Kohler C3-050 Assembly instructions

科勒（中国）投资有限公司
中国上海市静安区江场三路158号 邮编：200436
制造商：上海科勒电子科技有限公司
中国上海市宝山区丰翔路1955号 邮编：200444
Smart Seat
清舒宝智能便盖
English page 2-18
中 文 页 码 19-35
1305685-MY01-C
C3-050
K-18751MY-0

Table of Contents
CAUTIONS AND WARNINGS................................................................. 3
Specifications.......................................................................................... 5
Thank You For Choosing Kohler Company.............................................
6
Control Panel........................................................................................... 6
Operation ...............................................................................................
7
Preparation Before Initial Operation ....................................................... 9
Test the Functions...............................................................................................
10
Care and Clean....................................................................................... 11
Clean the Spray Wangs .......................................................................... 12
Remove the Seat .................................................................................... 13
Clean the Filter ....................................................................................... 14
Maintanance in Case of Long-term Idle Status....................................... 15
Troubleshooting...................................................................................... 16
Description of Content of Hazardous Substances in Product ................. 18
1305685-MY01-C
2
Kohler Co.

CAUTIONS AND WARNINGS
Children, elders or those with disabilities from their body, sensitivity or mental
disabilities or lacking of common sense should not use or get close to this
product unless under close tutelage. Children are not allowed to use or touch
this product. Do not leave children alone in a room with such product.
:DUQLQJ Risk of electric shock, fire or personal injury. This product
must be installed safely. Connect only to dedicated 220V~, 50 Hz , 10A
circuit protected by Ground-Fault Circuit-Interrupters (GFCI’s) or
Earth-Leakage Circuit-Breakers (ELCB’s).
:DUQLQJ Risk of electric shock or product damage. Do not immerse
the product into water.
,PSRUWDQWRisk of product damage. Do not install at a place where it may be
splashed by water.
,PSRUWDQWRisk of product damage. Do not install the product at a place
with excessive humidity, where moisture may condense at the surface of the
product. Please maintain that the usage envi-ronment is under adequate
ventilation, so as to prevent damage to electronic components. 
,PSRUWDQWRisk of product damage or property loss. Water leakage may
happen if the water pipe connector is pulled or pushed with excessive force.
,PSRUWDQWRisk of product damage. The product may be damaged if the
nozzle is applied with excessive force.
,PSRUWDQWRisk of product damage. The part of the pipe where water may be
frozen should be protected by thermal insulation. Any water left in the product
may be frozen during the winter season. Please keep the product in room
temperature before reinstallation or usage. 
,PSRUWDQWRisk of product damage. The power shall not be connected before
the work is finished. Otherwise it may lead to product failure. 
$WWHQWLRQThe thermal protector may be out of order during storage or
transportation in warm climate which can lead to product failure. Please
ensure the product cools to room temperature before reinstallation or usage.
When an electrical product is used, especially when children are near, the
following basic safety precautions shall be abided by:
'DQJHU5HGXFHULVNRIHOHFWULFVKRFN
□Do not place or store this appliance where it can fall or be pulled into a bath
or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug immediately.
:$51,1*7RUHGXFHWKHULVNRIORZJUDGHEXUQVHOHFWULFVKRFNILUHRU
LQMXU\WRSHUVRQV
□
□
□
Kohler Co.
3
1305685-MY01-C

WARNING - To reduce the risk of low grade burns, electric shock, fire or injury to persons:
Do not place or store this appliance where it can fall or be pulled into a bath or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug immediately.
CAUTIONS AND WARNINGS (cont.)
□
□
recommended by Kohler Co.
Do not lean on cover when use this appliance to prevent product from damage.
□
□
□
□
□
□
For those children and the elderly who are unable to adjust the
temperature, they should ask for help to adjust seat temp, water temp and
wind temp of toilet cover to proper gears.
□
□
been dropped into water.
Install this product properly by following the installation procedure.
This product shall be repaired by professionals only. The warranty will
become invalid if you try to repair this product by yourself.
When install the product in the room, a stop valve shall be installed in a close
proximity. For emergency circumstances, the water inlet valve shall be stopped
without using any tools; otherwise unexpected failure may cause the loss to
the customer.
Keep power line far from heated surface.
Do not drop or insert any substance to pipeline or the opening.
Do not use this product outdoor or in a place where a particle mist spray
device is used,neither at a place of provisions.
The installation should be subject to the instructions before the power is
connected.
Water should not be poured into the power plug.
Exposed skin should not make contact with heating seat for too long a time
to prevent low temperature burning.
□
□
□
□
□
□
□
the professionals from its maintenance
department or similar departments, to avoid the occurrence of danger.
Please use the water supply hose accompanying with new machine. The old
hose assembly shall not be used again.
When customer cut power supply off, if reactivation of power supply is
required, please wait until the end of “beep……” indication, and then turn on
power supply again.
1305685-MY01-C
4
Kohler Co.

Min water pressure 0.07Mpa (dynamic pressure)
Max water pressure 0.74Mpa
Water pressure
Rated voltage 220V~, 50Hz
*
About 1.5m
Rated power 1060W
Product outline dimension About 530mm × 430mm × 120mm
Weight of product About 4.25kg
Inlet water temp 1-35°C
Operation Environment 1-40°C
Rear wash YES, adjustable
Front wash YES, adjustable
Water flow
(water pressure 0.2Mpa) Max rear wash shall be no less than 500mL/min
OFF, adjustable 3 dials (ambient temp,
about 31-39°C)
About 300s
Thermal fuse
UV sanitize
Other safety devices Circuit-Breakers
Situated at the Side of the Body
Seat-on
*Power value testing condition: dynamic pressure 0.2Mpa, inlet water temp 15°C.
Kohler Co.
5
1305685-MY01-C

w
Cover (antibacterial)
Seat (antibacterial)
1305685-MY01-C
6
Kohler Co.

When WASH function is ON, press button to terminate WASH
function.
Press female wash when user seat on, activate female wash
(female only) and display current wash strength.
Continue press female wash to exchange spray strength when
female wash function is ON. The strength shall circulate per “min
dial, mid dial, max dial, mid dial” sequence.
Auto stop after continuous washing for 5min.
Press rear wash when user seat on. Activate rear wash and
display current wash strength.
Continue press rear wash to exchange spray strength when rear
wash function is ON. The strength shall circulate per "min dial,
mid dial, max dial, mid dial" sequence.
Default rear wash is oscillate mode, if you need to deactivate
oscillate or reactivate again, press and hold rear wash and
STOP button about 2s.
Auto stop after continuous washing for 5min.
The Bidet is equipped with wide oscillate function. If you want to
use wide oscillate function, please hold REAR + STOP button
both for 2s after REAR wash is activated.
Press WATER TEMP button to set spray water temperature per
OFF, low, mid, high, mid circulation when press button each time.
Set water temp and switch water temp parameter indicator ON. If it
is under OFF status, LED indicator is OFF.
Standby mode:
1. After deactivate water temp (water temp LED OFF), enter standby
mode. Meanwhile, minimize the product energy consumption.
2. After activate water temp (water temp LED ON), exit standby
mode, water temp heating function recovered.
Kohler Co.
7
1305685-MY01-C

UV radiation range Bidet nozzle
F - Sanitize
Auto UV sterilization function will be activated and start sterilizing nozzle
when unseated for a long time. No sterilization function shall be activated
after this process in another 24hrs.
1305685-MY01-C
8
Kohler Co.

Plug power cord into socket, Bidet seat generate one short beep, wand
extend and retract once, side panel backlight blink until initialization
completion.
Water temp: OFF
Ensure if water inlet valve is OPEN.
Kohler Co.
9
1305685-MY01-C

(inside)
Wrap toilet seat with plastic sheet to prevent water splash from the
toilet during testing.
The seat is activated by user sitting. To activate the seat controls for
testing purpose, facing the toilet first, then hold seat from right front
edge about ½ position by hand, hear the seat on right side of the
rotating shaft generate one “click” (gravity induction).
The contact might not be activated
Note:
It is difficult to activate contact for light weight children.
There’s clearance between seat bumper to toilet due to moveable
structrure design.
if customer does not sit all way in.
Toilet seat downward
Clearance
Contact
Switch ON
1305685-MY01-C
10
Kohler Co.

Soft Cloth
Abrasive
Corrosive
Kohler Co.
11
1305685-MY01-C

Hold "female wash or rear wash" button, clean the spray wand with
a soft-bristled brush after wand extended completely.
Hold "female wash or rear wash" button after nozzle cleansing; wand
retracts or wait for wand to auto retract.
1305685-MY01-C
12
Kohler Co.

Kohler Co.
13
1305685-MY01-C

1305685-MY01-C
14
Kohler Co.

Open cover or add water inside the toilet might avoid the plastic parts
yellowing problem caused by backflow air from discharge pipe after
residual toilet water evaporated during long-term idle status.
Kohler Co.
15
1305685-MY01-C

A. Power failure occurred.
B. The power cord is discon-
nected.
C.Ground-Fault Circuit
Interrupt (GFCI) may be
tripped.
D.User does not enter
detecting zone.
E.Thermal protector auto
protection activated.
F.None of the above actions
correct the symptom.
A.Seat does not detect user.
B.Water supply stop closed.
C.Water supply screen
clogged.
D.None of the above actions
correct the symptom.
A.The screen is clogged.
B.Insufficient water supply
pressure.
A.Spray function auto stop
after 5min continuous
spray.
B.The seat sensor is not
detecting the user.
A,When necessary, press
CLEAN button again.
B.Refer to activating the
seat information in
"FUNCTION TEST" section.
A.Refer to "CLEAN THE
SCREEN" section.
B.Raise water pressure to
product required water
pressure range.
A．Contact seat detecting
zone.
B.Turn off power supply,
eliminate water supply
failure, reload power.
C.Refer to "CLEAN THE
SCREEN" section.
D.Contact a Kohler Service
Representative.
A.Wait until the power is
restored.
B.Insert the power cord into
an electrical outlet.
C.Reset the GFCI and
locate the problem.
D.Contact seat detecting
zone.
E.Place product within
ambient temperature for
some time.
F.Contact a Kohler Service
Representative.
2.
3.
4.
Cleansing Functions
1305685-MY01-C
16
Kohler Co.

unseated.
5
6
7
8
9
10
A. Due to room temperature
change.
A. The seat sensor is
covered by an heavy object.
A. The seat sensor might
not be able to detect you
depending on the way you're
sitting.
A. Remove heavy object
fromthe seat sensor area.
Kohler Co.
17
1305685-MY01-C

Description of Content of Hazardous Substances in Product
:Indicates that the substance in the material composition is below the
high limits of the current requirements in GB/T 26572.
10
×:
Indicates that at least one of the homogeneous substance in the
Note: the information provided is based on the supplier data and Kohler
inspection results. The product is designed not to hurt the environment.
Under current technology, all hazardous materials have been used in the
smallest amounts possible. Kohler will strive to reduce the use of these
hazardous materials used in this product.
The product “service life for environment protection” is 10 years;
Kohler Company will specify product service life based on
product characteristics. The product “service life for environment
protection” is only effective when the product is used as
described in the product specification.
Reclaim Indication
When the product exceeds service life or is unable to use after repair, do
not throw the product away in the normal trash. Please dispose the waste
electronic parts through a qualified reclamation enterprise. Make sure the
product is handled properly. Disposing of product must be done in
accordance with the local or national government law.
Statistics of Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substance or Elements
Part name
Plastic Assy. ○ ○ ○ ○ ○ ○
Control Assy. × ○ ○ ○ ○ ○
PCBA Assy. × ○ ○ ○ ○ ○
Motor Assy. × ○ ○ ○ ○ ○
Wire Harness Assy. ○ ○ ○ ○ ○ ○
Water Inlet Assy. ○ ○ ○ ○ ○ ○
Wand Assy. ○ ○ ○ ○ ○ ○
Heater Assy. ○ ○ ○ ○ ○ ○
*Remote Assy. × ○ ○ ○ ○ ○
*Battery ○ ○ ○ ○ ○ ○
Lead
(Pb)
Mercury
(Hg)
Cadmium
（Cd）
Hexavalent
Chromium
(Cr(VI)）
Polybrominated
biphenyls
（PBB）
Polybrominated
Diphenyl Ethers
（PBDE）
○
material composition is below the high limits of the current requirements
in GB/T 26572.
*: Indicate only partial product series contains this substance.
1305685-MY01-C
18
Kohler Co.

目录
安全注意事项 .....................................................................................
20
规格 ..................................................................................................... 22
谢谢您选择科勒公司 ............................................................................ 23
控制面板 .............................................................................................. 23
使用方法
.....................................................................................
24
初次使用前准备 ................................................................................... 26
功能测试 .............................................................................................. 27
维护和清洗
........................................................................................
28
清洗喷嘴
...................................................................................
29
移除座便盖
.........................................................................................
30
清洗过滤网........................................................................................... 31
长期放置不用时的维护
......................................................................
32
疑难解答
.............................................................................................
33
产品中有害物质含量的说明
...................................................................
35
Kohler Co.
19
1305685-MY01-C

安全注意事项
常
识
警告：触电或产品损伤的危险。
重要！产品损伤的危险。不要安装在水可能溅到的地方。
重要！产品损伤的危险.
重要！
注意：
危险-降低触电的危险：
警告-避免低温灼伤、触电、火灾或人身损伤
待
重要！
重要！
重要！
220V~ , 50
H z, 10A
保存这些说明
警告：触电、火灾或人身伤害的危险。
1305685-MY01-C
20
Kohler Co.
