Kohler STANCE K-37467T User manual

13-1 528437
INSTALLATION INSTRUCTIONS
L 8mm
PIVOT DOOR, L-SHAPE, 8mm
K-37467T
STANCE
-1-
, 2010
Copyright Kohler China Ltd., 2010
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
3
(
) 50~80mm
3mm/m
·
·
·
·
·
·
Before you install your shower door, please read
these instructions carefully to familiarize yourself
with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Make sure that the bath and the finished wall
material are completely and correctly installed prior
to installing your shower door. Prepare waterproof
layer to wall and floor of the showering area. It is not
allowed for any presence of electric switches and
sockets. Make sure the floor drain runs smoothly.
Before starting the door installation, lay out and
identify all the parts. Use the exploded view
illustrated on page 3 for reference.
For the installation method of customized shower
with different dimensions, please refer to this
instructions.
Tempered glass cannot be cut, drilled or
knocked by hard object. Make sure corner area
of the glass refraining from knocking so as to
cause personal injury due to broken glass.
Please install this door on Kohler
receptors or curbs. (Not included). If the curb is not
Kohler-branded, please note its top width should fall
within the range of 50~80mm.
The shower door requires a flat vertical
finished wall. The squareness of the wall is
recommended no more than 3 mm/m. KOHLER
Company won t take responsibility of the installation
quality.
please leave these
instructions for the consumer.
CAUTION: Risk of injury or product damage.
ATTENTION:
IMPORTANT:
1161742-T01-A

-2-
ROUGHING-IN
Unit: mm
BCH
SKU
K-37467T 1000-1400 700-1000 1850-2000
H
B
C
800-820-2628
IMPORTANT
800-820-2628
The wall channel for the side panel is delivered to the
door assembly. Remove the panel wall channel before
installing the door, but do not remove the transit blocks.
Before installation check that all components are
correctly supplied.
If any parts are missing please ring the helpline.
PARTS IDENTIFICATIONPARTS IDENTIFICATION
1161742-T01-A

-3-
·
·
·
·
·
·
·
·
·
·
·
·
·
Phillips Screwdriver
Pencil
Caulk Gun
Measuring Tape
Safety Glasses
Center Punch
Hammer
Knife
Masonry Drill & 6mm Drilll Bit
Level
Drop Cloth
Materials Required
Tape
Silicone Sealant
Tools Required
·
·
·
·
·
·
·
·
·
·
·
·
·
6mm
INSTALLATION REQUIREMENTSINSTALLATION REQUIREMENTS
Side Seal
Side Panel
Return Panel Assy
Cover Strip
Edge Strip
Top Frame
Wall Frame
Magnetic Strip
Wall Jamb
Bottom Frame
Door Glass
Pivot Caver, Bottom
Pivot Caver, Top
Handle Assy.
Glass Shelf
X2
Pivot Pin
X2
Cover Cap
Frame Cap, Bottom
X4
Frame Cap, Top
X8
4mm Allen Key
4mm
X6
Cover
X6
X10
X6X4
1161742-T01-A

20
-4-
INSTALLATION
The wall jamb
be kept
vertical.
must
0mm
Fix the wall jamb.
STEP
3
STEP
2
Mark the wall 20mm in from the
front edge of the tray on both
sides.
20mm
STEP
1
IMPORTANT:
MUSTTray be level
along front edge.
NOTE
LH version shown. RH fitting is a mirror image of these instructions.
IMPORTANT
Tray must be level in all planes
or door will not install properly.
0mm
20
6mm
RETURN SIDE
Mark the wall 20mm in from the front edge of the tray
on both sides.
20mm
1161742-T01-A

-5-
STEP
5
STEP
4
Fix the side wall jamb.
STEP
7
STEP
6
The wall jamb
be kept
vertical.
must
0mm
6mm
The side
of the wall
frame with hole
shall face
inside.
Note:
Frames raised
shall face outside.
Note:
Fix both top and bottom frame to the side wall frame.
Insert the frame into the wall jamb. Insert the return panel assy into the wall jamb.
1161742-T01-A

STEP
8
Connect the return panel assy with the top and the bottom frame.
-6-
STEP
9
Please first insert the glass into the top frame and then into the bottom frame.
Please insert the glass in the
correct direction: the end with the
hole shall be close to the top frame
and the labeled side with arrows on
the label shall be against the wall.
1161742-T01-A

-7-
STEP
10
STEP
11
Insert the glass into the wall frame.
Lift the door into place.
Insert the pin into the base and then insert the glass door.
IMPORTANT: Ensure the door is fully supported
at all times.
Note: Please make sure
that there should be inserts
with correct directions at
both these two places.
1161742-T01-A

STEP
12
STEP
13
STEP
15
STEP
14
Remove the pivot pin assembly on top. Insert the pivot pin both into the base and the body.
Then tighten the glass and the pivot pin assembly.
Note: The pivot
pin assembly
should be
vertical after
being tightened.
Push the wall frames at both sides to make the gap even between the
glass and the top and bottom frames.
Install the handle.
-8-
1161742-T01-A

STEP
16
Tighten the wall jamb and the wall frames.
STEP
17
STEP
18
STEP
19
-9-
Fix the magnetic strips onto the door glass and the
wall frames.
When the door is closed the
magnetic strips should touch along
their length.
Install the edge strip to fix the side panel.Fix the glass and the top frame. Then insert the side
seal into the wall frame.
1161742-T01-A

STEP
20
Install the base of the glass bracket.
Note: Ensure the accessory is
positioned in a horizontal way.
6mm
Note: Ensure the
accessory is positioned
in a horizontal way.
STEP
21
Line, then fix the bracket base.
STEP
22
Fix the glass bracket.
STEP
23
-10-
Insert the cover seal to the top frame.
1161742-T01-A
