Kontron Embedded Computers V Panel Express User manual

V Panel Express
V Box Express II
User’s Manual
Version 1.0
Kontron Embedded Computers GmbH
0-0096-3678
StockCheck.com

Table of Contents
V Panel Express – User’s Manual 1
Table of Contents
Table of Contents.................................................................................................1
Introduction ..........................................................................................................3
Symbols used in this Manual..................................................................................4
Important Instructions.........................................................................................5
Warranty Note........................................................................................................5
Exclusion of Accident Liability Obligation ...............................................................5
Liability Limitation / Exemption from the Warranty Obligation.................................5
Safety Instructions...............................................................................................6
Electrostatic Discharge (ESD)................................................................................8
Grounding Methods...........................................................................................8
Instructions for the Lithium Battery.........................................................................9
FCC Statement.....................................................................................................10
Electromagnetic Compatibility ..............................................................................10
Scope of Delivery ..............................................................................................11
Optional Parts.......................................................................................................11
Type Label and Product Identification..................................................................11
Product Description...........................................................................................12
Front Side View....................................................................................................14
Panel mount Front Plate..................................................................................14
Display.............................................................................................................15
Touch Screen..................................................................................................15
USB (2.0) Connector .......................................................................................17
Rear Side .............................................................................................................18
Bottom Side (with Interfaces)................................................................................19
Interfaces on the Bottom Side (Rear side of the System)................................20
Power Button...................................................................................................21
LED Control Indicators.....................................................................................21
Power LED Error codes This function display four important fail conditions: ..22
CompactFlash™ Slot.......................................................................................23
Removable HDD Drive Cage...........................................................................23
Left Side (Expansion Card Access Side)..............................................................25
Right Side.............................................................................................................26
Top Side...............................................................................................................27
Integrated ETXexpress® Module..........................................................................28
Riser Card........................................................................................................28
StockCheck.com

Table of Contents
2 V Panel Express – User’ Manual
Starting Up ..........................................................................................................29
DC-Connection.................................................................................................29
Accessing Internal Components......................................................................30
Installing/Removing the Expansion Cards.............................................................31
Maintenance and Prevention............................................................................33
Replacing the Lithium Battery...............................................................................33
Installation Instructions.....................................................................................35
Operating System and Hardware Component Drivers..........................................36
Main Specifications............................................................................................37
Power Specifications ............................................................................................38
Electrical Specifications........................................................................................38
Mechanical Specifications ....................................................................................38
Environmental Specifications................................................................................39
CE Directives and Standards................................................................................40
Technical Appendix - Interfaces.......................................................................41
Serial Port (COM1, COM2)...................................................................................41
USB Port...............................................................................................................42
DVI-I Connector (Single Link)................................................................................43
Technical Support..............................................................................................44
Returning Defective Material ................................................................................45
StockCheck.com

Introduction
V Panel Express – User’s Manual 3
Introduction
Kontron Embedded Computers would like to point out that the information
contained in this manual may be subject to technical alteration, particularly as a
result of the constant upgrading of Kontron Embedded Computers products. The
attached documentation does not entail any guarantee on the part of Kontron
Embedded Computers with respect to the technical processes described in the
manual or any product characteristics set out. Kontron Embedded Computers
does not accept any liability for any printing errors or other inaccuracies in the
manual unless it can be proven that Kontron Embedded Computers is aware of
such errors or inaccuracies or that Kontron Embedded Computers is unaware of
these as a result of gross negligence and Kontron Embedded Computers has
failed to eliminate these errors or inaccuracies for this reason. Kontron Embedded
Computers expressly informs the user that this manual only contains a general
description of technical processes and instructions which may not be applicable in
every individual case. In cases of doubt, please contact Kontron Embedded
Computers.
This manual is protected by copyright. All rights are reserved by Kontron
Embedded Computers. Copies of all or part of this manual or translations into a
another language may only be made with the prior written consent of Kontron
Embedded Computers. Kontron Embedded Computers points out that the
information contained in this manual is constantly being updated in line with the
technical alterations and improvements made by Kontron Embedded Computers
to the products and thus this manual only reflects the technical status of the
products by Kontron Embedded Computers at the time of printing.
© 2007 by Kontron Embedded Computers
Printing and duplication, even of sections, is only permissible with the express
approval of
Kontron Embedded Computers GmbH
Oskar-von-Miller-Str. 1
85385 Eching
Germany
StockCheck.com

Introduction
4 V Panel Express – User’ Manual
Symbols used in this Manual
Symbol Meaning
This symbol indicates the danger of injury to the user or the risk of
damage to the product if the corresponding warning notices are
not observed.
This symbol indicates that the product or parts thereof may be
damaged if the corresponding warning notices are not observed.
This symbol indicates general information about the product and
the user manual.
This symbol indicates detail information about the specific product
configuration.
This symbol precedes helpful hints and tips for daily use.
StockCheck.com

Important Instructions
V Panel Express – User’s Manual 5
Important Instructions
This chapter contains instructions which must be observed when using the
V Panel Express.
The manufacturer’s instructions provide useful information on the
V Panel Express.
Warranty Note
Due to their limited service life, parts which by their nature are subject to a
particularly high degree of wear (wearing parts) are excluded from the warranty
beyond that provided by law. This applies to batteries and display, for example.
Exclusion of Accident Liability Obligation
Kontron Embedded Computers shall be exempted from the statutory accident
liability obligation if the user fails to observe the safety instructions.
Liability Limitation / Exemption from the
Warranty Obligation
In the event of damage to the device caused by failure to observe the hints in this
manual and on the device (especially the safety instructions), Kontron Embedded
Computers shall not be required to honor the warranty even during the warranty
period and shall be exempted from the statutory accident liability obligation.
StockCheck.com

Safety Instructions
6 V Panel Express – User’ Manual
Safety Instructions
Please read this section carefully and observe the instructions for your own safety
and correct use of the device.
The chapter also contains information on approval and interference suppression
of your device.
Observe the warnings and instructions on the device and in the manual.
The device has been built and tested by Kontron Embedded Computers in
accordance to EN 60950-1 and left the company in a perfectly safe condition.
In order to maintain this condition and ensure safe operation, the user must
observe the instructions and warnings contained in this manual.
 The device must be used in accordance with the instructions for use.
 The electrical installations in the room must correspond to the requirements of
the respective regulations.
 Take care that there are no cables, particularly power cables, in areas where
persons can trip over them.
 Do not use a power cable in sockets shared by a number of other power
consumers. Do not use an extension cable.
 Only use the power cord supplied.
 Do not place the device in direct sunlight, near heat sources or in a damp
place. Make sure the device has adequate ventilation.
 Only devices and components which fulfill the requirements of an SELV circuit
(safety extra low voltage) in accordance with EN60950 may be connected to
the interfaces of the system.
 All plugs on the connection cables must be screwed or locked to the housing.
 The device is designed to be used in vertical position with the interfaces
downwards.
StockCheck.com

Safety Instructions
V Panel Express – User’s Manual 7
 Repairs may only be carried out by a person authorized by Kontron Embedded
Computers.
 Maintenance or repair on the open device may only be done out by qualified
personnel authorized by Kontron Embedded Computers which is aware of with
the associated dangers.
 The device may only be opened for the installation and removal of PCI cards
in accordance with the description in this manual. These procedures have to
be carried-out only by qualified specialist personnel.
 If extensions are made to the device the legal stipulations and the device
specifications must be observed.
 The device must be switched off before installation and removal of any PCI
and CompactFlash™ cards.
 Only original accessories approved by Kontron Embedded Computers may be
used.
 It must be assumed that safe operation is no longer possible,
•if the device has visible damage or
•if the device no longer functions.
In these cases the device must be shut down and secured against
unintentional operation.
For DC Powered Systems
 The DC-input must fulfill SELV requirements of EN60950-1 standard.
 DC/DC-supplies do not fulfil the requirements for centralized DC power
systems as required for use in the USA.
StockCheck.com

Safety Instructions
8 V Panel Express – User’ Manual
Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices
or micro-circuitry. Therefore proper packaging and grounding techniques are
necessary precautions to prevent damage. Always take the following precautions:
1. Transport boards in ESD-safe containers such as boxes or bags.
2. Keep electrostatic sensitive parts in their containers until they arrive at the
ESD-safe workplace.
3. Always be properly grounded when touching a sensitive board, component, or
assembly.
4. Store electrostatic-sensitive boards in protective packaging or on antistatic
mats.
Grounding Methods
The following measures help to avoid electrostatic damages to the device:
1. Cover workstations with approved antistatic material. Always wear a wrist
strap connected to workplace as well as properly grounded tools and
equipment.
2. Use antistatic mats, heel straps, or air ionizers for more protection.
3. Always handle electrostatic sensitive components by their edge or by their
casing.
4. Avoid contact with pins, leads, or circuitry.
5. Turn off power and input signals before inserting and removing connectors or
connecting test equipment.
6. Keep work area free of non-conductive materials such as ordinary plastic
assembly aids and Styrofoam.
7. Use field service tools such as cutters, screwdrivers, and vacuum cleaners
which are conductive.
8. Always place drives and boards PCB-assembly-side down on the foam.
StockCheck.com

Safety Instructions
V Panel Express – User’s Manual 9
Instructions for the Lithium Battery
The installed board is equipped with a lithium battery. To replace this battery refer
to the instructions described in the chapter
“Replacing the Lithium Battery ”
Warning
There is a danger of explosion if the wrong type of battery is used
for replacement. Replace only with the same or equivalent type of
battery as recommended by the manufacturer. Dispose of used
batteries according to the manufacturers instructions.
StockCheck.com

Safety Instructions
10 V Panel Express – User’ Manual
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Electromagnetic Compatibility
This product has been designed for industrial, commercial and office use,
including small business use. The most recent version of the EMC guidelines
(2004/108/EC) and/or the German EMC laws apply. If the user modifies and/or
adds to the equipment (e.g. installation of add-on cards), the prerequisites for the
CE conformity declaration (safety requirements) may no longer apply.
StockCheck.com

Scope of Delivery
V Panel Express – User’s Manual 11
Scope of Delivery
 V Panel Express
 V Panel Express - User’s Manual
Optional Parts
 CF Card
 DC Power Cable
Type Label and Product Identification
The type label with the corresponding Kontron product part number is at the rear
right hand side of the system.
Type Label for Systems Kontron
Product Identification
V Panel Express
121/150/170 2-AOHA-xxxx for V panel Express with ETXexpress-PM Module
V Panel Express
121/150/170 2-AOHA-xxxx for V panel Express with ETXexpress-CD Module
On the type label of your system, the "XXXX" group is replaced by Arabic
numerals combination according to the ordered system configuration.
StockCheck.com

Product Description
12 V Panel Express – User’ Manual
Product Description
The V Panel Express is a Human-Machine-Interface (HMI) System designed for
high industrial application. The V Panel Express is a workstation system with
integrated touch screen display. The system is designed for:
 Installation in an instrument panel or other cabinets
 Installation by VESA 75/100 compliant mounting system
The hardware of the V Panel Express system can be flexibly configured
corresponding to customized requirements. The rugged design offers excellent
mechanical stability. The V Panel Express provides the demanding characteristics
required for a computer that is very suitable for using in harsh industrial
environment.
The system accommodates a baseboard with an ETXexpress® module.
Depending on the ordered system configuration, your V Panel Express can be
equipped with the ETXexpress®-PM or -CD ETXmodule.
Depending on the ordered system configuration, the built-in display can be as a
12.1”, 15“ or 17” TFT-LCD display. In front of the display there is installed a glass
protection pane with antireflection properties. In front of the display is available a
resistive touch screen. This protects the display surface from dirt and scratches
also.
The V Panel Express accommodates two rear side accessible drive bays:
 drive bay (removable) for 2.5" SATA (I or II) HDD) and
 Compact Flash™-drive for CF card, type I.
Fig 1: V Panel Express (front side) Fig 1a: V Panel Express (interface side)
StockCheck.com

Product Description
V Panel Express – User’s Manual 13
The power button, the RESET button, the LED control indicators and user
interfaces such as DVI-I/VGA, USB (2.0) LANs (10/100Mbps or 1Gbps) and serial
ports (RS232) are accessible on the rear side of the system. At the front side is
available a
USB (2.0) port.
The V Panel Express is designed to be powered from a DC high voltage external
power sources.
The V Panel Express system ensures at the front side the IP65 (NEMA 250 Type
12 and 13) protection class.
The V Panel Express I is a fan less system. The cooling of the V Panel Express is
performed by the heat sink surface of the chassis (rear side).
When powering on the V Panel Express, make sure that the
air intake and exhaust openings are not obstructed.
StockCheck.com

Product Description
14 V Panel Express – User’ Manual
Front Side View
At the front side are located:
 Panel Mount front plate
 Display (12.1"/15"/17") with corresponding resistive touch screen
 USB (2.0) connector (covered)
Fig. 2:V Panel Express (shown with a 15" display)
1 Front plate (panel mount)
2 TFT display (12.1”/15”/17”)
3 USB (2.0) connector (covered)
Panel mount Front Plate
This version of front plate is suitable for the installation in an instrument panel or
other cabinets. Therefore at the rear side of the front plate are twelve threaded
M4 metric studs refer to the “Rear Side” chapter.
1
2
3
StockCheck.com

Product Description
V Panel Express – User’s Manual 15
Display
Depending on the ordered system configuration, the built-in TFT display has
12.1”, 15“ or 17”. For technical specifications of the built-in display refer to the
“Main Specification” chapter.
The display is mechanically protected by the resistive touch screen.
Touch Screen
The display unit is equipped with a resistive touch screen. The touch screen is
internally connected to the on-board USB interface of the installed
ETX baseboard.
The touch screen registers contacts of a finger or a pen and moves the mouse
pointer.
Do not use a hard or a pointed object to operate the touch screen,
since it can damage the touch screen foil surface.
Install touch controller software
Please download software form Kontron WEB server http://www.kontron.com/
>>Confirm license agreement
StockCheck.com

Product Description
16 V Panel Express – User’ Manual
>>Start touch calibration
After complete installation and calibration of touch you find a new icon in the
control panel to set additional features.
Calibrating the Touch Screen
Calibration serves two purposes:
 Sets the active area of the touch screen
 Aligns the active area of the touch screen to the screen’s image.
StockCheck.com

Product Description
V Panel Express – User’s Manual 17
Before you calibrate the touch screen, let the unit warm up for 30
minutes.
Calibration aligns the active touch-sensitive area of the touch screen with the
image on the display. Calibration also determines the edges of the screen’s image
and locates the center of the touch screen. If the touch screen is not calibrated
properly, the active area of the touch screen may not be aligned with the screen’s
image or may be unnecessarily small in size.
Use the calibration tool “Align” to recalibrate the touch screen as necessary:
The installed touch screen is calibrated at the factory. Run the calibration routine
when an alignment problem exists between the mouse pointer and the contact
location on the screen.
Carefully touch the location of the markers with your stylus to recalibrate the touch
screen.
USB (2.0) Connector
This connector allows connection of USB-compatible devices.
The front side USB port with mounted plastic cover is also
protected acc. IP65.
StockCheck.com

Product Description
18 V Panel Express – User’ Manual
Rear Side
At the rear side of the V Panel Express are rubber seal, the 12 mounting threaded
M4 metric studs and the PC unit with the heat sink. Also are available two screws
for securing the PC unit to the display unit (not visible in the picture below).
Fig. 3: V Panel Express (rear side)
1 Rear side of the front plate (panel mount)
2 Rubber seal (gasket)
3 Threaded M4 metric studs
4 Heat sink with VESA® 75/100 mounting holes
5 VESA® 75/100 compliant mounting holes
3
3 3
2
1
3
4
5
StockCheck.com

Product Description
V Panel Express – User’s Manual 19
Bottom Side (with Interfaces)
15
12 3 4 5 6
7
8
10
1112
1314
16
17
9
Fig. 4: V Panel Express (interface side)
1 4xUSB (2.0) connector
2 LAN2 interface connector
3 LAN1 interface connector
4 Power button (ATX)
5 LED control indicators
6 Free expansion slots for PCI cards
32bit@33MHz(half size)
7 COM2 (RS232) port connector
8 DC power plug (shown with DC
terminal for the power cord)
9 Reset switch
10 HDD drive cage with knurled
screws
11 COM1 (RS232) port connector
12 CF slot (not equipped)
13 Express Card slot
14 CF slot (shown with installed CF
card (type I)
15 DVI-I/VGA connector
16 Grounding Piont
17 COM3 and COM4 optional
