COUTUREt
TOILET
FEATURES
•12” (30.5cm) rough--in
•Vitreous china
•Round front bowl
•1.6 gpf (6 lpf)
•Ingeniumtflushing system
•2” (5cm) glazed trapway
•10--1/2” (26.7cm) x 8--7/8” (22.5cm) water area
•Combination toilet
•Includes polished chrome trip lever
•Less seat and supply
•With Insulinerinsulated tank lining (--U)
CODES/STANDARDS APPLICABLE
Specified model meets or exceeds the following:
•ASME/ANSI A112.19.2M
•ASME/ANSI A112.19.6M
•Energy Policy Act of 1992 (EPACT)
•IAPMO/UPC
•Canadian Standards Association (CSA)
K-3480
COLORS/FINISHES
•0White
•Other Refer to Price Book for additional colors
Accessories:
•0White
•CP Polished Chrome
•PB Polished Brass
•Other Refer to Price Book for additional colors
SPECIFIED MODEL:
Model Description Colors/Finishes
K-3480 Round front bowl toilet V0White VOther______
K-3480-U Toilet with Insulinertank V0White VOther______
Recommended Accessories
K-4663 French Curvetseat with cover V0White VOther______
K-7637 Angle supply with stop VCP VPB VOther______
PRODUCT SPECIFICATION:
We reserve the right to make revisions without notice in the design of fixtures or in
packaging unless this right has specifically been waived at the time the order is accepted.
Page1of2
86045-4-AD
The round front toilet combination shall be 12” (30.5cm) rough-in. Toilet shall be made of vitreous china. Toilet shall be
1.6 gpf (6 lpf) with Ingeniumtflushing system. Toilet shall have a 2” (5cm) glazed trapway. Toilet shall have 10-1/2”
(26.7cm) x 8-7/8” (22.5cm) water area. Toilet shall include polished chrome trip lever. Toilet shall be less seat and supply.
Toilet shall have Insulinerinsulated tank lining (-U). Toilet shall be Kohler Model K-3480-_______-_______.
COUTUREt
7/8”
(2.2cm) 26-7/8” (68.3cm)
3-1/4”
(8.3cm)
12” (30.5cm)
14-1/2”
(36.8cm)
28-5/8”
(72.7cm)
8”
(20.3cm)
5-1/8” (13cm)
17-7/8” (45.4cm)
3/8” N.P.S. SUPPLY
C
LOFOUTLET
14”
(35.6cm)
6-1/8”
(15.6cm)
9-5/8” (24.4cm)
FRONTOFBOWL
PRODUCT INFORMATION
Fixture:
Configuration 2-piece,
round front
Water per flush 1.6 gallons (6L)
Passageway 2” (5cm)
Water area 10-1/2” (26.7cm)
x 8-7/8” (22.5cm)
Water depth from rim 6” (15.2cm)
Seat post hole centers 5-1/2” (14cm)
Included Components:
Bowl K-4277
Tank K-4605
Tank cover 85314
Trip lever K-9408
INSTALLATION NOTES
Install this product according to the installation guide.
K-3480 CoutureToilet
Page2of2
86045-4-AD
PRODUCT DIAGRAM
