Kohler VEIL+ K-5401T-3-0 User manual

科勒（中国）投资有限公司
静安
制造商:
中国上海市宝山区丰翔路1955号 邮编: 200444
Installation Guide
English page 2-15
中文页 码16-29
安装说明
VEIL INTELLIGENT TOILET
新维亚智能座便器
K-5401T-3-0
K-5401T-XP3-0
1332623-T01-H

面遇到任何問題，務必請您與我們聯繫。
These instructions contain important care, cleaning, and warranty information - please leave instructions for the
consumer.
We appreciate your commitment to Kohler quality. Pleas
e take a few minutes to review this manual before
installation. If you encounter any installation or performan ce problems, please don't hesitate to contact us.Thanks
again for choosing Kohler Company.
Pre-arrange enough space for toilet installation. Make su
re it will not affect the opening and closing of the door.
Confirm the rough in 305mm, it need reach to 292~350mm, otherwise it may affect installation.
BEFORE YOU BEGIN
Please read the following instructions carefully and familiarize yourself with the required tools, materials, and
installation sequences. Follow the section that pertain to your particular installation. This will help you avoid costly
mistakes. In addition to proper installation, please also read all operating and safety instructions.
All information in the instructions is based upon the latest product information available at the time of publication.
Kohler China reserves the right to make changes in product characteristics, packaging, or availability atany time
without notice.
Please use the hose and tee valve come with the toilet.
Please use DN32mm or larger relief valve if there’s relief valve installed in water supply pipeline.
VEIL+
INSTALLATION INSTRUCTIONS
INTELLIGENT TOILET
K-5401T-3-0
K-5401T-XP3-0
Confirm the distance the water outlet connector away from the finished wall: upper the surface of finished wall
by 3mm and lower the surface of finished wall by 5mm, otherwise it may affect installation.
DN15mm or larger main water pipe is recommended to ensure following water supply requirements.
Do not use attachments not recommended by Kohler Co. such as angle valve etc.
WARNING: Must use 10A receptacle.
Observe all local plumbing and building codes.
Carefully inspect the new toilet for damage.
Water and electrical supplies may be wall mounted.
There is a wiring schematic on the inside of the of the junction box cover.
NOTES
DANGER: Risk of electric shock. Disconnect power before using.
NOTICE: Follow all local plumbing and electrical codes.
NOTICE: Receptacles installed in bathrooms to be located at least 1 meter from a bathtub or shower if practical.
CAUTION: Risk of hazardous gases. If a new toilet is not installed immediately, temporarily place a rag in
the floor flange opening.
When install the product in the room, a stop valve shall be installed in a close proximity. For emergency
circumstances, the water inlet valve shall be stopped without using any tools; otherwise unexpected failure may
cause the loss to the customer.
Customer shall avoid any obvious pipe shrinkage or blockage from pipe installation or PPR pipe thermal fusion
connection for better flushing effect. Ensure inlet water diameter after connection is greater than 15mm.
WARNING: Risk of electric shock，fire or personal injury. This product must be installed safely. Connect
only to dedicated 220V~, 50Hz, 10A circuit protected by Ground-Fault Circuit-Interrupters (GFCI’s) or
Earth-Leakage Circuit-Breakers (ELCB’s).
WARNING: Risk of electric shock. Connect only to circuits protected by Ground-Fault Circuit-Interrupters
(GFCI's) or Earth-Leakage Circuit-Breakers (ELCB's).
1332623-T01-H
2
Kohler Co.

Water
Measurements
Remote control Unit: mm
Waterproof socket (grounding type)
Inlet hose
Fig.#3
Kohler reserves the right to change marked dimensions without prior notice.
SPECIFICATIONS
* Power value testing condition: dynamic pressure 0.2MPa, inlet water temp 15°C.
Flush volume
Water efficiency grade*
Pit distance
Water pressure
Rated voltage
Rated power*
Max instantaneous power
Length of power line
Product outline dimension
Weight of product
Inlet water temp
Operation Environment
4.0L
Level III
305mm
Min water pressure 0
.07MPa (dynamic pressure)
Max water pressure 0.74MPa
220V~, 50Hz
1090W
About 1600W
About 1.3m
About 670mm × 438mm × 533mm
About 48kg
1-35°C
1-40°C
* The description of water efficiency label marked on intelligent toilet: water efficiency label represents a compliance mark of the water efficiency grade etc. performance of intelligent toilet.
Kohler Co.
3
1332623-T01-H

× 4
Fig.#5
Toilet
A. Hold the rim of the vitreous shell and take out the toilet.
WARNING: Risk of personal injury and product damage!Please do not hold the rim of the bidet seat when lifting the
the toilet. As the toilet is heavy, please seek help if necessary.
Overall Sketch
Crash pad
Seat (anti-microbial*)
Seating sensing area
Nozzle
Press it again to turn it off.
Press Warm Wind button to start the warm wind function.
Press the button to enter Rear Wash mode.
Light sensing area
Press the button to enter Front Wash mode.
Press it again to turn it off.
Press the button to turn off the night light function (long tone hint)
Press the button to turn off the power (long tone hint)
Press it again to turn it off.
Press it again to turn on (short tone hint)
PREPARATIONS BEFORE INSTALLATION
Cover (Antibacterial*)
Fig.#4
Press the button for Flushing(Press and hold the button to
activate emergency flush function after power is off)
*Antibacterial: the seat and cover contains long term inorganic anti-bacteria material which will inhibit bacteria growth on surface, this does not represent the mildew and other incidental
effects. The antibacterial rate is more than 90%. (Perform test in accordance with GB21551.2-2010 requirements. Testing lab: China household electrical appliances testing institute;
electromechanical products testing technology center of Shanghai Entry-Exit inspection and quarantine bureau.)
1332623-T01-H
4
Kohler Co.

Fig.#6
B. Roughing-In
DANGER: Risk of electric shock. Disconnect power before servicing.
NOTE: This product is designed to work with wall mounted electrical and water supplies as shown in the
mounting dimensions.
WARNING: Risk of electric shock. Connect only to circuits protected by Ground-Fault Circuit-Interrupters
(GFCI's) or Earth-Leakage Circuit-Breakers (ELCB's).
Keep bath and shower away from electrical parts (such as remote controller, receptacle,etc).
When the electrical supply is mounted on the wall, a GFCI or ELCB protected and water proof receptacle
is required.
Fig.#7
A.
INSTALLATION
Remove Existing Toilet (If There Is One)
Turn off the water supply. Flush the toilet, and use a sponge to remove the remaining water from the tank and
bowl. Disconnect the supply shut-off valve (if present), and remove the old tank and bowl.
B. Place an 800mmX800mm cushion on the floor, take out the toilet from the carton then put the
toilet on it.
Remove old gasket from the floor and closet flange with a putty knife. Remove old T-bolts and discard them.
NOTICE: if a new toilet is not installed immediately, temporarily stuff a rag in the closet floor flange.
Closet Floor Flange
Kohler Co.
5
1332623-T01-H

Unit: mm
Fig.#8
250 10 250 10
200 5
85 5
305
01051
01051
Fig.#10
Bolt
Mark symbol Hole(two sides)
C. 1.Confirm the drain hole center and mark down the“+”centerline
perpendicular to the finished wall.
2.Confirm the toilet drain hole center and mark down the centerline on
Front , back , left and right outside of toilet.
3.
Make sure the toilet side mark symbol is align to the drain hole
centerline on the finished floor.Mark down the left and right holes.
305mm
3/8
10mm
Fig.#9
D. Drill two holes and insert plastic inserts and T-bolts (Purchased by customer)
1332623-T01-H
6
Kohler Co.

E.
Silica gel
Fig.#1
Coated Silica gel on the opposite
side of floor flange
Position the floor flange align the
drain hole, and press it onto the
finished floor .
Install the Electrical Service and Water Supply.
properly-grounded, grounding-type receptacle protected by a Ground-Fault Circuit-Interrupter
(GFCI). Do not remove the grounding pin or use a grounding adapter.
DANGER: Risk of electric shock. Disconnect power before servicing.
DANGER: Risk of electrical shock. For plug-in installations/wall-mounted electrical supply: connect only to a
DANGER: Risk of electrical shock. For hardwire installations/through-floor electrical supply:
Connect only to a properly-grounded, dedicated 220V~, 10A, 50Hz circuit protected by
a Class A Ground-Fault Circuit-Interrupter (GFCI) or Earth-eakage Circuit-Breaker (ELCB).
NOTE: This product is designed for installation with the electrical supply attached to the wall. Both types
are illustrated. Refer to the dimensional information for your chosen installation.
Follow the dimensional information exactly when installing the hardwire electrical supply.
Nut cap
Side Plate
Fig.#1
F. Install the Floor Flange
G. Remove side plates
Unscrew the nut cap on the tee joint.
Kohler Co.
7
1332623-T01-H

Fig.#14
WARNING: Risk of personal injury. The vitreous shell weighs 35 kg. Use proper lifting technique when
handling the vitreous shell.
CAUTION: Risk of product damage. Do not set the shell down hard. Gently lift and move the shell if it is not
placed correctly. If handled harshly, the shell may chip or break.
Carefully pick up the vitreous shell.
Make sure the trap way sits fully in the outlet gasket. If the vitreous shell does not sit evenly on the floor, then the
trap way will not be properly aligned.
Make all adjustments gently reference the toilet side mark symbol and the drain hole centerline on the finished
floor until the trapway is properly seated.
Use nut and washer to fasten the bolts and fix up the toilet.
CAUTION: Risk of product damage . Do not move the toilet after the trap way is properly seated to
avoid the wax seal invalidated, Change the wax ring if it is needed to move.
WARNING: Risk of personal injury or product damage. Overtightening may cause breakage or chipping.
Fig.#13
H. Fix Wax Ring
Place the wax ring on the waste outlet.
I. Install the Vitreous Shell
Nut
1332623-T01-H
8
Kohler Co.

Fig.#16
Fig.#15
150 10
250 10
Close by rotating the handle clockwise and open by
rotating the handle counterclockwise
Handle of tee valve
Tee valve
Decorative cover
J.
2.
Install Tee Valve.
IMPORTANT!
1. Dimensions in the pictures are for reference only.
Please install deco cover on tee valve before installation.
NOTE: Do not reuse the old tee valve.
Unit: mm
1. Connect the water outlet.
2. Open the shut-off valve.
NOTE:Please use the water supply hose accompanying with new machine. The old hose assembly shall not be used
again.
K. Connect the Water
IMPORTANT!The supplied hose must be used for this installation.
Kohler Co.
9
1332623-T01-H

Fig.#17
Fig.#18
Side plate (two sides)
L. Testing Emergency Flush Button
M. Install left/right side plate after applying silicon gel; plug in and connect power supply.
NOTE:
Apply one circle of silicone gel around toilet bottom to seal the gaps. Wipe the excessive silicone gel on the
bottom of left/right plate.
Projecting portion
of silica gel are cu
t off (two sides)
Coated with silica gel
power
Press and hold flush button on toilet side panel to activate emergency function when power is off.
1332623-T01-H
10
Kohler Co.
