Kohler Strayt User manual

All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove any debris.
2. Do not remove the plaster guard from the valve body until instructed to.
3. Install valve 880A (or 98309A-CP for NZ) according to the rough-in dimensions of 37336A-4. Install valve
882A (or 98310A-CP for NZ) according to the rough-in dimensions of 37335A-4. For additional valve
installation instructions refer to the 40mm valve install guide (1071635-AN2-A).
4. All installations should comply with the relevant requirements of AS/NZS 3500.
5. 37335A-4 and 37336A-4 are trim only. The mixing valve is sold separately.
1154953-AN2-A 15/10/12
Bath / Shower mixer with diverter: 37335A-4
Bath / Shower mixer without diverter: 37336A-4
BEFORE YOU BEGIN
INSTALLATION INSTRUCTIONS
ROUGH-IN DIMENSIONS
Wall Mount Single Lever Mixers
STRAYT
SHOWER / BATH TAPWARE
1
37335A-4
37336A-4
54
166
32~42
or 40~49or 40~49
65
Finished Wall
135
83
110
54
166
Finished Wall
135
83
110
32~42
Rc 1/2” inlet
& outlet ports
Rc 1/2” inlet
& outlet ports

Note: Install valve 880A (or 98309A-CP for NZ) according to the rough-
in dimensions of 37336A-4. Install valve 882A (or 98310A-CP for NZ)
according to the rough-in dimensions of 37335A-4.
For additional valve installation instructions refer to the 40mm valve
install guide (1071635-AN2-A)
1.) After the finished wall has been completed, remove the plastic
guard(1).
NOTE: Discard screws(2).
2.) Slide the cover kit(4) onto the valve(3) with the plugs(5) facing out.
Note: Don’t squeeze out the rings(6,7). Push it firmly against the wall
and secure it with the screws(8).
3.) Slide the faceplate(9) onto the valve with the slots(10) on the bottom.
Align the faceplate with the cover plugs and push it against the wall.
4.) Slide sleeve(11) onto the valve(3). Screw the bonnet(12) onto the
valve. Choose the short or long sleeve depending on the valve’s
rough-in depth.
5.) To install the handle(13), slide the handle onto the valve stem.
Tighten the setscrew(15) with the hex wrench(14) and assemble
the plug button(16) into the hole.
INSTALLATION
CLEANING INSTRUCTIONS
SPARE PARTS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with a clean
soft cloth. Many cleaners may contain such chemicals as ammonia, chlorine, toilet chemicals etc. which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler fittings.
1154953-AN2-2 15/10/12
2
**Color code must be specified when ordering.
1154952-A**
Faceplate
3007134
Cover Kit
1
2
4
7
5
6
3
13
10 12
11
14
15
8
3007136
Cover Kit
(only for 37336A-4)
(only for 37336A-4)
(only for 37335A-4)
(only for 37335A-4)
(only for 37335A-4)
3010602
Screw 1154951-A**
Faceplate
Handle
1154948**
833438
Screw
833730
Hex Wrench
834705**
Plug
1154949**
(Long)
1154950**
(Short)
Sleeve
3006902
Ring
3006903
Ring
16
3006923**
Bonnet
3010602
Screw
9
