Kohler MING K-20029T-RW1 User manual

-1-
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Turn off the water supply.
The pluming installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any
particular regulations and practices, specified by the local
water company or water undertakers. The installation
should be carried out by a plumber.
Before installation carefully inspect the new fixture for any
signs of damage.
please leave instructions for the
consumer.
MING wood shelf adopts natural wood. With further
processing, its harmful emission is less than 1.5mg/L.
·This product complies with GB 24977-2010.
·
·
·
·
·
·
·
-
1.5mg/L
·GB 24977-2010
ORDERING INFORMATION
This installation covers the following products in the MING
range:
MING 700mm Open Shelf-Retro...............K-20029T-RW1
700mm ...................................K-20029T-RW1
SAFETY WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended
guidelines are given in the section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
MAINTENANCE
1.
2.
KOHLER CHINA INVESTMENT CO., LTD NO.158, JIANG CHANG SAN ROAD,
ZHABEI DISTRICT, SHANGHAI, PRC POST CODE: 200436
( ) 158 200436
©
©
Copyright Kohler China Investment Co., Ltd. 2016
2016
MING
INSTALLATION INSTRUCTIONS
700mm OPEN SHELF-RETRO
700mm
K-20029T-RW1
1294185-T01-A

-2-
ROUGHING-IN
UNIT : mm
INSTALLATION
1. Choose Desired Installation Position
Put the shelf at proper position on the cabinet (be sure not to
interfere with the faucet and the suggested height is
200mm above the cabinet), see Fig.2. Mark drilling holes
on the wall.
1.
200mm 2
Fig.2
2
Reference Value
Kohler reserves the right to change marked dimensions without prior notice.
Fig.1
1
700
107
40
Minimum
200mm
200mm
1294185-T01-A

Fig.3
3
Fig.4
4
Fig.5
5
2.
32
2
3.
14
2
2. Preparations
As shown in Fig.3, unscrew the 2 screws on bottom of the
shelf and then remove the 2 hardware.
3. Fixing
Drill holes on the marked positions (in step 1) on the wall as
shown in Fig.4. Insert expansion screws into the drilled holes
and then fix the 2 hardware on the wall.
-3-
4.
22
2
25
4. Install Shelf
Align the 2 round holes on the shelf with the 2 rods and then
push the shelf forwards. Tighten the 2 screws removed in
step 2, as shown in Fig.5.
Note: The maximum load of the shelf is 6kg. Do
not overload.
Pull out hardware
Remove screw
Step 2
2
682 1
24 0.5
24 0.5
Step 2
2
Step 1
1
Step 1
1
1294185-T01-A
