Kohler K-77123T User manual

-1-
JUTE
INSTALLATION INSTRUCTIONS
CABINET
K-77123T/K-77125T
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Turn off the water supply.
The pluming installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any
particular regulations and practices, specified by the local
water company or water undertakers. The installation
should be carried out by a plumber.
Before installation carefully inspect the new fixture for any
signs of damage.
please leave instructions for the
consumer.
JUTE bathroom cabinet adopts E1 grade natural black
walnut wood-based panel of high quality. With further
processing, its harmful emission is less than 1.5mg/L.
·This product complies with GB 24977-2010.
·
·
·
·
·
·
·
-
E1
1.5mg/L
·GB 24977-2010
ORDERING INFORMATION
This installation covers the following products in the JUTE
range:
JUTE Cabinet 914mm........................................K-77125T
JUTE Cabinet 1220mm......................................K-77123T
914mm.............................................K-77125T
1220mm...........................................K-77123T
SAFETY WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended
guidelines are given in the section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
MAINTENANCE
1.
2.
KOHLER CHINA INVESTMENT CO., LTD NO.158, JIANG CHANG SAN ROAD,
ZHABEI DISTRICT, SHANGHAI, PRC POST CODE: 200436
( ) 158 200436
©
©
Copyright Kohler China Investment Co., Ltd. 2016
2016
1282794-T01-A

-2-
ROUGHING-IN
UNIT : mm
K-77125T
Cabinet 914mm
914mm
K-77123T
Cabinet 1220mm
1220mm
INSTALLATION
A. Install Washbasin Cabinet
Install the services.
Hot (H) and Cold (C) inlets must be connected to the correct
inlet pipes.
Install the drain in accordance with the manufacturer's
instructions.
We suggest using P-trap drain. Connect P-trap pipe with
washbasin drain.
Make sure a watertight seal exisits on all
washbasin drain connections.
Provide access to the plumbing
connections for future plumbing maintenance.
The hot and cold water supplies must be installed
with isolating valves.
CAUTION !
CAUTION !
NOTE
A.
(H) (C)
P
Fig.2
2
Reference Value
Kohler reserves the right to change marked dimensions without prior notice.
Fig.1
1
914
1220
556
556
495
495
1282794-T01-A

Fig.3
3
1. 3
I ( K-77104T-B07)
1. Place the cabinet on the floor. Fix adjustable feet as shown
in Fig.3. (Put carton or foam on the floor first to prevent
scratching the cabinet.)
IInstallation with adjustable feet (K-77104T-B07 is not
supplied with cabinet and shall be purchased.)
2. Put the cabinet upright and place it at a desired position in
the bathroom. Adjust the adjustable feet to make the
cabinet level, as shown in Fig.4.
2.
4
Fig.4
4
3. Pre-drill wall anchors
Adjust cabinet level and use pencil to mark the hole of the
back bar on the wall.
Remove the cabinet, drill 8mm & 50mm deep holes at
the marked positions.
Hammer the anchors into the drilled holes.
Finish the step.
·
·
·
·
3.
8mm
50mm
·
·
·
·
-3-
Go Up Go Down
Horizontal
1282794-T01-A

1.
8mm 50mm
2. ( 6)
II ( )
1. Mark the positions of the wall hangers on the wall
according to the dimensions shown. Drill 8mm & 50mm
deep holes and hammer the anchors in. Fix the wll hangers
onto wall with screws supplied.
2. Hang the cabinet onto wall and adjust the hanger to make
the cabinet level,as shown in Fig.6.
II Hang onto wall (installation without adjustable feet)
Fig.5
5
Fig.6
6
Cabinet Outline Cabinet Outline
Wall Bracket Wall Bracket
380
380
766
766
495
495
20
914
Centre Centre
20
1220
3. Pre-drill wall anchors
Adjust cabinet level and use pencil to mark the hole of the
back bar on the wall.
Remove the cabinet, drill 8mm & 50mm deep holes at
the marked positions.
Hammer the anchors into the drilled holes.
Finish the step.
·
·
·
·
3.
8mm
50mm
·
·
·
·
-4-
B.
1.
B. Fix the cabinet onto wall
Note: For installation with or without adjustable feet,
the cabinet must be fixed onto wall with anchors.
1. Adjust the cabinet level after installation with or without
adjustable feet. Fix the cabinet onto wall through the holes
on the back bar with anchors and gaskets supplied.
1282794-T01-A

C. /
//
C. Install the Synthetic Top/Counter Top
Note: Please refer to the installation instructions of synthetic
top/counter top for its installation. To protect the
cabinet from dampness, please apply silicone sealant
where the synthetic top and the cabinet
connect.
/counter top
2. S
U
2. Floor drainage (S-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position
according to the suppliers instructions. You can put the
pipe into the U notch.
Fig.8
8
Faucet
Supply Lines
Shut-off Valve
Drain Assembly
Ripple Pipe
Outlet
Fig.7
7
1. (P )
/UU
Connect Drainage
1. Inwall drainage (P-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position
according to the suppliers instructions. You can put the
pipe into the U notch.
Faucet
Supply Lines
Shut-off Valve
Drain Assembly
-5-
1282794-T01-A

-6-
2.
2. Place the hinge cover and plastic cover.
Fig.9
9
D.
1. 9
D. Adjustments
1. Adjust the hinge cover in 3 direction to make sure the door
is level. As shown in Fig.9.
1.
2.
3.
4.
5.
6.
7.
USER MAINTENANCEUSER MAINTENANCE
Warning! Risk of product damage.
1.
2.
3.
4.
5.
6. Please do not sit, lean or step on the basin cabinet.
7. If any fixtures caused by abnormal reasons, Kohler China
can supply paid replacement for service parts caused by
abnormal reasons as shown in the Service Parts Page in
the limited duration of warranty.
Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
Kohler bathroom cabinet are dealt with strict procedures
for damp-proof, whose good damp-proof function ensures
good performance even in bathroom of huge humidity. Yet
do not splash and pour water directly on the bathroom
cabinet. Make sure that the bathroom is not over damp
and wipe any splashes from surfaces immediately.
Maintenance of door board: Clean and wipe door board
regularly, and wipe the condensation vapor with dry and
soft cloth.
Ensure that electrical connections for appliances such as
head lamp is insulated wipe mirror surface with chamois
regularly to guarantee the persistent excellent performance.
1282794-T01-A
