Kohler STRAYT 37331T User manual

所有的资料是按最新出版的产品资料编写而成。科
勒公司保留任何时候不经通知即可改变产品特性、
包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
注意事项：
1. 一定要先彻底冲洗供水管以清除管道中的杂质。
2. 尽可能在安装脸盆之前安装水龙头。
3. 检查供水管有无损坏和漏水。如需要，进行替换
和维修。
4. 遵守当地管路安装条例。
5. 切断供水管路。
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication. Kohler
Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer.
They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove
debris.
2. If possible, install this faucet before installing the
lavatory.
3. Inspect the supply tubing for damage and leakage.
Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
37331T 8″脸盆龙头
安装之前
使用说明 HANDLE OPERATION
INSTALLATION INSTRUCTIONS
安装说明书
Widespread Lavatory Faucet
安装尺寸 ROUGH-IN DIMENSIONS
顺时针旋转右把手为开，逆时针旋转左把手为开。
Right handle opens with turning clockwise. Left handle
opens with turning anticlockwise.
1167539-2-E 1
Ø32~Ø38
G1/2"
Ø30~Ø42
10~45
46x46
200~750
65 Min
65 最小
50x50
15º
135
115
138
88
74.5
清洗说明
安装结果检查
INSTALLATION CHECKOUT
适用于所有加工处理过的表面：以中性肥皂水清洗
镀层表面，再以干净的软布彻底擦干整个表面，许
多清洁剂，比如氨水、去污粉及洁厕灵等，会对电
镀表面造成伤害，切忌使用。
有磨损性的清洁用具或清洁剂也不可使用于科勒牌
的水龙头及其配件上。
1167539-2-E 4
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such
as ammonia, chlorine, toilet cleaner etc. which could
adversely affect the finish and are not recommended
for cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and fittings.
34
检查并确保所有的衔接处都已拧紧。
确保把手在关闭位置。
打开排水系统和主要供水源，检查并
修理有漏水的接口。
用工具(34)将起泡器(35)拆下，打开龙
头的冷热水，让水流出约一分钟以清
除杂质。冲洗起泡器，关闭龙头，重
新装回起泡器。
Ensure that all connections are
tightened and the handles are in the off
position.
Open the drain. Turn on main water
supply and check for leaks. Repair as
required.
Remove the aerator(35) with the key
(34). Turn the faucet handle on. Run
hot and cold water through the spout for
about one minute to remove any debris.
Remove debris from the aerator. Shut
off the faucet and reinstall the aerator.
35
斯磊
STRAYT
Ø54
Ø32
Ø36.5
Ø31.75
108
98
176.5

1167539-2-E 2
1167539-2-E 3
安装步骤 INSTALLATION
如何安装阀体和把手
从阀体组件(8)上取下螺母(9)。将O型
圈(10)嵌入装饰盖(11)底部凹槽。从脸
盆下方，将阀体组件穿过安装孔(注：
面向龙头时，贴有红圆的阀体组件装
在左侧，且安装之前阀芯处于关闭状
态。)。
将装饰盖装到每个阀体组件上。将螺
母(9)旋紧到阀体组件上，以固定装饰
盖。用六角扳手(12)旋松把手(13)内螺
钉(14)，将把手按在加长齿套(15)上(
注：面向龙头时，带有红色标记的把
手应装在左侧，且安装之前阀芯处于
关闭状态)。用六角扳手旋紧螺钉(14)
固定把手。用扳手锁紧螺母(16)。
把软管接到阀体组件上。当面对龙头
时，左边软管与左边阀体组件连接，
右边软管与右边阀体组件连接。
How to Install The Side Bodies
And The Handles
Remove the nut(9) from each side body
(8). Put the o-rings(10) into groove on
the escutcheons(11) bottom. Insert side
bodies through mounting holes from
bottom of the lavatory(NOTE: The valve
body with red dot should be installed on
the left when facing the front of the
faucet, and the valves are in the closed
position before installing them. ).
Install the escutcheon onto each side
body. Tighten the nut(9) onto each side
body to secure the escutcheon. Loosen
the screws(14) in the handles(13) with
the hex wrench(12), then press the
handles onto the extension stems
(NOTE: The handle with red mark
should be installed on the left when
facing the front of the faucet, and the
valves are in the closed position before
installing them. ). Tighten the screws
(14) to secure the handles with the hex
wrench. Wrench tighten the nuts(16).
Attach the hoses to the side bodies.
When facing the front of the faucet, the
left hose connects to the left side body,
the right hose connects to the right side
body.
9
33
31
30
11
27
28
29
15
12
13
14
16
如何安装排水器
将止水塞(17)、法兰盘(18)及垫片(19)
从排水本体(20)上取下，在法兰盘底面
套上垫片。从排水本体上,取下尾管
(21)。在尾管螺纹处缠绕足以密封的密
封胶带或涂合适的密封胶，将排水本
体装回。把排水本体带垫圈(22)、钢垫
(23)及锁紧螺母(24)从脸盆下方插入，
排水杆洞口(25)朝后方。
注意：如果需要，可直接在排水器法
兰盘(18)底面沿周围涂一圈密封油灰，
而不使用垫片(19)。
把排水器法兰盘旋入排水本体中。从
下方用手拧紧锁紧螺母。把止水塞放
入排水本体中，调整以使止水塞末端
孔(26)靠近并对正排水杆的洞口。
将固定螺母(27)取下，把塑料垫圈(28)
及固定螺母装在球杆(29)上，再把球杆
组件插入排水杆的洞口中并穿过止水
塞，拧紧固定螺母。
确保球杆指向脸盆后方，并拧紧排水
本体上的锁紧螺母，去除多余油灰。
注意：在锁紧螺母拧紧后，不可调整
排水本体的位置，否则会破坏油灰密
封。
用“V”形夹(30)将联杆(31)连接到球
杆组件上，将提拉杆(32)通过出水口背
部提拉孔插入联杆孔中，调整提拉杆
的高度，使得排水器在关闭状态下，
提拉杆头距龙头安装面约72mm。
将球杆下推到排水器全开的位置。拧
紧手捻螺丝(33)。
How to Install The Drain
Take off the stopper(17), drain flange
(18) and washer(19) from drain
body(20). Slide washer onto the
underside of the drain flange. Take off
the tailpiece(21) from the drain body.
Supply enough tape or sealant to
tailpiece thread. Reinstall the tailpiece.
With the gasket(22), steel washer(23)
and locknut(24) on the drain body,
insert it into the bidet from underside
with the drain lever hole(25) facing the
rear.
NOTE: If needed apply a ring of
plumbers putty around the underside of
the drain flange(18), instead of using
washer(19).
Thread the drain flange onto the drain
body. Tighten the locknut by hand from
the underside. Place stopper into drain
body aligning the flat side of stopper
hole(26) with the drain lever hole.
Remove the retaining nut(27). Fit the
plastic washer(28) and retaining nut
onto the ball lever(29). Insert the ball
lever assembly into the drain lever hole
and through the stopper hole. Tighten
the retaining nut.
Be sure that the ball lever rod points to
the back of the bidet, tighten the
locknut on the drain body. Remove any
excess putty.
NOTE: Do not reposition the drain after
the locknut is tightened, or you may
break the putty seal.
Connect the link(31) onto ball lever rod
with ‘V’-clip(30). Insert the lift rod(32)
into the link of the drain through the hole
on the rear of the spout. Position the lift
rod, ensure the distance between the lift
rod knob and the body is about 72mm.
Push the ball lever rod down to the
open position. Tighten thumb screw(33).
26
21
25 23
18
22
24
17
18
19
20
32
How To Install The Spout
Screw the stud(1) to the thread hole on
the bottom of faucet. Insert the lift rod(2)
into the hole at the rear of the body
assembly. Put the washer(3) into groove
on the bottom of escutcheon(5) through
the flexible hoses(4) and the stud. Insert
hoses and stud into the central hole of
lavatory. Position the faucet. From
underside of the lavatory, fit the brackets
(6)(Rubber washer is on the top) onto
the stud. Secure the faucet by
tightening nuts(7).
如何安装出水口
将安装组件中的固定螺杆(1)装在龙头
底部孔中，将提拉杆(2)插入水龙头后
侧小孔中，将垫片(3)通过软管(4)和固
定螺杆放入装饰盖(5)底部槽中，将软
管和固定螺杆插入脸盆中孔。调整好
水龙头的位置。从脸盆下方将托架(6)
(橡胶垫片放在上面)套在固定螺杆上，
锁紧螺母(7)以固定水龙头。
3
1
2
5
6
7
4
8
10

1167539-2-E 5
**订购时请说明颜色编号
**Color code must be specified when ordering
SERVICE PARTS
零 件 图
Widespread Lavatory Faucet
37331T 8″脸盆龙头
Handle(热)
把手
1162050**
(仅用于37331T-4)
Handle(热)
把手
1188272**
(仅用于37331T-4DPR)
1192952**
(仅用于37331T-4DPW)
837206
Valve
阀芯
78125
Adapter
齿套
1041022
Screw
螺钉
1162052**
Escutcheon
装饰盖
830915
Washer
垫片 864342
Nut
螺母
880062
Side Body Kit
阀体组件
1041022
Screw
螺钉
1021514
Extension Stem
加长齿套
1040731
Screw
螺钉
1167441**
Nut
螺母
1167543**
Lift Rod Kit
提拉杆
Handle(冷)
把手
1188276**
(仅用于37331T-4DPR)
1192956**
(仅用于37331T-4DPW)
1088637
Aerator
起泡器
1162051**
Escutcheon
装饰盖
834704
Hardware kit
安装组件
1024405
Hose
软管
1041022
Screw
螺钉
1162052**
Escutcheon
装饰盖
837207
Valve
阀芯
78125
Adapter
齿套
Handle(冷)
把手
1162049**
(仅用于37331T-4)
830915
Washer
垫片
864342
Nut
螺母
880062
Side Body Kit
阀体组件
1041022
Screw
螺钉
1182548
Screw
螺钉
1010167
O-ring
O型圈
1167441**
Nut
螺母
1010167
O-ring
O型圈
1040731
Screw
螺钉
1021514
Extension Stem
加长齿套
833730
Hex Wrench
六角扳手
3006147
Key
工具
斯磊
STRAYT
880037
Link Kit
排水联动组件
1080817
O-ring
O型圈
880406
Washer
垫片
880008**
Stopper
止水塞
834753**
Pop Up Drain
提拉排水组件
