Kokido Lektra FX User manual

BC12 BATTERY-POWERED POOL VACUUM
Specification : Motor: 12 Volt DC / Battery: Requires 8 x 1.5V AA (Not included) / Operating temperature: 41°F to
104°F (+ 5°C to + 40°C)
WARNING!
THIS IS NOT A TOY. KEEP CHILDREN OUT OF REACH OF THIS PRODUCT AND ITS
ACCESSORIES.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazard involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
This vacuum creates suction. Keep hair, loose clothing, fingers, and all body parts away
from nozzle.
Never use this pool vacuum if anyone is in water.
Never attempt to unscrew and disassemble the unit for any reasons.
CAUTION
- This pool vacuum is designed for
underwater use only. DO NOT attempt to
use this pool vacuum to clean anything
other than your pool or spa. It must be
submerged in water over the water vent.
- DO NOT operate this pool vacuum out
of water, otherwise the motor may be
damaged.
- DO NOT scrape the canopy against
acrylic spas, as this may damage the
spa surface.
- DO NOT insert any object into the water
vent of the pool vacuum.
- DO NOT leave the pool vacuum in pool
or spa when it’s not in use.
- NEVER use the pool vacuum without a
filter bag in place.
- NEVER block the pool vacuum’s water
vent during operation.
- NEVER rotate the pole of the pool
vacuum anticlockwise during operation,
otherwise the battery cover could loosen
and water might leak into the battery
com
p
artment.
Accessories
A
. Battery compartment
cover / pole connector
B. Battery holde
r
C. Gasket / O-ring
D. Battery compartment &
handle
E. ON/OFF button
F
. Impeller
G. Impeller chambe
r
H. Water vent
I. Filter bag
J. Canopy
K. Nozzle flap
L. Suction head
M. Wheel
N. Brush
0. Pole
Set Up of Pool Vacuum
Suction head assembly Pole Assembly
Note: For vinyl liner and fiberglass pools / spas, it is
recommended to keep the suction head
to avoid damaging
the pool / spa.
GB

Battery Assembly
Unscrew the battery compartment cover and remove the battery holder.
Place 8 AA batteries into the battery holder in accordance with the polarity markings.
Align the rib and slide the battery holder into the compartment with the marking “TOP”
facing outwards as shown. (Fig.1)
Securely screw the battery compartment cover back on. Make sure the O-ring is in place.
(Avoid stripping threaded fitting)
CAUTION: DO NOT press the ON/OFF button to switch on the pool vacuum until it is
submerged in water and the water level is above the water vent.
WARNING!
1. Ensure batteries are inserted properly and with the correct polarity
2. Do not mix new and used batteries or mix batteries of different types - ONLY use a
complete set of new batteries of the same type
3. Do not recharge non-rechargeable batteries
4. Remove exhausted batteries from the product
5. The supply terminals are not to be short-circuited
6. Dispose of batteries safely
To Clean Your Pool or Spa
Place the pool vacuum in water and make sure the water level is above the water vent. Use a telescopic pole (not
provided) if the total length of the assembled pole (included) is not sufficient. Press the ON/OFF button to start
vacuuming.
CAUTION:
NEVER use the pool vacuum without a filter bag in place, as this could permanently damage the pool vacuum impeller
and motor.
Cleaning the Filter Bag
WARNING! Turn off the pool vacuum before proceeding to following steps:
NOTE: Water will accumulate inside the suction head and the pole after use. To remove the water, lift the pool vacuum
from the pool or spa with the suction head facing down to drain the water.
1. Hold the pool vacuum body and turn the canopy anticlockwise until
the embossed marking on the canopy reaches the lock-unlock marking.
Detach the canopy and remove the filter bag from the pool vacuum.
2. Remove the filter bag. Rid the bag of leaves and other debris, then
rinse it. Rinse the canopy as well and make sure its suction hole is not
clogged.
3. Replace the filter bag inside the pool vacuum. Reverse the steps to
align and attach the canopy to pool vacuum and turn the canopy
clockwise until it comes to a halt.
AFTER EACH USE, ALWAYS DRAIN WATER FROM THE UNIT BY REMOVING THE CANOPY, HOLD IT
VERTICALLY, AND DRY IT BEFORE STORAGE. DO NOT LEAVE THE UNIT IN THE POOL OR SPA WHEN IT IS
NOT IN USE. DO NOT STORE IT UNDER DIRECT SUNLIGHT. DO NOT STORE THE UNIT OUTDOORS OR IN A
LOCATION WITH FREEZING TEMPERATURE OR BELOW. REMOVE THE BATTERIES AND THE CASE WHEN
THE UNIT IS NOT TO BE USED FOR A LONG PERIOD. ALWAYS KEEP THE BATTERY CHAMBER AND
COMPARTMENT DRY.
TROUBLESHOOTING
If the suction of the pool vacuum is weak or stops:
Check and see if the power switch is “ON”.
Check and see if batteries are low. Replace with new battery.
WARNING! Turn off the pool vacuum before proceeding to the following:
Check and see if the filter bag is full of debris. Clean as required.
Check and see if the suction nozzle on the canopy is clogged. Turn off the power and clean it.
If the impeller becomes clogged, be sure the pool vacuum is in the off position.
Remove batteries from the compartment. Remove filter bag and check for holes or damage (Replace if
necessary). Flush water vent H with water. Remove any visible debris. Replace filter bag, fittings, batteries, and
battery cover. Submerge the water vent and switch the pool vacuum on.
21010020
Kokido Development Ltd
1319, 27 Shing Yip St, Kwun Tong, HK
