Kohler MAXISPACE User manual

-1-
MAXISPACE
INSTALLATION INSTRUCTIONS
K-96106T-R/K-96106T-L/K-96107T
MIRRORED CABINET
BEFORE YOU BEGINBEFORE YOU BEGIN
!
!
!
!
!
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation . This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Before installation carefully inspect the new fixture for any
signs of damage.
This product complies with GB/T10357.4-2013,
GB/T10357.5-2013 and GB24977-2010.
Be
careful when opening the door to avoid pinching
fingers.
Don't use acidic or alkalic cleaners or
alcohol to clean the surface. Use a dampened cloth to
clean.
Electrical wiring
may need to be relocated.
Use anchors
(not provided) rated for the loaded weight of this
product. Refer to the anchor manufacturer's
instructions.
This cabinet is designed for
either right or left door swing. Check the wall cavity for
obstructions.
please leave instructions for the
consumer.
WARNING: Risk of injury or product damage.
WARNING:
CAUTION: Risk of electric shock.
CAUTION: Risk of property damage.
Important Information:
!
!
!
!
!
-
GB/T10357.4-2013 GB/T10357.5-2013
GB24977-2010
ZHONGSHAN KOHLER SHOWER CO., LTD. NO13-1, XINYE ROAD, ZHONGSHAN TORCH
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA POST CODE: 528437
13-1 528437
©
©
Copyright Kohler China Investment Co., Ltd. 2017
2017
1261996-T01-B

-2-
Kohler reserves the right to change marked dimensions without prior notice.
ROUGHING-IN
UNIT : mm
Reference Value
Mirrored Cablnet
K-96106T-L( )
K-96106T-R( )
Mirrored Cablnet
K-96107T( )
Glass Shelves
546*118*6mm
2PCS
Wall Anchors
5PCS
Top Clips
3PCS
Screw ST3.5X35
ST3.5X35
5PCS
Shelf Clip
10PCS
Mounting Bar
1PCS
Storage, Plastic
2( )
3( )
Glass Shelves
256*118*6mm
2PCS( )
Holedr, Dryer, Assy.
1PCS( )
ACCESSORIS LISTACCESSORIS LIST
590 158
130
776
776
890
590 297 158
130
Side Mirror
2PCS
1261996-T01-B

-3-
CABINET INSTALLATIONCABINET INSTALLATION
Item Electrical Function Type Descripetion Fixate Place
Defogger Input: 220V 50Hz, Pmax=30W Back of outer-mirror
Lighting Input: 220V 50Hz, Pmax=6W, LED 3000K Top of inner cabinet
Power Outlet Input: 220V 50Hz, 10A Bottom of inner cabinet
1
2
3
INSTALLATION
STEP
2
Drill mounting holes
Drill 5 (or 4) 6 holes on the wall as shown. The
holes on the same line shall keep level.
5(4)6
5- 6
6
745 0.3
L1=320(Single Door )
L2=320(Single Door )
L1=500(Double Door )
L2=590(Double Door )
558.5
L2
L1
40mm from top part of the countertop (such as faucet)
()40
Screw ST3.5x35
and Wall Anchor
ST3.5x35
Drill holes
4- 6mm
4- 6mm
Drill holes
4- 6mm
4- 6mm
Fix the mounting bar to the
wall, level the mounting bar.
1261996-T01-B

-4-
STEP
2
Install mounting bar. Take out the mounting bar and put level. Drill holes according to the hole spaces.
STEP
3
Fix the cabinet
1. Put the cabinet on the mounting bar.
2. Insert top clips from the center of the top. Slide the clips to align with the drilled holes. Fix with screws.
2.
1.
Top Clip
Cabinet
Mounting Bar
1261996-T01-B

-5-
Adjust the door (only necessary if the door does not completely match the cabinet when it is closed).
()
Door adjustments
Remove the hinge cover or the blumotion before adjustion, see Fig A.
A
Adjust the hinge of door in 3 directions to make sure the door level as shown in Fig.B.
B
STEP
4
Fig. B B
Height Adjustment Depth Adjustment
Side Adjustment
Fig. A A
AssembleAssemble Removal
1261996-T01-B

-6-
STEP
6
Adjust magnifying glass.
IMPORTANT!
To adjust mirror height, slide up or down.
Rotate mirror in before closing the door.
STEP
5
Install glass shelf
1. Insert the snap-in pins into the side holes.
1.
2. Insert the glass shelf into the snap-in pins.
2.
3.
3.
as shown in the left illustration.
In case the door opening angle is not enough, insert the glass shelf vertically upwards and then rotate to horizontal position,
as shown in the right illustration.
Method One Method Two
1261996-T01-B

-7-
STEP
7
Install accessories and side mirror as shown.
1. Align the side mirror with the top and bottom of the cabinet. Clean the back of the mirror.
1.
2. Peel off the double-sided tape and press onto the side mirror for 30 seconds.
2. 30
Note:
1. Two storage boxes with single door cabinet.
2. Three storage boxes and bracket for hair drier
with double door cabinet.
1. 2
2. 3 Side Mirror Bracket
Side Mirror
Side Mirror
Hang the storage box on the hook
Hang the storage box on the hook Hang the storage box on the hook
Fix bracket for hair drier on the
glass shelf with cross screwdriver
1261996-T01-B

-8-
STEP
8
Connect to power line
1. Open the wire box and pull out the terminal block.
1.
2. Put the terminal block back after connecting the power lines and then close the wire box.
2.
Terminal Block
Wire Box
Light, Defogger
Wire Input(three-core cable)
()
220V/50Hz
Plug
Wire Input(three-core cable)
220V/50Hz
()
Note:
1. LED light will be brighter when cabinet
door is closed and dimmer when cabinet
door is open.
2. A separated switch is needed for lighting.
3. It is recommended to arrange a
separated power line for the socket to
keep it power on all the time.
1. LED
2.
3.
1.5
4. 2000 .
Power line
shall be copper core 1.5m .
4. Power of the electrical equipments
connected to the socket shall not
exceed 2000w.
2
1261996-T01-B
