely
dark environments
Do not pull the plug out by the wire;
Never touch the plug with wet hands.
Excessive from earphones and headphones
can cause hearing loss.
volume
2
To avoid the fire, no naked flame source,
such as lighted candles, should be placed on the
apparatus.
Do not push or scratch the front filter, or place any objects on top of the TV set. The
image may be uneven or the screen may be damaged.

Important Safety Instructions and Maintenance
Installation
Do not place this apparatus near water, for example,
near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or a swimming pool; and
the like;
When the TV being moved in from cold place, it needs
some right time for dew inside unit evaporating fully
before turn on the unit;
Cleaning and handling the screen
surface and cabinet. Disconnect
the unit from the AC outlet before
cleaning. To remove dust, wipe
gently with a soft, lint free cloth. If
required use a slightly damp cloth.
Do not place the set on an unstable cart, stand, table
or shelf. The set may fall, causing serious personal
injury as well as damage to the product. Use only with
the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. An
appliance and cart combination should be moved with
care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.
To prevent injury, this apparatus must be securely
attached to the floor/wall in accordance with the
installation instructions.
3
Cleaning
Move
LED Screen
Although the LED screen is made with high precision technology and 99.99% or
more of the pixels are effective, black dots may appear or bright points of light (red,
blue or green) may appear constantly on the LED screen. This is a structural property
of the LED screen and is not a malfunction.
If the surface of the LED panel cracks, do not touch it until you have unplugged the
AC power cord. Otherwise electric shock may result.
Do not throw anything at the TV set. The LED panel may break from the impact and
cause serious injury.
Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen.
Do not display still images and partially still images on the LED panel for more
than 2 hours as it can cause screen image retention. This image retention is
also known as "screen burn". To avoid such image retention, reduce the
degree of brightness and contrast of the screen when displaying a still image.
Watching the LED TV in 4:3 format for a long period of time may leave traces
of borders displayed on the left, right and centre of the screen caused by the
difference of light emission on the screen. Playing a DVD or a game console
may cause a similar effect to the screen. Damages caused by the above effect
are not covered by the Warranty.
Displaying still images from Video games and PC for longer than a certain
period of time may produce partial after-images. To prevent this effect, reduce
the 'brightness' and 'contrast' when displaying still images.
MAINS PLUG
Wipe the mains plug with
a dry cloth at regular
intervals. Moisture and
dust may lead to fire or
electrical shock.
Use care not to subject the TV's surfaces to detergent.
(A liquid inside the TV could lead to product failure, fire or
electrical shock.)
Use care not to subject surfaces to bug repellent, solvent,
thinner, or other volatile substances as this may deteriorate the
surface and finish of the cabinet.
solvent thinner

Table of Contents
Important Information
4
Accessories-----------------------------------------------------------------------------------------------5
Introduction-----------------------------------------------------------------------------------------------6
Features---------------------------------------------------------------------------------------------------------6
Specifications--------------------------------------------------------------------------------------------------7
Stand and wall-mounting instructions (optional)------------------------------------------------8
--------------------------------------------------------------------------------10
Overview of back panel------------------------------------------------------------------------------------10
Overview of front panel-------------------------------------------------------------------------------------11
Overview of remote control-------------------------------------------------------------------------------12
Teletext --------------------------------------------------------------------------------------------------------14
Installing Batteries in the Remote Control------------------------------------------------------------16
External Connection------------------------------------------------------------------------------16
Antenna connection----------------------------------------------------------------------------------------16
Connecting VCR -------------------------------------------------------------------------------------------17
Connecting a Camcorder---------------------------------------------------------------------------------18
Connecting a DVD Player/Set-Top Box via DVI ----------------------------------------------------19
Connecting DVD Player/Set-Top Box via HDMI ----------------------------------------------------20
Connecting Digital Audio System-----------------------------------------------------------------------21
Connecting PC ---------------------------------------------------------------------------------------------22
Supporting signals ---------------------------------------------------------------------------------------22
Basic operation---------------------------------------------------------------------------------------23
Turning the TV on and off---------------------------------------------------------------------------------23
The main interface------------------------------------------------------------------------------------------24
Applications of the TV--------------------------------------------------------------------------------------25
Menu system instruction-----------------------------------------------------------------------26
TV menu-------------------------------------------------------------------------------------------------------26
Sound----------------------------------------------------------------------------------------------------------26
Image-----------------------------------------------------------------------------------------------------------28
Program-------------------------------------------------------------------------------------------------------29
Input Source--------------------------------------------------------------------------------------------------31
3D---------------------------------------------------------------------------------------------------------------31
General Description
Function-------------------------------------------------------------------------------------------------------32
Time------------------------------------------------------------------------------------------------------------34
PVR-------------------------------------------------------------------------------------------------------------35
Digital Media Player --------------------------------------------------------------------------------------38
Troubleshooting -------------------------------------------------------------------------------------------41
Picture defects and the reason------------------------------------------------------------------------43
Keep small accessories out of reach of children so they are not mistakenly swallowed.

Please make sure the following items are included with your LED TV. If any items are
missing, contact your dealer.
Accessories
5
Remote Control
HOME
Note: Detail operation please refer to HELP menu on the TV.

Features
Introduction
Input terminals used for external equipment connection
1 x CVBS output
1 x ANTENNA jack 4 x HDMI inputs
1 x computer PC-RGB input 3 x USB inputs
1 x COMPONENT input
1 x AV input 1 x SPDIF output
1 x Headphone output
l TV adopts 42” TFT display screen
l Zero X radiation complies to green environment protection requirement
l Connect to computer directly to realize TV/monitor combo.
l MHL2.0
l Android4.2
l USB3.0
l 16:9 wide screen
l Auto tuning and fine tuning
l HDMI input
l Component Compatible (480i; 480P; 576i; 576P; 720P; 1080i; 1080P)
l PC VGA
l Programmable sleep timer
l Wide range voltage input
l No-signal automatic power off
LED
6

Note:
- Design and specifications are subject to change without notice.
- Weight and Dimension shown are approximate.
o
- It is suggested to watch 3D program under the operation temperature above 10 C to
obtain the best 3D effect.
Introduction
Specifications
7
Analog: Antenna:
46.25MHz-855.25MHz
Digital:5-12, 21-69
PAL / NTSC / SECAM
³5 X2W
90W
o o
0 C-40 C
<1W
~110-240V, 50/60Hz
75 ohms, unbalanced
42” Diagonal (max.)
Display size
LED panel resolution
Power supply
TV receive system
Frequency range
Video in
Antenna Input
Speaker output power
Power consumption
Standby consumption
Work Temperature
Model
Controller power DC 3V
(Two AAA size batteries)
1920X1080
958X52X566mm
16Kg
958X250X623mm
KALED423DSMTZA
Digital: DVB-T
Analog: PAL: BG, I, DK,
SECAM: BG, D/K
14Kg

99
Stand and wall-mounting instructions (optional)
Mounting instruction:
Your LED TV is able to wall mounting with the use of a wall mounting bracket(not supplied with LED
TV), and the mounting holes on the back of the unit. After detaching the stand:
1.Find the four mounting holes where you want to mount according to wall mounting bracket ③
and drill these four mounting holes on the wall.
2.Drive Nylon sleeves ② into the mounting holes on the wall tightly.
3.Fasten wall mounting bracket ③ on the Nylon sleeves with self-tapping screws ④;
4.Fasten screws ⑤ into the two screw holes on the rear cabinet;
5.Tighten bolt ⑦ on the bottom of the rear cabinet with screws ⑨,then put rubber gaskets ⑧ on
the bolt ⑦;
6.Left the TV and hang it on the wall.
400mm
400mm
①.Wall ②.Nylon sleeve (4 piece) ③.Wall mounting bracket(1 piece)
④.Self-tapping screw(4 piece) ⑤.Mounting Screw (2 piece) ⑥.Rear cabinet ⑦.Bolt
⑧.Rubber gaskets (2 piece) ⑨.Screw (2 piece)
(optional)
Your LED TV is able to accommodate wall mounting with the use of a wall mount bracket
(not supplied with LED TV, please contact your local hardware store) and the mounting
holes on the back of the unit. We recommend removing the TV stand prior to wall mounting
the TV. Please
Wall mounting instructions
see previous page for instructions on removing the stand.

General Description
10
Overview of back panel
You can connect the TV with video devices such as DVD/VCD player, VCR and video camera
to enjoy the high quality picture.
SPDIF
Headphone
Microphone
Video output
SD card
USB 3
USB 2
USB 1
USB 1
USB 2
USB 3
(USB 3.0)
SPDIF
Pr
Pb
Y/V
L
R
MIC
VIDEO
COMPONENT/AV IN
VGA AUDIO ANT
HDMI4 HDMI3 HDMI2 HDMI1(MHL)
PC
Camcorder
DVD player
PC (HDMI-output)
Blu-ray disc player
DVD player

General Description
Overview of front panel
11
The buttons on the lower-left panel control your TV’s basic features, including the on-screen
menu. To use the more advanced features, you must use the remote control.
INPUT
MENU
PROG
VOL
1
2
3
4
5
VOLv/w Press to increase or decrease the volume.
6
7 Press button to toggle between normal and standby mode.
Standby button
Remote Control
Sensor
Power Indicator Green: In power on mode.
Red: In standby mode.
Power Switch
Press this button to turn TV on or off.
Aim the remote control towards this spot on the TV.
INPUT Toggles between all the available input sources.
MENU Press to display an on-screen menu of your TV's features.
PROGr/s Press to change programs.

12
Overview of Remote Control
General Description
1. INPUT: This button is used to switch among
different sources: DTV,ATV, AV,YPbPr,VGA, HDMI1,
HDMI2, HDMI3, HDMI4.
Select a source and press OK button to confirm.
2. POWER: Press this button to switch to standby
mode, and press it again to turn TV on.
3. Digital buttons(0~9): To select channel with
digital buttons.
4. INFO: This button is used to start the "Current
Service Banner" application that provides
information about the current service.
5. RECALL: Switch to the previous program.
6. FREEZE: Press this button to freeze the image.
7.
8. SLEEP: TV will be switched off automatically at
preset sleep time if you have set sleep timer. Use
your remote control to set the sleep timer.
Press SLEEP button on the remote control, then
press this button again to set sleep time: off, 10,
20,30, 60,90,120,180, 240 min. Press MENU
button to exit when you have set the sleep timer.
After you have set sleep timer, press SLEEP button
again, you will see the Remaining time.
Notes: The sleep timer you have set will be
cancelled when the TV turns off or if a power
failure occurs.
9. CH.LIST: Press it to show channel list on screen.
10. FAV: Press it to display favorite list.
11.
12.
GUIDE: In DTV source, this button is used to
start the EPG application.
14.
DTV: Switch to DTV mode.
16. 3D/2D: Press this button to display the “3D setting”.
MENU: Press this button to display main menu or
exit the menu. When you are in the submenu, you
can press it to return the main menu.
Arrow buttons: Press these buttons to move
cursor up/down/left/right for menu.
OK/REC LIST: Press this button to display a list
of recorded programs. In main menu and submenu,
it is a validation button.
13.
Exit: Exit the menu.
15.
Note:It is suggested to watch 3D program under
the operation temperature above 10 C to
obtain the best 3D effect.
HOME
