Kohler K-3901 Assembly instructions

Homeowners Guide
Toilet
Français, page “Français-1”
Español, página “Español-1”
K-3901
1212876-5-F

IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USING
When using electrical products, especially when children are present, basic safety precautions should
always be followed, including the following:
CAUTION: Risk of personal injury. Do not remove the UV lamp protective cover. Eye damage
may result from viewing the UV light directly. Always be certain the lamp is off before opening the
protective cover. The flashing nightlight indicates the UV lamp is in operation.
CAUTION: Risk of personal injury. Replacement of the UV lamp must only be performed by
qualified service personnel.
DANGER: Risk of electric shock. Connect only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI)*.
*Outside North America, this device may be known as a Residual Current Device (RCD).
WARNING: To reduce the risk of burns, electrocution, fire, or injury to persons:
Close supervision is necessary when this product is used by or near children, the elderly, or
invalids. Adjust the temperature of the seat for the elderly, those who are incapacitated, or persons
with sensitive skin.
Use this product only for its intended use as described in this manual. Do not use attachments not
recommended by Kohler Co.
Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has
been dropped, damaged, or dropped into water. Return the product for examination and repair.
Keep the cord away from heated surfaces.
Never block the air openings of the product. Keep the air openings free of lint, hair, and the like.
Never use while sleeping or drowsy.
Never drop or insert any object into any opening or hose.
Do not use outdoors or operate where aerosol spray products are being used or where oxygen is
being administered.
Connect this product to a properly grounded outlet only. See the ″Grounding instructions″section.
This product conforms to applicable provisions of US 21 CFR, Chapter 1, Subchapter J, Radiological
Health.
SAVE THESE INSTRUCTIONS
Important Information
SKU Electrical Water Supply Pressure Listings
K-3901 120 V, 15/A min., 20 A
recommended, 60 Hz, 1780 W 30 psi (206 kPa) min. - 80 psi (551 kPa) max. cUL, cUPC, NOM
1212876-5-F 2 Kohler Co.

Grounding Instructions
WARNING: Risk of electric shock, fire, or personal injury. This product must be grounded and
connected only to a dedicated, nominal 120 VAC, 60 Hz circuit protected by a minimum 15 A
Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device (RCD).
This product should be grounded. In the event of an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire for the electric current. This product is equipped
with a cord having a grounding wire with a grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded.
DANGER: Risk of electric shock. Improper use of the grounding plug can result in a risk of
electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to either
flat blade terminal. The wire with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire.
Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the product is properly grounded.
Do not use an extension cord with this product.
Grounded
Outlet
Grounding
Plug
Kohler Co. 3 1212876-5-F

Features
IMPORTANT! For proper operation, confirm that the remote control and toilet are linked. To ensure the
remote control and toilet are linked, see the remote control Homeowners Guide.
NOTE: Many of the features can be adjusted, enabled, or disabled using the remote control. Specific
directions for these procedures are listed later in this manual.
NOTE: There are different remote control options. The premium remote control is shown.
Flushing and Operation Features
Two Flushing Options - (not shown) Users may choose [flush-eco] for a 0.6 gallon (2.27 L) or
[flush-full] for a 1.28 gallon (4.5 L) flush.
Automatic Flushing - (not shown) When enabled, this feature automatically flushes the toilet after
the user stands up, lowers the seat, or leaves the area 60 seconds after use. The toilet arrives with
this feature enabled.
Front Motion Sensor - When auto open/close [near],[medium],or[far] is enabled, the cover opens
automatically when the front motion sensor is activated. The toilet arrives with this feature enabled,
set at [near].
Auto Open Side Sensor - When enabled, this feature automatically opens the seat when the motion
sensor light on the right side of the toilet senses movement. This feature is automatically enabled
when the front sensor is enabled. The side sensor can also be enabled and the front sensor disabled
by selecting [side sensor - lid only] or [side sensor - lid and ring]. A blue light on the right side of
the toilet, which is projected on the floor, allows the seat to be raised and lowered without touching
the toilet. Break the beam of light using your foot to open or close the seat. The toilet arrives with
this feature enabled.
Animated Flush - When animated flush is enabled a graphic will appear on the remote control
detailing the progress of the flushing process. The toilet arrives with this feature enabled.
Manual Controls
Auto Open Ring
Motion Sensor
Air Outlet -
Feet Heater
Remote
Control
Docking
Station
AUX In
Ambient Light
Bowl Light
Lid
Ring
Cleansing Wand
1212876-5-F 4 Kohler Co.

Features (cont.)
Toilet Sleep Mode - The toilet can be programmed to conserve energy. When toilet sleep mode is
enabled the toilet will enter and exit an energy conservation mode at the times programmed. The
toilet arrives with this feature disabled.
Deodorizer - The deodorizer eliminates or reduces unpleasant odors when enabled. It will begin
operation when the user sits down. The toilet arrives with the deodorizer feature enabled.
Manual Controls - Allows the user to control basic toilet features without the remote control.
Cleansing Features
Front/Rear Wash - Front and rear wash feature adjustable positioning, adjustable water temperature,
adjustable water pressure, and pulsate and oscillate water action.
Dryer - The dryer features adjustable air temperature and pressure.
Cleansing Wand - The cleansing wand features self cleaning UV options, lighted tip, and removable
spray tip for servicing. The wand can be manually extended for cleaning using the remote control.
Lighting
Ambient Light - Light located on the back sides of the toilet. Gently illuminates the area around the
toilet. Color of the light and brightness is adjustable. The lights can be set to cycle through the
different colors, display a different color each day, or stay the same color. Factory default color is
white.
Bowl Light - Light located on the end of the cleansing wand that illuminates the bowl when the
toilet is activated. The light will only activate when the room is dark. The toilet arrives with this
feature enabled.
Welcome Light- When enabled, the ambient light will automatically turn on when the toilet is
activated. The toilet arrives with this feature enabled.
Night Light - The bowl light and ambient light will automatically turn on in low light conditions
when this feature is enabled. The toilet arrives with this feature enabled.
Heating
Heated Feet - When activated, warm air emanates from the air outlet to warm the users’ feet.
Heated Seat - (not shown) When activated, the seat features an adjustable heating option that will
keep the seat warm. The toilet arrives with this feature enabled.
Music and Sounds
Music - Your toilet is equipped with FM radio, pre-loaded music, Bluetooth
®
capability, SD card
capability, and the ability to play music from external sources.
Welcome Music - When enabled, welcome music will play upon activation of the toilet. The toilet
arrives with this feature disabled.
Key Sounds - When enabled, sounds will help indicate the activation of some toilet features.
NOTE: MP3 and WMA formats are supported by the software. MP4 files are not supported and will not
work.
Aux in - Any type of standard auxiliary music player can be plugged in at one of the two locations
on the docking station or the back of the toilet. Music from the player can be played on the toilet.
Bluetooth - Music can be streamed from any Bluetooth enabled device.
SD Card - An SD card loaded with music files can be inserted in the slot on the back of the toilet.
Maximum capacity is 16 GB.
Cleaning
Automatic Wand Cleansing - Wand UV light cleaning can be programmed using your remote
control. This feature comes enabled, scheduled to occur at 2:00 am every day.
Kohler Co. 5 1212876-5-F

Features (cont.)
Backup Power
Battery Backup - A battery pack located on the back of the toilet is designed to provide emergency
power in the event of a power outage. The battery pack requires eight AA batteries.
1212876-5-F 6 Kohler Co.

Features - Back Panel
Power Button - Turns the power on and off.
Auxiliary Input - Plug in any standard external music source to play the music through the
speakers.
Deodorizer - The deodorizer eliminates or reduces unpleasant odors when enabled. It will begin
operation when the user sits down. The toilet arrives with the deodorizer feature enabled. The
deodorizer cartridge should be replaced when it loses effectiveness.
Speakers - Internal speakers.
Supply Hose - Water supply hose.
Air Filter - Filters air before it enters the blower for the dryer and heated feet option. The filter
should be checked once every six months and cleaned if needed.
External Speaker Output - Allows additional speakers to be connected to the system.
Docking Station Power Cord Connection - Docking station power is connected here.
External Antenna - Optional FM antenna (included) is connected here.
SD Card Slot - Insert an SD card loaded with music in the slot.
USB Connection - USB port for authorized personnel to update the on-board software.
Backup Battery - Holds eight AA batteries that will flush the toilet in the event of a power outage.
Power Button
Deodorizer
Docking Station
Power Cord Connection
External Speaker Outlets Air Filter
Supply Hose
Speakers
Auxiliary Input
External Antenna
Battery Backup
USB Port
SD Card Slot
Kohler Co. 7 1212876-5-F

Manual Operation
The basic functions of the toilet can be controlled manually using the buttons located on the right side of
toilet.
Cover and Seat - The cover and seat can be lifted manually to open and close them. Gently lift the
cover and seat to open them.
Flushing - Push the flush button to flush the toilet manually.
NOTE: When the manual cleansing features are activated using the manual buttons, they will default to
the middle temperature, pressure, and position settings.
Front Wash - Push the front wash button to activate the cleansing wand for front wash.
Rear Wash - Push the rear wash button to activate the cleansing wand for rear wash.
Dryer - Push the dryer button to activate the dryer.
Cleaning the Cleansing Wand - Press and hold the front or rear button for 2 seconds to extend the
wand for manual cleaning. Repeat to retract the wand.
Care and Cleaning
WARNING: Risk of property or product damage. Do not use in-tank cleaners in your toilet.
Products containing chlorine (calcium hypochlorite) can seriously damage fittings in the tank. This
damage can cause leakage and property damage.
Kohler Co. shall not be responsible or liable for any tank fitting damage caused by the use of cleaners
containing chlorine (calcium hypochlorite).
For best results, keep the following in mind when caring for your KOHLER product:
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
Dryer
Rear Wash
Front Wash
Flush
1212876-5-F 8 Kohler Co.

Care and Cleaning (cont.)
•For Artist Edition Toilets: Treat your decorative product just as you would treat your fine china.
DO NOT use bristle brushes or abrasive-backed sponges. They will scratch decorative surfaces. Use
only warm water to clean. Dry with a cotton cloth or soft sponge.
For detailed cleaning information and products to consider, visit kohler.com/clean. To order Care & Cleaning
information, call 1-800-456-4537.
Kohler Co. 9 1212876-5-F

Servicing the Filters
Servicing the Deodorizer
NOTE: The deodorizer should be replaced every 2 years or when its performance is decreasing.
Remove the deodorizer cartridge assembly by grasping it and gently pulling it out.
Remove the filter from the housing by pushing it through the back side from the vented side.
Insert the replacement filter into the housing.
Reinstall the deodorizer cartridge assembly.
Servicing the Air Filter
NOTE: This procedure should be performed once a year or more often as needed.
Remove the air filter cover.
Remove the air filter.
Clean the air filter using water.
Dry the air filter.
Reinstall the air filter.
Reinstall the air filter cover.
Servicing the Inlet Screen
NOTE: This procedure should be performed once every 6 months.
Air Filter Cover Air Filter Inlet Screen
Deodorizer
Cartridge
Filter
1212876-5-F 10 Kohler Co.
