Kontron MBATX-945G-VGA User manual

MBATX-945G-VGA
User’s Guide
PN: 931-00xx-xx
January 2007
Kontron America

page 2 MBATX-945G-VGA User’s Guide
Customer Service
Mailing Address: Kontron - United States
14118 Stowe Drive
Poway, CA 92064 USA
Tel: [phone]
Fax: [phone]
Technical Support: U.S. and Canadian Customers - 24 hours a day
Tel: [phone], option 1
Fax: [phone]
International Customers - 9am to 4pm local time
Tel: [phone]
Fax: [phone]
Visit our site at: www.kontron.com
© 2006 Kontron, an International Corporation. All rights reserved.
The information in this user’s guide is provided for reference only. Kontron does not
assume any liability arising out of the application or use of the information or products
described herein. This user’s guide may contain or reference information and products
protected by copyrights or patents and does not convey any license under the patent
rights of Kontron, nor the rights of others.
Kontron is a registered trademark of Kontron. All trademarks, registered trademarks,
and trade names used in this user’s guide are the property of their respective owners.
All rights reserved. Printed in the United States of America and Canada. This user’s
guide contains information proprietary to Kontron. Customers may reprint and use this
user’s guide in other publications. Customers may alter this user’s guide and publish it
only after they remove the Kontron name, cover, and logo.
Kontron reserves the right to make changes without notice in product or component
design as warranted by evolution in user needs or progress in engineering or
manufacturing technology. Changes which affect the operation of the unit will be
documented in the next revision of this user’s guide.

MBATX-945G-VGA User’s Guide page 3
Table Of Contents
Safety Instructions........................................................................................................ 7
Before You Begin......................................................................................................................7
When Working Inside a Computer ............................................................................................8
Preventing Electrostatic Discharge ...........................................................................................9
Preface.........................................................................................................................11
How to Use This Guide ...........................................................................................................11
Customer Comments ..............................................................................................................12
Unpacking ...............................................................................................................................12
Advisory Conventions..............................................................................................................13
Regulatory Compliance Statements........................................................................................14
FCC Compliance Statement for Class B Devices..............................................................................14
Guarantee and Warranty Policy..............................................................................................15
Guarantee ..........................................................................................................................................15
Limited Warranty................................................................................................................................15
Return Procedure...............................................................................................................................16
Limitation of Liability...........................................................................................................................16
Chapter 1: Introduction .............................................................................................. 17
What’s Included.......................................................................................................................17
Before Using the System Board..............................................................................................17
Specifications..........................................................................................................................18
Special Features of the System Board....................................................................................22
Watchdog Timer.................................................................................................................................22
PCI Express .......................................................................................................................................22
Intel Graphics Media Accelerator 950................................................................................................22
Hyper-Threading Technology Functionality Requirements................................................................22
Components:......................................................................................................................................22
CPU Overheat Protection...................................................................................................................23
DDR2..................................................................................................................................................23
S/PDIF................................................................................................................................................23
Serial ATA Interface...........................................................................................................................23
IrDA Interface.....................................................................................................................................23
USB Ports...........................................................................................................................................23
Dual Function Power Button ..............................................................................................................24
Wake-On-Ring....................................................................................................................................24
Wake-On-LAN....................................................................................................................................24
Wake-On-PS/2 Keyboard/Mouse.......................................................................................................24
Wake-On-USB Keyboard/Mouse.......................................................................................................25
RTC Timer to Power-on the System..................................................................................................25
ACPI STR...........................................................................................................................................25
AC Power Failure Recovery...............................................................................................................25

page 4 MBATX-945G-VGA User’s Guide
Chapter 2: Installation.................................................................................................27
System Board Layout .............................................................................................................27
System Memory......................................................................................................................28
Single Channel (SC)...........................................................................................................................28
Virtual Single Channel (VSC).............................................................................................................28
Dual Channel (DC) .............................................................................................................................29
Dynamic Mode Addressing.................................................................................................................29
BIOS Setting.......................................................................................................................................30
Installing the DIMM.............................................................................................................................31
CPU........................................................................................................................................32
Overview.............................................................................................................................................32
Installing the CPU...............................................................................................................................32
Installing the Fan and Heat Sink.........................................................................................................36
Jumper Settings......................................................................................................................38
Clear CMOS Data...............................................................................................................................38
PS/2 Power Select..............................................................................................................................39
USB Power Select..............................................................................................................................40
Power-on Select .................................................................................................................................41
Speaker On/Off Select........................................................................................................................42
Rear Panel I/O Ports...........................................................................................................................42
PS/2 Mouse and PS/2 Keyboard Ports ..............................................................................................43
Wake-On-PS/2 Keyboard/Mouse.......................................................................................................43
Serial Port...........................................................................................................................................44
Parallel Port........................................................................................................................................45
VGA Port.............................................................................................................................................46
USB Ports...........................................................................................................................................47
Wake-On-USB Keyboard/Mouse........................................................................................................48
RJ45 LAN Port....................................................................................................................................49
Audio (Rear Audio and Front Audio) ..................................................................................................50
I/O Connectors....................................................................................................................................51
S/PDIF-out..........................................................................................................................................51
Floppy Disk Drive Connector..............................................................................................................52
Serial ATA Connectors.......................................................................................................................53
IDE Disk Drive Connector...................................................................................................................54
IrDA Connector...................................................................................................................................56
Cooling Fan Connectors.....................................................................................................................57
LEDs...................................................................................................................................................58
Chassis Open Connector ...................................................................................................................59
Power Connectors..............................................................................................................................60
Front Panel Connectors......................................................................................................................61
Digital I/O Connector ..........................................................................................................................62
PCI Express x16 and x1 Slots............................................................................................................63
Chapter 3: BIOS Setup................................................................................................65
Award BIOS Setup Utility........................................................................................................65
Standard CMOS Features......................................................................................................66
Date ....................................................................................................................................................66
Time....................................................................................................................................................66
IDE Channel 0 Master/Slave and IDE Channel 1 Master/Slave ........................................................67
Advanced BIOS Features.......................................................................................................70

MBATX-945G-VGA User’s Guide page 5
CPU Feature ......................................................................................................................................71
Advanced Chipset Features....................................................................................................76
DRAM Timing Selectable...................................................................................................................76
Integrated Peripherals.............................................................................................................79
OnChip IDE Device............................................................................................................................79
Onboard Device .................................................................................................................................82
Super IO Device.................................................................................................................................84
Power Management Setup......................................................................................................87
ACPI Function....................................................................................................................................87
ACPI Suspend Type...........................................................................................................................87
Run VGABIOS if S3 Resume.............................................................................................................87
Power Management...........................................................................................................................88
Video Off Method ...............................................................................................................................88
Video Off In Suspend.........................................................................................................................88
Suspend Type....................................................................................................................................88
MODEM Use IRQ...............................................................................................................................88
Suspend Mode...................................................................................................................................88
HDD Power Down..............................................................................................................................89
Soft-Off by PWR-BTTN......................................................................................................................89
PWR Lost Resume State ...................................................................................................................89
Wake-Up By PCI Card.......................................................................................................................89
Power On By Ring..............................................................................................................................90
USB KB Wake-Up From S3...............................................................................................................90
Resume By Alarm ..............................................................................................................................90
Date (of Month) Alarm........................................................................................................................90
Time (hh:mm:ss) Alarm......................................................................................................................90
PnP/PCI Configurations ..........................................................................................................91
Init Display First..................................................................................................................................91
Reset Configuration Data...................................................................................................................91
Resources Controlled By ...................................................................................................................92
IRQ Resources...................................................................................................................................92
PCI/VGA Palette Snoop.....................................................................................................................92
INT Pin 1 Assignment to INT Pin 8 Assignment ................................................................................92
Maximum Payload Size......................................................................................................................93
PC Health Status.....................................................................................................................94
Current System Temp to +5 (V).........................................................................................................94
Frequency/Voltage Control......................................................................................................95
CPU Clock Ratio ................................................................................................................................95
Spread Spectrum ...............................................................................................................................95
Load Fail-Safe Defaults...........................................................................................................96
Load Optimized Defaults.........................................................................................................97
Set Supervisor Password........................................................................................................98
Set User Password..................................................................................................................99
Save & Exit Setup .................................................................................................................100
Exit Without Saving...............................................................................................................101
Updating the BIOS ................................................................................................................102
Chapter 4: Supported Software............................................................................... 103
Drivers, Utilities and Software Applications...........................................................................103
Intel Chipset Software Installation Utility...............................................................................104

page 6 MBATX-945G-VGA User’s Guide
Intel Graphics Drivers...........................................................................................................105
Audio Drivers........................................................................................................................106
LAN Driver............................................................................................................................107
Hardware Monitor for Windows ............................................................................................108
Microsoft DirectX 9.0C Driver...............................................................................................109
Intel USB 2.0 Drivers............................................................................................................110
Installation Notes..............................................................................................................................110
Appendix A: Enabling Hyper-Therading Technology.............................................111
Appendix B: System Error Messages......................................................................115
Error Messages ....................................................................................................................115
CMOS BATTERY HAS FAILED.......................................................................................................115
CMOS CHECKSUM ERROR...........................................................................................................115
DISPLAY SWITCH IS SET INCORRECTLY....................................................................................115
FLOPPY DISK(S) fail (80) ................................................................................................................115
FLOPPY DISK(S) fail (40) ................................................................................................................116
Hard Disk(s) fail (80).........................................................................................................................116
Hard Disk(s) fail (40).........................................................................................................................116
Hard Disk(s) fail (20).........................................................................................................................116
Hard Disk(s) fail (10).........................................................................................................................116
Hard Disk(s) fail (08).........................................................................................................................116
Keyboard is locked out - Unlock the key ..........................................................................................116
Keyboard error or no keyboard present............................................................................................116
Manufacturing POST loop................................................................................................................116
BIOS ROM checksum error - System halted....................................................................................116
Memory test fail ................................................................................................................................116
Appendix C: Troubleshooting..................................................................................117
Troubleshooting Checklist ....................................................................................................117
Monitor/Display.................................................................................................................................117
Power Supply....................................................................................................................................118
Floppy Drive......................................................................................................................................118
Hard Drive.........................................................................................................................................119
Parallel Port......................................................................................................................................119
Serial Port.........................................................................................................................................119
Keyboard ..........................................................................................................................................120
System Board...................................................................................................................................120
Appendix D: Watchdog Sample Code .....................................................................121
Appendix E: Digital I/O Input Sample Code.............................................................123
Appendix F - Digital I/O Output Sample Code.........................................................125

MBATX-945G-VGA User’s Guide page 7
Safety Instructions
Before You Begin
Before handling your MBATX-945G-VGA board, read the instructions and safety
guidelines on the following pages to prevent damage to the product and to ensure your
own personal safety. Refer to the “Advisories” section in the Preface for advisory
conventions used in this user’s guide, including the distinction between Warnings,
Cautions, Important Notes, and Notes.
Always use caution when handling or operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the interior
of a computer. The power supplies produce high voltages and energy hazards,
which can cause bodily harm.
If you have any problems or questions about the unit, please contact Kontron
Post-Sales Technical Support.
WARNING
High voltages are present inside a computer chassis when the
unit’s power cord is plugged into an electrical outlet. Turn off
system power, turn off the power supply, and then disconnect
the power cord from its source before removing the chassis
cover. Turning off the system power switch does not remove
power to components.

page 8 MBATX-945G-VGA User’s Guide
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1) Turn off the computer and any peripherals.
2) Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.
3) Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4) Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after turning
off the computer before removing a component, removing a system board, or
disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop, not
on the cable itself. Some cables have a connector with locking tabs. If you are
disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable. As you pull connectors apart, keep them evenly aligned
to avoid bending any connector pins. Also, before connecting a cable, make sure
both connectors are correctly oriented and aligned
CAUTION
Do not attempt to service the system yourself. Follow installation
and troubleshooting instructions closely.

MBATX-945G-VGA User’s Guide page 9
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and
follow proper ESD procedure to reduce the risk of damage to components. Kontron
strongly encourages you to follow proper ESD procedure, which can include wrist straps
and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic discharge
(ESD):
When unpacking a static-sensitive component from its shipping carton, do not
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.
When transporting a sensitive component, first place it in an antistatic container
or packaging.
Handle all sensitive components at an ESD workstation. If possible, use antistatic
floor pads and workbench pads.
Handle components and boards with care. Don’t touch the components or
contacts on a board. Hold a board by its edges or by its metal mounting bracket.
Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.

page 10 MBATX-945G-VGA User’s Guide
This page intentionally left blank.

MBATX-945G-VGA User’s Guide page 11
Preface
How to Use This Guide
This guide is designed to be used as step-by-step instructions for installation, and as a
reference for operation, troubleshooting, and upgrades.
Note: Additional technical information, BIOS updates, and drivers are
available on our web site, www.kontron.com, under Technical Support.
The following is a summary of the chapter contents:
Chapter 1, Introduction, Presents contents of package and a detailed overview
of the product specifications.
Chapter 2, Specifications, Provides functional, mechanical, electrical, and
environmental specifications.
Chapter 3, Hardware Configuration, Shows the definitions and locations of
jumpers and connectors for various system environments.
Chapter 4, System Installation, Explains how to install processors, main
memory, the SBC, Compact Flash Cards, as well as how to clear the CMOS and
how to set the Watch Dog Timer.
Chapter 5, BIOS, Explains the various available system configuration choices.
Appendix A, Troubleshooting, Provides you a few useful tips to quickly start
the SBC-815ET-VER operation. The chapter mainly focuses on system
integration matters, such as backplane setup, BIOS setting, and OS diagnostics.

page 12 MBATX-945G-VGA User’s Guide
Customer Comments
If you have any difficulties using this user’s guide, discover an error, or just want to
provide some feedback, please send us a message using the online form under
“Contact Us” on our web site (www.kontron.com) under “Technical Support.” Detail any
errors you find. We will correct the errors or problems as soon as possible and post the
revised user’s guide in our online Support Library. Thank you.
Note: You may also use the online form on our web site to submit comments or
concerns about our products, or request technical support.
Unpacking
When unpacking, follow these steps:
1) After opening the box, save it and the packing material for possible future
shipment.
2) Remove all items from the box. If any items listed on the purchase order are
missing, notify Kontron customer service immediately.
3) Inspect the product for damage. If there is damage, notify Kontron customer
service immediately. Refer to “Guarantee and Warranty Policy” for the return
procedure.

MBATX-945G-VGA User’s Guide page 13
Advisory Conventions
Four types of advisories are used throughout this user’s guide to provide helpful
information or to alert you to the potential for hardware damage or personal injury. They
are Notes, Cautions, and Warnings. The following is an example of each type of
advisory. Use caution when servicing any electrical component
Note: A note is used to make helpful information stand out.
Important: An important note indicates information that is important for you to
know.
CAUTION
A CAUTION indicates potential damage to hardware and tells you
how to avoid the problem.
WARNING
A WARNING indicates the potential for bodily harm and tells you
how to avoid the problem.
Disclaimer: We have tried to identify all situations that may pose a warning or caution
condition in this user’s guide. However, Kontron does not claim to have covered all
situations that might require the use of a Caution or Warning.

page 14 MBATX-945G-VGA User’s Guide
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class B devices and Safety
Standards.
FCC Compliance Statement for Class B Devices
The product(s) described in this user’s guide has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
the user’s guide, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly approved by Kontron
could void your authority to operate the equipment. This device complies with Part 15 of
the FCC Rules. Operation is subject to two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation
Note: The assembler of a personal computer system may be required to test
the system and/or make necessary modifications if a system is found to cause
harmful interference or to be noncompliant with the appropriate standards for its
intended use.

MBATX-945G-VGA User’s Guide page 15
Guarantee and Warranty Policy
Guarantee
A thirty day money-back guarantee is provided on all standard products sold. Special
order products are covered by our Limited Warranty, however they may not be returned
for refund or credit. EPROMs, RAM, Flash EPROMs or other forms of solid electronic
media are not returnable for credit - but for replacement only. An extended warranty is
available. Consult the factory.
Refunds
In order to receive a refund on a product for the purchase price, the product must not
have been damaged by the customer or by the common carrier chosen by the customer
to return the goods and the product must be returned complete (meaning all user’s
guides, software, cables, etc.) within 30 days of receipt and in an as-new and resalable
condition. The “Return Procedure” must be followed to assure a prompt refund.
Restocking Charges
Product returned after 30 days, and before 60 days, of the purchase will be subject to a
minimum 20% restocking charge and charges for any damaged or missing parts.
Products not returned within 60 days of purchase, or products which are not in an as-
new and resalable condition, are not eligible for a credit return and will be returned to
the customer.
Limited Warranty
Effective April 1, 1998, all products carry a 2-year limited warranty. Within 2 years of
purchase, Kontron will repair or replace, at our option, any defective product. Kontron
will service the warranty for all standard catalog products for the first two years from the
date of shipment. Please note: The 2-year warranty may not apply to special promotion
items. Please consult the factory for warranty verification.
The limited warranty is void if the product has been subjected to alteration, neglect,
misuse, or abuse; if any repairs have been attempted by anyone other than Kontron or
its authorized agent; or if the failure is caused by accident, acts of God, or other causes
beyond the control of Kontron or the manufacturer. Neglect, misuse, and abuse shall
include any installation, operation, or maintenance of the product other than in
accordance with the user’s guide.
No agent, dealer, distributor, service company, or other party is authorized to change,
modify, or extend the terms of this Limited Warranty in any manner whatsoever. Kontron
reserves the right to make changes or improvements in any product without incurring
any obligation to similarly alter products previously purchased.

page 16 MBATX-945G-VGA User’s Guide
Return Procedure
For any Guarantee or Limited Warranty return, please contact Kontron Customer
Service at 800-480-0044 or 858-677-0877 and obtain a Return Material Authorization
(RMA) Number. All product(s) returned to Kontron for service or credit must be
accompanied by a Return Material Authorization (RMA) Number. Freight on all returned
items must be prepaid by the customer who is responsible for any loss or damage
caused by common carrier in transit. Returns for Warranty must include a Failure
Report for each unit, by serial number(s), as well as a copy of the original invoice
showing the date of purchase.
To reduce risk of damage, returns of product must be in a Kontron shipping container. If
the original container has been lost or damaged, new shipping containers may be
obtained from Kontron Customer Service at a nominal cost.
Kontron owns all parts removed from repaired products. Kontron uses new and
reconditioned parts made by various manufacturers in performing warranty repairs and
building replacement products. If Kontron repairs or replaces a product, its warranty
term is not extended.
Kontron will normally return your replacement or repaired items via ground. Overnight
delivery or delivery via other carriers is available at an additional charge.
Shipments not in compliance with this Guarantee and Limited Warranty Return Policy
will not be accepted by Kontron.
Limitation of Liability
In no event shall Kontron be liable for any defect in hardware, software, loss, or
inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential
damages in connection with or arising out of the performance or use of any product
furnished hereunder. Kontron’s liability shall in no event exceed the purchase price of
the product purchased hereunder. The foregoing limitation of liability shall be equally
applicable to any service provided by Kontron or its authorized agent.
Some sales items and customized systems are not subject to the guarantee and limited
warranty. However in these instances, any deviations will be disclosed prior to sales
and noted in the original invoice. Kontron reserves the right to refuse returns or
credits on software or special order items.

MBATX-945G-VGA User’s Guide page 17
Chapter 1: Introduction
What’s Included
The system board package contains the following items. If any of these items are
missing or damaged, please contact Kontron for assistance.
One system board
One IDE cable
One FDD cable
One bracket mounted with 2 USB ports
One Serial ATA data cable
One Serial ATA power cable
One I/O shield
One “Motherboard Utility” CD
One user’s manual
Before Using the System Board
Before using the system board, prepare basic system components. If you are installing
the system board in a new system, you will need at least the following internal
components.
A CPU
Memory module
Storage devices such as hard disk drive, CD-ROM, etc.
You will also need external system peripherals you intend to use which will normally
include at least a keyboard, a mouse and a video display monitor.

page 18 MBATX-945G-VGA User’s Guide
Specifications
Processor
•Intel® Pentium® 4 Prescott processor
- Hyper-Threading Technology
- 533MT/s, 800MT/s (200MHz) and 1066MT/s (266MHz) system bus interface
•Socket LGA 775 (LAN Grid Array)
Chipset
•Intel chipset
- North bridge: Intel® 945G Express chipset
- South bridge: Intel® ICH7
System Memory
•Four 240-pin DDR2 DIMM sockets
•Supports DDR2 533 and DDR2 667 DIMMs
•Supports dual channel (128-bit wide) memory interface
•Supports up to 4GB system memory
•Supports non-ECC x8 and x16 DIMMs
•Supports up to 512Mb DRAM densities
•Supports unbuffered DIMMs
BIOS
•Award BIOS
•4Mbit flash memory
Energy Efficient Design
•Supports ACPI specification and OS Directed Power Management
•Supports ACPI STR (Suspend to RAM) function
•Wake-On-Events include:
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-Ring (external modem)
- Wake-On-LAN
- RTC timer to power-on the system

MBATX-945G-VGA User’s Guide page 19
•System power management supported
•CPU stopped clock control
•Microsoft®/Intel® APM 1.2 compliant
•Soft Power supported - ACPI v2.0 specification
•AC power failure recovery
Hardware Monitor
•Monitors CPU/system temperature and overheat alarm
•Monitors Vcore/VCC3/VBAT/3VSB/12V/1.5V/1.8V/5V voltages
•Monitors the speed of the CPU/2nd/system fan
•Read back capability that displays temperature, voltage and fan speed
•Watchdog timer function
Onboard VGA Features
•Built-in Intel Graphics Media Accelerator 950
Onboard Audio Features
•Realtek ALC202A
•18-bit stereo full-duplex codec with independent variable sampling rate
•High quality differential CD input
•True stereo line level outputs
•S/PDIF-out interface
•2-channel audio output
Onboard LAN Features
•One Marvell 88E8053 PCI Express Gigabit Ethernet controller
•Integrated power management functions
•Full duplex support at both 10 Mbps, 100 Mbps and 1Gbps
•Supports IEEE 802.3u auto-negotiation
•Supports wire for management

page 20 MBATX-945G-VGA User’s Guide
Serial ATA Interface
•Supports four SATA (Serial ATA) interfaces which are compliant with SATA 1.0
specification
•SATA speed up to 3Gb/s
IDE Interface
•Supports up to UltraDMA 100Mbps hard drives
•Supports PIO IDE transfers up to 16MB/sec
Rear Panel I/O Ports
•1 mini-DIN-6 PS/2 mouse port
•1 mini-DIN-6 PS/2 keyboard port
•1 DB-25 parallel port
•1 DB-9 serial port
•1 DB-15 VGA port
•1 RJ45 LAN port
•4 USB 2.0/1.1 ports
•Mic-in, line-in and line-out
I/O Connectors
•2 connectors for 4 additional external USB 2.0/1.1 ports
•1 connector for an external COM 2 port
•1 Digital I/O connector
•1 front audio connector for line-out and mic-in jacks
•1 CD-in internal audio connector
•1 S/PDIF-out connector
•1 connector for IrDA interface
•4 Serial ATA connectors
•1 40-pin IDE connector
•1 floppy connector
•1 24-pin ATX power connector
•1 4-pin 12V power connector
