Kohler VEIL+ K-5401T-3-0 Assembly instructions

科勒（中国）投资有限公司
静安
制造商:
中国上海市宝山区丰翔路1955号 邮编: 200444
VEIL INTELLIGENT TOILET
新维亚智能座便器
Homeowners Guide
English page 2-23
中文页 码24-45
K-5401T-3-0
K-5401T-XP3-0
1332624-T01-H

Contents
Cautions and warning………………………………………………………………………………........... 3
Specification…………………………………………………………………………………………………
Thank you for choosing Kohler Company………………………………………………………………..
Overall diagram……………………………………………………………………………………………..
Guide on usage of remote controller……………………………………………………………………..
Guide on setting of remote controller……………………………………………………………………..
Preparations before initial use……………………………………………………………………………...
Function for opening/closing of cover/seat…………………………………………………………….…
5
6
6
7
8
10
11
Flushing of toilet…………………………………………………………………………………………..... 12
15
15
16
Trouble shooting………………………………………………………………………………...............… 21
Description of Content of Hazardous Substances in Product ……………………………………...… 23
16
16
……………………………………………………………………………...…
Standby mode…
……………………………………………………………………………………………. … 15
Sanitize function
……………………………………………………………………………………………. …
Sterilization by sterilized water………………………………………………………………………….…
Automatic energy saving function…………………………………………………………………………
Maintenance and cleaning……………………………………………………………………………… .. …
Auxiliary keyboard function
1332624-T01-H
2
Kohler Co.

Cautions and Warnings
Save this instruction
Children, elders or those with disabilities from their body, sensitivity or mental disabilities or lacking of
common sense should not use or get close to this product unless under close tutelage. Children are not
allowed to use or touch this product. Do not leave children alone in a room with such product.
Warning: Risk of electric shock, fire or personal injury. This product must be installed safely. Connect
only to dedicated 220V~, 50Hz, 10A circuit protected by Ground-Fault Circuit-Interrupters (GFCI’s) or
Earth-Leakage Circuit-Breakers (ELCB’s).
Warning: Risk of electric shock or product damage. Do not immerse the product into water.
Warning: Do not use any hard setting material (cement mortar) while installing the toilet. Thermal
expansion of hard setting material (cement mortar) will damage or crash the feet of toilet. Kohler will
not be responsible for any damage because of using hard setting material (cement mortar) for toilet
installation.
Warning: Risk of product damage.Do not throw into the toilet what that will cause the toilet to
block such as newspapers and sanitary towel.Do not bump the vitreous china with great force as it
will cause damage and leaking.
Important! Risk of product damage. Do not install at a place where it may be splashed by water.
Important! Risk of product damage. Do not install the product at a place with excessive humidity, where
moisture may condense at the surface of the product. Please maintain that the usage envi-ronment is under
adequate ventilation, so as to prevent damage to electronic components.
Important! Risk of product damage or property loss. Water leakage may happen if the water pipe
connector is pulled or pushed with excessive force.
Important! Risk of product damage. The product may be damaged if the nozzle is applied with
excessive force.
Important! Risk of product damage. The part of the pipe where water may be frozen should be protected by
thermal insulation. Any water left in the product may be frozen during the winter season. Please keep the
product in room temperature before reinstallation or usage.
Important! Risk of product damage. The power shall not be connected before the work is finished.
Otherwise it may lead to product failure.
Attention: The thermal protector may be out of order during storage or transportation in warm climate
which can lead to product failure. Please ensure the product cools to room temperature before
reinstallation or usage.
When an electrical product is used, especially when children are near, the following basic safety
precautions shall be abided by:
Danger-Reduce risk of electric shock:
Do not place or store this appliance where it can fall or be pulled into a bath or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug immediately.
WARNING - To reduce the risk of low grade burns, electric shock, fire or injury to persons:
□
Kohler Co.
3
1332624-T01-H

CAUTIONS AND WARNINGS
□For those children and the elderly who are unable to adjust the temperature, they should ask for
help to adjust seat temp, water temp and wind temp of toilet cover to proper gears.
□
recommended by Kohler Co. such as angle valve etc.
Do not lean on cover when use this appliance to prevent product from damage.
□
□
□
□
□
When install the product in the room, a stop valve shall be installed in a close proximity. For emergency
circumstances, the water inlet valve shall be stopped without using any tools; otherwise unexpected failure
may cause the loss to the customer.
Keep power line far from heated surface.
Do not drop or insert any substance to pipeline or the opening.
Do not use this product outdoor or in a place where a particle mist spray device is used,neither at a
place of provisions.
The installation should be subject to the instructions before the power is connected.
Water should not be poured into the power plug.
Exposed skin should not make contact with heating seat for too long a time to prevent low temperature
burning.
□
□
□
□
□
□
□
□
□
□
the professionals from its maintenance department or similar departments, to avoid the occurrence of danger.
Please use the water supply hose accompanying with new machine. The old hose assembly shall not be
used again.
When customer cut power supply off, if reactivation of power supply is required, please wait until the end of
“beep……” indication, and then turn on power supply again.
been dropped into water.
Install this product properly by following the installation procedure.
This product shall be repaired by professionals only. The warranty will become invalid if you try to repair
this product by yourself.
1332624-T01-H
4
Kohler Co.

Specification
Flush volume 4.0L
Water efficiency grade*Level III
Pit distance 305mm
Min water pressure 0.07MPa (dynamic pressure)
Max water pressure 0.74MPa
Water pressure
Rated voltage 220V~, 50Hz
Rated power* 1090W
Max instantaneous power About 1600W
Length of power line About 1.3m
Product outline dimension About 670mm × 438mm × 533mm
Weight of product About 48kg
Inlet water temp 1-35°C
Operation Environment 1-40°C
Rear wash YES, adjustable
Spiral wash YES, adjustable
Front wash YES, adjustable
Water flow (water pressure 0.2MPa)
Max rear wash shall be no less than 500mL/min
Adjust cleaning water temp OFF, adjustable 5 dials (ambient temp, about 31-39°C)
Cleaning Cleaning time (Max) About 300s
Adjustment of nozzle position 5 gears
Impulse massage On/Off
Wand oscillate On/Off
Water temp overheat
protection Thermal fuse
Prevention of backflow Check valve
Thermal Temp adjustment OFF, adjustable 5 dials
Safety device Thermal fuse
Cover Automatic open/close, lower slowly, remote open/close
Comfort Seat Lower slowly, remote open/close
Dryer function Yes
Dryer Safety device Thermal fuse
Deodorizing function Yes
Remote controller For functional setting, see Page 8-9
Self-cleaning of nozzle Yes
Antibacterial materials Seat and cover
Sanitation sterilized water Yes
UV sanitize Yes
Other safety devices Circuit-Breakers
Auxiliary keyboard Yes
Seating detection Located inside the seat
Other Night light Yes
Auto cover opening/closing Microwave sensing
Manual flush Yes
* Power value testing condition: dynamic pressure 0.2MPa, inlet water temp 15°C.
Safety
device
* The description of water efficiency label marked on intelligent toilet: water efficiency label represents a compliance mark of the water efficiency grade etc. performance of intelligent toilet.
Kohler Co.
5
1332624-T01-H

Thank you for choosing Kohler. Kohler technology provides reliable performance and elegant life, satisfying your
demand now and into the future. Aesthetics and reliability of Kohler products will surely satisfy your personal
style. We are very proud of Kohler products and you will be as well.
Please take a few minutes to read this user manual and pay special attention to the maintenance and cleaning
instructions.
All information in this instruction is based on the latest published product information. We always persist in
improving the quality of all Kohler products. We reserve the right to change product features, packaging or
practicability of products at any time without making notification.
crash pad × 4
Seat (antibiosis*)
Nozzle
Cover (antibiosis*)
Seating sensing area
Thank you for choosing Kohler Company
Overall diagram
*Antibacterial: the seat and cover contains long term inorganic anti-bacteria material which will inhibit bacteria growth on surface, this does not represent the mildew and other incidental
effects. The antibacterial rate is more than 90%. (Perform test in accordance with GB21551.2-2010 requirements. Testing lab: China household electrical appliances testing institute;
electromechanical products testing technology center of Shanghai Entry-Exit inspection and quarantine bureau.)
1332624-T01-H
6
Kohler Co.

Guide on usage of remote controller
A
HG IE
B
C K L N O
Q- JFP M Q+
Press this button to flush the toilet.
Press this button to adjust temp dial, press+/- (Q+/Q-) to adjust seat temp.
Press this key to stop the mode of Front, Rear, Dryer and Deodorization, Manual Cleaning Effuser or UV.
Pressing this key for a long time will turn off the remote control.
Press +/- (Q+/Q-) to adjust water temp when front wash or rear wash is activated.
Warning: Take down the remote control from charger before pressing Start key to prevent risk of falling.
A - Start
Press this key to turn on the remote control. Press it again to switch on/off after start.
If the toilet is not connected after start, the icon in the third row will flicker. Connecting it successfully will stop it
from flickering and enter into serviceable condition.
B - Open/close cover
Under non-seating status, press this key to open/close the cover.
C - Open/close seat
Under non-seating status, press this key to open/close the seat.
G - Front
After seating, press this key to enter Front mode. After 5 minutes or so, the flush stops automatically or press the
stop key to turn it off immediately.
I - Rear
After sitting, press this key to enter Rear mode. After 5 minutes or so, the flush stops automatically or press the
stop key to turn it off immediately.
The Bidet is equipped with wide oscillate function. If you want to use wide oscillate function, please hold both
REAR+POWER buttons for 2s on side panel, then activate rear wash oscillate mode.
K - Massage
Under Front or Rear mode, press this key to enter the mode of mobile flushing. Press it again to enter the mode
of impulse flushing. Press it at a third time, and the mode of mobile/impulse flushing will be activated at the same
time. Press it at a fourth time to exit (When corresponding functions are activated, the light at the left side of icon
will turn on).
L - Spiral
During the operation under Rear mode, press this key to flush water in a spiral shape. The icon of Spiral mode
flickers. Press it again to exit (or press “Stop” to turn it off). The icon of Spiral mode will then stop flickering.
E - Flush
●
H - Stop
●
●
F - Seat temp
●
J - Water temp
●
Kohler Co.
7
1332624-T01-H

Remote Setup Guideline
Low voltage alarm
Press +/- (Q+/Q-) to adjust wand position when front or rear wash is activated.
N - Dryer
After sitting, Press this button to activate dryer function after seated, After 4 minutes or so, it stops automatically
or press the Stop key to turn it off immediately.
, short press this key to enter UV sterilization function. And the icon will flicker.
Caution:
●When the cover is powered on normally, press the Start key at the top of the remote control. When the icon of
the lowest row flickers for a long time, it means the remote control needs to be with the main unit.
●
●
●
●
Press and hold the Dryer key. When the icon at the lowest row flickers, start the operation at the main unit end.
● key and key at side keyboard. Do not release the key until hearing a Meanwhile the
.
●Once the icon at the lowest row of remote control stops flickering, it means it has been successfully.
Caution: Please charge in time when the voltage alarm is activated.
Communication between remote control and
Poweroff function
●If the remote control is moved away from the sensing area, the icon at the bottom row of remote control will
flicker automatically (indicating a searching the signal for the ).
Then the icon will stop flickering it is
connected successfully.
●Press and hold the key at any time, the remote controller will enter Power off mode.
When the button flickers, it indicates that the built-in battery in the remote control is used up. Put the
controller on the base to charge its battery;
HG I E
B
C K L N O
Q- JFP M Q+
M - Position
O - Sanitize
P- Water pressure
Under Front or Rear mode, press+/- (Q+/Q-) to adjust gears of water pressure.
Only J/F/P/M function is activated, the “+/-”key shall be used to adjust related parameter.
O - Parameter adjustment key Q+/Q-:
1332624-T01-H
8
Kohler Co.

Usage and Replacement of Battery for Remote Controller
Others
□Do not put the remote control at a place where it may be sprayed by liquid, or immersed in liquid.
□Do not place it near hand dryer, hair dryer and small size home appliances, to avoid disturbance of
normal usage of the remote control.
□Do not apply external force to the key zone of remote controller frequently or fiercely.
□After usage of remote control, put it back into the remote holder mounted on wall.
□Prevent dropping the remote control during usage.
□Anti-loss function: lock remote on docking station by screws. Specific method refers to installation instruction.
Keep pressing the key until a short is heard, and release the key only after the night lamp flickers for
three times. Then change the setting of B/C/E/F/O by the following requirements.
B - Open/close the cover…Sensing distance setting
Press and hold the key to set up the sensing distance for auto cover-turning:
1. .
2. .
3. .
4. .
C - Seat On/Off…Deodorization function setting
●
●
Press and hold this key to turn on/off the deodorization function.
1. .
2. .
E - Flush…Automatic flushing setting
●Press and hold this key to turn off the function of automatic flushing. Press and hold it again to restore
automatic flushing.
1. .
2. .
F - Seat temp…Energy saving setting
●Press and hold the key of Seat Temp to activate the function of energy saving. Press and hold it again to
deactivate this function.
1. .
2. .
key until a short pip is heard and release the key only after the night lamp flickers for three times before
the next change of setting.
M - Position…Effuser cleaning settings
●Under non-seating status, press and hold this key to activate the function of manual cleaning. The nozzle can be
When the setting of B/C/E/F/O is not modified for a certain period, repeat the process that is to keep pressing the
●Press and hold to set up the on/off status of automatic UV sterilization.
1. .
2. .
● of remote controller uses 4 #5 alkaline batteries.
●When battery is low,
●Caution:
1.The positive and negative polarities of battery must be consistent with
the mark of remote controller.
2.New and old batteries shall not be mixed.
3.Please use alkaline battery. Red Lamp Flicker
O - Sanitize Setting
cleaned manually. Press and hold it again or press Stop key to deactivate this function.
Kohler Co.
9
1332624-T01-H

Front:
Water temp: mid
Water flow intensity: mid
Position: dial 3
Rear:
●Water temp: mid
●Water flow intensity: mid
●Position: dial 3
Spiral:
●Water temp: mid
●Water flow intensity: mid
●Position: dial 3
Preparations before the initial use
□Confirm that the battery has been correctly installed in the "remote controller".
□Confirm that there is no obstacle in front of the product.
□the toilet complete the self check, after the product is powered on. During that time, it is normal to hear
rotating sound of the motor and bicker, or see the night light flicker. When the lighting stops flickering, the
self-check is completed.
□When used for the first time, it will be in a default state:
●
●
●
Tee valve connection
Seat temp: mid
Night light: On
Energy saving mode: On
Auto Lid Turning Function: On; distance, mid
Auto Flush Function: On
Sanitize Function: On
Electrolyzed water Function: On
Deodorizer: On
Water pump: On (press and hold flush and front
wash button on toilet side panel, short “beep”
indicates water pump is on, long “beep”
indicates water pump is off.)
□Ensure if water inlet valve is OPEN.
1332624-T01-H
10
Kohler Co.

Cover opening/closing by remote controller
Under unseated status, press Seat Open/Close key on the remote controller to execute corresponding
opening and closing function (details are shown in the diagram of the remote control). Under seating
status, the key of remote control will not respond.
●Auto cover opening/closing
When cover is CLOSE, user enters sensor area, cover auto open.
When cover is OPEN, user leave sensor area, cover auto close after a period of time.
Lid open/close by remote
Under unseated status, press Cover Open/Close key on the remote controller to execute corresponding
opening and closing function (details are shown in the diagram of the remote control). Under seating
status, the key of remote control will not respond.
Manual cover opening/closing
Users can open or close the cover directly by hands. When users
intend to open or close the cover under normal condition, the cover
can open or close automatically against the trend of motion.
Users will not have to use force. Once being stopped by any
obstacle during motion, the cover will automatically stop moving.
NOTES:
1.When the user walk by the sensing area slowly, the sensing
distance for cover opening/closing may be shortened. If no
response is made, please open or close the cover with the remote
control or by hands.
2.The function of auto cover opening/closing works only when “setting
of lid opening/closing" in remote controller is “On” (Refer to page 9
for setup method)
Do not place any movable obstacle within 40cm in front of toilet. If
any, the cover will open automatically; if you would like to
deactivate the function of “auto lid open/close”, please refer to page
9.
3.
Function for opening/closing of cover/seat
A Open/close cover
B Open/close seat
Kohler Co.
11
1332624-T01-H

1
11 12
2
10
3
4
5
9
8
76
Manual seat turning
Users can open or close the seat directly by hands. When user
intends to open or close the seat under normal condition,
the seat will open or close automatically against the trend
of motion. User will not need to use force. Once being stopped
by any obstacle during motion, the seat will stop moving
automatically.
Notes:
During automatic open/close of cover and seat, do not use excessive
force when opening/closing the cover seat.
Flushing of toilet
When seat is OPEN and toilet is in use. Toilet will auto flush after unseated for a certain time.
Close seat within a period of time.
A.Auto-flushing function
a)Usage of seat
1332624-T01-H
12
Kohler Co.

Notes:
1
11 12
10 2
3
4
5
9
8
76
When seat is OPEN, open seat manually or by remote; Toilet will auto flush after unseated for a certain time.
Auto close seat/cover after a period of time.
b)Man use
1.If the automatic flushing function is deactivated, user can control flushing by pushing manual buttons,
using the remote control, or a basin.
2.The function of auto flushing works only when “flushing setup” in remote controller is “On” (Refer to page
9 for setup method).
B.Flushing with the remote control
C. Emergency flush
When power is off, please press and hold flush
button on toilet side panel to activate
emergency flush function.
Press flush button on remote to enter flush function.
Notes: The action of flush will not be done twice until the flushing with the remote controller finishes.
power
Kohler Co.
13
1332624-T01-H

When emergency flush key is invalid, the cover and the seat will open, flush away the sewage by using
a container of water.
D.Manual flushing by basin
1332624-T01-H
14
Kohler Co.

Press Dryer key to activate the dryer function..
Press it again to deactivate.
Press this key to enter the mode of Rear.
Press it again to deactivate.
Light sensing area
If the product is not used for a long time, the function of UV sterilization will be activated automatically. By this
way, the effuser will then be sterilized. The function will not be activated again for another 24 hours.
If during UV sterilization a user is sitting on the seat, or the stop key on the remote control is pressed, UV
sterilization deactivate.
For setting of automatic UV function, see page 9.
If the cover is close, short press the UV key on remote control to execute the function of UV sterilization immediately.
If during UV sterilization a user is sitting on the seat, or the stop key on the remote control is pressed, UV
sterilization deactivate.
*UV sterilization (refers to the ultraviolet sterilization generated by UV lamp): During UV working cycle, the bacteria on nozzle surface will be eliminated by irradiation. The antibacterial
rate is more than 99%. (Measured after one UV working cycle, it was measured within 18mm×8mm irradiation area. Perform test in accordance with GB /T 23131 requirements, UV
radiation zone was shown in the diagram, UV working cycle activation mode refers to users guide. Testing lab: China household electrical appliances testing institute.)
Sanitize function*
Sanitize function is achieved by UV sterilization on wand.
Automatic UV sterilization
Manual UV sterilization
power
Auxiliary keyboard function
Press this key to enter the mode of Front.
Press it again to deactivate. Press the button to turn off the
night light function (long pip hint)
Press it again to activate the
function of night light (short pip
hint)
Press the button to turn off the
power (long pip hint)
Press it again to turn on the
power (short pip hint)
Press it to flush the toilet(press
and hold the key after power is
off to activate emergency flush
function)
UV radiation range Bidet nozzle
Notes:
1. Each function shall operate per factory setting.
2. Under the mode of Front or Rear wash, press it again to deactivate this function. Otherwise, it will stop automatically after 5 minutes.
3. Under the Dryer mode, press it again to deactivate this function. Otherwise, it will stop automatically after 4 minutes.
Standby mode
1.. Press POWER button on side panel, enter standby mode when generate one “beep”. Meanwhile, auto detection
and remote function OFF, seat heating function deactivated to minimize energy consumption.
2.. When press POWER button on side panel again, exit standby mode and all function recovered.
Kohler Co.
15
1332624-T01-H

Automatic energy saving function
When energy saving set to ON status, product shall auto detect the idle hours and decrease the
heating temperature to reach of energy saving purpose.
For details of automatic energy saving, refer to pages 9.
Maintenance and cleaning
A. Normal cleaning
For the best effect, remember the following rules during maintenance of your Kohler product:
Important! Do not flush the cover directly by water (including remote controller)
FiTesting - apply cleaning solution at an inconspicuous place on lid for testing. Make sure the cleaning
solution will not damage the outer surface of cover, and then apply it to the entire surface.
Avoid using materials that will damage the surface-Clean the surface with a soft and wet sponge or cotton
cloth, instead of materials that can damage the surface.
Do not immerse in cleaning solution. Do not immerse the product in cleaning solution.
Scrubbing - After adding the cleaner, use a wet towel to scrub the surface immediately to remove cleaner
or dirt sprayed to the surface.
Corrosive chemicals or cosmetics (such as nail polish or aftershave) should not come in contact with the
Do not use abrasive cleanser or sanitizer inside the spray tank for cleaning.
Caution: When clean the opening lid, brute force applied to
the lid will damage the product.
Cleaning the seat
Maintenance: In case of using a mixture of washing agent and
water as well as any available solution for seat cleaning, use
soft and wet sponge or towel to clean the seat. Use a soft towel
to make the seat dry, or let it dry naturally.
Caution: The success of the cleaning process depends on the water hardness and
temperature, the dose precision of composition, cleaning regulation variation and cleaning
product status etc. factors. Kohler can’t ensure the validity of rules since these factors
may change.
seat as this will damage the surface.
Caution: Failure to follow cleaning instructions may invalidate the warranty of Kohler.
Clean hinge arm
Wipe the hinge arm by a soft cloth on a regular basis to
prevent from sticking to the hinge arm, and to reduce the
brightness of the hinge.
Clean stainless steel beauty parts
Clean surface with neutral soap water, and then wipe the whole surface off with clean
and soft rag. Do not use cleaners, such as Ammonia, decontamination powder or toilet
cleaner which will cause surface damage.
Sterilized water*
The function of sterilized water is to disinfect the wand.
After customer uses front wash, rear wash or spiral wash function, the toilet will activate sterilized water
function after customer leaves toilet.
When the toilet is out of use, sterilization will be activated once every 8 hours.
*Sterilized water (refers to refers to the tap water containing hypochlorite generated by chlorine ions after ionization): Sterilized water generated during electrolysis working cycle eliminates
bacteria on the nozzle surface. The antibacterial rate is more than 96%. (Perform test in accordance with GB /T 23131 when the content of chlorine ions in tap water is >24ppm. Different
water quality might cause different sterilization effect. Electrolysis working cycle activation method refers to operation description. Testing lab: China household electrical appliances testing
institute.).
1332624-T01-H
16
Kohler Co.

Immerse nozzle into cleaning solution for 2 hours.
Clean with soft brush.
Mount nozzle back to original position along the dismantle direction.
Check nozzle clean function after power is ON.
B. Nozzle clean
Method of washing the front/rear wash nozzle with a soft brush:
Under unseated status, push and hold the “nozzle oscillate” key on the “remote control” for 2 seconds, or
press and hold the front wash or rear wash key on the side panel to extend the nozzle.
Use a wet soft brush to clean the nozzle.
Press one of the above keys or the stop key on remote control one more time. The nozzle will retract or
the nozzle will retract automatically after 2 min.
Customer to remove nozzle for cleaning：
When unseated, push and hold the “oscillate” button on the “remote control” for 2 seconds, or press and
hold the front wash or rear wash button on the side panel to extend the nozzle.
Disconnect power supply within 2mins.
Remove nozzle along the arrow direction as shown.
Kohler Co.
17
1332624-T01-H

Cleaning the toilet filter
Disconnect the power, turn off tee valve and remove the filter plug.
Filter
Filter cover
Disconnect the power
Tee valve
Turn off water valve
Remove side plate
Take out filter and clean it
Clean filter
Disconnect the power plug
Turn off tee valve, and remove filter cover
Remove filter
Clean filter
Reinstall the filter, attach the hose connector and turn on the tee valve.
Check that the connection does not have any water leakages before connecting the power.
Set the side plate to its original position.
Cleaning of tee valve filter
The steps to replace filter are the same as the above steps.
Notes:
If filter is found broken or serious blocked, please replace it in
time. The filter mesh shall be no less than 80.
C. Cleaning or replacing the filter
Clean or replace the filer if there's not enough water volume or water is not coming out.
1332624-T01-H
18
Kohler Co.

If users find the effect of deodorization is unobvious and feel any peculiar smell, please replace deodorization
block in time.
Steps to replace deodorization block:
Remove deodorization-door and deodorization block
Deodorization-Door
After replacing the deodorization block, put it back into the toilet.
Deodorization block
Deodorization block bracket
D.Replacement of deodorization block
Notes:
After removing the deodorization block, do not put your hands or other substances into holding cavity of
deodorization block as doing so will damage the fan and other parts.
Scan the QR code to order the replaced part with the part number 22761T-NA.
Kohler Co.
19
1332624-T01-H

Disconnect the power plug, and turn off the tee valve. Press the release button of heating pipe, exhaust
the water inside heating pipe with a small and long rod.
Disconnect the power plug
Notes:
1.If water is not completely drained and meanwhile the product is idle for a long time, the residual water may
freeze in Winter or go bad in Summer.
2.If you find the water supply pipe has been frozen, do not use the intelligent cover. You will need to raise
the room temperature and use it after the water is thawed.
4.Before use after long term idle condition, please close the tee valve and then press it again for flushing.
5.Before use after long term idle condition, make sure to wash it for several times and the inner pipelines are
clean.
6.In case of long term idle status, remove the batteries in the charging block of remote control.
3.When the temperature in Winter exceeds the normal working temperature, and there is a risk of freezing in
water pipe, please turn off the tee valve and perform one flush to the toilet.
E. Maintenance in case of long-term idle status
a) If the intelligent toilet will be idle for a long term, make sure the water in pipeline of cover is drained completely:
b) Open cover or add water inside the toilet might avoi the plastic parts yellowing problem caused by backflow
air from discharge pipe after residual toilet water evaporated during long-term idle status.
1332624-T01-H
20
Kohler Co.
