1) Unpack bath shell and skirt and check for any transit
damage prior to installation.
2) Position the bath shell in the desired location in the
bathroom.
3) Check that the plumbing can be connected to the
bath when in the desired location.
4) Reaching under the bath, slide the feet clips onto
the feet as they would be when the bath is clipped in.
Check that the clips are all oriented in the same
direction and then mark around the feet with a
marker pen.
1)
2)
3)
4)
INSTALLATION
INSTALLATION INSTRUCTIONS
FREE STANDING BATH
K-45346T
368 201419
-1-
·
·
·
·
Please read these instructions carefully to
familiarize yourself with the required tools, materials,
and installation sequences. Follow the sections that
pertain to your particular installation. This will help
you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Please provide adequate available space for the
bath unit in accordance with rough-in. Arrange the
location of drain in advance.
All installations must comply with council and local
authority by-laws. It is the responsibility of the installer
to ensure that the waste is made watertight by means
of silicone sealant or caulking compound.
Bath drain supplies should be arranged preliminarily
according to the selected bath.
please leave these
instructions for the consumer.
IMPORTANT:
NOTE: Bath can be installed after the wall is completed.
·
·
·
·
BEFORE YOU BEGIN
1175503-T01-A

-2-
a)a) Feet clips "clipped in"
b)
b) Feet clips "unclipped"
5)
6)
4
2
7)
2
8)
~3mm
5) Make sure that there will be room to slide the bath
out of the feet clips and that the surrounding walls
will not interfere with the installation. Also check that
the feet clips are oriented in such a way that the
bath can be slid in and out in one direction.
6) Remove the bath from position and attach the feet
clips to the floor using appropriate fixings screw.
Make sure the clips are fixed in the positions
marked in step 4. Use 2 screws to fix the clip on
diagnal position.
7) Adjust the nuts on the adjust feet, the nut should be
2~3mm lower than the top of the clip.
8) Install the bath drain on the bath.
Note: a) All clips are oriented in
the same direction.
b) Apply silicon to the hole
on the ground, then insert
the anchor.
a)
b)
6
1175503-T01-A

-3-
b)b) Floating rim joint.
9)
a)
9) If the apron on your bath has a "fixed" joint, then fix
the apron to the bath using the screw provided.
a) Fixed rim joint and screws being inserted.
10)
5mm
605mm
10) For fixed rim baths place the bath and apron upside
down on a level surface. Adjust the feet to protrude
aproximately 5mm past the skirt. Ensure the feet
are level with the floor by placing a spirit level
across them.
For floating rim joint baths adjust the feet to give a
level bath and the distance from the feet to the top
of the bath should be 605mm.
For fixed rim baths and the floating rim joint baths,
the weight of the baths should be supported by the
feet.
5mm
11)
12)
13)
11) With the skirt attached to the bath, connect the
plumbing to the bath.
12) Place the apron and bath over the feet clips and
slide the bath into the feet clips to lock the unit to
the floor. If the bath does not fit tightly into the clips,
remove the bath and adjust the nuts so that it does.
13) Fill the bath with water and test for leaks.
K-45346T
1175503-T01-A

-4-
*
*2
Mequiars 28 ( )
()
Cleaning and Care
Cleaning Acrylic Surfaces: Do not use abrasive
cleansers on any acrylic surfaces, as they will scratch
and dull the surface. Wipe out the bath after each use
to prevent a build-up of soap and scum.
If the acrylic surface becomes dull, an automotive type
rubbing compound may be used on the unit, followed
by an application of paste wax.
We recommend:
Rubbing compound mequiars mirror glaze 28 metal
polish (import product)
reen oil.
*
*
G
IMPORTANT CONSUMER INFORMATION
1175503-T01-A
