PURIST UPGRADE
INSTALLATION INSTRUCTIONS
10mm
SCREEN 1D2P, SHP, 10mm
K-99168T
-1-
13-1 528437
·
·
·
·
·
·
2
80mm
3mm/m
·
·
·
·
·
·
Before you install your shower door, please read
these instructions carefully to familiarize yourself
with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Make sure that the bath and the finished wall
material are completely and correctly installed prior
to installing your shower door. Prepare waterproof
layer to wall and floor of the showering area. It is not
allowed for any presence of electric switches and
sockets. Make sure the floor drain runs smoothly.
Before starting the door installation, lay out and
identify all the parts. Use the exploded view
illustrated on page 2 for reference.
For the installation method of customized shower
with different dimensions, please refer to this
instructions.
Tempered glass cannot be cut, drilled or
knocked by hard object. Make sure corner area
of the glass refraining from knocking so as to
cause personal injury due to broken glass.
Please install this door on Kohler
receptors or curbs (Not included). If the curb is not
Kohler-branded, please note its top width should fall
above 80mm.
The shower door requires a flat vertical
finished wall. The squareness of the wall is
recommended no more than 3 mm/m. KOHLER
Company won't take responsibility of the installation
quality.
please leave these
instructions for the consumer.
CAUTION: Risk of injury or product damage.
ATTENTION:
IMPORTANT:
1220638-T01-A

-2-
ROUGHING-IN
Unit: mm
BHSKU
K-99168T 1200-2200 1850-2000
PARTS IDENTIFICATIONPARTS IDENTIFICATION
Glass Clamp
Side Seal
Door Glass
Side Panel
Wall Channel
Hingelite Panel
Bottom Frame
Pressing Block
Purist Bracket Assy
X2
Purist Top Hinge Assy
Purist Bottom Hinge Assy
Purist Handle Assy
X1
X1 X8
X8
4mm Allen Key
4mm
3mm Allen Key
3mm
2.5mm Allen Key
2.5mm 2mm Allen Key
2mm
Cover
X2
B
H
1220638-T01-A

-3-
STEP
1
Pre-install the bottom rail with seals and
then put it onto the threshold.
STEP
2
Pre-install seals onto the wall channel and then fix it.
INSTALLATION
6mm
Wall channels
be
plumb.
MUST
Align
STEP
4
STEP
3
Insert the hingelite panel into the wall channel. Fix the wall channel and glass on the other side by
following the same steps.
1220638-T01-A

STEP
6
STEP
5
Fix the bottom hinge onto the side
panel.
Adjust the two side panels to make them about 662mm apart.
662mm
Note: When adjusting the
side panels, please clamp
as much of the hingelite
panel as possible.
Tighten the screws of the wall channels and clamp
the side panels.
STEP
7
STEP
8
-4-
Fix the upper hinge onto the door glass.
Pay attention to the
directions of the glass
panels.
662
662
<8
1220638-T01-A

STEP
9
-5-
STEP
10
STEP
11
Lift the door glass and insert into the bottom hinge.
STEP
12
Fix the clamp plate into the bottom hinge to tightly clip
the glass. Pay attention to the direction of the rubber
gasket.
Remove the upper and bottom hinge covers and the
clamp plates.
Fix the upper clamp plate. Adjust the rollers to make
the door glass level. Tighten the clamp plate.
0mm
1220638-T01-A

-6-
STEP
13
STEP
14
If 90 degree is not suitable, please turn the set screw
slightly and try again.
90
Install door handle.
STEP
15
STEP
16
Fix bottom seal.Fix door seal and side seal.
Outward-opening door
Inward-opening door
Inside
Inside
Outside
Outside
1220638-T01-A

-7-
STEP
17
STEP
18
Drill a 3.3 hole. Fix the bottom hinge and side panel
block to the bottom panel.
3.3
Adjust to a proper angle and install the handle.
X2
X2
0mm
0mm
STEP
19
STEP
20
Tighten the upper and bottom hinge covers by
tightening the screw.
Fix upper and bottom hinge covers.
1220638-T01-A

-8-
STEP
21
STEP
22
Fix other decorative covers. Apply a thin layer of silicone seal on the .bottom frame
STEP
23
Do not use the enclosure for at least 24 hours.
24
24hrs
