Konica Minolta CM-M6 User manual

Instruction Manual
Please read before using the instrument.

i
Ocial names for applications and the like used in this manual
(Wording used in text) (Ocial name)
Bluetooth Bluetooth®
Trademarks
• The Bluetooth® mark and logo are registered trademarks of The Bluetooth SIG, Inc. and are used under license.
• The KONICA MINOLTA logo and symbol marks and SpectraMagic are registered trademarks of Konica Minolta, Inc.

ii
 Safety Symbols
The following symbols are used in this manual and on the product to prevent accidents that may occur because of
incorrect use of the instrument.
Denotes an instruction regarding a safety warning or note.
Read the instruction carefully to ensure safe and correct use.
Denotes an instruction regarding the risk of electric shock.
Read the instruction carefully to ensure safe and correct use.
Denotes an instruction regarding the risk of fire.
Read the instruction carefully to ensure safe and correct use.
Denotes a prohibited operation.
This operation must never be performed.
Denotes an instruction.
This instruction must be strictly adhered to.
Denotes an instruction.
Be sure to disconnect the plug from the outlet.
Denotes a prohibited operation.
Never disassemble the instrument.
This symbol indicates alternating current (AC).
This symbol indicates direct current (DC).
This symbol indicates class II protection against electric shock.
 Notes on this Manual
• Copying or reproduction of all or part of the contents of this manual without the permission of KONICA MINOLTA is
strictly prohibited.
• The contents of this manual are subject to change without prior notice.
• The latest instruction manual can be downloaded from the following URL:
http://www.konicaminolta.com/instruments/download/instruction_manual/index.html
• Every eort has been made in the preparation of this manual to ensure the accuracy of its contents. However, should
you have any questions or find any errors, please contact your retailer or a KONICA MINOLTA-authorized service
facility.
• KONICA MINOLTA will not accept any responsibility for consequences arising from the use of the instrument.

1
Safety Precautions
To ensure correct use of this instrument, read the following points carefully and adhere to them. After you have
read this manual, keep it in a safe place where it can be referred to anytime a question arises.
The latest instruction manual can be downloaded from the following URL:
http://www.konicaminolta.com/instruments/download/instruction_manual/
WARNING
(Failure to adhere to the following points may result in death or serious injury.)
Do not use the instrument in places where flammable or combustible gases (gasoline, etc.) are
present.
Doing so may cause a fire.
Be sure to turn the instrument OFF in areas where use is prohibited, such as in airplanes or
hospitals. Using the instrument in such areas may aect the electronics and medical equipment,
which may cause an accident.
Always use the AC adapter supplied as a standard accessory or the optional AC adapter (AC-A311),
and connect it to a 100-240 VAC (50/60 Hz) AC outlet of the rated voltage and frequency. If an AC
adapter other than those specified by KONICA MINOLTA is used, or if the adapter is connected to an
unsupported voltage, it may result in damage to the adapter, fire, or electric shock. To use the
instrument outside the area of purchase, please contact a KONICA MINOLTA-authorized service
facility.
If the instrument will not be used for a long time, disconnect the AC adapter power plug from the
AC outlet. Accumulated dirt or water on the prongs of the AC adapter’s plug may cause a fire and
should be removed. Clean o any dirt or water on the prongs of the AC adapter’s plug before use.
Firmly push the AC adapter power plug completely into the outlet. Incomplete insertion may cause
fire or electric shock.
Do not forcibly bend, twist, or pull the cords or cables. Also, do not scratch, or place heavy objects
on the cables. Doing so may damage the cable and cause a fire or electric shock.
Do not disassemble or modify the instrument or the AC adapter. Doing so may cause a fire or
electric shock.
Take special care not to allow liquid or metal objects to enter the instrument and the AC adapter.
Doing so may cause a fire or electric shock. Should liquid or metal objects enter the instrument,
turn the power OFF immediately, disconnect the AC adapter power plug from the AC outlet (or
remove the lithium-ion battery if using battery power), and contact the nearest KONICA MINOLTA-
authorized service facility.
Do not dispose of the lithium-ion battery in a fire, short-circuit, heat, or disassemble the battery.
Doing so may cause the lithium-ion battery to rupture or leak, which could result in fire or injury.
In the event that a lithium-ion battery leaks and the fluid comes into contact with the eyes, do not
rub the eye. Wash it with clean water, and then immediately consult a doctor. If the leaked fluid
comes into contact with skin or clothing, immediately rinse with water. In addition, stop using the
instrument if the lithium-ion battery has leaked.
When disposing of the lithium-ion battery used in this instrument, use tape or some other material
to electrically insulate the contacts. Contact with other metals may cause the lithium-ion battery to
overheat, rupture, or catch fire. Properly dispose of the lithium-ion battery according to local
regulations or recycle the lithium-ion battery.
The instrument should not be operated if it or the AC adapter is damaged, or if smoke or odd smells
occur. Doing so may cause a fire. In such situations, turn the power OFF immediately, disconnect
the AC adapter plug from the AC outlet (or remove the lithium-ion battery if using battery power),
and contact the nearest KONICA MINOLTA-authorized service facility.
Do not insert or disconnect the AC adapter plug with wet hands. Doing so may cause electric shock.

2
Do not touch the lithium-ion battery with wet hands. Doing so may result in electric shock or a
malfunction.
Use the dedicated charger to charge the lithium-ion battery. If charging conditions or a charger
dierent from that specified is used for charging, the battery may leak, overheat, or catch fire.
Always hold the plug itself when disconnecting the cable from an outlet. Pulling on the cable may
damage it and cause a fire or electric shock.
Do not use, charge, or store the lithium-ion battery in a high-temperature environment. Doing so
may cause the batteries to overheat, catch fire, or rupture.
Do not throw or submit the lithium-ion battery to strong impacts such as from a fall from a high
location. If the lithium-ion battery is deformed or if the built-in protection system is broken, an
abnormal current or voltage may be applied to the battery during charging, which may cause the
batteries to overheat, rupture, or catch fire.
Do not step on the lithium-ion battery or pierce with a nail or hit with a hammer. If the lithium-ion
battery is deformed or if the protection system is damaged, the battery may overheat, rupture, or
catch fire.
Should an unusual odor, heat, discoloration, deformation, or other previously unnoticed
abnormality occur during use, charging, or storage, remove the lithium-ion battery from the
instrument or charger and discontinue use. Continued use of a lithium-ion battery in this condition
may cause the lithium-ion batteries to overheat, rupture, or catch fire.
If the lithium-ion battery is found to be leaking or emitting an unusual odor, keep the battery away
from any open flames. The electrolytic solution from the battery may catch fire, causing rupture or
fire.
Do not look directly at the lamp. The lamp is extremely bright and emits ultraviolet rays. Looking
directly at the light may injure the eyes.
CAUTION
(Failure to adhere to the following points may result in injury or damage to the
instrument or other property.)
When using the AC adapter, make sure, that an AC outlet is located near the instrument, and that
the AC adapter plug can be connected to and disconnected from the AC outlet easily.
When cleaning the instrument, unplug the AC adapter plug from the outlet. Failure to do so may
result in electric shock.
Do not use any lithium-ion battery other than that specified for use with the instrument. When
inserting a lithium-ion battery into the instrument, be sure to insert the battery correctly. Fire,
injury, or stains on surroundings may occur if the lithium-ion battery is damaged or leaking.
Do not use a wet lithium-ion battery.
Doing so may cause the lithium-ion battery to rupture or overheat, which could result in fire or
injury.
Do not place the instrument on an unstable or sloping surface. Doing so may result in the
instrument dropping or overturning, causing injury. Be careful not to drop the instrument when
carrying it as well.
Do not use the instrument if the sample specimen measuring port (measurement area) is in the line
of sight. Doing so may result in injury to the eye.
Take care not to pinch yourself on the areas of the instrument that open and close. Doing so may
result in injury.

3
Introduction
The CM-M6 is a multi-angle spectrophotometer capable of measuring from six angles in a single measurement.
Please read this manual carefully before using the instrument.
Packing materials of the product
Be sure to keep all packing materials used for shipping the instrument (cardboard box, cushioning material,
plastic bags, etc.). This instrument is a precision measuring instrument. When transporting the instrument to a
service facility for maintenance or for other reasons, be sure to use the packing materials to minimize shock or
vibration. If the packing materials are lost or damaged, contact a KONICA MINOLTA-authorized service
facility.
 Notes on Use
Operating Environment
• This instrument is a pollution level 2 product (equipment to be used primarily in manufacturing environments,
laboratories, warehouses, and similar locations). This instrument should be used in environments where
exposure to metallic dust or condensation is not a concern.
• This instrument is an overvoltage category I product (equipment for connection to circuits in which measures
are taken to limit transient overvoltage to an appropriately low level).
• Take care to prevent foreign matter from entering the instrument. Using the instrument while subjected to
intrusion of water or metals is extremely dangerous.
• Using the instrument in direct sunlight or near heating equipment can cause the internal temperature of the
instrument to become much higher than the ambient temperature, resulting in malfunction. Do not use the
instrument in such areas.
• Avoid subjecting the instrument to sudden temperature changes and condensation.
• Do not use the instrument in areas where dust, smoke, or chemical gases are present, or in extremely humid
environments.
• This instrument should be used in an environment with an ambient temperature between 0°C and 40°C and a
relative humidity of 85% or less (at 35°C) with no condensation. Use of the instrument outside this range will
result in unsatisfactory performance.
• Do not use the instrument at altitudes higher than 2,000 m.
• Do not use the instrument near equipment that produces a strong magnetic field (such as speakers).
• To secure the instrument for use, make sure the instrument is firmly attached with no possibility of falling o.
Failure to do so may result in harm to the instrument or people and objects around the instrument.
• This instrument is composed of precision electronic components. Never disassemble the instrument.
• The AC adapter supplied as a standard accessory (AC-A311) has been designed exclusively for indoor use.
Outdoor use is prohibited.
• Always use the AC adapter supplied as a standard accessory (AC-A311) and connect it to a 100-240 VAC
(50/60Hz) AC outlet. Use an AC power supply of the rated voltage (within ±10%).
System
• Do not subject the instrument to strong vibrations or impacts.
• Do not pull, forcibly bend, or apply excessive force to the connected cables and cords. Doing so may cause the
cable or cord to break.
• Do not allow the inside of the specimen measuring port of the instrument to become dirty or subject the port to
impact. In addition, make sure to attach the white calibration cap when the instrument is not in use.
• This instrument and the AC adapter are EMC Class B products. Use of the instrument and the AC adapter in
home environments may cause radio interference. Users may be required to take appropriate measures in such
cases.
• If the instrument is exposed to strong external static electricity, the LCD may go blank or fail to display
information correctly. Communication with a connected external device may also be interrupted. In such cases,
turn the power OFF and then ON again. If black smudges appear on the LCD, wait until they disappear naturally.

4
• When turning the power OFF and then ON again, wait several seconds after turning the power OFF before
turning the power ON again.
• The instrument should be connected to a power source with as little noise as possible.
• When a malfunction or abnormal behavior occurs, turn the power OFF immediately, disconnect the AC adapter
plug from the AC outlet, and refer to “Troubleshooting” on page 119.
• Should the instrument break down, do not try to disassemble and repair the instrument. Contact a KONICA
MINOLTA-authorized service facility.
Backup Battery
• The instrument uses a built-in backup battery to store various settings in the memory. The backup battery will
be fully charged in approximately seven days regardless of whether the instrument’s power switch is turned ON
or OFF so long as the instrument is powered from the AC adapter or from the lithium-ion battery. There is no
need to worry about overcharging the backup battery. At full charge, the backup battery can store data for up
to one year. However, the backup battery may not be fully charged when the instrument is purchased. The
backup battery will charge as the instrument is being used.
• Do not attempt to replace the built-in backup battery. The battery should only be replaced by KONICA
MINOLTA. To replace the backup battery, please contact a KONICA MINOLTA-authorized service facility.
• It is recommended to manage important data using the optional SpectraMagic DX software.
White Calibration Plate
• The calibration data for the white calibration plate was measured at 23°C. To achieve the highest accuracy
when measuring absolute values, calibration and measurement should be performed at 23°C.
• Do not allow the white calibration plate to become scratched or dirty.
• When the white calibration plate is not in use, be sure to close the cap so that the plate is not exposed to light.
• Hold the white calibration cap attached to the instrument and do not allow the instrument to move. Doing so
may cause the instrument to become separated from the white calibration cap and fall, which may damage the
instrument.
Power Source
• Make sure that the power is turned OFF when the instrument is not in use.
• This instrument can be powered from a lithium-ion battery (CM-A223, available as a standard accessory or
optional accessory) or the standard accessory AC adapter (AC-A311). Absolutely do not use any other type of
battery or AC adapter.
• Make sure the AC adapter output plug is not short-circuited. Doing so may cause a fire or electric shock.
• Do not connect the AC adapter to an overloaded electrical circuit. In addition, do not wrap or cover the AC
adapter with cloth or other material while in use. Doing so may cause an electric shock or fire.
• When removing the AC adapter from the instrument, first remove the power cord from the outlet, and then
remove the output plug.
Battery
• Use only the standard lithium-ion battery or the optional accessory lithium-ion battery (CM-A223). Absolutely
do not use any other type of battery.
• The battery is only slightly charged upon purchase and must therefore be charged.
• The lithium-ion battery takes about 5 hours to become fully charged. There is no need to worry about
overcharging.
• The lithium-ion battery will self-discharge. The battery will become unusable due to over discharging if left for a
long period. Charge the battery for at least one hour using the instrument or an optional battery charger at
least semiannually.
• After using up the lithium-ion battery, do not leave it uncharged.
• Charging should be performed at between 0 and 40°C. Charging will not be performed outside this
temperature range.
• If the lithium-ion battery will not be used for a long period, remove the battery from the instrument and store it
in a location not subject to high temperatures or high humidity.

5
Introduction (Cont.)
 Notes on Storage
• When not in use, store the instrument in the packing used for shipment or in the hard case (optional).
• Storing the instrument in direct sunlight or near heating equipment can cause the internal temperature of the
instrument to become much higher than the ambient temperature, resulting in malfunction. Do not store the
instrument in such areas.
• This instrument should be stored at a temperature between -20°C and 45°C with a relative humidity of 85% or
less (at 35°C) and no condensation. Storing the instrument in an environment with high temperatures and high
humidity will result in unsatisfactory performance. Storing the instrument and the drying agent at or near room
temperature is recommended.
• Make sure that the instrument is not subjected to condensation when stored. In addition, take care to prevent
rapid temperature changes to prevent condensation from occurring when transporting the instrument to the
storage location.
• Do not store the instrument in areas where dust, smoke, or chemical gases are present. Doing so may cause
deterioration in performance or a malfunction.
• Do not leave the instrument inside the cab or trunk of a vehicle. Otherwise, the temperature and/or humidity
during midsummer or midwinter may exceed the allowable range for storage, resulting in a malfunction.
• Dust inside the specimen measuring port may prevent accurate measurements from being performed. When
the instrument is not in use, use the lid to prevent the intrusion of dust and the like.
• The white calibration plate may become discolored if left exposed to light. Therefore, make sure to close the cap
when the plate is not in use in order to prevent the plate from being exposed to light.
• Take care not to pinch yourself on the areas of the hard case (optional) that open and close. Doing so may cause
injury.
 Notes on Cleaning
• If the instrument becomes dirty, wipe it with a soft, dry cloth. Never use organic solvents (such as benzene or
thinner) or other chemicals for cleaning.
• If there is dust or dirt on the lens or the receptor window, use a blower or the like to blow it o. Never use
organic solvents (such as benzene or thinner) or other chemicals for cleaning.
• If the white calibration plate becomes dirty, wipe it with a soft, clean dry cloth. If the dirt is dicult to remove,
wipe it o with a cloth dampened with commercially available lens cleaning solution, remove the solution with
a cloth dampened with water, and allow the plate to dry before using.
• If you are unable to remove dirt from the instrument through the above procedure, or if the instrument
becomes scratched, contact a KONICA MINOLTA-authorized service facility.
• If you are unable to remove dirt from the instrument or if the instrument becomes scratched, contact a KONICA
MINOLTA-authorized service facility.
 Notes on Transporting
• When transporting the instrument, be sure to use the packing materials to minimize shock or vibration.
• When sending the instrument in for service, package and send the instrument and all accessories.
 Maintenance and Inspection
• To maintain measurement accuracy, the instrument should be inspected once a year. For information on
inspection, contact the nearest KONICA MINOLTA-authorized service facility.

6
 Disposal Method
• Make sure that the instrument, all accessories (including any used batteries), and the packing materials are
either disposed of or recycled correctly in accordance with local laws and regulations.
• In the United States and Canada, you can recycle your lithium-ion battery through the Call2Recycle program.
For more information, in the United States visit www.call2recycle.org and in Canada visit www.call2recycle.ca.

7
Table of Contents
 Safety Symbols .................................................ii
 Notes on this Manual ........................................ii
Introduction .....................................................3
 Notes on Use.................................................... 3
 Notes on Storage ............................................. 5
 Notes on Cleaning............................................ 5
 Notes on Transporting...................................... 5
 Maintenance and Inspection ............................ 5
 Disposal Method.............................................. 6
 Conventions .................................................... 9
 Instrument Firmware Version ...................... 9
Chapter 1 Before Using the
Instrument................... 10
Accessories ....................................................11
 Standard Accessories..................................... 11
 Optional Accessories...................................... 12
System Diagram .............................................14
Names and Functions of Parts.........................15
Handling the Instrument ................................17
 Attaching the Hand Strap .......................... 17
 Inserting/Removing the Battery................ 18
 Connecting the AC Adapter....................... 19
 White Calibration Cap.................................... 20
 Attaching to/Removing from Instrument ... 20
 Zero Calibration Box....................................... 21
 Attaching to/Removing from Instrument ... 21
 Attaching/Removing the White Calibration
Cap to/from the Zero Calibration Box........ 22
 Cleaning Parts................................................ 24
 White Calibration Cap
(StandardAccessories).............................. 24
 Zero Calibration Box
(StandardAccessories).............................. 24
 Turning the Power ON/OFF....................... 25
 Display Language...................................... 26
 Instrument Operation/Display....................... 26
 Display (LCD Screen)................................. 26
 Status Bar Icons ........................................ 27
 Control Keys.............................................. 28
 Data Saving ................................................... 29
Chapter 2 Measurement............... 30
Flow of Measurement .....................................31
Calibration .....................................................32
 Zero Calibration ............................................. 32
 White Calibration........................................... 34
Measurement.................................................36
 Average Measurement ................................... 37
Measurement (Color Dierence).....................38
 Target Setting ................................................ 38
 Checking Color Dierences............................ 38
Pass/Fail Judgment for Color Dierence..........39
 Pass/Fail Judgment Based on Tolerances........ 39
 Changing Screens ..................................... 41
 Measurement/Data Display Screen................ 42
Chapter 3 Environment Settings/
Other Settings .............. 44
 Menus ........................................................... 45
Color Dierence Target Color Operation .........47
 Print .............................................................. 48
 Edit Name...................................................... 49
 Target Data Management............................... 50
 Delete Data ............................................... 50
 Change List Position.................................. 51
 Protect Data.............................................. 52
 Delete All Data .......................................... 53
 Pass/Fail........................................................ 54
 Tolerance Settings..................................... 55
 Warning Level Setting ............................... 56
 Parametric Coecient Setting................... 57
Handling the Sample ......................................58
 Print .............................................................. 59
 Edit Name...................................................... 60
 Sample Data Management............................. 61
 Delete ....................................................... 61
 Setting Measurement Data as Target ......... 62
 Change Target Reference .......................... 63
 Change List Position.................................. 64
 Delete All Data .......................................... 65
Measurement Condition Settings ...................66
 Measurement Condition Settings................... 66

8
 Measurement Option Settings ....................... 67
 Measurement Angle.................................. 68
 Auto Average (1 to 10)............................... 69
 Manual Average (1 to 10)........................... 70
 Manual Average Option............................. 71
 Tilt Detection ............................................ 71
 Display Condition Settings............................. 72
 Observer/Illuminant 1 .............................. 73
 Observer/Illuminant 2 .............................. 74
 Display Settings ............................................. 75
 Display Type.............................................. 76
 Color Space............................................... 77
 Equation ................................................... 78
 Direction................................................... 79
System Settings..............................................80
 Default Data Settings ..................................... 80
 Default Tolerance Setting .......................... 81
 Warning Level Setting ............................... 82
 Parametric Coecient Setting................... 82
 Calibration Setup ........................................... 84
 Calibration Interval Messages.................... 85
 Annual Calibration Messages .................... 86
 Measurement Instrument Option Settings ..... 87
 User Type .................................................. 88
 Display Language Settings ........................ 89
 Setting the Date Format ............................ 90
 Setting the Clock....................................... 91
 Screen Brightness ..................................... 92
 Display Orientation ................................... 93
 Buzzer....................................................... 94
 Measurement Button ................................ 95
 Power saving ............................................ 96
 Displaying Diagnosis Information .................. 97
 Displaying the Instrument Information........... 98
Chapter 4 Other Functions.......... 100
Connecting to an External Device .................101
 Connecting to a Personal Computer............. 101
 Connecting via USB Cable ....................... 102
 Connecting via Bluetooth........................ 103
{ Instrument Preparations ......................... 104
x Connecting the Bluetooth Module........... 104
 Communication Setup ................................. 105
 USB Host................................................. 105
{ Connecting the Instrument to a PC.......... 107
 Connecting to a Printer ................................ 108
 Connecting via USB Cable ....................... 108
 Connecting via Bluetooth........................ 109
{ Printer Preparations................................ 110
{ Instrument Preparations ......................... 111
 Registering a Bluetooth Address ............. 111
 Configuring PIN Code ............................. 112
 Printing Data........................................... 113
 Auto Print................................................ 114
Chapter 5 Troubleshooting ......... 116
Message List.................................................117
Troubleshooting ...........................................119
Chapter 6 Appendix ................... 120
Main Specifications ......................................121
Dimensions ..................................................122

9
 Conventions
This manual describes how to safely operate the CM-M6 using a specific procedure to perform measurement.
· Viewing Pages
Symbols used in this manual are explained below.
* Explanatory pages are constructed as follows. (The content of the explanatory illustration will dier from the
actual page.)
* Display screenshots used in the explanations may include dierent content and values, and may have a dierent
layout than the actual display.
86
3
Environment Settings/Other Settings
 Annual Calibration Messages
As the time for periodic calibration approaches, the instrument shows a message reading “Regularly scheduled
device calibration is required. Please contact the nearest service center.” at start-up to recommend annual service
recalibration.
The annual calibration message can be turned OFF from the MENU.
Notes Although the annual calibration message can be hidden, it is recommended to accept our recalibration
service.
Memo Display of the annual calibration message is set to “ON (Display)” under the initial settings.
Operating Procedure Start the procedure from the <Setting> - <Calibration setup> screen.
1 Press [MENU].
The <Annual calibration> screen is displayed.
Settings
{ OFF : Do not show the annual calibration message
even if the next calibration date is near.
{ ON : Show the annual calibration message when the
next calibration date approaches.
2 Use [] or [] to move the cursor to select “OFF” or
“ON”.
Memo If the annual calibration notification message is set to ON,
the annual calibration message will be displayed when the
specified day approaches. The date of the next calibration is
specified under the initial settings or during KONICA
MINOLTA calibration service (or maintenance) and cannot be
changed.
3 Press the [Confirmation] key.
The selection is confirmed and the screen returns to the
<Setting> screen.
Notes If [ESC] is pressed without pressing the [Confirmation]
key, the settings will not be changed and the screen will
return to the <Setting> screen.
Calibration setup
Annual calibration
ON
Calibration interval
8 (hour)
Sample 0002 TARGET-2
Setting
Calibration setup
Annual calibration
ON
Calibration interval
8 (hour)
Sample
Setting
0002 TARGET-2
Annual calibration
OFF
ON
Next date
2016/01/01
 Instrument Firmware Version
The version of the instrument firmware can be confirmed on the <Instrument info.> screen. For details, refer to
page 98 “Displaying the Instrument Information” in this manual.
Procedure
Indicates an
operating procedure.
Settings
Describes ranges and
provides
explanations
regarding settings for
the screen in
question.
Memo
Provides useful
information,
supplementary
explanations, and
similar details.
Notes
Provides essential
information for
correct operation of
the instrument.
Always read this
information before
operating the
instrument.
Start screen
Indicates the initial
screen from which
the operation is
commenced.
Screenshot
Indicates the state of
the screen when the
operation described
in the procedure to
the left is carried out.

10
1
Before Using the Instrument
Chapter 1
Before Using the
Instrument
Accessories ..........................................................11
Standard Accessories ..............................................11
Optional Accessories ...............................................12
System Diagram ...................................................14
Names and Functions of Parts...............................15
Handling the Instrument ......................................17
White Calibration Cap..............................................20
Zero Calibration Box ................................................21
Cleaning Parts .........................................................24
Instrument Operation/Display ................................26
Data Saving .............................................................29

11
Accessories
Standard and optional accessories are available with the instrument.
Memo The shape of some products may be dierent from those shown.
*Not available in all areas.
 Standard Accessories
AC Adapter AC-A311*
Used to supply power from an AC outlet to the instrument.
Input: 100 to 240 V 50/60 Hz 31 to 43 VA 0.31 to 0.18 A
Output: 11 V 1.5 A
Plug design: Center-negative
Lithium-Ion Battery CM-A223*
• This lithium-ion battery is designed specifically for use with the
instrument.
• Insert the battery into the instrument, and connect the
instrument to the AC adapter to charge.
• The battery itself can also be charged using a separately sold
charger.
White Calibration Cap CM-A226
Used to perform calibration. The set includes the white calibration
plate, the zero calibration hole, and a gloss calibration plate.
A data CD with calibration plate calibration data and software for
writing calibration values is also included.
Hand Strap CM-A220
Used to keep the instrument steady during measurement.
USB Cable (2 m) IF-A17
Used to connect the instrument to a personal computer (PC).
Power will not be supplied through the cable while the instrument
is connected to the PC.

12
1
Before Using the Instrument
Zero Calibration Box CM-A222
Used to perform zero calibration.
 Optional Accessories
Hard Case CM-A221
Used for carrying the instrument and accessories by hand.
Lithium-Ion Battery (spare) CM-A223*
This battery is a replacement for the standard lithium-ion battery.
Bluetooth Module CM-A219*
Used for establishing wireless communication and transferring
data between the instrument and a PC or a printer.
Cable Set for Bluetooth Module CM-A225
Used to connect the instrument to the Bluetooth module.
The cable set is attached to the wrist strap for use.
Color Data Software SpectraMagic DX
Used to control the instrument and manage data from a PC.
Memo This software can be provided on a USB memory stick or
downloaded from the web.

13
Battery Charger CM-A227*
Used as the dedicated charger to charge the lithium-ion battery.
The battery charger must be connected to the AC adapter (AC-
A311) supplied with the instrument for use.
Color Plates (White, black, and 12 other colors)
Used for simple diagnosis of instrument measurement
performance (instrumental errors and repeatability).

14
1
Before Using the Instrument
System Diagram
Bluetooth Module Set
CM-A264**
Standard Accessories
Optional
Accessories
AC Adapter
AC-A311*
USB Cable
(2 m)
IF-A17
Spectrophotometer
CM-M6
Hand Strap
CM-A220
Computer
(commercially available)
Bluetooth Adapter
(commercially available)
Bluetooth Printer
(commercially
available)
USB Cable
(commercially
available)
USB Converter Cable
(commercially
available)
Lithium-Ion Battery
CM-A223*
White Calibration Cap
CM-A226
Zero Calibration Box
CM-A222
Lithium-Ion Battery
(spare)
CM-A223*
Hard Case
CM-A221
Battery Charger
CM-A227*
Optional
Accessories
Color Data Software
SpectraMagic DX
Bluetooth Module
CM-A219*
Cable Set for
Bluetooth Module
CM-A225**
Color Plates
(14 colors)
* Not available in all areas.
**Model number varies by area.

15
Names and Functions of Parts
1
8
9
4
6
5
2
3
10
11
12
14
13
7

16
1
Before Using the Instrument
1 Power switch Used to turn ON/OFF power. Sliding the switch turns the power ON or OFF.
2 Hand strap attachment hole Used to attach the hand strap.
3 Measurement key Press to calibrate or measure. Measurement can also be performed by
pressing the measurement button (10).
4 Specimen measuring port This is the aperture for measuring samples.
5 Control panel The keys are used to switch screens and to select, set, or save settings. For
details, refer to page 28 “Control Keys”.
6 LCD screen Displays settings, measurement results, messages, etc.
7 USB connection terminal
(Micro-AB)
Used to connect the instrument to a printer via USB or to connect the
instrument to the Bluetooth module (CM-A219) via the cable set for
Bluetooth module (CM-A225).
Notes Only the Bluetooth module (optional) or the printer (optional) can be
connected to the MicroUSB connector on the instrument. No other
devices can be connected. Doing so may result in a malfunction. Use the
dedicated cables (optional) to connect each device.
8 USB connection terminal
(Type B)
Used to connect the instrument to a PC when using the supplied USB cable
(IF-A17).
Memo Power will not be supplied through the cable while the instrument is
connected to the PC.
9 AC adapter socket Used to connect the AC adapter connector plug when using the supplied
AC adapter (AC-A311).
10 Measurement button Press to calibrate or measure. Measurement can be performed by pressing
either the measurement key or the measurement button depending on the
orientation of the instrument to the sample when measuring.
Memo Users are able to disable the measurement button. For how to configure
this setting, refer to page 95 “Measurement Button”.
11 Battery compartment cover Open this cover to replace the battery.
12 Screw holes for securing (M6) Used for mounting and securing the instrument to jigs or other
components.
Memo When securing the instrument to a jig or other component, securing the
instrument in at least two locations is recommended. Securing the
instrument in only one location may resulting in the instrument falling
and becoming damaged.
13 Ready lamp (blue) Displays the measurement ready status when charging of the emission
circuit is complete.
14 Charger lamp (orange) Lights during charging.

17
Handling the Instrument
 Attaching the Hand Strap
Notes Do not put a load on the hand strap such as by swinging the instrument or moving the instrument by the strap.
Doing so may cause the strap to become detached, allowing the instrument to fall and become damaged.
1 Pass one end of the hand strap through the hand
strap attachment hole.
2 Pass the strap through the buckle and secure it.
3 To prevent rotation, insert the protrusion (a) into
the hole (a’) and attach the hand strap bracket to
the screw hole for mounting.
4 Adjust the length of the hand strap.
5 Cover the strap.
a
a´
