Kohler Hourglass 30 K-1201 User manual


System 1 Bath Whirlpools:
K-1201 Hourglass 30
K-1206 K-1206-L
K-1206-R Hourglass 32
K-1211 Cocoon 5’
K-1216 Cocoon 6’
K-1221 Seadream
113867-2-EA (-) Copyright 1998 Kohler Co.

Kohler Co., Kohler WI
113867-2-EA (-) 2
IMPORTANT SAFETY INSTRUCTIONS
ATTENTION INSTALLER: INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: When using this unit, always follow basic precautions, including the following:
WARNING: RISK OF ELECTRICAL SHOCK.
The unit must be connected only to a circuit
that is protected by a Ground-Fault
Circuit-Interrupter (GFCI). Such a GFCI should
be provided by the installer and should be tested
on a routine basis. To test the GFCI, press the test
button. The GFCI should interrupt power. Press
the reset button. Power should be restored. If the
GFCI fails to operate in this manner, there is a
ground current flowing or the GFCI is defective.
The possibility of an electric shock may exist.
DO NOT use this unit. Disconnect the unit and
havetheproblemcorrectedby aqualifiedlicensed
electrician.
Grounding is required. The unit should be installed
and grounded by a qualified service representative.
A pressure wire connector is provided on the pump to
permit connection of a solid copper bonding conductor
between this unit and all other electrical equipment and
exposed metal in the vicinity, as needed to comply with
local requirements.
DANGER: RISK OF INJURY.
Hotwhirlpoolbathscanputcertainstressesonthebody,
as do any hot bath, shower, sauna, or steam bath.
Prolonged immersions in hot water may induce
hyperthermia. Hyperthermia occurs when the internal
temperatureofthebodyreachesalevelseveraldegrees
above the normal body temperature of 98.6°F. The
symptoms of hyperthermia include an increase in the
internal body temperature, dizziness, lethargy,
drowsiness, and fainting. The effects of hyperthermia
include: (1) failure to perceive heat, (2) failure to
recognize the need to exit the bath, (3) unawareness of
impendinghazard,(4)fetal damageinpregnantwomen,
(5) physical inability to exit the bath, and (6)
unconsciousness resulting in the danger of drowning.
Warning: Theuseofalcohol,drugs,orothermedication
can greatly increase the risk of fatal hyperthermia.
DO NOT operate this unit without the guard on the
suction fitting.
Never drop or insert any object into any opening.
Use this unit only for its intended use as denoted in this
manual. DO NOT use attachments not recommended
by the Kohler Co.
Install to permit access for servicing.
DANGER: RISK OF INJURY. To reduce the risk
of injury, do not permit children to use this unit
unless they are closely supervised at all times.

3113867-2-EA (-)
Kohler Co., Kohler WI
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 2. . . . . . . .
INTRODUCTION 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ROUGHING-IN: K-1201 4. . . . . . . . . . . . . . . . . . . . . . .
Ordering Information 4. . . . . . . . . . . . . . . . . . . . . . .
Required Electrical Service 4. . . . . . . . . . . . . . . . . .
Product Information 4. . . . . . . . . . . . . . . . . . . . . . . .
Installation Notes 4. . . . . . . . . . . . . . . . . . . . . . . . . .
ROUGHING-IN: K-1206, K-1206-L, K-1206-R 5. . .
Ordering Information 5. . . . . . . . . . . . . . . . . . . . . . .
Required Electrical Service 5. . . . . . . . . . . . . . . . . .
Product Information 5. . . . . . . . . . . . . . . . . . . . . . . .
Installation Notes 5. . . . . . . . . . . . . . . . . . . . . . . . . .
ROUGHING-IN: K-1211 6. . . . . . . . . . . . . . . . . . . . . . .
Ordering Information 6. . . . . . . . . . . . . . . . . . . . . . .
Required Electrical Service 6. . . . . . . . . . . . . . . . . .
Product Information 6. . . . . . . . . . . . . . . . . . . . . . . .
Installation Notes 6. . . . . . . . . . . . . . . . . . . . . . . . . .
ROUGHING-IN: K-1216 7. . . . . . . . . . . . . . . . . . . . . . .
Ordering Information 7. . . . . . . . . . . . . . . . . . . . . . .
Required Electrical Service 7. . . . . . . . . . . . . . . . . .
Product Information 7. . . . . . . . . . . . . . . . . . . . . . . .
Installation Notes 7. . . . . . . . . . . . . . . . . . . . . . . . . .
ROUGHING-IN: K-1221 8. . . . . . . . . . . . . . . . . . . . . . .
Ordering Information 8. . . . . . . . . . . . . . . . . . . . . . .
Required Electrical Service 8. . . . . . . . . . . . . . . . . .
Product Information 8. . . . . . . . . . . . . . . . . . . . . . . .
Installation Notes 8. . . . . . . . . . . . . . . . . . . . . . . . . .
PRODUCT NOTICES 9. . . . . . . . . . . . . . . . . . . . . . . . .
Installer Hazard Notification 9. . . . . . . . . . . . . . . . .
Factory-Assembled Features 9. . . . . . . . . . . . . . . .
PRODUCT REQUIREMENTS 9. . . . . . . . . . . . . . . . .
Summary of Key Requirements 9. . . . . . . . . . . . . .
Plumbing Specifications 9. . . . . . . . . . . . . . . . . . . . .
Product Inspection 9. . . . . . . . . . . . . . . . . . . . . . . . .
Connections and Service Access 9. . . . . . . . . . . . .
Electrical Requirements 9. . . . . . . . . . . . . . . . . . . . .
INSTALLATION REQUIREMENTS 10. . . . . . . . . . . . .
Tools Required 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Materials Required 10. . . . . . . . . . . . . . . . . . . . . . . . .
Clearance Requirements 10. . . . . . . . . . . . . . . . . . . .
New Or Replacement Installation Requirements 10
SITE REQUIREMENTS 11. . . . . . . . . . . . . . . . . . . . . . .
Old Bath Removal 11. . . . . . . . . . . . . . . . . . . . . . . . . .
Subfloor Preparation 11. . . . . . . . . . . . . . . . . . . . . . . .
Stud Pocket Preparation 11. . . . . . . . . . . . . . . . . . . .
Plumbing Preparation 12. . . . . . . . . . . . . . . . . . . . . . .
BEFORE INSTALLING UNIT 13. . . . . . . . . . . . . . . . . .
Tiling-In Bead Installation 13. . . . . . . . . . . . . . . . . . . .
Partially Install Bath Drain 13. . . . . . . . . . . . . . . . . . .
Protect Whirlpool Unit 13. . . . . . . . . . . . . . . . . . . . . .
INSTALL WHIRLPOOL 14. . . . . . . . . . . . . . . . . . . . . . .
Whirlpool Set-In 14. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Integral Flange Models 15. . . . . . . . . . . . . . . . . . . . . .
Pump Banding Strap Cut 15. . . . . . . . . . . . . . . . . . . .
Install Plumbing 16. . . . . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRICAL CONNECTIONS 16. . . . . . . . . . . . . . . .
Identify Electrical Requirements 16. . . . . . . . . . . . . .
Wiring Information – 120 V, 60 Hz 16. . . . . . . . . . . .
WATER TEST WHIRLPOOL & ELECTRONICS 17. .
COMPLETE FINISH WALL 17. . . . . . . . . . . . . . . . . . . .
Drop-In Models 17. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Integral Flange Models 18. . . . . . . . . . . . . . . . . . . . . .
COMPLETE INSTALLATION 18. . . . . . . . . . . . . . . . . .
Install Handles and Spouts 18. . . . . . . . . . . . . . . . . .
CLEAN-UP AFTER INSTALLATION 18. . . . . . . . . . . .
CONFIRM PROPER OPERATION 18. . . . . . . . . . . . .
Start-Up Whirlpool 18. . . . . . . . . . . . . . . . . . . . . . . . .
Operating Sequence 19. . . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING PROCEDURES 19. . . . . . . . .
Flexjet Installation 19. . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshoot Whirlpool System 20. . . . . . . . . . . . . .
INTRODUCTION
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and
installation sequences. Follow the sections that pertain
to your particular installation. This will help you avoid
costlymistakes.Inadditiontoproperinstallation,readall
operating and safety instructions.
The variety of installations possible with this bath may
require framing procedures other than those described
in this manual.
All information in this manual is based upon the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in
product characteristics, packaging, or availability at any
time without notice.
Identify and record the model and serial numbers below (found at the pump end of the bath):
Model No. Serial No. Date of Manufacture

15”
1-1/2”
8-1/2” 60”
PUMP/CONTROL ACCESS
30”
2-7/8”
3” 1-1/2” O.D.
17”
3/16”
1-1/2”
2-3/4”
15-1/2”
4
113867-2-EA (-) Kohler Co., Kohler WI
1. ROUGHING-IN: K-1201, HOURGLASS 30
A. ORDERING INFORMATION
Accessories/hardware:
Jet trim kit K-9694 included
Apron K-1279 optional
Drain K-7161-AF recommended
Vinyl tiling-in bead* K-1177 optional
*Use K-1177 vinyl bead when wall material contacts any
top surface of bath.
B. REQUIRED ELECTRICAL SERVICE
Dedicated branch circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 15 A, 60 Hz
C. PRODUCT INFORMATION
Fixture*: basin area top area weight
Bathing well 42” x 17” 55” x 25” 93 lbs.
water depth capacity
To overflow 12-1/8” 50 gal.
* Approximate measurements for comparison only.
Pump: HP V Hz A
1-speed 3/4 120 60 10.5
D. INSTALLATION NOTES
Read the entire installation instruction before beginning the
installation.
Pump is supplied with a grounding-type plug-in cord. Locate
the outlet behind the whirlpool, and within 24” of the pump.
The optional apron must be installed before the finish floor
and wall materials are installed.
ROUGHING-IN NOTES
Fixture conforms to ANSI Standard Z124.1. All
dimensions are nominal.
No change in measurements if connected with drain il-
lustrated.
Cut-out 58-1/2” x 28-1/2”
Minimum access panel:
Pump/control 20” W x 15” H required

1/2” R.
1-1/4” 1-1/2”
INTEGRAL
FLANGE
DETAIL
DROP-IN
RIM
DETAIL
16”
1-3/8”
8-3/8” 60”
PUMP/CONTROL ACCESS
32”
2-7/8”
3” 1-1/2” O.D.
20”
3/8”
2-3/4”
18-1/2”
5113867-2-EA (-)
Kohler Co., Kohler WI
2. ROUGHING-IN: K-1206, K-1206-L, K-1206-R, HOURGLASS 32
A. ORDERING INFORMATION
Applicable product:
Drop-in rim style K-1206 shown
Left outlet, integral flange K-1206-L not shown
Right outlet, integral flange K-1206-R not shown
Accessories/hardware:
Jet trim kit K-9694 included
Apron K-1278 optional
Drain K-7161-AF recommended
Vinyl tiling-in bead* K-1177 optional
*Use K-1177 vinyl bead when wall material contacts any
top surface of bath.
B. REQUIRED ELECTRICAL SERVICE
Dedicated branch circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 15 A, 60 Hz
C. PRODUCT INFORMATION
Fixture*: basin area top area weight
Bathing well 44” x 22” 55” x 25” 100 lbs.
water depth capacity
To overflow 15-1/8” 68 gal.
* Approximate measurements for comparison only.
Pump: HP V Hz A
1-speed 3/4 120 60 10.5
D. INSTALLATION NOTES
Read the entire installation instruction before beginning the
installation.
Pump is supplied with a grounding-type plug-in cord. Locate
the outlet behind the whirlpool, and within 24” of the pump.
The optional apron must be installed before the finish floor
and wall materials are installed.
ROUGHING-IN NOTES
Fixture conforms to ANSI Standard Z124.1. All
dimensions are nominal.
No change in measurements if connected with drain il-
lustrated.
Cut-out K-1206 drop-in rim style, 58-1/2” x
30-1/2”
Minimum access panel:
Pump/control 20” W x 15” H required

18”
1-7/8” 8-7/8” PUMP/CONTROL ACCESS
36”
21”
1-1/8”
2-7/8”
3” 1-1/2” O.D.
3-1/4”
59-9/16”
19-1/4”
6
113867-2-EA (-) Kohler Co., Kohler WI
3. ROUGHING-IN: K-1211, COCOON 5’
A. ORDERING INFORMATION
Accessories/hardware:
Jet trim kit K-9694 included
Apron K-1278 optional
Drain K-7161-AF recommended
Vinyl tiling-in bead* K-1179 optional
*Use K-1179 vinyl bead when wall material contacts any
top surface of bath.
B. REQUIRED ELECTRICAL SERVICE
Dedicated branch circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 15 A, 60 Hz
C. PRODUCT INFORMATION
Fixture*: basin area top area weight
Bathing well 39” x 22” 54” x 27” 105 lbs.
water depth capacity
To overflow 15-1/2” 70 gal.
* Approximate measurements for comparison only.
Pump: HP V Hz A
1-speed 3/4 120 60 10.5
D. INSTALLATION NOTES
Read the entire installation instruction before beginning the
installation.
Pump is supplied with a grounding-type plug-in cord. Locate
the outlet behind the whirlpool, and within 24” of the pump.
The optional apron must be installed before the finish floor
and wall materials are installed.
ROUGHING-IN NOTES
Fixture conforms to ANSI Standard Z124.1. All
dimensions are nominal.
No change in measurements if connected with drain il-
lustrated.
Cut-out 58-1/2” x 34-1/2”
Minimum access panel:
Pump/control 20” W x 15” H required

18”
1-7/8” 8-7/8” PUMP/CONTROL ACCESS
36”
1-3/4”
21”
15/16”
2-7/8”
3” 1-1/2” O.D.
3”
71-3/16”
7113867-2-EA (-)
Kohler Co., Kohler WI
4. ROUGHING-IN: K-1216, COCOON 6’
A. ORDERING INFORMATION
Accessories/hardware:
Jet trim kit K-9696 included
Apron K-1278 optional
Drain K-7161-AF recommended
Vinyl tiling-in bead* K-1179 optional
*Use K-1179 vinyl bead when wall material contacts any
top surface of bath.
B. REQUIRED ELECTRICAL SERVICE
Dedicated branch circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 15 A, 60 Hz
C. PRODUCT INFORMATION
Fixture*: basin area top area weight
Bathing well 52” x 23” 66” x 27” 110 lbs.
water depth capacity
To overflow 15-1/2” 76 gal.
* Approximate measurements for comparison only.
Pump: HP V Hz A
1-speed 3/4 120 60 10.5
D. INSTALLATION NOTES
Read the entire installation instruction before beginning the
installation.
Pump is supplied with a grounding-type plug-in cord. Locate
the outlet behind the whirlpool, and within 24” of the pump.
The optional apron must be installed before the finish floor
and wall materials are installed.
ROUGHING-IN NOTES
Fixture conforms to ANSI Standard Z124.1. All
dimensions are nominal.
No change in measurements if connected with drain il-
lustrated.
Cut-out 70” x 34-1/2”
Minimum access panel:
Pump/control 20” W x 15” H required
Faucet area recommended

2”
9”
PUMP/CONTROL ACCESS
48”
23”
13/16”
2-7/8”
3” 1-1/2” O.D.
3-1/2” 72”
24”
1-3/4”
8
113867-2-EA (-) Kohler Co., Kohler WI
5. ROUGHING-IN: K-1221, SEADREAM
A. ORDERING INFORMATION
Accessories/hardware:
Jet trim kit K-9696 included
Apron K-1223 optional
Drain K-7161-AF recommended
Vinyl tiling-in bead* K-1179 optional
*Use K-1179 vinyl bead when wall material contacts any
top surface of bath.
B. REQUIRED ELECTRICAL SERVICE
Dedicated branch circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 15 A, 60 Hz
C. PRODUCT INFORMATION
Fixture*: basin area top area weight
Bathing well 47” x 37” 67” x 42” 120 lbs.
water depth capacity
To overflow 16-7/8” 122 gal.
* Approximate measurements for comparison only.
Pump: HP V Hz A
1-speed 3/4 120 60 10.5
D. INSTALLATION NOTES
Read the entire installation instruction before beginning the
installation.
Pump is supplied with a grounding-type plug-in cord. Locate
the outlet behind the whirlpool, and within 24” of the pump.
The optional apron must be installed before the finish floor
and wall materials are installed.
ROUGHING-IN NOTES
Fixture conforms to ANSI Standard Z124.1. All dimen-
sions are nominal.
No change in measurements if connected with drain il-
lustrated.
Cut-out 70-1/4” x 46-1/4”
Minimum access panel:
Pump/control 20” W x 15” H required

9113867-2-EA (-)
Kohler Co., Kohler WI
6. PRODUCT NOTICES
A. INSTALLER HAZARD NOTIFICATION
DANGER: Risk of fire, electric shock, or injury
to persons. Readimportantsafetyinstructionson
inside front cover of these instructions.
WARNING: Risk of electrical shock. A licensed
electrician should make all electrical connections.
WARNING: Risk of electrical shock. Connect
only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI).
WARNING: Risk of electrical shock.Disconnect
power before servicing.
WARNING: Risk of injury or property damage.
Please read all instructions thoroughly before
beginning installation, including the following
Product Requirements.
NOTICE: Follow all local plumbing and electrical
codes.
B.FACTORY-ASSEMBLED FEATURES
Factoryinstalledcomponentsincludepumpwithintegral
timer and air switch transmitter. No installation is
needed.
The whirlpool pump and piping are factory-assembled.
WARNING: Unauthorized modification may
cause unsafe operation and poor performance
of the whirlpool. Do not relocate the whirlpool
pump,ormakeothermodificationstothewhirlpool
system, as this could adversely affect the
performance and safe operation of the whirlpool.
Kohler Co. shall not be liable under its warranty or
otherwiseforpersonalinjuryordamagecausedby
any such unauthorized modification.
7. PRODUCT REQUIREMENTS
A. SUMMARY OF KEY REQUIREMENTS
Install unit to a level subfloor.
Provide properly dimensioned framing.
Whirlpools are designed for a variety of installa-
tions, depending upon the model chosen.
The optional apron must be installed before the
finish floor and wall materials are installed.
B. PLUMBING SPECIFICATIONS
Confirm adequate support for the faucet; large faucets
that may be inadvertently used as a means of support
are not appropriate or safe for this installation.
C. PRODUCT INSPECTION
Carefully unpack and inspect the whirlpool for damage.
Leave all materials in the carton during construction to
prevent damage.
NOTICE: Make sure both union connections to the
pump are securely tightened.
D. CONNECTIONS AND SERVICE ACCESS
Before installation, ensure proper access to the final
connections.
NOTICE: Provideunrestrictedserviceaccesstothe
pump. Anaccesspanelmustbeconstructedtoallowfor
sufficient clearance for servicing the pump or controls.
Theaccesspanelmustbelocatedatthepumpendofthe
whirlpool.
An optional removable apron is available for access to
thepumpandcontrols.Additionalaccess,however,may
make servicing of the pump and controls easier.
E. ELECTRICAL REQUIREMENTS
The installation must have a Class A Ground-Fault
Circuit-Interrupter (GFCI). The GFCI protects against
line-to-ground shock hazard. Use a 120 V, 15 A, 60 Hz
dedicated service for the whirlpool.

10
113867-2-EA (-) Kohler Co., Kohler WI
8. INSTALLATION REQUIREMENTS
A. TOOLS REQUIRED
Conventional woodworking tools
Arc pliers or 14” pipe wrench
Rule
Level
Safety shoes
Safety glasses
Square
Screwdriver
Pliers
Utility knife
Tin snips
B. MATERIALS REQUIRED
Plumbers putty
Wall coverings, as necessary
Silicone sealant
Construction adhesive (optional)
2x4’s
Drop cloth
Nails
C. CLEARANCE REQUIREMENTS
Check the roughing-in and room dimensions to provide
adequate available space for the bath unit.
D. NEW OR REPLACEMENT INSTALLATION
REQUIREMENTS
This unit can be installed in new or existing bathrooms.
For new installations: Positiontheplumbingaccording
toroughing-indimensions beginningon Page4. Cap the
supplies, and check for leaks.
For replacement installations: Remove the old bath.
Remove the old wall material, and remove any old floor
covering from the area. Remove any old plumbing that
does not conform to roughing-in requirements.

11 113867-2-EA (-)
Kohler Co., Kohler WI
9. SITE REQUIREMENTS
A. OLD BATH REMOVAL
Disconnect the drain at the trap. Remove the old wall
material. Slip boards under the old bath feet to
protect the floor andslidetheoldbathoutoftherecess
as illustrated.
Floor
Protection
Boards
Old Bath
B. SUBFLOOR PREPARATION
Check the flooring under the bath, and make repairs as
needed. Make sure the subfloor is level.
C. STUD POCKET PREPARATION
Possible stud frame arrangementsare illustratedbelow.
Usethestud construction appropriate foryourparticular
whirlpoolmodel.Somemodificationsmaybeneededfor
other types of construction, if preferred.
If an apron wall without a ledge is desired, the finished
apron wall surface must be 1/16” under the bath rim.
1. Recommended For K-1201, K-1206, K-1211,
K-1216, and K-1221 Drop-In Models:
Corner Installation: The suggested stud construction
is illustrated. Whirlpool
Rim
1/16” Gap
Between
Whirlpool
Rim and
Framing
2. Recommended For K-1201, K-1206, K-1211,
K-1216, and K-1221 Drop-In Models:
Recess Installation: The suggested stud construction
is illustrated. Whirlpool
Rim
1/16” Gap
Between
Whirlpool
Rim and
Framing

12
113867-2-EA (-) Kohler Co., Kohler WI
3. Recommended For K-1206-L and K-1206-R
Integral Flange Models:
Recess Installation: The suggested stud construction
is illustrated.
4. Recommended For K-1201, K-1206, K-1211,
K-1216, and K-1221 Drop-In Models:
Peninsular Installation: The suggested stud
construction is illustrated.
Whirlpool
Rim
1/16” Gap
Between
Whirlpool
Rim and
Framing
5. Recommended For K-1201, K-1206, K-1211,
K-1216, and K-1221 Drop-In Models:
Sunken Installation: Refer to Roughing-In notes
beginning on Page 4 for cut-out details. Make sure the
whirlpool is supported by the supporting feet on the
bottom of the whirlpool. Do not hang the whirlpool by
the rim.
Whirlpool
Rim 1/16” Gap
Between
Whirlpool Rim
and Framing
D. PLUMBING PREPARATION
Position the plumbing according to the roughing-in
dimensions. Cap the supplies, and check for leaks.

13 113867-2-EA (-)
Kohler Co., Kohler WI
10. BEFORE INSTALLING UNIT
A. TILING-IN BEAD INSTALLATION – DROP-IN
MODELS ONLY
Anoptionaltiling-in beadisrecommendedforthesideof
the whirlpool that contacts the wall. This bead prevents
water from seeping between the whirlpool and the wall.
RefertoOrderingInformationlocatedintheRoughing-In
section beginning on Page 4.
Installthisbeadnow.Refertotheinstallationinstructions
packed with the tiling-in bead.
B. PARTIALLY INSTALLBATHDRAIN
Install the drain on the bath according to the drain
manufacturer’s instructions. When installing the drain
overflow tube and hood, be sure to adequately seal
along the edges of the hood to prevent leakage.
C. PROTECT WHIRLPOOL UNIT
Position a drop cloth or similar material in the bottom of
the unit. Be careful not to scratch the surface of the
product.

14
113867-2-EA (-) Kohler Co., Kohler WI
11. INSTALL THE WHIRLPOOL
A. WHIRLPOOL SET-IN
Choose the installation option (Step 1., 2., or 3.
below) that applies to your particular installation. Follow
the appropriate instructions.
Ifthesubfloorisnotlevel,someshimmingofthebathwill
be necessary.
NOTICE: Do not hang the whirlpool by the rim.
Whirlpool Rim
1/16” Gap Between
Whirlpool Rim and
Framing
1. Option For Sunken Installation: Setthebathinto
the sunken installation. Make sure the unit is level
and resting on all support feet. Insert the drain
tailpiece into the trap. Apply a bead of silicone
sealant under the rim of the unit.
CAUTION: Risk of product damage. Do not
hang the unit by the rim.
2. Option For Using Gypsum: Spread a 2” thick
layerofgypsum cementonthe floorwherethe bath
istobeset.This willhelp secure,level, andsupport
theunit.Setthebathintoposition.Clearanyexcess
cement from the vicinity of the pump.
NOTE: Support bracket must sit flat on the floor.
Insertthedraintailpieceintothetrap.Makesurethe
bath is level and resting on all support feet.
3. Option For Using Construction Adhesive:
Apply a generous amount of constructionadhesive
tothe bottom ofthe support feet.Set the bathin the
desired location, and level it.
Insertthedraintailpieceintothetrap.Makesurethe
bath is level and resting on all support feet.
Apply Construction Adhesive
to Support Feet

15 113867-2-EA (-)
Kohler Co., Kohler WI
B. INTEGRAL FLANGE MODELS
1. Drillapilotholethroughthenailing-inflangeateach
stud.
2. Add shims between the nailing-in flange and the
studs as needed to eliminate gaps.
3. Nail1/4”thickfurring stripstothe wall studsto shim
out to the edge of the nailing-in flange. Install
water-resistant wall material as required.
1/4” Furring Strip
Stud
Nailing-In
Flange
C. PUMP BANDING STRAP CUT
NOTICE: This step is necessary to make your
Kohler whirlpool operate more quietly.
1. Use tin snips to cut the two banding straps. These
banding straps secure the pump to the
bath-mounted shipping bracket. When thebanding
straps are cut, the support bracket and pump will
drop about 1/2” until they rest on the subfloor. If the
pump drops more than 1/2”, be sure the proper
pitch is maintained (with shims under the motor) to
allow the pump to drain through the suction line
when the whirlpool is drained.
Shipping Bracket
(leave attached
to bath)
Suction Line
Pump
Subfloor
Banding Straps
Support Bracket
2. If the subfloor is level, no adjustments to the pump
are necessary. Proceed to Step 3. If the subfloor is
notlevel,slide plywood shims between the support
bracket and the subfloor, but only high enough to
allow water to drain out the suction line when the
bath is drained.
NOTE: Do not raise the pump higher than it was before
youcutthebandingstraps.Ifthepumpisraisedtoohigh,
it may not prime properly. Shim if necessary, using 5” x 7”
(minimum) plywood
Drainage
Suction Pipe
3. To minimize pump noise and vibration, be sure the
pump is not in direct contact with the shipping
bracket afterthebandingstraps arecut. Securethe
support bracket to the subfloor with screws or lag
screws (not provided).
Subfloor
Support Bracket
Screws or
Lag Bolts
Pump Shipping Bracket

16
113867-2-EA (-) Kohler Co., Kohler WI
D. INSTALL PLUMBING
CAUTION: Risk of damage to bath bottom and
subfloor. Ensure a watertight seal on the bath
drain connections.
1. When the bath is securely positioned, connect the
drain to the trap.
NOTE: An access panel will simplify future mainte-
nance. Connect Here
2. Install the faucet valving and spout tee. Open the
hot and cold water valves, and check the supply
connections for leaks.
3. Run water into the bath, and check the drain
connections for leaks.
12. ELECTRICAL CONNECTIONS
A. IDENTIFY ELECTRICAL REQUIREMENTS
The model number is printed on a label at the pump end
of the whirlpool.
The label identifies electrical rating.
B. WIRING INFORMATION – 120 V, 60 HZ –
1-SPEED PUMP (UL LISTED) MODELS
WARNING: Risk of electrical shock. To reduce
theriskofelectricshock,connectonlytoaproperly
grounded, grounding-type receptacle, protected
by a Ground-Fault Circuit-Interrupter (GFCI). Do
not remove the plug’s grounding pin. Do not usea
grounding adapter.
Your Kohler whirlpool bath is equipped with a cord and
plug. All wiring of the pump and control has been
completed at the factory. A licensed electrician must
install a GFCI-protected, 120 V, 15 A, grounded outlet.
Your whirlpool may then be plugged into this outlet. No
other load should be on this circuit. Locate the outlet
behind the whirlpool, and within 24” of the pump.
NOTE: Be sure the air actuator tubing is securely
attached to the pump. Ensure that it is not kinked or
damaged.
* For bonding in accordance with national and local
codes.
Air
Actuator
Air
Actuator
Tubing
Bonding
(Earthing) Lug*
Pump
Plug-in
Cord
15 A
Receptacle

17 113867-2-EA (-)
Kohler Co., Kohler WI
13. WATER TEST WHIRLPOOL AND ELECTRONICS
Check all electrical connections.
Makesureallpipeconnectionstothepumparesecurely
tightened.
Fillthe whirlpooltoalevelatleast2” abovethe topof the
highest jet.
Operate the whirlpool for 5 minutes, and check all
whirlpool harness (piping) connections for leaks.
For additional information on whirlpool operation, see
Start-Up Whirlpool instructions on Page 18.
14. COMPLETE FINISH WALL
A. DROP-IN MODELS
CAUTION: Risk of product damage. Do not
support the weight of the bath by the rim.
Protect the whirlpool surface. Make sure the vinyl bead
is attached securely to the sides being built intothe wall.
Cover the framing and walls with water-resistant wall
material.
Tapeandmudthewater-resistantwallmaterial.Sealthe
wall material and joints under the whirlpool rim. Install
the finish wall material. Seal the joints between the
whirlpool rim and the finish wall using silicone sealant.
RTV (Room Temperature Vulcanizing) sealant is
recommended.
ÍÍ
ÍÍ
ÍÍ
É
É
É
É
É
Ç
Ç
ÇÇ
ÇÇ
ÇÇ
ÇÇ
Ç
Ç
Ç
Finish Wall Covering
Water-Resistant
Wall Material
Silicone Sealant
Vinyl Bead
2x4 Studding
Framing or
Ledger Strip
Whirlpool
For installations that do not use a vinyl bead, cover the
framing with water-resistant wall material as shown.
Seal the joints between the whirlpool rim edge and the
wall material with silicone sealant.
Tape and mud the water-resistant wall material. Install
the finish wall to the water-resistant wall material as
shown.Sealthe jointsbetweenthewhirlpoolrimandthe
finish wall material with silicone sealant.
Silicone Sealant
Whirlpool
Finish Wall
Material
Water-Resistant
Wall Material

18
113867-2-EA (-) Kohler Co., Kohler WI
B. INTEGRAL FLANGE MODELS
Tape and mud the water-resistant wall material. Install
the finish wall to the water-resistant wall material as
shown.Sealthe jointsbetweenthewhirlpoolrimandthe
finish wall material with silicone sealant.
2x4 Studding
Finish Wall
Water-Resistant
Wall Material
Silicone
Sealant
Whirlpool
15. COMPLETE INSTALLATION
A. INSTALL HANDLES AND SPOUT
Install the faucet handles and spout according to the
manufacturer’s instructions. Seal around the plumbing
fittings.
16. CLEAN-UP AFTER INSTALLATION
When cleaning up after installation, do not use
abrasive cleansers as they may scratch and dull the
bath surface. Use warm water and a liquid detergent to
clean the surface.
Stubborn stains, paint, or tar can be removed with
turpentine or paint thinner. Do not allow cleaners
containing petroleum distillates to remain in
contact with whirlpool surfaces for long periods of
time. Plaster can be removed by scraping with a wood
edge. Do not use metal scrapers, wire brushes, or other
metal tools. A powder-type detergent may be used on a
dampclothtoprovidemildabrasiveactiontotheresidual
plaster.
17. CONFIRM PROPER OPERATION
A. START-UP WHIRLPOOL
Refer to Important Safety Instructions on Page 2.
Please perform the following so the owner can safely
receive the benefits of whirlpool bathing.
1. Rotate the jets so they are facing down toward the
basin.
2. Fill the whirlpool to a water level at least 2” above
the top of the highest jet.
Water temperature in the bath should not exceed
104F (40C).
Bath
Wall 2” Minimum
Water Line
Jet Trim

19 113867-2-EA (-)
Kohler Co., Kohler WI
B. OPERATING SEQUENCE
Refer to the chart at right for the proper operating
sequence.
1. Turn on the whirlpool jets. Adjust each jet for
optimum air/water mixture.
2. A built-in timer automatically stops the motor after
approximately 20 minutes of operation. Reduce
Air Add
Air
TO METHOD OBSERVE
Turn on the
whirlpool
massage.
To add air and
water to the
whirlpool action,
rotate trim ring
counterclockwise.
To reduce air and
water, turn it
clockwise.
Shut off whirlpool.
Restart whirlpool
after 20 minute
cycle is
complete.
18. TROUBLESHOOTING PROCEDURES
A. FLEXJET INSTALLATION
NOTE: The Flexjet O-ring must be correctly positioned,
must be lubricated, and must be in good condition to
permit easy rotation and proper operation.
1. Install the O-ring onto the first shoulder of the
Flexjet. Lubricate the O-ring with silicone lubricant
to prevent noisy operation of the Flexjet.
2. Insert the Flexjet into the housing, and lightly push
androtatethe Flexjetuntil itsnapsintoposition.Do
not force the Flexjet.
NOTE: When installed correctly, the Flexjet should turn
smoothly both clockwise and counterclockwise.
Flexjet Housing
O-Ring (Must
Be Lubricated)
Flexjet
Slide O-Ring

20
113867-2-EA (-) Kohler Co., Kohler WI
B. TROUBLESHOOT WHIRLPOOL SYSTEM
Thistroubleshootingguideisforgeneralaidonly.AKohlerAuthorizedServiceRepresentativeoraqualifiedelectrician
should correct all electrical problems. For warranty service, contact your dealer or wholesale distributor.
SYMPTOMS PROBABLE CAUSES RECOMMENDED ACTION
1. Whirlpool does not
start/stop. A. No power to pump. A. Set/Reset GFCI breaker; check wiring to pump.
B. Air actuator tubing disconnected,
loose, kinked, plugged or damaged. B. Connect, straighten, clean or replace tubing.
C. Faulty air actuator. C. Replace air actuator.
D. Faulty motor/pump assembly. D. Rebuild or replace motor and pump
assembly.
2. Motor starts, all jets
are not functioning
A. Jet is closed. A. Rotate jets counterclockwise to open.
are not functioning. B. Trim kit installed incorrectly. B. Reinstall trim kit, checking for O-ring
damage or improper placement.
C. Jets are blocked. C. Remove blockage.
3. Motor turns, water
is
p
um
p
ing but
A. No aspiration at jets. A. Rotate jets counterclockwise.
i
s pump
i
ng,
b
u
t
there is no air
injection. B. Jet O-rings are missing, or are
improperly installed. B. Replace or reposition jet O-rings.
4. Whirlpool stops
automatically
A. GFCI trips. A. Identify source of fault and correct.
automatically
before 18 minutes. B. Suction blocked. B. Remove obstruction.
before
18
minutes
.C. Jets are blocked. C. Remove blockage.
D. Motor overheated and protection
device activated. D. Check for blockage at motor vents. Remove blockage and allow motor to
cool.
Check for suction blockage. Remove
blockage and allow motor to cool.
Check for jet blockage. Remove
blockage and allow motor to cool.
5. Whirlpool does not
automatically stop
after 22 minutes
A. Faulty timer mechanism. A. Replace timer board inside
pump/motor.
after 22 minutes. B. Wiring error. B. Refer to dealer.
6. Pump does not
prime. A. Pump shimmed too high. A. Lower pump to subfloor level that bath is resting upon.
7. Noisy operation. A. Pump straps have not been cut. A. Cut straps with tin snips and secure
pump bracket to subfloor.
B. Jet squeals due to dislodged jet
O-ring. B. Remove jet, replace and lubricate O-ring on valve body, and reinstall jet.
