Kongsberg MBR 144 OEM User manual

G210–58/3
?????2020©KongsbergSeatexAS
MBR144OEM
MaritimeBroadbandRadio
InstructionManual

KongsbergSeatexAS
www.kongsberg.com
Documentinformation
•Product:MBR144OEM
•Document:InstructionManual
•Documentpartnumber:G210–58
Copyright
TheinformationcontainedinthisdocumentremainsthesolepropertyofKongsbergSeatexAS.Nopartof
thisdocumentmaybecopiedorreproducedinanyformorbyanymeans,andtheinformationcontained
withinitisnottobecommunicatedtoathirdparty,withoutthepriorwrittenconsentofKongsberg
SeatexAS.
Warning
Theequipmenttowhichthismanualappliesmustonlybeusedforthepurposeforwhichitwas
designed.Improperuseormaintenancemaycausedamagetotheequipmentand/orinjurytopersonnel.
Youmustbefamiliarwiththecontentsoftheappropriatemanualsbeforeattemptingtooperate
orworkontheequipment.
KongsbergSeatexdisclaimsanyresponsibilityfordamageorinjurycausedbyimproperinstallation,
useormaintenanceoftheequipment.
Disclaimer
KongsbergSeatexASendeavourstoensurethatallinformationinthisdocumentiscorrectandfairly
stated,butdoesnotacceptliabilityforanyerrorsoromissions.
Supportinformation
Ifyourequiremaintenanceorrepair,contactKongsbergMaritime’ssupportorganisation.Youcancontact
ususingthefollowingaddress:[email protected]g.com.Ifyouneedinformationaboutour
otherproducts,visithttp://www.kongsberg.com.

G210–58/33
Tableofcontents
ABOUTTHISMANUAL..............................................................5
MBR144OEM..........................................................................6
Systemdescription.............................................................................................................6
Systemdiagram..................................................................................................................7
Scopeofsupply..................................................................................................................7
Restrictionsinguarantee....................................................................................................8
Radiofrequencylicense.....................................................................................................8
Equipmentidentication....................................................................................................8
FCCcompliancestatement................................................................................................9
ISEDCanadacompliancestatement..................................................................................9
Exposurestatement..........................................................................................................10
Healthandsafety..............................................................................................................11
Networksecurity..............................................................................................................11
Supportinformation.........................................................................................................12
OPERATION...........................................................................13
Gettingstarted..................................................................................................................13
TurningontheRadioUnit......................................................................................13
EnablingcontactwiththeRadioUnit....................................................................14
DeningtheIPaddressonthecomputernetworkadapter.....................................15
Operatingprocedures.......................................................................................................17
Settinguptheradiositeforoperation....................................................................17
Creatinganewradionetwork................................................................................22
Joiningaradionetwork..........................................................................................24
Editinganexistingradionetwork..........................................................................25
Addingorremovingthirdpartyequipment............................................................26
CheckingthestatusoftheMBRnetwork..............................................................28
Userpreferenceprocedures..............................................................................................29
Choosingthecolourpalette....................................................................................29
Userinterface...................................................................................................................30
Operationalprinciples............................................................................................30
Displayorganisation...............................................................................................30
Functionsanddialogboxes..............................................................................................31
Menusystem...........................................................................................................32
Welcome.................................................................................................................32
Congurationguide................................................................................................33
Createsite...............................................................................................................34
Addradiostosite....................................................................................................35
InstructionManual

4G210–58/3
Conguresite.........................................................................................................36
Thirdpartyequipment............................................................................................38
Status......................................................................................................................39
Editcurrentnetwork...............................................................................................40
Newnetwork..........................................................................................................41
Resourcemanagement............................................................................................43
Joinnetwork...........................................................................................................44
Systemstatus..........................................................................................................45
Networkstatus........................................................................................................45
Individualradiositestatus......................................................................................45
INSTALLATION......................................................................46
Preparations......................................................................................................................46
Mechanicaldrawings..............................................................................................46
Necessarytoolsandequipment..............................................................................47
RadioUnitlocation................................................................................................47
Arrangingtheantennas....................................................................................................47
InstallingtheRadioUnit..................................................................................................49
Cablelayoutandinterconnections...................................................................................50
Settingtoworksummary.................................................................................................51
DRAWINGS............................................................................52
Aboutdrawings................................................................................................................52
RadioUnitdimensions.....................................................................................................53
TECHNICALSPECIFICATIONS................................................54
Performancespecications..............................................................................................54
Interfacespecications.....................................................................................................54
Frequencyspecications..................................................................................................55
Weightandoutlinedimensions........................................................................................55
Powerspecications.........................................................................................................56
Environmentalspecications...........................................................................................56
Standardsandregulations................................................................................................56
MAINTENANCE......................................................................58
Checkingtheproductversion..........................................................................................58
RepairingtheRadioUnit.................................................................................................58
EQUIPMENTHANDLING.........................................................60
Takingdelivery................................................................................................................60
Unpackingandhandling..................................................................................................60
Storage.............................................................................................................................61
Disposal...........................................................................................................................61
MBR144OEM

G210–58/35
Aboutthismanual
Purposeofmanual
Thepurposeofthismanualistoprovidethedescriptionsandproceduresrequiredto
install,congure,operateandmaintaintheMBR144OEM.
Targetaudience
ThismanualisintendedforallusersoftheMBR144OEM.Thisincludesproject
engineeringpersonnel,installationpersonnel,ITadministratorsandoperators.
Licenseinformation
TheMBR144OEMisnotsubjecttoproductlicensing.Theproductisaradio
transmittingdevice.Afrequencylicenseisrequiredforoperation.
Maintenancepurposes
Thismanualisalsointendedasreferencematerialforthemaintenancepersonnel.Keep
thismanualforlateruse.
Aboutthismanual

6G210–58/3
MBR144OEM
Topics
Systemdescription,page6
Systemdiagram,page7
Scopeofsupply,page7
Restrictionsinguarantee,page8
Radiofrequencylicense,page8
Equipmentidentication,page8
FCCcompliancestatement,page9
ISEDCanadacompliancestatement,page9
Exposurestatement,page10
Healthandsafety,page11
Networksecurity,page11
Supportinformation,page12
Systemdescription
TheMBR144OEMisaMaritimeBroadbandRadio(MBR).TheMBR144OEMis
intendedforoperationswherepersonnelrequirearobustcommunicationlinkduring
surveillanceandinspection.Thetiltedantennasaresuitableforhelmetmounting.
TheMBR144OEMisalsoavailablewithadedicatedplug-and-playcameraforlive
streamingandbatterypacks.
Thesystemisamaritimeradionetworkdistributionsystemwhichconnectscomputers
andsystemstogetherinawirelessnetwork.EachMBR144OEMworksinanetwork
withtwoormoreradiounits.Aradiositeisoneorseveralradiounitsconnectedtogether
byEthernetononelocation.Aradionetworkisawirelessnetworkofradiosites.
MBR144OEMInstructionManual

G210–58/37
TheMBR144OEMrequiresnoextrainfrastructuretooperate.Itservesasanextension
ofyourlocalradionetwork.
TheMBR144OEMissetupviaawebinterfacewhichisavailableoneachradiounit.
Systemdiagram
ARadioUnit
BAntennacable
CAntennaradiatingpart
DCombinedEthernetandpowercable
EEthernetconnectiontouserequipment
FConnectiontopowersourceonvessel
Scopeofsupply
Thebasicitemsareincludedinthedelivery.Additionaloptionalitemscanbepurchased
fromKongsbergSeatexAS.
Basicitems
•1eaRadioUnit
•1eaCombinedEthernetandpowercable
•1eaEnduserdocumentation
MBR144OEM

8G210–58/3
Additionalrequireditems
Observetheseadditionalitemswhicharerequiredforinstallationand/oroperation.They
canbeorderedfromKongsbergSeatexASorpurchasedlocally.
•Dipoleantenna
•Powersupply
•Computer
Forcongurationpurposes
Restrictionsinguarantee
ChangesormodicationstotheproductnotexplicitlyapprovedbyKongsbergSeatex
ASwillvoidtheguarantee.
TheliabilityofKongsbergSeatexASislimitedtorepairofthisproductonlyunderthe
giventermsandconditionsstatedinthesalesdocuments.Consequentialdamagessuch
ascustomer'slossofprotordamagetoothersystemstraceablebacktothisproduct's
malfunctions,areexcluded.
Thewarrantydoesnotcovermalfunctionsoftheproductresultingfromthefollowing
conditions.
•Incorrectpowerconnection.
•InsufcientcoolingoftheRadioUnit.
Radiofrequencylicense
Thisproductcontainsaradiotransmittingdevice.Afrequencylicensefortheuse
ofradiofrequenciesisrequiredforoperation.Useinnationalwaterswillrequirea
frequencylicenseissuedbytherelevantnationalauthorities.Theowneranduserofthe
equipmentareresponsibleforobtainingsuchalicensepriortoswitchingtheproductON.
ThisproductisincompliancewiththestandardETSIEN303276.Thisappliestothe
frequencychannels5862and5890MHz.
ThisproductisincompliancewithFCC(FederalCommunicationsCommission)Part
15.407.Thisappliestothefrequencychannels5725to5850MHz.
Equipmentidentication
ThisproducthasthefollowingidenticationsforFCC(FederalCommunications
Commissions)andIC(IndustryCanada).
MBR144OEMInstructionManual

G210–58/39
•FCCID:Q8IM144M2OEM
•IC:5637A-M144M2OEM
FCCcompliancestatement
ThisdevicecomplieswithPart15oftheFCC(FederalCommunicationsCommission)
Rules.Operationofthedeviceissubjecttothefollowingconditions.
1Thisdevicemaynotcauseharmfulinterference.
2Thisdevicemustacceptanyinterferencereceived.Includinginterferencethat
maycauseundesiredoperation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferencewhentheequipmentisoperatedina
marineand/orcommercialenvironment.Thisequipmentgenerates,usesandcanradiate
radiofrequencyenergy.Ifnotinstalledandusedinaccordancewiththeinstructions,
theequipmentmaycauseharmfulinterferencetoradiocommunication.Theequipment
isnotintendedforoperationinaresidentialarea.Operationinsuchanareaislikely
tocauseharmfulinterference.Inwhichcasetheuserwillberequiredtocorrectthe
interferenceathisownexpense.
Changesormodicationsnotexpresslyapprovedbythepartyresponsiblefor
compliance,couldvoidtheuser’sauthoritytooperatetheequipment.
ISEDCanadacompliancestatement
TextinEnglish
ThisdevicecomplieswithIndustryCanada(IC)license-exemptRSSstandard(s).
Operationissubjecttothefollowingtwoconditions.
1Thisdevicemaynotcauseinterference.
2Thisdevicemustacceptanyinterference,includinginterferencethatmaycause
undesiredoperationofthedevice.
TexteenFrançais
LeprésentappareilestconformeauxCNRd’IndustrieCanadaapplicablesauxappareils
radioexemptsdelicence.L’exploitationestautoriséeauxdeuxconditionssuivantes.
1L’appareilnedoitpasproduiredebrouillage.
2L’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesilebrouillard
estsusceptibled’encompromettrelefonctionnement.
TextinEnglish
MBR144OEM

10G210–58/3
Thisradiotransmitter(IC:5637A-M144M2OEM)hasbeenapprovedbyIndustry
Canadatooperatewiththeantennatypeslistedbelowwiththemaximumpermissible
gainandrequiredantennaimpedanceforeachantennatypeindicated.Antennatypesnot
includedinthislist,havingagaingreaterthanthemaximumgainindicatedforthetype,
arestrictlyprohibitedforusewiththisdevice.
Thisdevicehasbeendesignedtooperatewiththeantenna(s)listedbelow,andhavinga
maximumgainof6dB.Antennasnotincludedinthislistorhavingagaingreaterthan6
dB,arestrictlyprohibitedforusewiththisdevice.
Therequiredantennaimpedanceis50ohms.
Supportedantennas:
•MBR144OEMantennas(MBR-E-ANTxx)
TexteenFrançais
Leprésentémetteurradio(IC:5637A-M144M2OEM)aétéapprouvéparInnovation,
SciencesetDéveloppementéconomiqueCanadapourfonctionneraveclestypes
d'antenneénumérésci‑dessousetayantungainadmissiblemaximal.Lestypesd'antenne
noninclusdanscetteliste,etdontlegainestsupérieuraugainmaximalindiquépour
touttypegurantsurlaliste,sontstrictementinterditspourl'exploitationdel'émetteur.
Cetappareilaétéconçupourfonctionneraveclesantenneslistéesci-dessousetayant
ungainmaximumde6dB.Lesantennesnoninclusesdanscetteliste,ouayantungain
supérieurà6dB,sontstrictementinterditespourl'exploitationdel'émetteur.
L'impédanced'antennerequiseestde50ohms.
Antennessupportées:
•AntennesOEMMBR144(MBR-E-ANTxx)
Exposurestatement
TocomplywithFCCorICRFexposurelimitsforgeneralpopulationoruncontrolled
exposure,theantenna(s)usedforthistransmittermustbeinstalledonoutdoorpermanent
structuresinordertoprovideaseparationdistanceatleast20cmfromallpersonsand
mustnotbeco-locatedoroperatinginconjunctionwithanyotherantennaortransmitter.
Thisproductcontainsaradiotransmittingdevice.Accordingtotheoutputpowerofthe
equipment,theminimumdistanceforhumanbeingsinacontrolledenvironmentis:
•Maximumpower/ETSIEN303276:40cm
•FCCPart15.407:40cm
MBR144OEMInstructionManual

G210–58/311
Healthandsafety
Operationortroubleshootingofthisequipmentwillnotimplyanyriskforhighvoltages,
explosionsorexposuretogas.TheequipmentcomplieswithIEC61010-1/EN61010-1
standardsregardingproductsafety.
Networksecurity
IfaMBR144OEMsystemisconnectedtoalocalareanetwork,datasecurityis
important.
EquipmentmanufacturedbyKongsbergSeatexisfrequentlyconnectedtothevessel's
localareanetwork(LAN).Whenyouconnectacomputertoalocalareanetworkyou
willalwaysexposethedataonthatcomputer.Allothercomputersconnectedtothesame
networkmaybeabletoaccessyourdata.Severalthreatsmayimmediatelyoccur:
•Remotecomputerscanreadthedata.
•Remotecomputerscanchangethedata.
•Remotecomputerscanchangethebehaviourofthecomputer,forexampleby
installingunwantedsoftware.
Usually,twoparametersareusedtodenethethreatlevel:
1Thelikelihoodthatanyremotecomputerwilldoanyoftheabove.
2Thedamagedoneifaremotecomputersucceedsdoingthis.
KongsbergSeatexhasnoinformationregardingthecompletesysteminstallationon
anyvessel.SystemsprovidedbyKongsbergSeatexareregardedasstand-aloneofine
systems.Theyarestand-aloneeventhoughtheymaybeconnectedtoanetworkfor
sensorinterfacesand/ordatadistribution.
Note
NonetworksafetyapplicationsareinstalledonKongsbergSeatexcomputers.The
computersarethereforenotprotectedagainstviruses,malwareorunintentionalaccess
byexternalusers.
SecuringtheMBR144OEMsystemitselfhasnomeaningunlessthereisapolicyin
placethatsecuresallcomputersinthenetwork.Thispolicymustincludephysicalaccess
bytrainedandtrustedusers.Thecustomer/enduseroftheMBR144OEMsystem
willalwaysbeinchargeofdeningandimplementingasecuritypolicy,andproviding
therelevantnetworksecurityapplications.
Note
KongsbergSeatexwillnotacceptanyresponsibilityforerrorsand/ordamagescaused
byunauthorizeduseoforaccesstotheMBR144OEM.
MBR144OEM

12G210–58/3
Supportinformation
IfyouneedtechnicalsupportforyourSeatexMBR144OEMyoumustcontactyour
localdealer,oroneofoursupportdepartments.
•Companyname:KongsbergSeatexAS
•Address:Havnegata9,7010Trondheim,Norway
•Telephone:[phone]
•Telephone,24hsupport:[phone]
•E-mailaddress:[email protected]
•Website:http://www.kongsberg.com
MBR144OEMInstructionManual

G210–58/313
Operation
Topics
Gettingstarted,page13
Operatingprocedures,page17
Userpreferenceprocedures,page29
Userinterface,page30
Functionsanddialogboxes,page31
Gettingstarted
Topics
TurningontheRadioUnit,page13
EnablingcontactwiththeRadioUnit,page14
DeningtheIPaddressonthecomputernetworkadapter,page15
TurningontheRadioUnit
TheRadioUnitisturnedonwhenthepowerconnectorisinsertedinthepowersourceon
thevessel.Thesystempoweriscontrolledfromthepowersource.
Context
Thesoftwareispre-installedandthesystemwillstartautomaticallyafterithasbeen
turnedon.
Note
UseadedicatedpowersupplyorbatterytopowertheRadioUnit.
Operation

14G210–58/3
Procedure
1MakesurethattheEthernetcableisproperlyconnected.
2Insertthepowerconnectorintothededicatedpowersourceonthevessel.24VDC.
3ToturnofftheRadioUnit,simplyremovethepowerconnector.
Result
Thesystemisnowreadyforconguration.
Relatedtopics
EnablingcontactwiththeRadioUnit,page14
DeningtheIPaddressonthecomputernetworkadapter,page15
Settingtoworksummary,page51
EnablingcontactwiththeRadioUnit
TobeabletosetupandcommunicatewiththeRadioUnityoumustenablecontact
withtheunitviaabrowser.
Prerequisites
InordertosetuptheRadioUnityouneedtheseitems.
•ComputerwithanEthernetadapter.
•Up-to-datebrowser.ForexampleChrome,Firefox,InternetExplorerversion10
ornewer.
TheIPaddressoftheRadioUnitisfoundonalabelattherearoftheunit.
YoumustdenewhichIPAddressandSubnetmasktheEthernetadapterinthecomputer
shalluseforthiscommunication.
Context
Youonlyneedthecomputerforcongurationorre-congurationpurposes.
Note
TheWelcomepageonlyappearsthersttimeyousetupyoursite.Aftertheconguration
iscompleted,thewebinterfacetakesyoudirectlytotheMainview.
Procedure
1Setupthecomputerwith:
•IPaddress:10.19.127.10
•Subnetmask:255.255.0.0
2ConnectthecomputertotheRadioUnitviaEthernet.
MBR144OEMInstructionManual

G210–58/315
3Typetheradio’sIPaddressinthebrowseraddressbar.
ObservethattheWelcomepageappears.
ForpreviouslyconguredsystemstheMainviewappears.
Result
Youarenowconnectedtothewebinterfaceonyourlocalradio.
Relatedtopics
TurningontheRadioUnit,page13
DeningtheIPaddressonthecomputernetworkadapter,page15
Settinguptheradiositeforoperation,page17
Welcome,page32
Settingtoworksummary,page51
DeningtheIPaddressonthecomputernetworkadapter
YoumustdenewhichIPAddressandSubnetmasktheEthernetadapterinthecomputer
shalluseforthiscommunication.Aslongasyoudonotreplacethecomputerorthe
networkadapterinthecomputer,youonlyneedtodothisonce.
Prerequisites
ThisprocedureismadefortheMicrosoft®Windows®7and10operatingsystems.
ItisassumedthatyouarefamiliarwiththeWindows®operatingsystems,computer
technology,andinterfaceprinciples.
Procedure
1Closealltheprogramsthatarerunningonthecomputer.
Operation

16G210–58/3
2OpentheNetworkConnectionsdialogbox.
ThisprocedureismadefortheMicrosoft®Windows®10operatingsystem.
aInthebottom-leftcornerofyourdesktop,selecttheWindows®Startbutton.
bOnthemenu,selectSettings.
cObservethattheWindowsSettingsdialogboxopens.
dSelectNetwork&Internet.
eSelectChangeadapteroptions.
fSelectthenetworkadapteryouaregoingtouse;thenright-clickandselect
Propertiesontheshort-cutmenu.
gOnthelistofconnections,selectInternetProtocol4(TCP/IPv4),andthen
Properties.
ThisprocedureismadefortheMicrosoft®Windows®7operatingsystem.
aInthebottom-leftcornerofyourdesktop,selecttheWindows®Startbutton.
bOntheright-handsideoftheStartmenu,selectControlPanel.
cObservethattheControlPanelopens.
dSelectNetworkandSharingCenter.
(IftheControlPanelisshownwithcategories,selectViewnetworkstatusand
tasks.)
eOntheleft-handmenu,selectChangeadaptersettings.
fClickonceonyournetworkadaptertoselectit,thenright-clickandselect
Propertiesontheshortcutmenu.
gOnthelistofconnections,selectInternetProtocol4(TCP/IPv4),andthen
Properties.
3SelectUsethefollowingIPaddress,andtypetheIPaddressandnetworkmask.
•IPAddress:10.19.127.10
•Subnetmask:255.255.0.0
4SelectOKtosavetheselectedsettings,andthencloseallthedialogboxes.
Relatedtopics
TurningontheRadioUnit,page13
EnablingcontactwiththeRadioUnit,page14
Settinguptheradiositeforoperation,page17
Settingtoworksummary,page51
MBR144OEMInstructionManual

G210–58/317
Operatingprocedures
Topics
Settinguptheradiositeforoperation,page17
Creatinganewradionetwork,page22
Joiningaradionetwork,page24
Editinganexistingradionetwork,page25
Addingorremovingthirdpartyequipment,page26
CheckingthestatusoftheMBRnetwork,page28
Settinguptheradiositeforoperation
Thesetupisdoneusingawizard.Aradiositeisoneorseveralradiounitsconnected
togetherbyEthernetononelocation.Aradionetworkisawirelessnetworkofradio
sites.Youmustsetuptheradiositebeforeyoucanstarttheradionetworkconguration.
AllcongurationoftheMBR144OEMMaritimeBroadbandRadio(MBR)isdone
throughthewebinterface.
Prerequisites
TheIPaddressfortheRadioUnitislocatedatthebottomoftheRadioUnit.Y oumust
haveenabledcontactwiththeRadioUnit.
TheIPaddressandtheMACaddressforthethirdpartyequipmentmustbeknown.
Context
TheMBR144OEMMaritimeBroadbandRadio(MBR)usesstaticlayer2bridging
(OSImodel-OpenSystemsInterconnectionBasicReferenceModel).Thereforeit
needsboththeIPaddressandtheMACaddressoftheequipmentinordertoestablish
anIPconnection.
Procedure
1OntheWelcomepage,whichappearsafteryouhaveenabledcontactwiththeRadio
Unit,selectConguresitetostarttheinstallationwizard.
Operation

18G210–58/3
Note
Thedefaultcolourpalettesettingiswithdarkbackground.Ifyourcurrentlight
conditionsrequirewhitebackground,selecttheSystemmenubutton[+]toopenthe
Systemmenu.InthePalettegroupyoucanchangethecolourpalette.
2SelectStartontheCongurationguidepagetostartthestep-by-stepconguration
ofyourradiosite.
3TypeasuitablenameforyourradiositeandselectContinue.
MBR144OEMInstructionManual

G210–58/319
4Selecttheradiosyouwanttoaddtothesite.Typeadescriptionofthelocationof
theRadioUnit.SelectContinue.
Note
RadiounitsconnectedonthelocalEthernetwillappearautomatically.Theyare
bydefaultselected.
Operation

20G210–58/3
5Typetheradiofrequency.SelectthedataratefortheradiositefromtheRatelist.
6SelectManagethirdpartyequipmenttoopentheThirdpartyequipmentdialogbox.
Thisiswhereyouaddthirdpartyequipmenttoyourradiosite.
7TypetheIPaddressoftheequipmentyouwanttoconnect.Selecttypeofequipment
fromtheTypelist.Typeadescriptionoftheequipmentforidenticationpurposes.
MBR144OEMInstructionManual
