Kohler K-11496X Assembly instructions

©2016 Kohler Co.
1091786-X2-A
ขอสําคัญถึงผูติดตั้ง!

ขอสังเกต:


ข้อควรระวัง:


IMPORTANT NOTICE TO INSTALLERS!:
Please leave these instructions for the consumer.
Please retain for future reference.
NOTE: The toilet pictured in the installation steps
may differ from the model being installed.
CAUTION: Turn on the water and allow
water to flow through the supply pipe to
flush the system of any debris before
connecting fill valve.
K-11496X
Position the template on the floor to ensure
the template against the wall.
Position the brackets as shown
on the template and install the
brackets.
1 2

 

1210 
Install the screw into the bracket and tighten
the screw. Do not overtighten!
9


Connect supply and turn on the water. 11  Apply silicone around base. Press down on the large button.
13 
Pull out and remove the small button.
14 
Pull out and remove the large button.
15 
Insert green rod into small hole. Insert black rod into large hole. Mark the position on both
rods along the top of the housing.
16


Slide the metal washer and the rubber
washer onto the bolts. Tighten the bolts.
Do not overtighten!
7

อยาขันแนนจนเกินไป!
Put the wax ring on to the waste pipe.
Carefully put toilet which trap outlet align
with wax ring and waste pipe.
8




อยาขันแนนจนเกินไป!
ระยะการติดตั้ง
Roughing-in
Silicone

Installation and Care Guide
ขอแนะนําการติดตั้งและการดูแลรักษา
Tape in place and drill holes.
ติดเทปกระดาษแมแบบและเจาะรู
3

Position the gasket over the
flush valve nut.
4


Position the tank the bowl.
5

Slide the hose guide onto the hose, with the flared end last. Slide the two inserts into the
flared of the hose guide.
6

200
216
Unti: mm

305
10
mm/
Draw centerline
on the floor.
ลากเสนกึ่งกลางบนพื้น
Hose Guide
 Washer

Rubber
Washer

Cap

Bushing

1/2" Supply

Remove the tape and protective pad.
แกะเทปและวัสดุกันกระแทกออก
Tank Cover
 Green Rod
 Black Rod 
Housing

Wax Ring

Waste Pipe

CAUTION: Turn on the water and allow
water to flow through the supply pipe
toflush the system of any debris before
connecting fill valve.
ขอควรระวัง:


Thread the supply hose onto fill
valve.
1/2" Supply


©2016 Kohler Co.
1091786-X2-A
Insert the push button with rods into
the holes of the push button housing
until they click into place.
19

 

Shut off the water supply.
1
Cut both rods, ensure that they are equal
the top of push button housing.
17


18


2
Note the position of
the colored button for
reinstallation.
3



Squeeze the tabs and
pull staight up on the
canister.
4


5

Flush several time and check for leaks.
Do not overtighten!
20 Adjust the water level.
21 
Install the tank cover and the seat.
22 
Reinstall the canister
so it snaps into place.
6


8
Turn on the water supply.
9
7


10


อยาขันแนนจนเกินไป!
Remove the tank cover.
Reinstall the tank cover.
Flush several times
and check for leaks.
Do not overtighten!
Remove and replace
the seal.

อยาขันแนนจนเกินไป!
Rotate the canister so that
the colored button are in
their original positions.
Press the large button onto the black rod.
Press the small button onto the green rod.
เปลี่ยนซีลยาง
Replace the Seal
WARNING: Risk of property or product damage. Do not use
in-tank cleaners in your toilet. Products containing chlorine
(calcium hypochlorite) can seriously damage fittings in the
tank. This damage can cause leakage and property damage.
For best results, keep the following in mind when caring for your product:
• Carefully read the cleaner product label to ensure the cleaner is safe
for use on the material.
• Always test your cleaning solution on an inconspicuous area before
applying to the entire surface.
• Wipe surfaces clean and rinse completely with water immediately
after cleaner application. Rinse and dry any overspray that lands on
nearby surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a soft, dampened sponge or cloth. Never use an abrasive material
such as a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the surface
for extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot dry any
water from the surface after each use.
Troubleshooting Care and Cleaning การดูแลรักษาและการทําความสะอาด
Symptoms Recommended Action
1.Poor flush. A. Adjust the tank water level to match the waterline.
B. Fully open the water supply shut-off valve.
C.
Clear obstructions from the trapway, jet, or bowl rim holes.
D Clear obstructions from the waste line.
2.No flush. A. Make sure the push button rods are in place. Adjust as
needed.
4.Long tank
fill cycle.
A. Fully open the water supply shut-off valve.
B. Clean the valve inlet, valve head, or supply line. Flush lines.
5.Noisy tank
fill cycle.
A. Partially close the water supply shut-off valve if the water
pressure to the toilet is too high. Check the toilet
performance following any such adjustment.
B. Remove dirt or obstructions from the valve head. Flush
the lines.
3.
The fill valve
turns on/off
by itself or
it runs,
allowing
water to
enter the
tank.
A. Adjust push button rods for proper slack so the flush valve
seal isn’t held off the flush valve.
B. Clean or replace the flush valve seal if it is worn, dirty, or
misaligned with the valve seat or flush valve seat is
damaged.
C. Remove the tank andtighten the flush valve nut if flush
valve gasket is leaking. Do not overtighten. If leakage
continues replace the gasket.
D. Clean the fill valve seal of debris or replace the seal
assembly.
E. Replace the fill valve if the valve float sinks.
F. Adjust the tank water level if it is too high.
ASIA EMERGING MARKETS
Asia Customer Service Centre, Kohler Asia Pacific Limited
No. 158, Jiang Chang San Road, Zhabei District, Shanghai, PRC Post Code 200436.
Tel: +(86) 21 2606 2572 Fax: +(86) 21 6107 8900
KOHLER (THAILAND) PUBLIC COMPANY LIMITED
16th FL. Jasmine City Bldg., 2 Soi Sukhumvit 23, Sukhumvit Road, Wattana, Bangkok 10110 Thailand
Call Center Tel. +(66) 2204 6222 Fax. +(66) 2204 6224
ชั้น 16 อาคารจัสมิน วิตี้, 2 ซอยสุขุมวิท 23 ถนนสุขุมวิท แขวงคลองเตยเหนือ เขตวัตนา กรุงเทพฯ10110
ลูกคาสัมพันธ โทร.0 2204 6222 โทรสาร 0 2204 6224
E-mail: [email protected]
ปญหาที่พบ วิธีการแกไข

 
 





  

 
 
 

 
 


 


 
 
ขอแนะนําการแกไขปญหาเบื้องตน
ขอควรระวัง ความเสี่ยงซึ่งอาจกอใหเกิดความเสียหายกับที่พัก
อาศัยและสุขภัณฑ 



Cutting osition

Top of housing
position


Small Button

Green Rod

Large Button

Black Rod

+
-
Turn here to adjust
the water level
if needed.
หมุนที่นี่เพื่อปรับ
ระดับนํ้าหากตองการ
Waterline

Buttons

Buttons



•   
  
• 
 
•   
 
• 
•    
 
• 
•  
  

 

 








 
