Kohler C3-150 Assembly instructions

静安
：上海科勒电子科技有限公司
中国上海市宝山区丰翔路1955号 邮编：200444
English page 2-19
中 文 页 码 20-37
Smart Seat
清舒宝智能便盖
C3-150
K-8297T-0
K-8297T-XP-0
1351304-T01-E

Table of Contents
CAUTIONS AND WARNINGS.................................................................
3
Specifications..........................................................................................
5
Thank You For Choosing Kohler Company.............................................
6
Control Panel...........................................................................................
6
Operation ................................................................................................
7
Preparation Before Initial Operation........................................................ 9
Test the Functions...............................................................................................
10
Care and Clean.......................................................................................
11
Clean the Spray Wangs
..........................................................................
12
Remove the Seat
....................................................................................
13
Clean the Filter
.......................................................................................
14
Exchange Deodorization Block.
..............................................................
15
Maintanance in Case of Long-term Idle Status.......................................
15
Troubleshooting.......................................................................................
16
Description of Content of Hazardous Substances in Product
..................
19
1351304-T01-E
2
Kohler Co.

CAUTIONS AND WARNINGS
Children, elders or those with disabilities from their body, sensitivity or mental
disabilities or lacking of common sense should not use or get close to this
product unless under close tutelage. Children are not allowed to use or touch this
product. Do not leave children alone in a room with such product.
Warning: Risk of electric shock, fire or personal injury. This product
must be installed safely. Connect only to dedicated 220V~, 50Hz, 10A
circuit protected by Ground-Fault Circuit-Interrupters (GFCI’s) or
Earth-Leakage Circuit-Breakers (ELCB’s).
Warning: Risk of electric shock or product damage. Do not immerse
the product into water.
Important! Risk of product damage. Do not install at a place where it may be
splashed by water.
Important! Risk of product damage. Do not install the product at a place
with excessive humidity, where moisture may condense at the surface of the
product. Please maintain that the usage envi-ronment is under adequate
ventilation, so as to prevent damage to electronic components.
Important! Risk of product damage or property loss. Water leakage may
happen if the water pipe connector is pulled or pushed with excessive force.
Important! Risk of product damage. The product may be damaged if the
nozzle is applied with excessive force.
Important! Risk of product damage. The part of the pipe where water may be
frozen should be protected by thermal insulation. Any water left in the product
may be frozen during the winter season. Please keep the product in room
temperature before reinstallation or usage.
Important! Risk of product damage. The power shall not be connected before
the work is finished. Otherwise it may lead to product failure.
Attention: The thermal protector may be out of order during storage or
transportation in warm climate which can lead to product failure. Please
ensure the product cools to room temperature before reinstallation or usage.
When an electrical product is used, especially when children are near, the
following basic safety precautions shall be abided by:
Danger-Reduce risk of electric shock:
□Do not place or store this appliance where it can fall or be pulled into a bath
or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug immediately.
WARNING - To reduce the risk of low grade burns, electric shock, fire or
injury to persons:
□
□
□
Kohler Co.
3
1351304-T01-E

□
□
recommended by Kohler Co. such as T-valve etc.
Do not lean on cover when use this appliance to prevent product from damage.
□
□
□
□
□
(cont.)
For those children and the elderly who are unable to adjust the
temperature, they should ask for help to adjust seat temp, water temp and
wind temp of toilet cover to proper gears.
□
□
been dropped into water.
Install this product properly by following the installation procedure.
This product shall be repaired by professionals only. The warranty will
become invalid if you try to repair this product by yourself.
When install the product in the room, a stop valve shall be installed in a close
proximity. For emergency circumstances, the water inlet valve shall be stopped
without using any tools; otherwise unexpected failure may cause the loss to
the customer.
Keep power line far from heated surface.
Do not drop or insert any substance to pipeline or the opening.
Do not use this product outdoor or in a place where a particle mist spray
device is used,neither at a place of provisions.
The installation should be subject to the instructions before the power is
connected.
Water should not be poured into the power plug.
Exposed skin should not make contact with heating seat for too long a time
to prevent low temperature burning.
□
□
□
□
□
□
□
the professionals from its maintenance
department or similar departments, to avoid the occurrence of danger.
Please use the water supply hose accompanying with new machine. The old
hose assembly shall not be used again.
When customer cut power supply off, if reactivation of power supply is
required, please wait until the end of “beep……” indication, and then turn on
power supply again.
1351304-T01-E
4
Kohler Co.

Water efficiency grade*Level II
Min water pressure 0.07MPa(dynamic pressure)
Max water pressure 0.74MPa
Water pressure
Rated voltage
220V~, 50Hz
About 1.5m
Rated power*
Max instantaneous power
About 1400W
Product outline dimension
About
522mm x 448mm x 130mm
Weight of product
About 4.5kg
Inlet water temp
1-35°C
Operation Environment
1-40°C
Rear wash YES, adjustable
Front wash YES, adjustable
Water flow
(water pressure 0.2MPa) Max rear wash shall be no less than 500mL/min
OFF, adjustable 5 dials (ambient temp,
about 31-39°C)
About 300s
ON/OFF
ON/OFF
Thermal fuse
OFF, adjustable 5 dials
Thermal fuse
Deodorizing function
OFF, adjustable 5 dials
Thermal fuse
Antibacterial material
Other safety devices Circuit-Breakers
Control panel Located on side panel
Seating detection Located inside the seat
Night light Yes
IOT function For K-8297T-XP-0
*The description of water efficiency label marked on Bidet: water efficiency label represents a compliance mark of the water
efficiency grade etc. performance of Bidet.
*Power value testing condition: dynamic pressure 0.2MPa, inlet water temp 15°C.
Kohler Co.
5
1351304-T01-E

B
C
D
E
A
J
I
H
G
F
Cover (antibacterial*)
Seat (antibacterial*)
*Antibacterial: the seat and cover contains long term inorganic anti-bacteria material which will inhibit bacteria growth on surface,
this does not represent the mildew and other incidental effects. The antibacterial rate is more than 90%. (Perform test in
accordance with GB21551.2-2010 requirements. Testing lab: China household electrical appliances testing institute;
electromechanical products testing technology center of Shanghai Entry-Exit inspection and quarantine bureau.)
1351304-T01-E
6
Kohler Co.

Kohler Co.
7
1351304-T01-E

The Bidet is equipped with wide oscillate clean function. If you
would like to use wide oscillate function, please hold pulsate
key about 2s after activate rear wash + pulsate function.
1351304-T01-E
8
Kohler Co.

Ensure if water inlet valve is OPEN.
Kohler Co.
9
1351304-T01-E

1351304-T01-E
10
Kohler Co.

Kohler Co.
11
1351304-T01-E

1351304-T01-E
12
Kohler Co.

Kohler Co.
13
1351304-T01-E

1351304-T01-E
14
Kohler Co.

Open cover or add water inside the toilet might avoid the plastic parts
yellowing problem caused by backflow air from discharge pipe after
residual toilet water evaporated during long-term idle status.
Kohler Co.
15
1351304-T01-E
Scan the QR code to order the replaced part with the part number
22761T-NA.

1351304-T01-E
16
Kohler Co.

Kohler Co.
17
1351304-T01-E

1351304-T01-E
18
Kohler Co.

Description of Content of Hazardous Substances in Product
:Indicates that the substance in the material composition is below the
high limits of the current requirements in GB/T 26572.
10
×:
Indicates that at least one of the homogeneous substance in the
Note: the information provided is based on the supplier data and Kohler
inspection results. The product is designed not to hurt the environment.
Under current technology, all hazardous materials have been used in the
smallest amounts possible. Kohler will strive to reduce the use of these
hazardous materials used in this product.
The product “service life for environment protection” is 10 years;
Kohler Company will specify product service life based on
product characteristics. The product “service life for environment
protection” is only effective when the product is used as
described in the product specification.
Reclaim Indication
When the product exceeds service life or is unable to use after repair, do
not throw the product away in the normal trash. Please dispose the waste
electronic parts through a qualified reclamation enterprise. Make sure the
product is handled properly. Disposing of product must be done in
accordance with the local or national government law.
Statistics of Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substance or Elements
Part name
Plastic Assy. ○ ○ ○ ○ ○ ○
Control Assy. × ○ ○ ○ ○ ○
PCBA Assy. × ○ ○ ○ ○ ○
Motor Assy. × ○ ○ ○ ○ ○
Wire Harness Assy. ○ ○ ○ ○ ○ ○
Water Inlet Assy. ○ ○ ○ ○ ○ ○
Wand Assy. ○ ○ ○ ○ ○ ○
Heater Assy. ○ ○ ○ ○ ○ ○
*Remote Assy. × ○ ○ ○ ○ ○
*Battery ○ ○ ○ ○ ○ ○
Lead
(Pb)
Mercury
(Hg)
Cadmium
（Cd）
Hexavalent
Chromium
(Cr(VI)）
Polybrominated
biphenyls
（PBB）
Polybrominated
Diphenyl Ethers
（PBDE）
○
material composition is below the high limits of the current requirements
in GB/T 26572.
*: Indicate only partial product series contains this substance.
Kohler Co.
19
1351304-T01-E

目录
安全注意事项 .....................................................................................
21
规格
.....................................................................................................
23
谢谢您选择科勒公司
............................................................................
24
控制面板
..............................................................................................
24
使用方法
.....................................................................................
25
初次使用前准备
..................................................................................
27
功能测试
..............................................................................................
28
维护和清洗
........................................................................................
29
清洗喷嘴
...................................................................................
30
移除座便盖
.........................................................................................
31
清洗过滤网........................................................................................... 32
更换除臭块
.........................................................................................
33
长期放置不用时的维护
......................................................................
33
疑难解答
.............................................................................................
34
产品中有害物质含量的说明
...................................................................
37
1351304-T01-E
20
Kohler Co.
