Kohler K-77780KR-0 Assembly instructions

Homeowners Guide
사용자 가이드
ＫＡＲＩＮＧ ２．０ ＩＮＴＥＬＬＩＧＥＮＴ ＴＯＩＬＥＴ
K-77780KR-0
KOHLER CHINA INVESTMENT CO., LTD.
NO.158, JIANG CHANG SAN ROAD, JING'AN DISTRICT,
SHANGHAI, PRC POST CODE: 200436
MANUFACTURER: SHANGHAI KOHLER ELECTRONICS., LTD.
NO. 1955, FENGXIANG ROAD, BAOSHAN AREA, SHANGHAI, PRC
POST CODE : 20044
21-39
English page 2-20
한글 페이지
1308458-KR01-B

Contents
1308458-KR01-B 2 Kohler Co.
Cautions and warning…………………………………………………………………………………............... 3
5
Overall diagram…………………………………………………………………………………………….........6
Preparations before the first use………………………………………………………………………….....7
Function for opening/closing of cover/seat…………………………………………………..………............ 8
Flushing of toilet…………………………………………………………………………………………......... 9
Auxiliary keyboard function……………………………………………………………………………… ..... 12
12
12
13
......13
Long time seated on indication function……………………………………………………………………… 14
Maintenance and cleaning………………………………………………………………………………………14
Trouble shooting………………………………………………………………………………………………….19
Specification……………………………………………………………………………………………………….
Thank you for choosing Kohler Company……………………………………………………………………... 6
..
...
……………………………………………………………………… .
…………………………………………………………………………….13
Water purification ……………………………………………………………………………………………….13
UV sterilization function………………………………………………………………………………………….12
Sterilization

Kohler Co. 3 1308458-KR01-B
Cautions and Warnings
6DYHWKLVLQVWUXFWLRQ
Warning: 5LVNRIHOHFWULFVKRFNRUSURGXFWGDPDJH'RQRWLPPHUVHWKHSURGXFWLQWRZDWHU
Warning:5LVNRIHOHFWULFVKRFNILUHRUSHUVRQDOLQMXU\7KLVSURGXFWPXVWEHLQVWDOOHGVDIHO\&RQQHFW
RQO\WRGHGLFDWHG9a+]$FLUFXLWSURWHFWHGE\*URXQG)DXOW&LUFXLW,QWHUUXSWHUV*)&,¶VRU
(DUWK/HDNDJH&LUFXLW%UHDNHUV(/&%¶V
Important! 5LVNRISURGXFWGDPDJH'RQRWLQVWDOODWDSODFHZKHUHLWPD\EHVSODVKHGE\ZDWHU
Important! 5LVNRISURGXFWGDPDJH'RQRWLQVWDOOWKHSURGXFWDWDSODFHZLWKH[FHVVLYHKXPLGLW\ZKHUH
PRLVWXUHPD\FRQGHQVHDWWKHVXUIDFHRIWKHSURGXFW3OHDVHPDLQWDLQWKDWWKHXVDJHHQYLURQPHQWLVXQGHU
DGHTXDWHYHQWLODWLRQVRDVWRSUHYHQWGDPDJHWRHOHFWURQLFFRPSRQHQWV
Important! 5LVNRISURGXFWGDPDJHRUSURSHUW\ORVV:DWHUOHDNDJHPD\KDSSHQLIWKHZDWHUSLSH
FRQQHFWRULVSXOOHGRUSXVKHGZLWKH[FHVVLYHIRUFH
Important! 5LVNRISURGXFWGDPDJH7KHSURGXFWPD\EHGDPDJHGLIWKHQR]]OHLVDSSOLHGZLWK
H[FHVVLYHIRUFH
Important! 5LVNRISURGXFWGDPDJH7KHSDUWRIWKHSLSHZKHUHZDWHUPD\EHIUR]HQVKRXOGEHSURWHFWHGE\
WKHUPDOLQVXODWLRQ$Q\ZDWHUOHIWLQWKHSURGXFWPD\EHIUR]HQGXULQJWKHZLQWHUVHDVRQ3OHDVHNHHSWKH
SURGXFWLQURRPWHPSHUDWXUHEHIRUHUHLQVWDOODWLRQRUXVDJH
Important! 5LVNRISURGXFWGDPDJH7KHSRZHUVKDOOQRWEHFRQQHFWHGEHIRUHWKHZRUNLVILQLVKHG
2WKHUZLVHLWPD\OHDGWRSURGXFWIDLOXUH
Attention:7KH WKHUPDO SURWHFWRU PD\ EH RXW RI RUGHU GXULQJ VWRUDJH RU WUDQVSRUWDWLRQ LQ ZDUPFOLPDWH
ZKLFKFDQOHDGWRSURGXFWIDLOXUH3OHDVHHQVXUHWKHSURGXFWFRROVWRURRPWHPSHUDWXUHEHIRUH
UHLQVWDOODWLRQRUXVDJH
:KHQDQHOHFWULFDOSURGXFWLVXVHGHVSHFLDOO\ZKHQFKLOGUHQDUHQHDUWKHIROORZLQJEDVLFVDIHW\
SUHFDXWLRQVVKDOOEHDELGHGE\
Danger-Reduce risk of electric shock:
□Children, elders or those with disabilities from their body, sensitivity or mental disabilities or lacking of
common sense should not use or get close to this product unless under close tutelage. Children are not
allowed to use or touch this product. Do not leave children alone in a room with such product.
Warning:5LVNRISURGXFWGDPDJH'RQRWWKURZLQWRWKHWRLOHWZKDWWKDWZLOOFDXVHWKHWRLOHWWR
EORFNVXFKDVQHZVSDSHUVDQGVDQLWDU\WRZHO'RQRWEXPSWKHYLWUHRXVFKLQDZLWKJUHDWIRUFHDVLW
ZLOOFDXVHGDPDJHDQGOHDNLQJ
WARNING - To reduce the risk of low grade burns, electric shock, fire or injury to persons:
Do not place or store this appliance where it can fall or be pulled into a bath or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug immediately.
Warning: Do not use any hard setting material (cement mortar) while installing the toilet. Thermal
expansion of hard setting material (cement mortar) will damage or crash the feet of toilet. Kohler will
not be responsible for any damage because of using hard setting material (cement mortar) for toilet
installation.

1308458-KR01-B 4 Kohler Co.
&$87,216$1':$51,1*6
□)RUWKRVHFKLOGUHQDQGWKHHOGHUO\ZKRDUHXQDEOHWRDGMXVWWKHWHPSHUDWXUHWKH\VKRXOGDVNIRU
KHOSWRDGMXVWVHDWWHPSZDWHUWHPSDQGZLQGWHPSRIWRLOHWFRYHUWRSURSHUJHDUV
□UHFRPPHQGHGE\.RKOHU&R
'RQRWOHDQRQFRYHUZKHQXVHWKLVDSSOLDQFHWRSUHYHQWSURGXFWIURPGDPDJH
□
WKHSURIHVVLRQDOVIURPLWVPDLQWHQDQFHGHSDUWPHQWRUVLPLODUGHSDUWPHQWVWRDYRLGWKHRFFXUUHQFHRIGDQJHU
□
□
□
□
EHHQGURSSHGLQWRZDWHU
,QVWDOOWKLVSURGXFWSURSHUO\E\IROORZLQJWKHLQVWDOODWLRQSURFHGXUH
7KLVSURGXFWVKDOOEHUHSDLUHGE\SURIHVVLRQDOVRQO\7KHZDUUDQW\ZLOOEHFRPHLQYDOLGLI\RXWU\WRUHSDLU
WKLVSURGXFWE\\RXUVHOI
□
□
:KHQLQVWDOOWKHSURGXFWLQWKHURRPDVWRSYDOYHVKDOOEHLQVWDOOHGLQDFORVHSUR[LPLW\)RUHPHUJHQF\
FLUFXPVWDQFHVWKHZDWHULQOHWYDOYHVKDOOEHVWRSSHGZLWKRXWXVLQJDQ\WRROVRWKHUZLVHXQH[SHFWHGIDLOXUH
PD\FDXVHWKHORVVWRWKHFXVWRPHU
.HHSSRZHUOLQHIDUIURPKHDWHGVXUIDFH
'RQRWGURSRULQVHUWDQ\VXEVWDQFHWRSLSHOLQHRUWKHRSHQLQJ
'RQRWXVHWKLVSURGXFWRXWGRRURULQDSODFHZKHUHDSDUWLFOHPLVWVSUD\GHYLFHLVXVHGQHLWKHUDWD
SODFHRISURYLVLRQV
7KHLQVWDOODWLRQVKRXOGEHVXEMHFWWRWKHLQVWUXFWLRQVEHIRUHWKHSRZHULVFRQQHFWHG
:DWHUVKRXOGQRWEHSRXUHGLQWRWKHSRZHUSOXJ
([SRVHGVNLQVKRXOGQRWPDNHFRQWDFWZLWKKHDWLQJVHDWIRUWRRORQJDWLPHWRSUHYHQWORZWHPSHUDWXUH
EXUQLQJ
□
□
□
□
□
□
□
□
3OHDVHXVHWKHZDWHUVXSSO\KRVHDFFRPSDQ\LQJZLWKQHZPDFKLQH7KHROGKRVHDVVHPEO\VKDOOQRWEH
XVHGDJDLQ
:KHQFXVWRPHUFXWSRZHUVXSSO\RIILIUHDFWLYDWLRQRISRZHUVXSSO\LVUHTXLUHGSOHDVHZDLWXQWLOWKHHQGRI
³EHHS««´LQGLFDWLRQDQGWKHQWXUQRQSRZHUVXSSO\DJDLQ

Kohler Co. 5 1308458-KR01-B
Specification
Water supply volume 4.8L
Water efficiency grade Level I
Pit distance 305mm
Min water pressure 0.07Mpa (dynamic pressure)
Max water pressure 0.74Mpa
Water pressure
Rated voltage 220V~, 60Hz
Rated power* 1100W
Max instantaneous power About 1600W
Length of power line About 1.1m
Product outline dimension About
705mm x 451mm x 526mm
Weight of product About 46kg
Inlet water temp 1-35°C
Operation Environment 1-40°C
Rear wash YES, adjustable
Spiral wash YES, adjustable
Front wash YES, adjustable
Water flow (water pressure 0.2Mpa) Max rear wash shall be no less than 500mL/min
Adjust cleaning water temp OFF, adjustable 5 dials (ambient temp, about 31-39°C)
Cleaning Cleaning time (Max) About 300s
Adjustment of nozzle position 5 gears
Impulse massage On/Off
Wand oscillate On/Off
Water temp overheat
protection Thermal fuse
Prevention of backflow Check valve
Thermal Temp adjustment OFF, adjustable 5 dials
Safety device Thermal fuse
Cover Automatic open/close, lower slowly, remote open/close
Comfort Seat Lower slowly, remote open/close
Dryer function Yes
Dryer Safety device Thermal fuse
Deodorizing function Yes
Self-cleaning of nozzle Yes
Sanitation sterilized water Yes
UV sanitize Yes
Other safety devices Circuit-Breakers
Electrolyzed water treatment Yes
Toilet clean function Yes
Other Auxiliary keyboard Yes
Seating detection Located inside the seat
Night light Yes
Auto cover opening/closing Microwave sensing
*Power value testing condition: dynamic pressure 0.2Mpa, inlet water temp 15°C.
Safety
device

Thank you for choosing Kohler Company
Overall diagram
Thank you for choosing Kohler. Kohler technology provides reliable performance and elegant life,
satisfying your demand now and into the future. Aesthetics and reliability of Kohler products will
surely satisfy your personal style. We are very proud of Kohler products and you will be as well.
Please take a few minutes to read this user manual and pay special attention to the maintenance
and cleaning instructions.
All information in this instruction is based on the latest published product information. We always
persist in improving the quality of all Kohler products. We reserve the right to change product
features, packaging or practicability of products at any time without making notification.
Press dryer button to
activate dryer function
Press button to
activate rear wash
1.Standby function.
Hold “ ” button (over 2s) to enter standby mode.
Details refer to “Standby function” chapter on page 12.
2.Stop function.
Press “ ” button to stop flushing, dryer, air
purification, one button sterilization, manual wand
clean or UV function.
Light sensing area
Press button to
activate front wash
Bumper x 2
Seat Cover
Auxiliary Panel
Fllush button
Nozzle
Seat
Seat Sensor Area
1308458-KR01-B 6 Kohler Co.

□Confirm that the battery has been correctly installed in the "remote controller".
□Confirm that there is no obstacle in front of the product.
□Wait for the toilet to finish the self-checking. During that time, it is normal to hear rotating sound
of the motor and bicker. When night light blinking, self inspection is in process, stop blinking, self-
inspection completed.
□When used for the first time, it will be in a default state:
Preparations before the first use
Connect t o st op valve
Front Wash:
Rear Wash:
Seat Temperature: mid
Night light: ON
Energy saving: OFF
Function of Auto Lid-Turning: On
Function of Auto Flushing: On
Auto UV function: ON
Auto sterilization function: ON
Standby function: OFF
Long time seated on indication function: OFF
1308458-KR01-B 7Kohler Co.
Water Temperature: mid
Pressure: mid
Position: mid
Water Temperature: mid
Pressure: mid
Position: mid

●Auto cover opening/closing
Under non-seating status, press Cover Open/Close key on the remote controller to execute corresponding opening and
closing function (details are shown in the diagram of the remote control). Under seating status, the key of remote
control will not respond.
●Cover opening/closing of remote controller
Users can open or close the cover directly by hands. When users intend to
open or close the cover under normal condition, the cover can open or close
automatically against the trend of motion. Users will not have to use force.
Once being stopped by any obstacle during motion, the cover will automati-
cally stop moving.
NOTES:
1.When the user walk by the sensing area slowly, the sensing distance for
cover opening/closing may be shortened. If no response is made, please open
or close the cover with the remote control or by hands.
2.The function of auto cover opening/closing works only when “setting of cover
opening/closing” in remote controller is “On” .
3.Do not place any movable obstacle within 40cm in front of toilet. If any, the
cover will open automatically; if you would like to deactivate the function of “Auto
cover opening/opening”.
●Manual cover opening/closing
Function for opening/closing of cover/seat
A Open/close cover
Under non-seating status, press Seat Open/Close key on the remote controller to execute corresponding opening and
closing function (details are shown in the diagram of the remote control). Under seating status, the key of remote
control will not respond.
●Cover opening/closing of remote controller
B Open/close seat
Kohler Co.
8
1308458-KR01-B
When cover is CLOSE, user enters sensor area, cover auto open.
When cover is OPEN, user leave sensor area, cover auto close after a period of time.

Users can open or close the seat directly by hands. When user intends to open
or close the seat under normal condition, the seat will open or close automati-
cally against the trend of motion. User will not need to use force. Once being
stopped by any obstacle during motion, the seat will stop moving automati-
cally.
Notes:
During automatic open/close of cover and seat, do not use large force when
opening/closing the cover seat.
●Manual seat turning
a)Usage of seat
A.Auto-flushing function
Flushing of toilet
1
12
11
10 2
3
4
5
9
8
76
1308458-KR01-B 9Kohler Co.
When seat is OPEN and toilet is in use. Toilet will auto flush after unseated for a certain time. Close seat within a period of time.

Users can activate the function of flush with the Flush-full or Flush-eco key on the remote controller.
Note: remote flushing function shall not execute twice within 60s.
B.Flushing with the remote control
Customer shall be able to flush the toilet by press flush
button on toilet.
Note: manual flush function shall not execute
twice within 60s.
C.Manual flushing
Notes:
1.If the automatic flushing function is deactivated, user can control flushing by pushing manual buttons, using the remote control, or a
basin.
2.The function of auto flushing works only when “setting of flushing” in remote controller is “On” .
b)Man use
1
12
11
10 2
3
4
5
9
8
76
Kohler Co.
10
1308458-KR01-B
*There will be a small amount of water drip into bowl after each flushing. This is a normal cleaning process.
When seat is OPEN, open seat manually or by remote; Toilet will auto flush after unseated for a certain time.
Auto close seat/cover after a period of time.

When the toilet can’t be flushed automatically due to power interruption, the cover and the seat will open, and flush away the
sewage in the toilet by a special basin for taking in water.
D.Manual flushing by basin
1308458-KR01-B 11Kohler Co.

Notes:
1.Each function will enter a mode according to factory setting.
2. When front/rear wash is ON, activate corresponding function, auto deactivated after 5 min.
3. When dryer is ON, activate this function, auto deactivated after 4 min.
4. Use STOP button to deactivate front/rear wash/dryer function.
●UV function sterilizes the nozzle with ultraviolet ray. UV function can be activated only under non-
seating status.
●Automatic UV sterilization
□If the product is not used for a long time, the function of UV sterilization will be activated automatically. By this way,the nozzle
will then be sterilized. The function will not be activated again for another 24 hours.
Auxiliary keyboard function
UV sterilization function *
A.Press dryer button to activate
dryer function
B.Press button to
activate rear wash
E.1.Standby function
Hold “ ” button (over 2s) to enter
standby mode. Details refer to “Standby
function” chapter on page 12.
2. Stop function.
Press “ ” button to stop flushing, dryer, air
purification, one button sterilization, manual
wand clean or UV function.
C.Light sensing area
D.Press button to activate front wash
F. Under unseated status, hold rear
wash or front wash button until wand
extend, perform manual clean on
nozzle, hold STOP button to terminate
manual clean function.
Kohler Co.
12
1308458-KR01-B
1.
Standby function
Hold “ " button on side panel (over 2s), enter standby mode when hear one “beep” generated.
Auto detection or remote function deactivated, the top indication LED off. Ring heating function stops
to decrease energy saving.
2. When press any button on side panel or seat on, auto deactivate standby mode, all function recovered.
Wide range clean mode
1. The Bidet is equipped with wide oscillate clean function. If you would like to use wide oscillate function,
please hold rear wash + STOP key about 2s on auxiliary panel after activate rear wash function.

●When energy saving is activated, product shall auto detect idle duration and decrease ring temperature to
achieve energy saving purpose.
●For details of automatic energy saving.
1. Water used for rear/spiral/front wash has been purified.
i. When filter cartridge is almost due, the orange LED keeps ON (as shown).
ii. The filter cartridge is expired, the orange LED flashing.
iiii. Refer to page 15 for exchange filter cartridge.
Automatic energy saving function
Water purification
Deodorizing/Air Purification
1308458-KR01-B 13Kohler Co.
Sterilized water*
●Manual UV sterilization
□When unseated, press “one button sterilization” button on remote, activate UV sterilization function (details refer to remote user’s manual).
□During UV sterilization process, if there’s customer open lid and use toilet, or press STOP button on remote, UV sterilization function will
be terminated.
iii. Improper filter cartridge installation, the orange and white LED flashing in turn.
□During UV sterilization process, if there’s customer open lid and use toilet, or press STOP button on remote, UV sterilization function
will be terminated.
□For setting of automatic UV function .
*Sterilized water (refers to refers to the tap water containing hypochlorite generated by chlorine ions after ionization): Sterilized water generated during electrolysis working cycle eliminates
bacteria on the nozzle surface. The antibacterial rate is more than 96%. (Perform test in accordance with GB /T 23131 when the content of chlorine ions in tap water is >24ppm. Different
water quality might cause different sterilization effect. Electrolysis working cycle activation method refers to operation description. Testing lab: China household electrical appliances
testing institute.).
1. Electrolyzed water performs nozzle sterilization function.
□After a user leaves the toilet under the mode of Front, Rear or Spiral, the toilet will activate the function of sterilization by sterilized
water.
After customer used up and leave toilet, it will auto activate electrolyzed water spray function after flushing the toilet.
3.
□
Perform electrolyzed water spray function inside the bowl.
□
*UV sterilization (refers to the ultraviolet sterilization generated by UV lamp): During UV working cycle, the bacteria on nozzle surface will be eliminated by irradiation. The antibacterial rate
is more than 99%. (Measured after one UV working cycle, it was measured within 18mm×8mm irradiation area. Perform test in accordance with GB /T 23131 requirements, UV radiation
zone was shown in the diagram, UV working cycle activation mode refers to users guide. Testing lab: China household electrical appliances testing institute.)
*Air purification indicates the positive and negative ions are deodorized by the positive and negative ions generation device.
1.. Auto activates air purification function when deodorizing function is activated.
2. Press “
”on remote to activate air purification function.

Maintenance and cleaning
Cleaning the seat
A . Normal cleaning
For the best effect, remember the following rules during maintenance of your Kohler product:
Important! Do not flush the cover directly by water (including remote controller)
●Firstly, clean at an inconspicuous place on the cover to test for safety. Make sure the cleaning
solution will not damage the outer surface of cover, and then apply it to the entire surface.
●Do not immerse in cleaning solution. Do not immerse the product in cleaning solution.
●Avoid using materials that will damage the surface-Clean the surface with a soft and wet
sponge or cotton cloth, instead of materials that can damage the surface.
●Scrubbing After adding the cleaner, use wet a cloth to scrub the surface immediately to
removecleaner or dirt sprayed to the surface.
●Abrasive cleaner and sanitizer are not acceptable by gas spray tank for cleaning.
●Corrosive chemicals or cosmetics (such as nail polish or aftershave) should not
come in contact with the seat as this will damage the surface.
Caution: Failure to follow cleaning instructions may invalidate the warranty of Kohler.
Caution: The success of the cleaning process depends on the water temperature, a
balanced proportion of composition usage, and using a regular cleaning motion. Kohler can’t
ensure the validity of rules since these factors may change.
Caution: Brute force applied to opening the seat will damage the product.
Maintenance: In case of using a mixture of washing agent and water as well
as any available solution for seat cleaning, use soft and wet sponge or cloth
to clean the seat. Use a soft towel to make the seat dry, or let it dry naturally.
Kohler Co. 141308458-KR01-B
Long time seated on indication function.
If customer seat on for a long period of
time, the system shall remind customer by
beep.

1.Open toilet cover.
Open toilet cover by tool (provided), remove cover from the top.
2.Unscrew air filter cartridge as shown direction.
3.Slightly press down and unscrew as shown direction, tighten new filter cartridge.
4.System auto release alarm, return to normal usage status.
5.Close toilet cover again
Snap toilet cover downward manually, no loose snap-fit on both
sides and rear end to complete installation.
Note: i. No power failure during cartridge exchange, otherwise the system shall
not be able to release alarm.
Please exchange filter cartridge immediately when customer found red
light ON all the time as following:
B. Water purification cartridge exchange
2
1
2
1
ii. Change cartridge when power is OFF, release alarm by re-plug cartridge after power is on.
1308458-KR01-B 15Kohler Co.

□Under non-seating status, long press the “ ” key on the “remote control” for
2 seconds, or long press the front flushing or rear flushing key on the side keyboard to stretch out
the nozzle.
□Use a wet soft brush to clean the nozzle.
□Press one of the above keys or the stop key on remote control once more. The nozzle will
retract, or the nozzle will retract automatically after 2 minutes.
□Nozzles can be removed manually for cleaning.
Method of washing the haunch/female nozzle with a soft brush:
B.Cleaning of nozzle
Kohler Co. 161308458-KR01-B

□Shut power supply down, close stop valve, remove toilet cover.
□Take out filter and clean it
□Reinstall the filter, open angle valve.
□Check that the connection does not have any water leakages before connecting the power.
The steps to replace filter are the same as the above steps. Notes:
If filter is found broken or serious blocked, please replace it in time.
Please clean or replace the filter if user finds the water washing volume smaller or if water is not
coming out.
D.Cleaning or replacing the filter
Cleaning the toilet filter
Turn off water valve
Disconnect the power
1308458-KR01-B 17 Kohler Co.

Pull plug out
Kohler Co. 18 1308458-KR01-B
a) If the intelligent toilet will be idle for a long term, make sure the water in pipeline of cover is
drained completely:
□Disconnect the power plug, and turn off the tee valve. Press the release button of heating pipe, exhaust the water inside
heating pipe with a small and long rod.
Notes:
1. If water is not completely drained and meanwhile the product is idle for a long time, the residual water may
freeze in Winter or go bad in Summer.
2. If you find the water supply pipe has been frozen, do not use the intelligent cover. You will need to raise
the room temperature and use it after the water is thawed.
3. When the temperature in Winter exceeds the normal working temperature, and there is a risk of freezing
in water pipe, please turn off the tee valve and flush the empty toilet to release all of the water.
4. Before use after long term idle condition, please close the tee valve and then press it again for flushing.
5.Before use after long term idle condition, make sure to wash it for several times and the inner pipelines
are clean.
6. In case of long term idle status, remove the batteries in the charging block of remote control.
E.Maintenance in case of long-term idle status
b)) Open cover or add water inside the toilet might avo the plastic parts yellowing problem caused by backflow
air from discharge pipe after residual toilet water evaporated during long-term idle status.

This guide of trouble shooting is for general help only. Authorised representatives or qualified elec-tricians of
Kohler Company shall be able to solve all electrical failures. If you want to know about the service of warranty,
please contact local dealers or wholesalers.
Trouble shooting
Possible reasons Suggestions and measures
1. Toilet does not work
2. Toilet can not flush A. Water failure
B. Tee valve for water supply is closed
C. Power failure
D. Product is at standby mode
E. Wash mode is in progress
F. Auto-flushing is deactivated
3. Toilet is not clean
after flushing
A. Filter screen is blocked
B. Water pressure is insufficient
4.
5. Flushing mode
stops in the
operation process
6. The wash mode
runs even when no
one is sitting on the
toilet.
A. Remove the foreign matters or dry the seat
7. Dryer fan stops
in .the operation
process
8. Deodorization fan
not work
A. The seat is unable to sense human body
B. Stop button is pressed by mistake during operation
C. Auto deodorization function is deactivated
Troubles
A. Power failure
B. Plug not connected or no power to socket
A. Refer to "Washing of filter screen"
Wash mode is
abnormal
A. Wait until the water supply is restored
B. Fully open the tee valve for water supply
F. Refer to "Guide on setting of remote controller"
A. Water failure
B. Tee valve for water supply is closed or not opened
completely
C. Product is at standby mode
D.Not yet seated or current sitting posture unable
to be sensed by the seat
E. Filter screen is blocked
F. Water pressure is insufficient
G.Incorrect water purification filter cartridge
installation.
A. Flushing mode stops automatically after
continuous flushing for 5 minutes
B. The seat is unable to sense human body
A. If necessary, press the flushing button again.
B. Adjust your sitting posture or sit on the toilet
again.
A. The seat is covered by foreign matters or the
seat is wet
A. The dryer fan stops automatically after continuous
usage for 4 minutes
B. The seat is unable to sense human body
A. If necessary, press the Dryer button again
B. Adjust your sitting posture or sit on the toilet
again
A. Adjust your sitting posture or sit on the toilet
again.
B. If necessary, please seat on again 2s after
seat off.
C. Refer to "Guide on setting of remote controller"
C. The leakage circuit breaker at cable plug can
not reset
D. Product is at standby mode
A. Wait until the power is restored
B. Insert the plug or detect the power socket
C. Press Reset button on the plug
D. Press " " button on side panel.
B. Check if all tee valves are opened. If not,
please open
C. Check if the inlet hoses are bent. If so,
adjust the hoses.
C.Press “ “button on side panel.
D. Sit on or adjust your sitting posture
E. Refer to the section of "Washing the filter screen"
F. Check if the inlet hoses are bent. If so,adjust
the hoses.
G. Correct purification filter cartridge installation
(refer to Page 15).
A. Wait until the water supply is restored B.
Open the tee valve for water supply
C. Wait until the power is restored or check
"manual flushing" to have manual flushing or
through use of basin
D. Press " "button on side panel.
E. Do it after the operation at wash mode is
completed
1308458-KR01-B 19 Kohler Co.

9.
10.Cover unable to
open/close
automatically
A. Please sit or leave the sensing area
B. Refer to "Guide on setting of remote controller"
C. Wait until the flushing process is completed
11.Night light does
not work
A. The night function is turned off
B. The indoor light is too bright
12.UV sterilization
function not work
13.Remote failures A. Out of battery
B. Battery polarities are mounted reversely
C. The remote controller is not woken up
14.Remote control
fails to control
the toilet
A.
B.
E .
15.The ring is
not warm.
A.Remote ring temp setting is too low.
B.Toilet is on Standby mode.
A. Set ring temp to proper dial.
B.Press “ “button on side panel.
Kohler Co. 201308458-KR01-B
Cover fails to
close/open
A.
B.
C.
D.
E.
Lower battery
The remote control is too far from the toilet The toilet
is not yet powered on
The toilet itself is on standby mode
The toilet is not connected to the remote control
Replace battery by referring to the section of
"Usage and replacement of battery for remote
control"
Check the section of "Communication between
remote controller and this machine", and get
close to the toilet
C. Power on the toilet
Check the section of "Communication betwe
remote control and this machine", and
connect the toilet and the remote control
Touch the screen of the remote control
Sit near the toilet or on it
Press Wake up key on the remote control
A. Replace with new batteries
B. Reinstall properly
C.
A. The seat is covered by foreign matters or the seat
is wet
B. The toilet cover is interfered by people at
the open/close process before
A. Remove the foreign matters or dry the seat
B. Use the remote control to open/close the toilet
cover or do it manually until it works normally.
The cover switch should not be stopped during
the open/close process
A. Human body is sensed by seat.
B. The seat is covered by foreign matters or the seat
is wet
A. Please activate the function of UV sterilization
again after leaving
B. Remove the foreign matters or dry the
seat
A. Users are not seated yet or left the sensing area
B. The function of "automatic cover-turning" of remote
controller is deactivated
C. The toilet is in the process of flushing
A. Check the section of night light at "auxiliary
keyboard function" to activate the night function
B. Please turn off the indoor light and close the
curtain
D.Press " "button on side panel.
