BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2.Shut off the water supplies to the fitting.
3.Inspect the supply tubing for damage. Replace as necessary.
4.Observe local plumbing codes.
5.If possible, install this faucet before installing the tub.
6. The highest working pressure for handspray is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure
reducer is needed. The highest water and environment temperature is 60ºC. Please keep handspray, shower
head and the shower arm away from heater, or it may become damaged and cause injury to the user.
1070390-2A-C 1
16380 98125 DECK-MOUNT DIVERTER WITH HANDSPRAY
HANDLE OPERATION
INSTALLATION INSTRUCTIONS
**Color code must be specified when ordering
SERVICE PARTS Deck-Mount Diverter with Handspray
Turn diverter handle clockwise for the bath spout, turn counter-clockwise for the handspray, middle position
for both.
1070390-2A-C 4
ROUGH-IN DIMENSIONS
16380 98125 DECK-MOUNT DIVERTER WITH HANDSPRAY
Deck-Mount Diverter with Handspray
16380 98125
1142332**
Handle
870916
Rachet Ring
870205
Washer
3002772
Fixing Bush
3004794
Valve Extension
834792
Nut
3004795
Valve
831289
Washer
831289
Washer
830915
Washer
836725**
Handspray
(Only for 16380)
831289
Washer
833226
Hose
831289
Washer
834428
Hose
898324**
Hose
864342
Nut
870205
Washer
3002693**
Escutcheon
1172476
Guide
1044149**
Connection
831752
Check Valve
864342
Nut
871132
Adapter
3002319**
Escutcheon
830915
Washer
1183428**
Handspray
(Only for 98125)
1030624
Restrictor
1070390-2A-C 2
How To Install The Diverter Body
Remove the parts according to the following order: ratchet ring(2),
escutcheon(3) and washer(4). Insert the side body with washer(5) and
nut(6) through mounting hole from underside of the deck. Reinstall the
parts according to the following order: washer(4), escutcheon(3) and
ratchet ring(2). Adjust the side body's height above the deck according to
the adjustive cardboard(1). Wrench tighten the nut(6).
Note: When installing the diverter body, the end with the check valve is
towards the side of the hole for handspray.
1070390-2A-C 3
INSTALLATION
CLEANING INSTRUCTIONS
INSTALLATION CHECKOUT
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
Ensure that all connections are tight. Ensure that the handle is in the off
position. Remove the handspray(12). Open the drain. Turn on the main
supply and check for leaks. Open both hot and cold valves and run water
through the spout to remove any debris. Turn the valve off. Reinstall the
handspray.
Gently rotate the handspray head. You can get three different flows
signed on handspray head.
Put the fiber washer into connecting nut of the hose(15), then thread the nut to the end with check-valve of
diverter(18). Put the fiber washer into each connecting nut of the hose(17), then connect the Tee(16) and inlet
end of the diverter. Connect the spout and the other end of the diverter with the hose(19)(Provided with the
deck-mount bath faucet 16390). Tighten all the connecting nut.
To ensure the water flow smoothly and the handspray can be drawn out easily, the hose should avoid kinking,
twisting.
Note: The end with the check valve of diverter must be connected to the handspray. Hoses should only be
used where defined.
How To Install The Diverter Handle
Place the handle(7) onto the diverter body. The correct status of the
handle in the middle position is as shown in the figure.
How To Install The Handspray And Hoses
Remove the nut(11), washer(10). Put the rubber washer(9) into the
groove of the escutcheon(8). From underside, install the washer(10) and
nut(11) to the escutcheon. Then tighten the nut firmly.
Slide the hose(14) through escutcheon(8), and attach to the hose(15).
Put the restrictor(13) in the handspray(12) inlet. Connect the hose(14) to
the handspray.
12
2
3
5
6
4
1
12
Spout
Cold
Hot
19(100cm)
17(100cm)
16
18 15
9
7
8
10
11
8
15
14
12
13
