Kohler K-4026 Assembly instructions

Homeowners Guide
Toilet with Cleansing Seat
Français, page ″Français-1″
Español, página ″Español-1″
K-4026
1221754-5-C

IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USING
When using electrical products, especially when children are present, basic safety precautions should
always be followed, including the following:
DANGER: Risk of electric shock. Connect only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI)*.
WARNING: Risk of electric shock. Disconnect power before servicing.
*Outside North America, this device may be known as a Residual Current Device (RCD).
WARNING: To reduce the risk of burns, electrocution, fire, or injury to persons:
Close supervision is necessary when this product is used by or near children, the elderly, or
invalids. Adjust the temperature of the seat for the elderly, those who are incapacitated, or persons
with sensitive skin.
Use this product only for its intended use as described in this manual. Do not use attachments not
recommended by Kohler Co.
Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has
been dropped, damaged, or dropped into water. Return the product for examination and repair.
Keep the cord away from heated surfaces.
Never block the air openings of the product. Keep the air openings free of lint, hair, and the like.
Never use while sleeping or drowsy.
Never drop or insert any object into any opening or hose.
Do not use outdoors or operate where aerosol spray products are being used or where oxygen is
being administered.
Connect this product to a properly grounded outlet only. See the ″Grounding instructions″section.
SAVE THESE INSTRUCTIONS
Grounding Instructions
This product should be grounded. In the event of an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire for the electric current. This product is equipped
with a cord having a grounding wire with a grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded.
DANGER: Risk of electric shock. Improper use of the grounding plug can result in a risk of
electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to either
flat blade terminal. The wire with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire.
Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt whether the product is properly grounded.
Do not use an extension cord with this product.
1221754-5-C 2 Kohler Co.

Features - Toilet
NOTE: Many of the features can be adjusted, enabled, or disabled using the remote control. Specific
directions for these procedures are listed later in this manual.
General Features
Automatic Flushing - Automatically flushes the toilet after the user stands up, lowers the seat, or
leaves the area 60 seconds after use.
Automatic Open/Close - Automatically opens the seat cover when the toilet is approached. The
cover and seat will automatically close when approached if they are open. The seat and seat cover
will automatically close 3 minutes after the toilet has been used.
Energy Save Mode - The toilet can be programmed to conserve energy. When enabled, the toilet
will enter and exit an energy conservation mode at programmed times. The toilet comes with this
feature enabled and set to 6 hours.
Deodorizer - Eliminates or reduces unpleasant odors while the toilet is in use.
Side Controls - Allow the user to control basic toilet features without the remote control.
Heated Seat - An adjustable heating option that keeps the seat warm.
Night Light - Automatically turns on in low light conditions.
Cleansing Features
Front/Rear Wash - Front and rear wash feature adjustable positioning, adjustable water temperature,
adjustable water pressure, and pulsate and oscillate water action.
Dryer - The dryer features adjustable air temperature.
Actuation Switch
Remote Control
Signal Sensor
Side Control Panel
Seat Sensor Area
Sensor Area
Dryer
Power On/Off
Rear Wash
Low Light Sensor
Front Wash
Spray
Wand
Kohler Co. 3 1221754-5-C

Features - Remote Control
Top of Remote Control
Manual Flush - Press to flush the toilet.
Presets 1 and 2 - Allows two sets of user settings to be saved. Select one of these buttons to use the
settings saved with that preset.
Wake Up - Press to activate the remote control when it is hibernating.
Seat Cover Close - Press to close the cover.
Seat Cover Open/Seat Close - Press to open the seat cover or close the seat.
Seat and Seat Cover Open - Press to open the seat cover and seat.
Signal Window - Signal emanates from this area. The signal window should not be covered when
the remote control is in use.
Front of Remote Control
Stop - Press to stop the cleansing wash and deodorizer.
Selection Adjustment Arrows - Press to change the selections shown in the display window, adjust
settings, or change the options on features.
Menu - Press to activate or deactivate features, program features, and program the clock.
Front - Press to activate the front wash.
Rear - Press to activate the rear wash.
Pulsate - Press to activate pulsating action from the cleansing wand. Water pressure will vary while
pulsating action is activated.
Pressure
Temperature
Wand Position
Time Display
Auto Open/Close
Power Save
Auto Flush
Preset
Battery Low Display
Infrared Sending Indication
Pulsate
Deodorizer
Dryer
Oscillate
Rear Wash
Front Wash
Menu
Selection Adjustment
Arrows
Stop
Preset 1 & 2
Seat Cover Close
Wake Up
Seat and Seat Cover Open
Seat Cover Open / Seat Close
Manual Flush
Menu
Stop Front Rear
OscillatePulsate
DryerDeodorizer
Selection Box
Signal Window
Signal Window
1221754-5-C 4 Kohler Co.

Features - Remote Control (cont.)
Oscillate - Press to activate or deactivate oscillating action on the cleansing wand. When oscillate is
activated the wand slides in and out.
Deodorizer - Press to activate or deactivate the deodorizer feature. When activated the deodorizer
fan will turn on.
Dryer - Press to activate the dryer.
Display Screen On Remote Control
Time or Feature Display - This area will display the time when the remote control is not in use. The
active feature will be displayed when the remote control is in use. When the menu option is selected
the features will display here.
Temperature - Select this icon to adjust the water temperature or air temperature when the
cleansing features are in use. Press the left arrow to decrease the temperature or right arrow to
increase the temperature.
Pressure - Select this icon to adjust the water pressure when front or rear wash is activated.
Selection Box - Appears around a feature that is selected. That feature can then be adjusted using
the right and left arrows. Move the box to another option by using the up or down arrows.
Wand Position - Select this icon to adjust the position of the wand. Press the left arrow to move the
wand back or right arrow to move the wand forward.
Infrared Sending Indication - The remote control is connected to the toilet when this icon is
present.
Low Battery Indicator - Batteries need replacement when this icon is present.
Power Save - The remote control is inactive when this icon is present.
Auto Flush - The auto flush feature is activated when this icon is present.
Preset - One of the user presets is selected when this icon is present.
Auto Open/Close - When this icon is pictured the auto open/close feature is activated. The feature
is deactivated if this icon is not present.
Kohler Co. 5 1221754-5-C

Feature Setup or Changes
Clock
Press the [Wake Up] button.
Press the ″Menu″icon and press the up or down arrow until [Clock set] is displayed.
Press the right arrow. Select [12H] or [24H] for the display style using the up or down arrows.
Press the right arrow and adjust the hour using the up and down arrows. The hours will also
change the [am] or [pm] setting.
Press the right arrow and adjust the minutes using the up or down arrows.
Press the ″Menu″icon to save the setting.
Auto-flush
Press the [Wake Up] button.
Press the ″Menu″icon and press the up or down arrow until [Auto-flush] is displayed.
Press the right arrow, and change the setting to [Auto-flush:on] or [Auto-flush:off] using the up or
down arrows.
Press the ″Menu″icon to save the setting.
Power Save
NOTE: Power save mode deactivates the heated seat. When the toilet is in power save mode the indicator
light in the sensing window appears red.
Press the [Wake Up] button.
Press the ″Menu″icon and press the up or down arrow until you find [Power save].
Pressure
Temperature
Wand Position
Time Display
Auto Open/Close
Power Save
Auto Flush
Preset
Battery Low Display
Infrared Sending Indication
Pulsate
Deodorizer
Dryer
Oscillate
Rear Wash
Front Wash
Menu
Selection Adjustment
Arrows
Stop
Preset 1 & 2
Seat Cover Close
Wake Up
Seat and Seat Cover Open
Seat Cover Open / Seat Close
Manual Flush
Menu
Stop Front Rear
OscillatePulsate
DryerDeodorizer
Selection Box
Signal Window
Signal Window
1221754-5-C 6 Kohler Co.

Feature Setup or Changes (cont.)
Press the right arrow and change the setting to [Timer: off ],[Timer: 3 hrs ],[Timer: 6 hrs],or
[Timer: 9 hrs].
Press the ″Menu″icon to save the setting.
Seat Temperature
Press the [Wake Up] button.
Press the ″Menu″icon and press the up or down arrow until [Seat temp] appears.
Select the right arrow, then use the up or down arrow until your desired setting is displayed.
Press the ″Menu″icon to save the setting.
Language
Press the [Wake Up] button.
Press the ″Menu″icon
Press the up or down arrow until you reach the [Language] selection.
Select the right arrow, then select the up or down arrow until the desired language appears.
Press the ″Menu″icon to save the setting.
Night Light
Press the [Wake Up] button.
Press the ″Menu″icon and press the up or down arrow until [Night light] appears.
Select the right arrow, then use the up or down arrow to change the setting to [Light: on] or [Light:
off].
Press the ″Menu″icon to save the setting.
Seat Auto Open/Close
Press the [Wake Up] button.
Press the ″Menu″icon and press the up or down arrow until [Auto-open seat] appears.
Select the right arrow, then use the up or down arrow to change the setting to [Auto-open: on] or
[Auto-open: off].
Press the ″Menu″icon to save the setting.
Kohler Co. 7 1221754-5-C

Manual Operation
NOTE: When the cleansing wash features are activated from the side control panel, they will default to
the middle temperature, pressure, and wand position settings.
″Rear″-Press the icon to activate rear wash. Press again to stop rear wash.
″Front″-Press the icon to activate front wash. Press again to stop front wash.
″Dryer″-Press the icon to activate the dryer. Press again to stop the dryer.
″Power″-Press the icon to turn the power off.
Remote Control Sensor - Receives the signal from the remote control.
Low Light Sensor - Senses low light levels and turns the nightlight on when the automatic feature
is enabled. To enable or disable the nightlight, refer to the ″Enable/Disable Automatic Features″
section.
Flush - Press the actuation button to manually flush the toilet. To flush during a power outage, pour
a 2-gallon bucket of water into the bowl.
Actuation Switch
Remote Control
Signal Sensor
Side Control Panel
Seat Sensor Area
Sensor Area
Dryer
Power On/Off
Rear Wash
Low Light Sensor
Front Wash
Spray
Wand
1221754-5-C 8 Kohler Co.

Using the Cleansing Features
NOTE: The cleansing feature will automatically stop after 5 minutes.
NOTE: Cleansing features can also be activated using the side controls on the toilet.
NOTE: Water temperature, water pressure, wand position, and massage action are adjustable while the
front or rear wash is in use.
Using the Front Cleansing Wash
Press the [Wake Up] button.
Press the ″Front″icon.
Press the ″Stop″icon to end.
Using the Rear Cleansing Wash
Press the [Wake Up] button.
Press the ″Rear″icon.
Adjusting the Water Temperature
NOTE: The temperature level is shown next to the thermometer in the display.
Make sure the thermometer icon is indicated and [Front: temp] appears in the window.
If needed, select the thermometer icon using the up and down arrows.
Press the right arrow to increase the water temperature or left arrow to decrease the water
temperature. There are three settings available.
Adjusting the Water Pressure
Make sure the water pressure icon is indicated and [Front: pressure] appears in the window.
If needed, select the thermometer icon using the up and down arrows.
Press the right arrow to increase the water pressure or left arrow to decrease the water pressure.
There are three settings.
Adjusting the Wand Position
Make sure the wand icon is indicated and [Front: position] appears in the window.
If needed, select the wand position icon using the up and down arrows.
Press the right arrow to increase the water temperature or left arrow to decrease the water
temperature. There are three settings.
Oscillate
Pulsate
Display Window
Water Pressure
Wand Position
Thermometer
Adjustment Arrows Deodorizer Dryer
Pulsate Oscillate
RearFront
Stop
Menu
Wake Up
Rear Wash
Front Wash
Kohler Co. 9 1221754-5-C

Using the Cleansing Features (cont.)
Oscillate and Pulsate
Select the ″Pulsate″or ″Oscillate″icons.
If needed, select the thermometer icon using the up and down arrows.
Press the right arrow to increase the water temperature or left arrow to decrease the water
temperature. There are three settings.
1221754-5-C 10 Kohler Co.
