Konica Minolta BizHub C352 User manual

User’s Guide [Copy Operations]

Introduction
C352 x-1
Introduction
Thank you for choosing this machine.
This manual contains details on the operation of the various functions of the
machine, precautions on its use, and basic troubleshooting procedures. In
order to ensure that this machine is used correctly and efficiently, carefully
read this manual before using the machine. After reading the manual, store
it in the designated holder so that it can easily be referred to when questions
or problems arise during operation.
The illustrations used in this manual may appear slightly different from views
of the actual equipment.
Energy Star®
As an ENERGY STAR®Partner, we have determined that this machine meets
the ENERGY STAR®Guidelines for energy efficiency.
What is an ENERGY STAR®Product?
An ENERGY STAR®product has a special feature that allows it to automat-
ically switch to a “low-power mode” after a period of inactivity. An ENERGY
STAR®product uses energy more efficiently, saves you money on utility bills
and helps protect the environment.

Introduction
x-2 C352
Trademarks and Registered Trademarks
KONICA MINOLTA, KONICA MINOLTA Logo, and The essentials of imaging
are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS,
INC.
PageScope and bizhub are registered trademarks or trademarks of KONICA
MINOLTA BUSINESS TECHNOLOGIES, INC.
Netscape Communications, the Netscape Communications logo, Netscape
Navigator, Netscape Communicator, and Netscape are trademarks of Net-
scape Communications Corporation.
This machine and PageScope Box Operator are based in part on the work of
the Independent JPEG Group.
Compact-VJE
Copyright 1986-2003 VACS Corp.
RC4®is a registered trademark or trademark of RSA Security Inc. in the Unit-
ed States and/or other countries.
RSA®is a registered trademark or trademark of RSA Security Inc. RSA
BSAFE®is a registered trademark or trademark of RSA Security Inc. in the
United States and/or other countries.
License information
This product includes RSA BSAFE Cryptographic software
from RSA Security Inc.
OpenSSL Statement
OpenSSL License
Copyright ©1998-2000 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modifica-
tion, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice,
this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright no-
tice, this list of conditions and the following disclaimer in the documen-
tation and/or other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must
display the following acknowledgment:
“This product includes software developed by the OpenSSL Project for
use in the OpenSSL Toolkit. (http://www.openssl.org/)”

Introduction
C352 x-3
4. The names “OpenSSL Toolkit” and “OpenSSL Project” must not be used
to endorse or promote products derived from this software without prior
written permission. For written permission, please contact openssl-
[email protected].
5. Products derived from this software may not be called “OpenSSL” nor
may “OpenSSL” appear in their names without prior written permission
of the OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following ac-
knowledgment:
“This product includes software developed by the OpenSSL Project for
use in the OpenSSL Toolkit (http://www.openssl.org/)”
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND
ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIM-
ITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FIT-
NESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CON-
SEQENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCURE-
MENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON
ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY
WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Young
([email protected]). This product includes software written by Tim Hud-
son ([email protected]).
Original SSLeay License
Copyright ©1995-1998 Eric Young ([e-mail]) All rights reserved.
This package is an SSL implementation written by Eric Young (eay@crypt-
soft.com).
The implementation was written so as to conform with Netscapes SSL.
This library is free for commercial and non-commercial use as long as the fol-
lowing conditions are aheared to. The following conditions apply to all code
found in this distribution, be it the RC4, RSA, Ihash, DES, etc., code; not just
the SSL code.
The SSL documentation included with this distribution is covered by the
same copyright terms except that the holder is Tim Hudson (tjh@crypt-
soft.com).
Copyright remains Eric Young’s, and as such any Copyright notices in the
code are not to be removed. If this package is used in a product, Eric Young
should be given attribution as the author of the parts of the library used. This
can be in the form of a textual message at program startup or in documen-
tation (online or textual) provided with the package.

Introduction
x-4 C352
Redistribution and use in source and binary forms, with or without modifica-
tion, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the copyright notice, this list
of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright no-
tice, this list of conditions and the following disclaimer in the documen-
tation and/or other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must
display the following acknowledgement:
“This product includes cryptographic software written by Eric Young
([email protected])”
The word ‘cryptographic’ can be left out if the rouines from the library be-
ing used are not cryptographic related.
4. If you include any Windows specific code (or a derivative thereof) from
the apps directory (application code) you must include an acknowledge-
ment:
“This product includes software written by Tin Hudson (tjh@crypt-
soft.com)”
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EX-
PRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AU-
THOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCI-
DENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE
GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILI-
TY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE
OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.
The licence and distribution terms for any publically available version or de-
rivative of this code cannot be changed. i.e. this code cannot simply be cop-
ied and put under another distribution licence [including the GNU Public
Licence.]
All other product names mentioned are trademarks or registered trademarks
of their respective companies

Introduction
C352 x-5
Contents
Introduction
Energy Star®..................................................................................... x-1
What is an ENERGY STAR®Product? ............................................x-1
Trademarks and Registered Trademarks ...................................... x-2
Contents ............................................................................................ x-5
Available features ........................................................................... x-18
Selecting the print color ................................................................x-18
Automatically selecting the paper .................................................x-18
Adjusting copies to the size of the paper .....................................x-18
Specifying separate horizontal and vertical zoom ratios ..............x-18
Scanning the original in separate batches ....................................x-18
Center binding ...............................................................................x-19
Sorting copies ...............................................................................x-19
Stapling copies .............................................................................x-19
Punching holes in copies ..............................................................x-19
Copying multiple original pages onto a single page .....................x-20
Copying an original containing various page sizes .......................x-20
Adjusting copies according to the image quality of the original ...x-20
Inserting paper between copies of OHP .......................................x-20
Adding a cover page .....................................................................x-21
Inserting different paper into copies .............................................x-21
Inserting pages from a different original at specified locations
in a copy ........................................................................................x-21
Printing double-sided copies with the specified page on the
front side .......................................................................................x-22
Copying with reversed colors .......................................................x-22
Printing a mirror image ..................................................................x-22
Copying with a background color .................................................x-23
Improving the copy color quality ...................................................x-23
Separately copying a page spread ...............................................x-23
Creating booklets from copies of pamphlets ................................x-23
Repeating copy images ................................................................x-24
Printing the enlarged image on multiple pages ............................x-24
Making copies for filing .................................................................x-24
Copying with the page layout of a magazine ................................x-25
Erasing sections of copies ............................................................x-25
Adjusting the image to fit the paper size ......................................x-25
Printing distribution numbers or copy protection text on
copies ............................................................................................x-26
Managing jobs ...............................................................................x-26
Programming copy settings ..........................................................x-26
Checking the copy settings ..........................................................x-26

Introduction
x-6 C352
Enlarging the size of text in touch panel screens .........................x-26
Displaying explanations of functions and settings .......................x-26
Interrupting a copy job ..................................................................x-27
Printing a sample copy .................................................................x-27
Adjust color parameters .................................................................x-28
General information about color ....................................................x-30
Relationship between hue, brightness and saturation
(color model) ....................................................................................x-31
“Red” parameter ..............................................................................x-32
“Green” parameter ..........................................................................x-33
“Blue” parameter .............................................................................x-34
“Color Balance” parameter (CMYK color adjustment) ................x-35
“Brightness” parameter ..................................................................x-37
“Contrast” parameter ......................................................................x-38
“Saturation” parameter ...................................................................x-39
“Sharpness” parameter ..................................................................x-40
“Hue” parameter ..............................................................................x-41
“Copy Density” parameter ..............................................................x-42
“Single Color” function ...................................................................x-43
“2 Color” function ............................................................................x-44
“Background Color” function .........................................................x-45
“Neg-/Pos. Reverse” function ........................................................x-46
Monotone copy .............................................................................x-46
Full-color copy and “Background Color” function ........................x-46
“Mirror Image” function ..................................................................x-47
Explanation of manual conventions ...............................................x-48
Descriptions and symbols for originals and paper ......................x-50
“Width” and “Length” ...................................................................x-50
Paper Orientation ..........................................................................x-50
User’s Guides ...................................................................................x-52
User’s Guide [Copy Operations] <this manual> ...........................x-52
User’s Guide [Network Scanner Operations] ................................x-52
User’s Guide [Box Operations] .....................................................x-52
User’s Guide [Enlarge Display Operations] ...................................x-52
User’s Guide [FK-502 Facsimile Operations] ................................x-52
User’s Guide [Network Facsimile Operations] ..............................x-52
User’s Guide [Print Operations] ....................................................x-53
Quick Guide [Print Operations] .....................................................x-53

Introduction
C352 x-7
Legal restrictions on copying ........................................................ x-54
1 Installation and operation precautions
1.1 Safety information ............................................................................ 1-2
Warning and precaution symbols .................................................. 1-2
Meaning of symbols ....................................................................... 1-2
1.2 Regulation notices ............................................................................ 1-9
CE Marking (Declaration of Conformity) for users of the
European Union (EU) ...................................................................... 1-9
USER INSTRUCTIONS FCC PART 15 - RADIO FREQUENCY
DEVICES (for U.S.A. users) ............................................................ 1-9
INTERFERENCE-CAUSING EQUIPMENT STANDARD
(ICES-003 ISSUE 4) (for Canada users) ......................................... 1-9
For users in countries not subject to class B regulations ............ 1-10
Laser safety .................................................................................. 1-10
Internal laser radiation .................................................................. 1-10
CDRH regulations ........................................................................ 1-11
For European users ...................................................................... 1-12
For Denmark users ....................................................................... 1-12
For Finland, Sweden users .......................................................... 1-12
For Norway users ......................................................................... 1-13
Laser safety label ......................................................................... 1-13
Ozone release .............................................................................. 1-14
Acoustic noise (For European users only) .................................... 1-14
For EU member states only ......................................................... 1-14
1.3 Caution notations and labels ......................................................... 1-15
1.4 Space requirements ....................................................................... 1-16
1.5 Operation precautions ................................................................... 1-17
Power source ............................................................................... 1-17
Operating environment ................................................................ 1-17
Storage of copies ......................................................................... 1-17
2 Before making copies
2.1 Part names and their functions ....................................................... 2-2
Options ........................................................................................... 2-2
Outside of machine ........................................................................ 2-5
Inside of machine ......................................................................... 2-11
Saddle stitcher SD-503/mailbin kit MT-501 ................................. 2-13
Finisher FS-514/output tray OT-601/punch kit PK-510 ............... 2-14
Control panel ................................................................................ 2-17
Basic screen ................................................................................. 2-20
Icons That Appear in the Screen .................................................. 2-22

Introduction
x-8 C352
2.2 Adjusting the angle of the control panel .......................................2-23
To adjust the angle of the control panel .......................................2-23
2.3 Turning on the Main Power and the Sub Power ...........................2-25
To turn on the machine .................................................................2-25
To scan during warm-up ...............................................................2-27
To turn off the machine .................................................................2-29
Automatically canceling the settings (automatic panel reset) .......2-30
Automatically canceling the mode screen
(automatic system reset) ...............................................................2-30
Automatically conserving energy (Low Power mode) ...................2-31
Automatically conserving energy (Sleep mode) ............................2-32
Manually conserving energy .........................................................2-33
Automatically turning the machine on/off (weekly timer) ..............2-34
Controlling each user’s use of this machine
(user authentication) .....................................................................2-36
Controlling each account’s use of this machine
(account track) ..............................................................................2-40
2.4 Loading paper into the tray 1 .........................................................2-43
To load paper (tray 1) ....................................................................2-43
2.5 Loading paper into the tray 2, 3 or 4 ..............................................2-47
To load paper (tray 2, 3 or 4) ........................................................2-47
2.6 Loading paper into the LCT ............................................................2-49
To load paper (LCT) ......................................................................2-49
2.7 Loading paper into the bypass tray ...............................................2-52
To load paper (bypass tray) ..........................................................2-52
3 Basic copy operations
3.1 General copy operation ....................................................................3-2
To make a copy ..............................................................................3-2
3.2 Operations that cannot be combined ..............................................3-5
Operations where the setting specified last is given priority ..........3-5
Operations where the setting specified first is given priority ..........3-6
3.3 Feeding the original ...........................................................................3-7
To load the original into the ADF ....................................................3-7
To place the original on the original glass ......................................3-9
Scanning the original in separate batches
(“Separate Scan” setting) ..............................................................3-11
Scanning a multi-page original from the original glass .................3-15
3.4 Specifying original settings ............................................................3-20
Copying originals of mixed sizes (“Mixed Original” setting) .........3-20
Positioning folded (Z-Folded) original ...........................................3-22

Introduction
C352 x-9
Selecting the original orientation (Original Direction settings) ..... 3-23
To specify an original direction setting ........................................ 3-24
Selecting the position of the binding margin (Margin settings) .... 3-25
To specify a margin setting .......................................................... 3-26
Removing specks from the left partition glass (Despeckle) ......... 3-28
To change scan settings for each original ................................... 3-29
3.5 Selecting a color setting ................................................................ 3-32
To select a color setting ............................................................... 3-33
3.6 Selecting a paper setting ............................................................... 3-35
Automatically Selecting the Paper Size
(“Auto Paper Select” setting) ....................................................... 3-35
Manually selecting the desired paper size ................................... 3-37
3.7 Specifying a zoom setting ............................................................. 3-38
Automatically selecting the zoom ratio (“Auto Zoom” setting) .... 3-38
Specifying the same zoom ratio as the original
(“×1.0” setting) ............................................................................. 3-39
Slightly reducing the copy (“Minimal” setting) ............................. 3-40
Selecting a preset zoom ratio (enlarge and reduce settings) ....... 3-41
Typing In the zoom ratio (XY Zoom setting) ................................. 3-42
Typing In separate X and Y zoom ratios
(independent zoom settings) ........................................................ 3-44
Selecting a stored zoom ratio ...................................................... 3-46
Storing the desired zoom ratio ..................................................... 3-47
3.8 Selecting the original and copy type settings
(Simplex/Duplex settings) .............................................................. 3-49
To select single-sided copies ...................................................... 3-51
To select double-sided copies ..................................................... 3-53
3.9 Selecting the quality of the original .............................................. 3-55
Loading originals with small print or photos
(Original Type settings) ................................................................ 3-55
To specify an original type setting ............................................... 3-56
3.10 Specifying the density settings ..................................................... 3-59
Adjusting the print density (Density settings) ............................... 3-60
Adjusting the background density
(Background Removal settings) ................................................... 3-61
Printing with a glossy finish (“Glossy” setting) ............................. 3-63
Adjusting the reproduction quality of text .................................... 3-64
3.11 Selecting a combine originals setting .......................................... 3-66
Copying multiple original pages onto a single page
(Combine Originals) ...................................................................... 3-68
3.12 Selecting finishing settings ............................................................ 3-70
Separating copies by sets (“Sort” setting) ................................... 3-72

Introduction
x-10 C352
Separating copies by pages (“Group” setting) .............................3-73
Stapling copies (Staple settings) ..................................................3-75
To bind copies with staples ..........................................................3-76
Punching holes in copies (Punch settings) ...................................3-78
To punch holes in copies ..............................................................3-79
3.13 Specifying center binding ...............................................................3-81
To bind copies at the center (“Fold & Staple”) .............................3-82
3.14 Scanning the next original to be copied while a copy job is
being printed (next job reservation) ...............................................3-84
To reserve a copy job ...................................................................3-84
3.15 Stopping scanning/printing ............................................................3-86
To stop scanning/printing .............................................................3-86
3.16 Deleting a stopped job ....................................................................3-87
To delete a stopped job ................................................................3-87
4 Additional copy operations
4.1 Checking the copy settings (Mode Check) .....................................4-2
To check the settings ......................................................................4-2
To change the settings ...................................................................4-4
4.2 Printing a proof copy to be checked (Proof Copy) .........................4-5
To make test prints .........................................................................4-5
4.3 Interrupting a copy job (Interrupt mode) .........................................4-8
To interrupt a copy job ....................................................................4-8
4.4 Registering copy programs (Mode Memory) ................................4-10
To store a copy program ..............................................................4-10
To delete a copy program .............................................................4-13
4.5 Copying with programmed copy settings (Mode Memory) .........4-14
To recall a stored job ....................................................................4-14
4.6 Displaying function descriptions (Help) ........................................4-17
Overview of Help Screens ............................................................4-17
To display the Main Help Menu screen ........................................4-20
To display the Help screen while specifying a setting ..................4-22
4.7 Specifying control panel settings (Accessibility mode) ...............4-23
Displaying the Accessibility Setting Screen ..................................4-23
To set the “Key Repeat Start/Interval Time” function ...................4-23
To set the “Enlarge Display Timer Setting” function .....................4-26
To set the “Message Display Time” function ................................4-28
To set the “Sound Setting” function .............................................4-30
To set the “Touch Panel Adj.” function .........................................4-33
To set the “Auto Reset Notification” function ...............................4-35

Introduction
C352 x-11
To set the “Enlarge Display Confirmation Screen” function ........ 4-38
5 Troubleshooting
5.1 When the message “Malfunction detected.” appears
(call technical representative) ......................................................... 5-2
To call the technical representative ............................................... 5-3
5.2 When the message “Misfeed detected.” appears ......................... 5-5
Location of Paper misfeed ............................................................. 5-5
Paper misfeed indications .............................................................. 5-7
To clear a paper misfeed in the bypass tray .................................. 5-8
To clear a paper misfeed in the ADU ........................................... 5-11
To clear a paper misfeed in the tray 1 ......................................... 5-12
To clear a paper misfeed in the tray 2 ......................................... 5-15
To clear a paper misfeed in a paper tray (tray 3 or 4) .................. 5-16
To clear a paper misfeed in the LCT ............................................ 5-17
To clear a paper misfeed in the right-side door ........................... 5-19
To clear a paper misfeed in the fusing unit .................................. 5-23
To clear a banner paper misfeed ................................................. 5-28
To clear a paper misfeed in the ADF (feed section) ..................... 5-33
To clear a paper misfeed in the ADF (transport section) ............. 5-37
To clear a paper misfeed in the ADF (scanning section) ............. 5-41
To clear a paper misfeed in the ADF (output section) .................. 5-46
To clear a paper misfeed in the ADF (turnover section) ............... 5-49
To clear a paper misfeed in the finisher ....................................... 5-52
To clear a paper misfeed in the mailbin ....................................... 5-56
To clear a paper misfeed in the saddle stitcher ........................... 5-58
5.3 When the message “Replenish paper.” appears ......................... 5-60
To replenish paper ....................................................................... 5-60
5.4 When the message “... Not enough remaining memory.”
appears ............................................................................................ 5-61
Memory becomes full while scanning .......................................... 5-61
Memory becomes full while queuing a job .................................. 5-62
5.5 When “Please replace following unit(s).” appears ...................... 5-63
5.6 When the message “Need to replace XXXX.” appears ............... 5-64
5.7 Simple troubleshooting .................................................................. 5-66
Main unit ...................................................................................... 5-66
ADF .............................................................................................. 5-68
Finisher ......................................................................................... 5-69
5.8 Main messages and their remedies .............................................. 5-70

Introduction
x-12 C352
6 Specifications
6.1 Specifications ....................................................................................6-2
bizhub C352 ....................................................................................6-2
ADU .................................................................................................6-4
Option specifications ......................................................................6-4
Reverse automatic document feeder DF-608 .................................6-4
Paper feed cabinet PC-103 ............................................................6-6
Paper feed cabinet PC-203 ............................................................6-6
Paper feed cabinet PC-403 ............................................................6-6
Finisher FS-514 ...............................................................................6-7
Punch kit PK-510 ............................................................................6-7
Saddle stitcher SD-503 ...................................................................6-8
Output tray OT-601 .........................................................................6-8
Mailbin kit MT-501 ..........................................................................6-8
7 Copy paper/originals
7.1 Copy paper .........................................................................................7-2
Possible paper sizes .......................................................................7-2
Paper types and paper capacities ..................................................7-4
Special paper ..................................................................................7-5
Precautions for paper .....................................................................7-7
Paper storage .................................................................................7-7
Auto tray switch feature ..................................................................7-8
Order for Selecting the Paper trays ................................................7-8
7.2 Selecting the paper settings .............................................................7-9
To automatically detect the paper size
(“Auto Paper Select” setting) ..........................................................7-9
To specify a paper size (Set Size settings) ...................................7-11
To specify a non-standard paper size (Custom Size settings) .....7-13
To store a non-standard paper size (Custom Size settings) .........7-15
To specify a setting for oversized paper
(Oversized Paper settings) ............................................................7-18
To specify a setting for special paper ...........................................7-21
To print double-sided copies manually ........................................7-23
7.3 Originals ...........................................................................................7-25
Originals that can be loaded into the ADF ....................................7-25
Precautions for loading originals into the ADF .............................7-27
Originals that can be placed on the original glass ........................7-28
Precautions for Positioning Originals on the Original Glass .........7-28
8 Application functions
8.1 Inserting paper between OHP (“OHP Interleave” function) ...........8-2
To copy using the “OHP Interleave” function .................................8-3

Introduction
C352 x-13
8.2 Adding cover pages (“Cover Mode” function) ............................... 8-5
To copy using the “Cover Mode” function ..................................... 8-6
8.3 Inserting different paper into copies (“Insert Sheet” function) .... 8-8
To copy using the “Insert Sheet” function ..................................... 8-9
8.4 Inserting copies of a different original for a specified page
(“Insert Image” function) ................................................................ 8-12
To copy using the “Insert Image” function .................................. 8-12
8.5 Specifying pages to be printed on the front side
(“Chapters” function) ...................................................................... 8-16
To copy using the “Chapters” function ........................................ 8-17
8.6 Scanning originals with different settings and printing copies
all together (“Program Job” function) .......................................... 8-19
To copy using the “Program Job” function ................................. 8-19
8.7 Producing separate copies of each page in a page spread
(“Book Copy” function) .................................................................. 8-24
To copy using the “Book Copy” function .................................... 8-25
8.8 Copying pamphlets (“Booklet Original” function) ....................... 8-30
To copy using the “Booklet Original” function ............................. 8-31
8.9 Tiling copy images (“Image Repeat” function) ............................ 8-34
To copy using the “Image Repeat” function ................................ 8-35
8.10 Copying an enlarged image on multiple pages
(“Poster Mode” function) ............................................................... 8-38
To copy using the “Poster Mode” function .................................. 8-38
8.11 Copying with the page layout of a magazine
(“Booklet” function) ........................................................................ 8-43
To copy using the “Booklet” function .......................................... 8-44
8.12 Copying with image colors inversed
(“Neg-/Pos. Reverse” function) ..................................................... 8-45
To copy using the “Neg-/Pos. Reverse” function ........................ 8-46
8.13 Copying in a mirror image (“Mirror Image” function) .................. 8-47
To copy using the “Mirror Image” function .................................. 8-47
8.14 Adding a background color to copies
(“Background Color” function) ...................................................... 8-51
To copy using the “Background Color” function ......................... 8-51
8.15 Adjusting the copy color quality (Adjust Color parameters) ...... 8-53
To adjust the Adjust Color parameters ........................................ 8-54
Checking the Print Result of the Adjust Color Settings
(Sample Copy) .............................................................................. 8-56
To make sample copies ............................................................... 8-57

Introduction
x-14 C352
8.16 Adding filing margins to copies (“Page Margin” function) ..........8-58
To copy using the “Page Margin” function ...................................8-59
8.17 Erasing specified areas of copies (“Erase” function) ..................8-61
To copy using the “Erase” function ..............................................8-61
8.18 Adjusting the image to fit the paper
(Image Adjustment settings) ..........................................................8-63
To copy using the Image Adjustment settings .............................8-64
8.19 Printing the Date/Time, page number or distribution number
on copies (Stamp functions) ...........................................................8-67
To copy using the “Date/Time” function .......................................8-68
To copy using the “Page #” function ............................................8-71
To copy using the “Set Numbering” function ...............................8-74
Printing copy protection text (“Copy Protect” function) ...............8-76
To copy using the “Copy Protect” function ..................................8-76
9 Replacing toner cartridges and staples and emptying
waste containers
9.1 Replacing the toner cartridge ..........................................................9-2
To replace the toner cartridge ........................................................9-6
9.2 Replacing the staples ......................................................................9-10
To replace the staple cartridge in the finisher ...............................9-11
To replace the staple cartridge in saddle stitcher .........................9-13
9.3 Clearing a staple jam ......................................................................9-16
To clear jammed staples in the finisher ........................................9-17
To clear jammed staples in the saddle stitcher ............................9-22
9.4 Emptying the waste containers ......................................................9-26
To empty the hole-punch waste container ...................................9-28
9.5 Replacing the waste toner box ......................................................9-30
To replace the waste toner box ....................................................9-32
10 Care of the machine
10.1 Cleaning ...........................................................................................10-2
Housing .........................................................................................10-2
Original glass ................................................................................10-3
Slit glass ........................................................................................10-3
Control panel ................................................................................10-4
Original cover pad .........................................................................10-5
Paper feed roller ...........................................................................10-6
Electrostatic charger wire .............................................................10-6
Print head ......................................................................................10-7

Introduction
C352 x-15
10.2 Viewing counters (Meter Count) .................................................... 10-8
Viewing counters .......................................................................... 10-8
To view the counters .................................................................... 10-8
Viewing the coverage rate ............................................................ 10-9
To view the coverage rate ............................................................ 10-9
10.3 When the message “Preventive maintenance time.”
appears .......................................................................................... 10-10
11 Managing jobs (Job List)
11.1 Overview of the Job List screen .................................................... 11-2
Jobs ............................................................................................. 11-2
Multi-Job feature .......................................................................... 11-2
Job List screens ........................................................................... 11-3
11.2 Performing operations on jobs ...................................................... 11-6
To delete a job ............................................................................. 11-6
To check the job settings ............................................................. 11-8
Displayed information .................................................................. 11-9
To check the job details ............................................................. 11-10
To display current jobs (held jobs and active jobs lists) ............ 11-11
To display Job History ............................................................... 11-12
To print a sample copy of a stored job ...................................... 11-13
To print a stored job ................................................................... 11-15
To increase priority for printing .................................................. 11-17
12 Utility
12.1 Overview of utility mode parameters ............................................ 12-2
List of registration information and parameters ........................... 12-2
12.2 Selecting a destination register .................................................. 12-14
Scan ........................................................................................... 12-14
Fax ............................................................................................. 12-14
User box ..................................................................................... 12-14
Displaying the destination register screen ................................. 12-15
12.3 Specifying user settings ............................................................... 12-17
System setting ........................................................................... 12-17
Display setting ............................................................................ 12-19
Initial setting ............................................................................... 12-21
Copier setting ............................................................................. 12-22
Scanner setting .......................................................................... 12-25
Printer setting ............................................................................. 12-25
Displaying the utility setting screen ........................................... 12-25
12.4 Specifying administrator settings ............................................... 12-27
System setting ........................................................................... 12-27

Introduction
x-16 C352
Administrator/machine setting ....................................................12-35
One-Touch registration ...............................................................12-36
User authentication/account track .............................................12-37
Network setting ...........................................................................12-39
Copier setting .............................................................................12-39
Printer setting ..............................................................................12-40
Fax setting ..................................................................................12-40
System connection .....................................................................12-41
Security setting ...........................................................................12-42
Displaying the Administrator Setting screen ...............................12-47
12.5 Overview of weekly timer settings ...............................................12-49
Requisite .....................................................................................12-49
12.6 Adjusting the printer .....................................................................12-50
Adjusting the starting print position at the leading edge
position .......................................................................................12-50
Adjusting the starting print position at the left edge ...................12-52
Adjusting the starting print position for the second side ............12-54
Adjusting printing according to the media ..................................12-56
12.7 Adjusting the finisher ....................................................................12-58
Adjusting the center folding position ..........................................12-58
Adjusting the center stapling position ........................................12-60
Adjusting the horizontal punch position .....................................12-62
Adjusting the angle of punched holes ........................................12-64
12.8 Adjusting the color registration ...................................................12-66
Adjusting the color registration for yellow, magenta and
cyan ............................................................................................12-66
12.9 Adjusting the gradation levels ......................................................12-69
Requisite .....................................................................................12-69
12.10 Authentication method .................................................................12-72
User authentication and account track .......................................12-72
When user authentication and account track are
synchronized ...............................................................................12-73
When user authentication and account track are used
separately ...................................................................................12-74
To select an authentication method ...........................................12-75
12.11 User authentication setting ..........................................................12-79
Administrative setting—user name list .......................................12-79
Default function permission ........................................................12-80
To specify the default function permissions ...............................12-80
Authenticating public users ........................................................12-82
User registration .........................................................................12-83
User counter ...............................................................................12-88
To check the counter ..................................................................12-89

Introduction
C352 x-17
12.12 Account track setting ................................................................... 12-91
Account track registration .......................................................... 12-91
Account track counter ................................................................ 12-95
To check the counter ................................................................. 12-96
12.13 Password rules ............................................................................. 12-98
Conditions of the password rules .............................................. 12-98
12.14 Enhanced security settings ....................................................... 12-100
12.15 Viewing the status of the consumables .................................... 12-103
Displaying the unit life indicator screen ................................... 12-103
13 Appendix
13.1 Entering text .................................................................................... 13-2
To type text .................................................................................. 13-4
List of Available Characters ......................................................... 13-4
13.2 Glossary ........................................................................................... 13-5
13.3 Index .............................................................................................. 13-10

Introduction
x-18 C352
Available features
Selecting the print color
The color used to print copies can be specified, for example, the copy can
be printed in full color or in black and white.
For details, refer to “Selecting a color setting” on page 3-32.
Automatically selecting the paper
The most appropriate paper size can automatically be selected based on the
size of the loaded original and the specified zoom ratio.
For details, refer to “Automatically Selecting the Paper Size (“Auto Paper Se-
lect” setting)” on page 3-35.
Adjusting copies to the size of the paper
The most appropriate zoom ratio can automatically be selected based on the
size of the loaded original and the specified paper size.
For details, refer to “Automatically selecting the zoom ratio (“Auto Zoom”
setting)” on page 3-38.
Specifying separate horizontal and vertical zoom ratios
By specifying separate horizontal and vertical zoom ratios, copies of the orig-
inal can be resized as desired.
For details, refer to “Typing In separate X and Y zoom ratios (independent
zoom settings)” on page 3-44.
Scanning the original in separate batches
An original with a large number of pages can be divided and scanned in sep-
arate batches. Double-sided copies can be produced by using the original
glass or the original pages can be alternately loaded onto the original glass
or into the ADF, and then all pages can be copied together as a single job.
For details, refer to “Scanning the original in separate batches (“Separate
Scan” setting)” on page 3-11 and “Scanning a multi-page original from the
original glass” on page 3-15.
ABC
ABC
ABC

Introduction
C352 x-19
Center binding
Copies can be folded at their center and bound with staples.
For details, refer to “To bind copies at the center (“Fold & Staple”)” on
page 3-82.
Sorting copies
The finishing method for copies can be selected.
For details, refer to “Separating copies by sets (“Sort” setting)” on
page 3-72, “Separating copies by pages (“Group” setting)” on page 3-73.
Stapling copies
Multi-page originals can be copied and stapled together.
For details, refer to “Stapling copies (Staple settings)” on page 3-75.
Punching holes in copies
Holes for filing can be punched in the copies.
For details, refer to “Punching holes in copies (Punch settings)” on
page 3-78.
ABC
ABC ABC
ABC ABC
ABC
