Konica Minolta SKR 4000 User manual

DIRECT DIGITIZER
SKR 4000
User Manual
Document Version: 00
Document ID: ACNNBA01EN00
Release Date: 2019-05-08
Before operating, please read this user manual and pay attention to all safety precautions.
Please ensure that this user's manual is properly maintained so that it can be accessed at any time
(reserve).
Please use it correctly on the basis of full understanding of the content.
E

To Customer
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
………………….………..1
Congratulations on your purchase of KONICA SKR 4000 DIRECT DIGITIZER. At
KONICA, we strive to not only make the world-class products that deliver the best value
to our users but also offer the highest quality of service and customer care. Please take time to read user
manual to utilize the product effectively. We hope you enjoy the experience with SKR 4000.
Notes on usage and management of the equipment
1. Read all of the instructions in user manual before operation. Give particular attention
to all safety precautions.
2. Only a physician or a legally certified operator could use the product.
3. The product should be maintained in a safe and operable condition by maintenance
personnel.
4. Use computers and image display monitors complying with IEC 60601-1 or IEC
60950-1. For details, consult our sales representative or local KONICA dealer.
5. Use dedicated cables. Do not use any cables other than those supplied with the
product.
6. Request your sales representative or local KONICA dealer to install the product

SKR 4000 DIRECT DIGITIZER User Manual
2....................................................................................................................................................KONICA
MINOLTA, INC.
Caring for your environment
This symbol indicates that this product is not to be disposed of with your residential or
commercial waste
Recycling KONICA Equipment
Please do not dispose of this product with your residential or commercial waste. Improper
handling of this type of waste could have a negative impact on health and on environment.
Some countries or regions, such as the European Union, have set up systems to collect and
recycle electrical or electronic waste. Contact your local authorities for information about
dropping off waste product for recycling. If collection systems are not available, call
KONICA Customer Service for assistance.
Disclaimer
1. KONICA shall not be liable to the purchaser of this product or third parties for any
damage, loss, or injury incurred by purchaser or third parties as a result of fire,
earthquake, any accident, misuse or abuse of the product.
2. KONICA shall not be liable to any damage, loss, or injury arising from unauthorized
modifications, repairs, or alterations to the product or failure to strictly comply with
KONICA operating and maintenance instructions.
3. KONICA shall not be liable for any damage or loss arising from the use of any
options or consumable products other than those dedicated as Original products by
KONICA Technology.
4. It is the responsibilities of user or physician to maintain the privacy of image data
and provide medical care services. KONICA shall not be responsible for the legality
of image processing, reading and storage nor shall it be responsible for loss of image
data for any reason.
5. Information regarding specification, compositions, and appearance of this product is
subject to change without prior notice.
Copyright
1. All rights reserved
2. No part of this publication may be reproduced in any form or by any means without
the written permission of KONICA. The information contained herein is designed
only for use with KONICA SKR 4000.
Trademarks
The KONICA name and KONICA logo are registered trademarks of KONICA MINPLTA,
INC.

To Customer
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..3
Symbols and Conventions
The following symbols and conventions are used in user manual.
This symbol is used to identify conditions under which
improper use of the product may cause death or serious
personal injury.
This notice is used to identify conditions under which
improper use of the product may cause minor personal
injury.
This notice is used to identify conditions under which
improper use of the product may cause property damage.
This is used to indicate a prohibited operation.
This is used to indicate an action that must be performed.
This is used to indicate important operations and
restrictions.
This is used to indicate operations for reference and
complementary information.
This symbol indicates the name and address of
manufacturers.
Labels and markings on the equipment
The contents of the labels and markings on SKR 4000 product are indicated below:
ICON MEANING
Caution: please refer to the instructions in user manual.
This symbol indicates that the product has passed CE certification
andfollowedbyCEnumber.

SKR 4000 DIRECT DIGITIZER User Manual
4....................................................................................................................................................KONICA
MINOLTA, INC.
This symbol is used to identify the manufacture series number which
is after, below or adjacent to the symbol. The series number of
KONICA products is usually made of thirteen digits as shown below:
This symbol indicates the name and address of manufacturer.
This symbol is used to indicate consultation of the user guide for
general information.
Safety Signs: please refer to user manual for safety instructions
Safety Signs: Dangerous Voltage
Handled with care
This symbol indicates operational temperature limits.
This symbol indicates storage temperature limits.
This symbol indicates the product radiates wireless signal.
Numerical Order
Year
Date
Month
Version
Product Code
A1A2A3A4 C1C2 M DD Y XXX

To Customer
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..5
FCC This symbol indicates the product has passed FCC certification.
Package symbol, fragile.
Package symbol, keep away from sunlight.
Package symbol, keep dry.
This symbol indicates the humidity limits.
Keep the product up right
Do not roll the transportation package.
This symbol indicates stacking limit number.
Type-B applied part
IPX1 for working surface only

SKR 4000 DIRECT DIGITIZER User Manual
6....................................................................................................................................................KONICA
MINOLTA, INC.
Contents
1. SAFETY.................................................................................................................... 10
1.1. Safety precautions..........................................................................................................................10
1.2. Notes for Using................................................................................................................................15
2. GENERAL DESCRIPTION..........................................................................................18
2.1. Scope................................................................................................................................................. 18
2.2. Model..................................................................................................................................................18
2.3. Characteristic...................................................................................................................................18
2.4. Intended use/ essential performance/ application specification.......................................19
2.4.1. Intended use............................................................................................................................19
2.5. Essential performance.................................................................................................................. 19
2.5.1. Application specification...........................................................................................................19
2.6. The relative position between patient and detector..............................................................20
2.7. Product Components.....................................................................................................................20
2.8. Components Description..............................................................................................................22
2.8.1. Detector..................................................................................................................................... 22
2.8.2. Battery........................................................................................................................................23
2.8.3. Battery Charger.........................................................................................................................24
2.9. Product Specification.................................................................................................................... 25
2.9.1. Detector..................................................................................................................................... 25
2.9.2. Battery........................................................................................................................................26
2.9.3. Battery Charger.........................................................................................................................27
2.9.4. Power supply............................................................................................................................. 27
2.9.5. AP Router (Optional).................................................................................................................27
2.9.6. Wireless Communication...........................................................................................................28
2.9.7. Recommended Application Condition....................................................................................... 28
2.9.8. Mechanical Outlines..................................................................................................................29
2.9.9. Use Environment....................................................................................................................... 29

Contents
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..7
2.10. IT network....................................................................................................................................30
2.10.1. Purpose for IT-network..............................................................................................................30
2.10.2. Required characteristics............................................................................................................30
2.10.3. Required configuration..............................................................................................................30
2.10.4. Technical specifications.............................................................................................................30
2.10.5. Intended information flow..........................................................................................................30
2.10.6. Warning..................................................................................................................................... 30
3. INSTALLATION.........................................................................................................32
3.1. Panel Installation.............................................................................................................................32
3.1.1. Attach Battery Pack...................................................................................................................32
3.1.2. Attach DC Power.......................................................................................................................32
3.1.3. Booting Up.................................................................................................................................33
3.1.4. Button Function......................................................................................................................... 35
3.2. Battery Charger Installation.........................................................................................................36
3.3. Battery lock and activation.......................................................................................................... 36
3.4. Software Installation...................................................................................................................... 37
3.5. Panel Infrastructure........................................................................................................................37
3.5.1. Wireless Client Mode.................................................................................................................38
3.5.2. Wireless AP Mode......................................................................................................................42
4. OPERATION..............................................................................................................48
4.1. Main Operation................................................................................................................................48
4.1.1. Software Mode...........................................................................................................................48
4.1.2. Inner2 Mode...............................................................................................................................50
4.1.3. Freesync Mode...........................................................................................................................52
4.2. Connection Build............................................................................................................................ 53
4.3. Panel Configuration....................................................................................................................... 54
4.4. Correction and Calibration Template Generation..................................................................55
4.4.1. Pre-offset Template Generation................................................................................................ 55
4.4.2. Gain Calibration Template Generation.....................................................................................57

SKR 4000 DIRECT DIGITIZER User Manual
8....................................................................................................................................................KONICA
MINOLTA, INC.
4.4.3. Defect Correction Template Generation...................................................................................58
4.5. Image Check and upload..............................................................................................................60
4.5.1. Local Image Check....................................................................................................................60
4.5.2. Panel Image Upload..................................................................................................................61
4.6. Defect Template Check and Modification................................................................................ 61
4.6.1. Defect Template Check..............................................................................................................62
4.6.2. Defect Template Modification................................................................................................... 63
4.7. Correction and Calibration Management................................................................................. 64
4.7.1. Correction and Calibration template synchronization..............................................................64
4.7.2. Correction and Calibration management..................................................................................65
4.8. Firmware Update.............................................................................................................................66
4.8.1. MCU Update..............................................................................................................................66
4.8.2. FPGA Update............................................................................................................................ 69
4.8.3. ARM Update.............................................................................................................................. 71
4.8.4. ALL FIRMWARE Update.......................................................................................................... 73
4.9. Short cut............................................................................................................................................73
4.10. Software....................................................................................................................................... 74
4.10.1. Main GUI...................................................................................................................................74
4.10.2. Message Box..............................................................................................................................75
4.10.3. Configuration GUI.....................................................................................................................76
4.11. List of the HAZARDOUS SITUATIONS resulting from a failure of the IT-
NETWORK.........................................................................................................................................79
5. REGULATORY INFORMATION..................................................................................80
5.1. Medical equipment safety standards........................................................................................ 80
5.2. The compliance for each EMISSIONS and IMMUNITY standard or test specified by
IEC60601-1-2 standard.................................................................................................................. 81
5.3. Radio Frequency Compliance Information..............................................................................84
5.3.1. FCC Compliance.......................................................................................................................84
5.4. Battery Safety Standards..............................................................................................................85

Contents
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..9
6. TROUBLE SHOOTING...............................................................................................86
7. SERVICE INFORMATION..........................................................................................87
7.1. Product Lifetime..............................................................................................................................87
7.2. Regular Inspection and Maintenance........................................................................................87
7.3. Repair.................................................................................................................................................87
7.4. Replacement Parts Support.........................................................................................................87
APPENDIX A INFORMATION OF MANUFACTURES...........................................................88

Safety
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
…………….….………..10
1. Safety
1.1. Safety precautions
Follow these safeguards and properly use the product to prevent injury and damage to it.
WARNING
Installation and
environment of
use
Do not use or store the product near flammable
chemicals such as alcohol, thinner, benzene, etc.
If chemicals are spilled or evaporated, it may result in fire
or electric shock through contact with electric parts inside
the product. Also, some disinfectants are flammable. Be
sure to take care when using them.
Do not connect the equipment with anything other than
specified.
Doing so may result in fire or electric shock.
All patients with active implantable medical devices
should be kept away from the product.
Power supply Do not operate the product with power supply other
than the one indicated on the rating label.
Otherwise, it may result in fire or electric shock.
Do not handle the product with wet hands.
You may experience electric shock that could result in
death or serious injury.
Do not place heavy object on cables and cords. Do not
pull, bend, bundle, or step on them to prevent their
sheath from being damaged, and do not alter them
neither.
Doing so may damage the cords which could result in fire
or electric shock.
Do not supply power to more than one piece of product
with the same AC outlet.
Doing so may result in fire or electric shock.
Do not turn on system power when condensation has
formed on the equipment.
Doing so may result in fire or electric shock.
Do not connect multiple portable socket-outlets or
extension cords to the system.
Doing so may result in fire or electric shock.
To avoid the risk of electric shock, this product must
only be connected to power supply with protective
earth.
Not doing so may result in fire or electric shock.
Do not connect the adapter cord when connect the
panel to patient.

Safety
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..11
Securely plug the power cord into the AC outlet.
If contact failure occurs, or if metal objects come into
contact with exposed metal prongs of the plug, fire or
electric shock may result.
Be sure to turn off the power before connecting or
disconnecting the cords.
Otherwise, you may get an electric shock that could result
in death or serious injury.
Be sure to hold the plug or connector to disconnect the
cord.
If you pull the cord, the core wire may be damaged,
resulting in fire or electric shock.
WARNING
Handling Never disassemble or modify the product. No
modification is allowed.
Doing so may result in fire or electric shock. Also, since
the product incorporates parts that may cause electric
shock as well as other hazardous parts, touching them may
cause death or serious injury.
Do not place anything on top of the product.
The object may fall and cause an injury. Also, if metal
objects such as needles or clips fall into the product, or if
liquid is spilled, it may result in fire or electric shock.
Do not hit or drop the product.
The product may be damaged if it receives a strong jolt,
which may result in fire or electric shock if it is used
without being repaired.
Do not put the product and pointed objects together.
The product may be damaged. If so, it should be used in
bucky.
Have the patient take a fixed posture and do not let the
patient touch parts unnecessarily.
If the patient touches connectors or switches, it may result
in electric shock or malfunction.
When a problem
occurs
Should any of the following occurs, immediately unplug
the power cord of adaptor or battery, and contact your
sales representative or local KONICA dealer:
When there is smoke, an odd smell or abnormal sound.
When liquid has been spilled into the equipment or a metal
object has entered through an opening.
When the product has been dropped and damaged.
Maintenance and
inspection Please turn off power of the product and unplug power
cord of adapter before cleaning.
Never use alcohol, ether and other flammable cleaning
agent for safety. Never use methanol, benzene and acid
because they would corrode the equipment.
Don’t dip the product into liquid.
Please make sure that surface & plugs are dry before
turning on.

SKR 4000 DIRECT DIGITIZER User Manual
12 ..................................................................................................................................................KONICA
MINOLTA, INC.
Otherwise, it may result in fire or electric shock.
Clean the plug of the power cord periodically by
unplugging it from the AC outlet and removing dust or
dirt from the plug, its periphery and AC outlet with a
dry cloth.
If the cord is kept plugged in for a long time in a dusty,
humid or sooty place, dust around the plug will attract
moisture; this could cause insulation failure that may result
in a fire.
For safety reasons, be sure to turn off the power when
performing inspections indicated in this manual.
Otherwise, electric shocks may occur.
CAUTION
Installation and
environment of
use
Do not install the product in any of the locations listed
below. Doing so may result in failure, malfunction,
falling, fire or injury.
Close to facilities where water is used
Where it will be exposed to direct sunlight
Close to the air outlet of an air-conditioner or ventilation
equipment
Close to heat source such as a heater
Where the power supply is unstable
In a dusty environment
In a saline or sulfurous environment
Where temperature or humidity is high
Where there is freezing or condensation
In areas prone to vibration
On an incline or in an unstable area
Take care that cables do not become tangled during
use. Also, be careful not to get your feet caught by
cable.
Otherwise, it may cause a malfunction of the product or
injury of the user due to tripping over the cable.
Non-medical equipment such as battery charger, access
point and infrared register tools cannot be used in
patient’s vicinity.

Safety
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..13
Power supply Always connect three-core power cord plug to a
grounded AC power outlet.
To make it easy to disconnect the plug at any time,
avoid putting any obstacles near the outlet. Otherwise,
it may not be possible to disconnect the plug in an
emergency.
Be sure to ground the product to an indoor grounded
connector. Also, be sure to connect all the grounds of
system to common ground.
Do not use any power source other than the one
provided with the product.
Otherwise, fire or electric shock may be caused due to
leakage.
Handling Do not spill liquid or chemicals onto the equipment. In
case the patient is injured, it is not allowed to contact
with blood or other body fluids.
Doing so may result in fire or electric shock.
In such a situation, protect the equipment with a disposable
cover as necessary.
Turn OFF the power and pull out the plug to each
piece of equipment for safety when not used.
CAUTION
Handling Handle the product carefully.
Do not submerge the product in water.
Only working surface meets IPX1
The internal image sensor may be damaged if
something hits against it or it is dropped. If the product
is dropped, the drop sensor inside would record and
the product would not be warranted by KONICA.
Do not place excessive weight on the panel.
Otherwise, the internal image sensor may be damaged and
image may be incorrect.
Patients stand on the product temporarily, and the intended
weight can be 135kg.
Based on the internal TFT character, cannot load the
dynamic forces due to loading from persons

SKR 4000 DIRECT DIGITIZER User Manual
14 ..................................................................................................................................................KONICA
MINOLTA, INC.
<Load Limit>
Uniform load：135 kg over the whole area of the surface.
Local load：100 kg on an area 4 cm diameter.
Be sure to use the product on flat surface so it would
not bend. Otherwise, the internal image sensor may be
damaged. Be sure to securely hold the product while
using it in upright positions. Otherwise, the product
may fall over, resulting in injury to user or patient, or
may flip over, resulting in damage to the inner device.
Keep the same load on the product when acquiring image.
The image will be incorrect.
CAUTION
Do not close to fire, do not use in high temperature
Do not invert positive and negative pole
Do not contact with metal in case of short circuit
Do not insert sharp objects into battery
Do not beat battery
Do not stand on battery
Do not use battery out of rules
Do not dispose of battery or change inner structure
Do not submerge battery in water, please keep dry in
storage and do not contact with water in use

Safety
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
……………….………..15
Please charge battery with charger following GB
9706.1 Standards provided by us
Do not mix battery with ones not provided by our
company
Do not charge battery with broken charger.
Substitution of battery inside main unit must be
carried out by qualified people
Do not touch output connector for adaptor
1.2. Notes for Using
When using the product, take the following precautions. Otherwise, problems may
occur and the product may not function correctly.
Before exposure
Be sure to check the product daily and confirm it work properly.
Sudden heating of the room in cold areas will cause condensation on the
product. In this case, wait until the condensation evaporates before performing
an exposure. If it is used when condensation is formed, problems may occur in
the quality of captured images. When an air-conditioner is used, be sure to
raise/lower the temperature gradually to prevent condensation.
The product should be warmed up for 15 minutes before exposure or updating
the gain map and defect map.
Make sure exposure rate is over 900nGy/s @70KV.
Make sure wave form of the energy going to the X ray tube is square not pulse.
Be cautious with circumstance that someone has radio isotope recently injected
into them, it may cause that panel transmit image without x ray.
During exposure
Do not move Power Cable, or it may cause image noise or artifacts, even
incorrect images.
Do not use the product near the equipment generating a strong magnetic field.
Otherwise, it may cause image noise, artifacts or even incorrect images.
After usage
It’s strongly recommended to remove battery from panel if panel is not used
more than 5 days. If battery stores for a long time, it should be charged (30% to
50%) every 3 month or charged (50% to 70%) every 6 month.

SKR 4000 DIRECT DIGITIZER User Manual
16 ..................................................................................................................................................KONICA
MINOLTA, INC.
Contact with the patients parts cleaning, disinfection and sterilization
After every examination, wipe the patient contact surfaces with nonflammable
disinfectants to prevent the risk of infection. For details on how to sterilize,
consult a specialist.
Do not spray the product directly with disinfectants or detergents.
Wipe it with a cloth slightly damped with a neutral detergent. Do not use
solvents such as benzene and acid. Doing so may damage the surface of the
product.
It’s recommended to use a waterproof non-woven cover as the isolated layer
between product and the blooding patient.
Applied part
The front and back of detector is application part.

SKR 4000 DIRECT DIGITIZER User Manual
17 ..................................................................................................................................................KONICA
MINOLTA, INC.
2. GENERAL DESCRIPTION..........................................................................................18
2.1. Scope................................................................................................................................................. 18
2.2. Model..................................................................................................................................................18
2.3. Characteristic...................................................................................................................................18
2.4. Intended use/ essential performance/ application specification.......................................19
2.5. Essential performance.................................................................................................................. 19
2.6. The relative position between patient and detector..............................................................20
2.7. Product Components.....................................................................................................................20
2.8. Components Description..............................................................................................................22
2.9. Product Specification.................................................................................................................... 25
2.10. IT network....................................................................................................................................30

General Description
KONICA MINOLTA,
INC..………….……………………………………………………………………………………………………
….…………….………..18
2. General Description
SKR 4000 is a cassette-size wireless X ray direct digitizer based on amorphous silicon thin-
film transistor technologies. It is developed to provide the highest quality of radiographic
image, which contains an active matrix of 2304×2800 with 150um pixel pitch. The greatest
feature is SKR 4000 supports wireless communication between panel and Workstation. SKR
4000’s power supply includes battery. SKR 4000 can be used as a real portable panel.
2.1. Scope
This manual contains information about the SKR 4000. Information in the manual, including
the illustrations, is based on prototype. If your configuration does not have any of these items,
information about these items does not apply to your panel.
SKR 4000
Share SKR 4000 for different Radiography modality like an IP plate
2.2. Model
Product Type: SKR 4000-----------Product series: DIRECT DIGITIZER
-----------Product dimension: 1417, 14inch×17inch
-----------Product scintillator: CsI
Product Type: Battery-KV---------Rechargeable lithium battery
Product Type: Charger-Combo--------Battery charger
2.3. Characteristic
Wireless static flat panel detector used for general radiography.
Cassette-size
