BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
The slide bar 72798T must be used with slide bar trim 72799T.
INSTALLATION INSTRUCTIONS
72798T Slider Bar
72799T Slider Bar Trim
ROUGH-IN DIMENSIONS
34
25
Ø57
34
72798T
72799T
64
68
80
712
779
ARTIFACTS

1271403-2A-A 2 1271403-2A-A 3
INSTALLATION
Select a suitable location to drill two holes on the finished
wall according to the rough-in dimensions and diameter of
the anchor(1), their distance is 712mm. Press the anchors
into the holes.
Apply a ring of plumbers putty or sealant into the groove on
the backside of the slide bar trim. Position the trim and
post(3) over the mounting hole. Secure the trim and post to
the wall with a screw(4). Loosely tighten the screw.
Hold the slide bar up against the posts. Adjust the position
of the posts until the slide bar fits snug against the curved
cutout of the posts. Remove the slide bar and tighten the
screws to secure the posts.
Thread the pin(5) into the post, tighten with a flat blade
screwdriver.
Line up the hole of each lock assembly(6) with the holes of
the slide bar. If needed, use a screwdriver to adjust the
position of the lock assemblies.
Align the pins with the holes in the slide bar and slide bar
locks. Insert the pins through the slide bar and lock
assemblies.
Secure the slide bar by tightening the setscrews(7) into the
lock assemblies． Press the cap(8) into each end of the
slide bar.
5
4
7
8
3
2
1
712mm
6
7
8
6
5
4
3
2
1
SERVICE PARTS
INSTALLATION CHECKOUT
Ensure that all coupling nuts are tightened.
The height of handshower holder can be adjusted by
pressing the pinch cock and sliding up and down.
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
Pinch cock
ARTIFACTS
72798T Slider Bar
72799T Slider Bar Trim
72798T:1061576
72798T:1271405**
72798T:1033797**
72798T:1033800**
72798T:1040645**
72798T:1033799**
72799T:1199644**
72798T:1199646**
72798T:1033803
72798T:34300
72798T:34300
**Color code must be specified when ordering.
NOTE: For all Asia pacific regions (excluding China) add SP (SPxxxxxxx**) in front of the part number when ordering.
