Roughing-In Guide
Guide de raccordement
Diagrama de instalación
Enameled Cast Iron Bath
Baignoire en fonte émaillée
Bañera de hierro fundido esmaltado
K-721, K-722
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de M
corresponden a México (Ej. K-12345M)
1084144-1-A
Information/Information/Información
Applicable product:/Produit applicable:/Producto correspondiente:
Left drain/Drain gauche/Desagüe a la izquierda K-721
Right drain/Drain droit/Desagüe a la derecha K-722
Fixture*:/Appareil sanitaire*:/Producto*:
Bathing well:/Bassin de la baignoire:/Área de la bañera:
Basin area, bottom/Espace du bassin, base/Área del fondo 45″(114.3 cm) x
23″(58.4 cm)
Basin area, top/Espace du bassin, dessus/Área superior 54″(137.2 cm) x
25″(63.5 cm)
Weight/Poids/Peso 350 lbs (158.7 kg)
To overflow/Au trop plein/Al rebosadero
Water depth/Profondeur d’eau/Profundidad del agua 11-5/8″(29.5 cm)
Capacity/Capacité/Capacidad 52 gal (196.8 L)
* Approximate measurements for comparison only./* Mesures approximatives pour
comparaison uniquement./* Dimensiones aproximadas sólo para fines de comparación.
60" (152.4 cm)
2-7/8" (7.3 cm)
3" (7.6 cm)
33-3/4"
(85.7 cm)
1-13/16"
(4.6 cm)
1/8"
(3 mm)
16"
(40.6 cm)
32"
(81.3 cm)
1-1/2"
(3.8 cm)
3-1/4"
(8.3 cm)
17-7/16"
(44.3 cm)
8-1/2"
(21.6 cm)
No change in measurements if connected
with drain illustrated. (K-7147-AF)
Aucun changement des mesures n'est
nécessaire si connecté au drain illustré.
(K-7147-AF)
No es necesario cambiar las medidas si
se conecta con el desagüe ilustrado.
(K-7147-AF)
1-1/2" OD
Ø Ext. 1-1/2"
1-1/2" D.E.
1084144-1-A 2 Kohler Co.
Notes
Install this product according to the installation guide.
Floor support under bath must provide for minimum of 58 lbs/square foot (281
kg/square meter) loading.
Fixture conforms to ANSI Standard A112.19.1. All dimensions are nominal.
Remarques
Installer ce produit selon le guide d’installation.
Le support de plancher sous la baignoire doit pouvoir soutenir une charge minimale de
58 lbs/pied carré (281 kg/m2).
L’appareil sanitaire est conforme à la norme Standard ANSI A112.19.1. Toutes les
dimensions sont nominales.
Notas
Instale este producto conforme a la guía de instalación.
El soporte del piso debajo de la bañera debe poder soportar una carga mínima de 58
lbs/pie cuadrado (281 kg/metro cuadrado).
El producto cumple con la norma A112.19.1 del ANSI. Todas las dimensiones son
nominales.
Kohler Co. 3 1084144-1-A
USA: 1-800-4-KOHLER
Canada: 1-800-964-5590
México: 001-877-680-1310
kohler.com
©2007 Kohler Co.
1084144-1-A
