1260106-2A-C 1
R97009T Multifunction Handshower With Air-Geometric
97009T Multifunction Handshower With Air-Geometric
INSTALLATION INSTRUCTIONS
ROUGH-IN DIMENSIONS
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. The highest working pressure for handshower is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure reducer
is needed. The highest water and environment temperature is 60°C. Please keep handshower, shower head and
the shower arm away from heater, or it may become damaged and cause injury to the user.
BEFORE YOU BEGIN
RAINDUET
INSTALLATION
How to Install the Handshower
Flush both water supply for about one minute before the
handshower(1) is installed.
Put the screen washer(3) into the shower hose(4)
connector. Connect the handshower to shower hose.
NOTE: Don’t over tighten.
Install check valve(2) into the handshower inlet if
needed.
Connect another end of shower hose to the water
supply.
1
2
3
4
R97009T 97009T
G1/2˝
130
256

1260106-2A-C 2
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could adversely
affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
How to Operate the Handshower
Press the buttons of the handshower to
change the water flow.
How to Maintain the Handshower
Any debris or mineral build-up may cause the flow stream to become
distorted or reduce the flow rate. To remove the debris or mineral
build-up, run water through the handshower, firmly press or rub your
finger back and forth across the rubber nozzles.
Remove and clean the screen washer.
SERVICE PARTS
Champaign spray
Katalyst spray
Massage spray
77420
**Color code must be specified when ordering.
1286913
