Kohler K-5401TW-2-0 Assembly instructions

IMPORTER: KOHLER ASIA PACIFIC TAIWAN BRANCH, TEL.: [phone]
8F., No. 148, SONGJIANG Rd., ZHONGSHAN DIST., TAIPEI CITY 104,
TAIWAN (R.O.C.), POST CODE: 104492
進口商 : 香港商科勒亞洲有限公司台灣分公司 電話: [phone]
台灣台北市中山區松江路148號8樓 郵編: 104492
Homeowners Guide
用戶手冊
VEIL+ INTELLIGENT TOILET
Veil全自動馬桶便座
K-5401TW-2-0
English page
2-23
24-45
1413476-TW01-A

Contents
Cautions and warning………………………………………………………………………………........... 3
Specification…………………………………………………………………………………………………
Thank you for choosing Kohler Company………………………………………………………………..
Overall diagram……………………………………………………………………………………………..
Guide on usage of remote controller……………………………………………………………………..
Guide on setting of remote controller……………………………………………………………………..
Preparations before initial use……………………………………………………………………………...…
Function for opening/closing of cover/seat…………………………………………………………….…
5
6
6
7
8
.. 10
11
Flushing of toilet…………………………………………………………………………………………..... 12
15
15
16
16
16
16
Trouble shooting………………………………………………………………………………...............… 21
Description of Content of Hazardous Substances in Product ……………………………………...… 23
Auxiliary keyboard function………………………… …………………………………………………...…
Standby mode …………………………………………………………………………………………….… 15
UV sterilization function…………………………………………………………………………………. …
Sterilized water…………………………………………………………………………………………….…
Automatic energy saving function…………………………………………………………………………
Deodorizer………………………………………………………………………………………………………
Maintenance and cleaning……………………………………………………………………………… .. …
1413476-TW01-A
2
Kohler Co.

Cautions and Warnings
Save this instruction
Children, elders or those with disabilities from their body, sensitivity or mental disabilities or lacking of
common sense should not use or get close to this product unless under close tutelage. Children are not
allowed to use or touch this product. Do not leave children alone in a room with such product.
Warning: Risk of electric shock, fire or personal injury. This product must be installed safely. Connect
only to dedicated 110V~, 60Hz, 15A circuit protected by Ground-Fault Circuit-Interrupters (GFCI’s) or
Earth-Leakage Circuit-Breakers (ELCB’s).
Warning: Risk of electric shock or product damage. Do not immerse the product into water.
Warning: Do not use any hard setting material (cement mortar) while installing the toilet. Thermal
expansion of hard setting material (cement mortar) will damage or crash the feet of toilet. Kohler will
not be responsible for any damage because of using hard setting material (cement mortar) for toilet
installation.
Warning: Risk of product damage.Do not throw into the toilet what that will cause the toilet to
block such as newspapers and sanitary towel.Do not bump the vitreous china with great force as it
will cause damage and leaking.
Important! Risk of product damage. Do not install at a place where it may be splashed by water.
Important! Risk of product damage. Do not install the product at a place with excessive humidity, where
moisture may condense at the surface of the product. Please maintain that the usage envi-ronment is under
adequate ventilation, so as to prevent damage to electronic components.
Important! Risk of product damage or property loss. Water leakage may happen if the water pipe
connector is pulled or pushed with excessive force.
Important! Risk of product damage. The product may be damaged if the nozzle is applied with
excessive force.
Important! Risk of product damage. The part of the pipe where water may be frozen should be protected by
thermal insulation. Any water left in the product may be frozen during the winter season. Please keep the
product in room temperature before reinstallation or usage.
Important! Risk of product damage. The power shall not be connected before the work is finished.
Otherwise it may lead to product failure.
Attention: The thermal protector may be out of order during storage or transportation in warm climate
which can lead to product failure. Please ensure the product cools to room temperature before
reinstallation or usage.
When an electrical product is used, especially when children are near, the following basic safety
precautions shall be abided by:
Danger-Reduce risk of electric shock:
Do not place or store this appliance where it can fall or be pulled into a bath or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug immediately.
WARNING - To reduce the risk of low grade burns, electric shock, fire or injury to persons:
□
Kohler Co.
3
1413476-TW01-A

CAUTIONS AND WARNINGS
□
been dropped into water.
Install this product properly by following the installation procedure.
□
□For those children and the elderly who are unable to adjust the temperature, they should ask for
help to adjust seat temp, water temp and wind temp of toilet cover to proper gears.
□
recommended by Kohler Co.
Do not lean on cover when use this appliance to prevent product from damage.
□
□
□
□
When install the product in the room, a stop valve shall be installed in a close proximity. For emergency
circumstances, the water inlet valve shall be stopped without using any tools; otherwise unexpected failure
may cause the loss to the customer.
Keep power line far from heated surface.
Do not drop or insert any substance to pipeline or the opening.
Do not use this product outdoor or in a place where a particle mist spray device is used,neither at a
place of provisions.
The installation should be subject to the instructions before the power is connected.
Water should not be poured into the power plug.
Exposed skin should not make contact with heating seat for too long a time to prevent low temperature
burning.
□
□
□
□
□
□
□
□
□
the professionals from its maintenance department or similar departments, to avoid the occurrence of danger.
Please use the water supply hose accompanying with new machine. The old hose assembly shall not be
used again.
When customer cut power supply off, if reactivation of power supply is required, please wait until the end of
“beep……” indication, and then turn on power supply again.
This product shall be repaired by professionals only. The warranty will become invalid if you try to repair
this product by yourself.
1413476-TW01-A
4
Kohler Co.

Specification
Water supply volume
Average 4.0L, Full flush 6.0L, Flush ECO 3.0L
Pit distance 305mm
Min water pressure 0. MPa (dynamic pressure)
Max water pressure 0.74MPa
Water pressure
Rated voltage 110V~, 60Hz
Rated power* 1100W
Length of power line About 0.9m
Product outline dimension About 670mm × 438mm × 533mm
Weight of product About 43kg
Rear wash YES, adjustable
Spiral wash YES, adjustable
Front wash YES, adjustable
Water flow (water pressure 0.2MPa)
Max rear wash shall be no less than 500mL/min
Adjust cleaning water temp OFF, adjustable 5 dials (ambient temp, about 31-39°C)
Cleaning Cleaning time (Max) About 300s
Adjustment of nozzle position 5 gears
Impulse massage On/Off
Wand oscillate On/Off
Water temp overheat
protection Thermal fuse
Prevention of backflow Check valve
Thermal Temp adjustment OFF, adjustable 5 dials
Safety device Thermal fuse
Cover Automatic open/close, lower slowly, remote open/close
Comfort Seat Lower slowly, remote open/close
Temp adjustment OFF, adjustable 5 dials
Dryer Safety device Thermal fuse
Deodorizing function Yes
Remote controller For functional setting, see Page 8-9
Self-cleaning of nozzle Yes
Antibacterial materials Seat and cover
Sanitation sterilized water Yes
UV sanitize Yes
Auxiliary keyboard Yes
Seating detection Located inside the seat
Other Night light Yes
Auto cover opening/closing Microwave sensing
Manual flush Yes
*Power value testing condition: dynamic pressure 0.2MPa, inlet water temp 15°C.
Safety
device
Kohler Co.
5
1413476-TW01-A

Thank you for choosing Kohler. Kohler technology provides reliable performance and elegant life, satisfying your
demand now and into the future. Aesthetics and reliability of Kohler products will surely satisfy your personal
style. We are very proud of Kohler products and you will be as well.
Please take a few minutes to read this user manual and pay special attention to the maintenance and cleaning
instructions.
All information in this instruction is based on the latest published product information. We always persist in
improving the quality of all Kohler products. We reserve the right to change product features, packaging or
practicability of products at any time without making notification.
crash pad × 4
Seat (antibiosis)
Nozzle
Cover (antibiosis)
Seating sensing area
Thank you for choosing Kohler Company
Overall diagram
1413476-TW01-A
6
Kohler Co.

Warning: Take down the remote control from charger before pressing Start key to prevent risk of falling.
Guide on usage of remote controller
Press this key to flush the toilet with a small volume of water.
●Press this key to flush the toilet with a small large volume of water.
Press this key to stop the mode of Front, Rear, Dryer and Deodorization, Manual Cleaning Effuser or UV.
●Pressing this key for a long time will turn off the remote control.
A - Start
Press this key to turn on the remote control. Press it again to switch on/off after start.
If the toilet is not connected after start, the icon in the third row will flicker. Connecting it successfully will stop it
from flickering and enter into serviceable condition.
B - Open/close cover
Under non-seating status, press this key to open/close the cover.
C - Open/close seat
Under non-seating status, press this key to open/close the seat.
E - Flush-full
F - Seat temp
Press this key to adjust the desired seat temp. Adjust to 5 blue points, and the heating function for the seat will
be turned off.
G - Front
After seating, press this key to enter Front mode. After 5 minutes or so, the flush stops automatically or press the
stop key to turn it off immediately.
I - Rear
After sitting, press this key to enter Rear mode. After 5 minutes or so, the flush stops automatically or press the
stop key to turn it off immediately.
J - Water temp
Under Front or Rear mode, press this key to adjust gears of water temp.
K - Massage
Under Front or Rear mode, press this key to enter the mode of mobile flushing. Press it again to enter the mode
of impulse flushing. Press it at a third time, and the mode of mobile/impulse flushing will be activated at the same
time. Press it at a fourth time to exit (When corresponding functions are activated, the light at the left side of icon
will turn on).
L - Spiral
During the operation under Rear mode, press this key to flush water in a spiral shape. The icon of Spiral mode
flickers. Press it again to exit (or press “Stop” to turn it off). The icon of Spiral mode will then stop flickering.
H - Stop
●
D - Flush-eco
●
Kohler Co.
7
1413476-TW01-A
B
G
H
DC
I
J
F
N
O
E
P
M
L
K
A
Cover 便蓋 Seat 座圈 Flush-eco 小沖 Flush-full 大沖 Seat temp 圈溫
UV
Stop 停止 Front 女性沖洗 Rear 臀部沖洗 Dryer 暖風 Clean 紫外線除菌
Water temp 水溫 Massage脈沖/移動 Spiral
旋轉沖洗 Wand 噴管移動 Pressure 水壓

Low voltage alarm
Pairing
Caution: Pairing can be done only under unseated status.
● When the cover is powered on normally, press the Start key at the top of the remote control. When the icon of
the lowest row flickers for a long time, it means the remote control needs to be paired with the main unit.
●Press and hold the Dryer key. When the icon at the lowest row flickers, start the operation at the main unit end.
● key and key at side keyboard. Do not release the key until hearing a Meanwhile press and hold the
short beep.
●Once the icon at the lowest row of remote control stops flickering, it means it has been paired successfully.
Caution: Please charge in time when the voltage alarm is activated.
Communication between remote control and toilet
Poweroff function
Remote Setup Guideline
● If the remote control is moved away from the sensing area, the icon at the bottom row of remote control will
flicker automatically (indicating a searching the signal for the toilet). When the remote is near to the toilet, the
signal will be connected automatically under normal power condition. Then the icon will stop flickering when it is
connected successfully.
●Press and hold the key at any time, the remote controller will enter Power off mode.
When the button flickers, it indicates that the built-in battery in the remote control is used up. Put the
controller on the base to charge its battery;
M - Wand movement
Under Front or Rear mode, press this key to adjust moving position of effuser.
N - Dryer
After sitting, press it once to turn on the dryer function. Press it again to adjust dryer gears. After 4 minutes
or so, it stops automatically or press the Stop key to turn it off immediately.
O - UV serialization
During non-seating status, short press this key to enter UV sterilization function. And the icon will flicker.
P - Water pressure
Under front or rear wash mode, press this key to adjust water pressure.
1413476-TW01-A
8
Kohler Co.
B
G
H
DC
I
J
F
N
O
E
P
M
L
K
Cover 便蓋 Seat 座圈 Flush-eco 小沖 Flush-full 大沖 Seat temp 圈溫
UV
Stop 停止 Front 女性沖洗 Rear 臀部沖洗 Dryer 暖風 Clean 紫外線除菌
Water temp 水溫 Massage脈沖/移動 Spiral旋轉沖洗 Wand 噴管移動 Pressure 水壓

Cover 便蓋 Seat 座圈 Flush-eco 小沖 Flush-full 大沖 Seat temp圈溫
UV
Stop 停止 Front 女性沖洗 Rear 臀部沖洗 Dryer 暖風 Clean 紫外線除菌
Water temp 水溫 Massage 脈沖/移動 Spiral
旋轉沖洗 Wand 噴管移動 Pressure 水壓
Red Lamp Flicker
Usage and Replacement of Battery for Remote Controller
Others
□Do not put the remote control at a place where it may be sprayed by liquid, or immersed in liquid.
□Do not place it near hand dryer, hair dryer and small size home appliances, to avoid disturbance of
normal usage of the remote control.
□Do not apply external force to the key zone of remote controller frequently or fiercely.
□After usage of remote control, put it back into the remote holder mounted on wall.
□Prevent dropping the remote control during usage.
□Anti-loss function: lock remote on docking station by screws. Specific method refers to installation instruction.
Keep pressing the key until a short beep is heard, and release the key only after the night lamp flickers for
three times. Then change the setting of B/C/E/F/O by the following requirements.
B-Open/close the cover…Sensing distance setting
2. Night light slow flickers once to turn off auto UV function (long beep).
Battery holder - of remote controller uses 4 #5 alkaline batteries.
When battery is low, the battery holder lamp will flicker in red indicating
the batteries need to be replaced, indicate the replacement of battery.
Caution:
1.The positive and negative polarities of battery must be consistent with
the mark of remote controller.
2.New and old batteries shall not be mixed.
3.Please use alkaline battery.
Press and hold the key to set up the sensing distance for auto cover-turning:
1.Night light quick flickers once means short distance (short beep).
2.Night light quick flickers twice means mid distance (short beep) .
3.Night light quick flickers three times means long distance (short beep).
4.Night light slow flickers once means turn off auto lid-turning function (long beep).
C - Seat On/Off…Deodorization function setting
●
●
●
●Press and hold this key to turn on/off the deodorization function.
1. .
2. .
●Press and hold this key to turn off the function of automatic flushing. Press and hold it again to restore
1.Night light quick flickers once to turn on auto flush function (short beep).
2.Night light slow flickers once to turn off auto flush function (long beep).
●Press and hold the key of Seat Temp to activate the function of energy saving. Press and hold it again to
.
.
●
●Under non-seating status, press and hold this key to activate the function of manual cleaning. The nozzle can be
O - UV sterilization (UV light)…Setting of UV automatic sterilization
Night light quick flickers once to turn on auto UV function (short beep).
1.
2.
E - Flush-full…Automatic flushing setting
flushing.
F - Seat temp…Energy saving setting
function.
Press and hold to set up the on/off status of automatic UV sterilization.
1.
When the setting of B/C/E/F/O is not modified for a certain period, repeat the process that is to keep pressing the
key until a short pip is heard and release the key only after the night lamp flickers for three times before
the next change of setting.
M - Effuser movement…Effuser cleaning settings
Kohler Co.
9
1413476-TW01-A

Preparations before the initial use
□Confirm that the battery has been correctly installed in the "remote controller".
□Confirm that there is no obstacle in front of the product.
□the toilet complete the self check, after the product is powered on. During that time, it is normal to hear
rotating sound of the motor and bicker, or see the night light flicker. When the lighting stops flickering, the
self-check is completed.
□When used for the first time, it will be in a default state:
Tee valve connection
Seat temp: mid
Wind temp: mid
Night light: On
Energy saving mode: On
Electrolyzed water function: On
Water pump: On (press and hold flush and front
wash button on toilet side panel, short “beep”
indicates water pump is on, long “beep”
indicates water pump is off.)
Front:
●Water temp: mid
●: mid
●Position: mid
Rear:
●Water temp: mid
Position: mid
●: mid
●
Spiral:
●Water temp: mid
●: mid
●Position: mid
□Ensure if water inlet valve is OPEN.
1413476-TW01-A
10
Kohler Co.
