INSTALLATION INSTRUCTIONS
L 10mm
L SHPE, SEALED, 10mm C
K-99172T
PURIST UPGRADE
-1-
, 2014
Copyright Kohler China Ltd., 2014
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
3
(
) 80mm
3mm/m
·
·
·
·
·
·
Before you install your shower door, please read
these instructions carefully to familiarize yourself
with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Make sure that the bath and the finished wall
material are completely and correctly installed prior
to installing your shower door. Prepare waterproof
layer to wall and floor of the showering area. It is not
allowed for any presence of electric switches and
sockets. Make sure the floor drain runs smoothly.
Before starting the door installation, lay out and
identify all the parts. Use the exploded view
illustrated on page 3 for reference.
For the installation method of customized shower
with different dimensions, please refer to this
instructions.
Tempered glass cannot be cut, drilled or
knocked by hard object. Make sure corner area
of the glass refraining from knocking so as to
cause personal injury due to broken glass.
Please install this door on Kohler
receptors or curbs (Not included). If the curb is not
Kohler-branded, please note its top width should be
more than 80mm.
The shower door requires a flat vertical
finished wall. The squareness of the wall is
recommended no more than 3 mm/m. KOHLER
Company won't take responsibility of the installation
quality.
please leave these
instructions for the consumer.
CAUTION: Risk of injury or product damage.
ATTENTION:
IMPORTANT:
1227978-T01-A

-2-
ROUGHING-IN
Unit: mm
BCH
SKU
K-99172T 900-1600 250-1100 2000-2500
PARTS IDENTIFICATIONPARTS IDENTIFICATION
Wall Channel
Glass Clamp
Door Glass
Bottom Frame
Hingelite Panel
Side Seal
Top Frame
Transom
Return Panel
Bottom Frame, Return Side
Top Frame, Return Side
Pressing Block
Steel Piece Assy
Purist Top Hinge Assy
Purist Bottom Hinge Assy
Purist Handle Assy
L Shape Connector
Purist Transom Pivot Assy, 1D2P
Purist Transom Pivot Assy, 1D1P
X1
X2X1 X15
X15
4mm Allen Key
4mm
3mm Allen Key
3mm
2.5mm Allen Key
2.5mm 2mm Allen Key
2mm
Cover
X6
B
c
H
1227978-T01-A

STEP
1
-3-
·
·
·
·
·
·
·
·
·
·
·
·
·
Phillips Screwdriver
Pencil
Caulk Gun
Measuring Tape
Safety Glasses
Center Punch
Hammer
Knife
Masonry Drill & 6mm Drilll Bit
Level
Drop Cloth
Materials Required
Tape
Silicone Sealant
Tools Required
·
·
·
·
·
·
·
·
·
·
·
·
·
6mm
INSTALLATION REQUIREMENTSINSTALLATION REQUIREMENTS
INSTALLATION
Disconnect the L shape connector.
STEP
2
Connect the two bottom frames with corner
connecting block.
1227978-T01-A

-4-
STEP
3
STEP
4
Pre-install seals onto the wall channel and then fix it.
0mm
Wall jamb
be
plumb.
MUST
6mm
Align
Pre-install the bottom rail with seals and then put it onto the threshold.
This instruction is based on simple
water divider of Kohler brand, which is
installed with 20mm offset. You may
choose and adjust its width as desired.
20mm
IMPORTANT
Tray must be level in all planes
or door will not install properly.
Position for Measurement
Position for Measurement
Position for Measurement
Position for Measurement
Position for Measurement
Position for Measurement
20mm offset
20mm
10mm offset
10mm
20mm offset
20mm
Kohler simple water divider Kohler classic water divider
Common water divider used by customer
20
1227978-T01-A

-5-
6mm
STEP
8
STEP
7
Insert the return panel into the wall channel.Make sure the ceiling is firm enough. Trace the line
and drill holes.
STEP
5
STEP
6
Fix the wall channel on the other side by following the
same steps.
Connect and combine top frame.
1227978-T01-A

-6-
STEP
12
STEP
11
Fix the bottom hinge onto the side panel.Insert the hingelite panel into the wall channel.
STEP
10
STEP
9
Fix the top frame onto the ceiling.Insert the top frame along the return panel.
1227978-T01-A

-7-
Fix the upper hinge onto the door glass.
STEP
15
STEP
16
Remove the upper and bottom hinge covers and the
clamp plates.
STEP
13
STEP
14
Tighten the screws of the wall channels and clamp the
side panels.
Adjust the two side panels to make them about
662mm apart.
662mm
<8
662
662
1227978-T01-A

-8-
0mm
STEP
19
Fix the upper clamp plate. Adjust the rollers to make
the door glass level. Tighten the clamp plate.
STEP
18
STEP
17
Fix the clamp plate into the bottom hinge to tightly clip
the glass. Pay attention to the direction of the rubber
gasket.
Lift the door glass and insert into the bottom hinge.
Ensure the door is fully
supported at all times.
IMPORTANT:
If 90 degree is not suitable, please turn the set screw
slightly and try again.
90
STEP
20
1227978-T01-A

-9-
STEP
21
STEP
22
Fix the transom assembly to the side panel and wall
channel. Do not tighten the screws.
Install door handle.
STEP
23
Fix door seal and side seal.
STEP
24
Fix the transom to the assembly, adjust the gaps on
each side and then tighten the screws.
Inward-opening door
Outward-opening door
Inside
Inside
Outside
Outside
1227978-T01-A

-10-
STEP
25
STEP
26
Insert side seal between side panel and top frame.
Insert decorative seal into top frame.
Insert seals into two sides of the transom panels.
Fix bottom seal.
STEP
27
STEP
28
Assemble the L shape connector and fix the pressing
block onto it.
Drill a 3.3 hole. Fix the bottom hinge and side panel
block to the bottom panel.
3.3
