ECX-BYT - Quick Installation Guide - Version 1.0 // www.kontron.com // 1
 ECX-BYT - QUICK INSTALLATION GUIDE
Thank you for purchasing the Kontron ECX-BYT embedded board. This document provides information to allow you to
quickly install this product.
Packing Checklist
1. Take the ECX-BYT out of the packing box and check if the unit is properly secure in the plastic bag.
2. Check the contents of the carton box: (*: optional)
ECX-BYT main board
1x DC IN Cable
PS/2 Cable*
COM Port Cable*
DIO Cable*
2-Port USB Cable*
1-Port USB Cable*
SATA Cable*
SATA Power Cable*
Audio Cable*
3G Mini SIM Card Holder Kit*

ECX-BYT - Quick Installation Guide - Version 1.0 // www.kontron.com // 2
Top Side Jumper and Internal Connector Locations
Jumper List
Item Designation Description
1 JP1 RTC Reset Selection
2 JP2 MPCIE Activity LED Indication
3 JP4 Backlight Enable Selection
4 JP5 Panel & Backlight Power Selection
5 JP6 USB Power Selection
6 JP7 AT / ATX Power Mode Selection
7 JP8 ME F/W Selection
Internal Connector List
Item Designation Description
8 BAT1 CR2032 Battery Power Input Wafer
9 COM1 RS-232/422/485 Port Wafer
10 COM2 RS-232/422/485 Port Wafer
11 COM3 RS-232 Port 3 Wafer
12 COM4 RS-232 Port 4 Wafer
13 COM5 RS-232 Port 5 Wafer
14 COM6 RS-232 Port 6 Wafer
15 CN1 DC12V Power Input Wafer
1
16
7
3
5
19
6
20
15
4
24
2 818 17
25
26
9
11
13
14
23
21
22
10
12
27
28 29
30
31
32

ECX-BYT - Quick Installation Guide - Version 1.0 // www.kontron.com // 3
Item Designation Description
16 CN2 PS/2 Keyboard / Mouse Wafer
17 CN3 HDD Power Output Wafer
18 CN4 P80 Header
19 CN9 Audio Input / Output Pin Header
20 CN10 SIM Interface Wafer for MPCIE2
21 CN11 Right Channel 3W Audio AMP Output Wafer
22 CN12 Left Channel 3W Audio AMP Output Wafer
23 CN13 Digital Input / Output Wafer
24 DIMM1 DDR3 Memory SO-DIMM Socket
25 FAN1 DC5V FAN Wafer
26 FP1 Front Panel 1 Pin Header
27 FP2 Front Panel 2 Pin Header
28 MPCIE1 Mini-PCI Express v1.2 Socket (Full Size)
29 MSATA1 Serial ATA Port-1 mSATA Socket (Full Size)
30 SATA1 Serial ATA Port 0 Connector
31 CN15 USB2.0 Port 2 Pin Header
32 CN16 USB2.0 Port USBDN_1,2 Pin Header
Jumper Settings
RTC Reset Selection (JP1)
Jumper Position Description
Pin 1-2
X Enable Clear CMOS RTC content
(board does not boot with the jumper in this position)
- Normal operation (default position)
“X” = Jumper set (short) and “-” = jumper not set (open)

ECX-BYT - Quick Installation Guide - Version 1.0 // www.kontron.com // 4
MPCIE1 Activity LED Indication (JP2)
Pin Signal
1 LED+
2 LED-
Backlight Enable Selection (JP4)
Jumper 1 Position Description
Pin 1-3 Pin 3-5
X - Backlight Enable Voltage = +3.3V
- X Backlight Enable Voltage = +5V
Jumper 2 Position Description
Pin 2-4 Pin 4-6
X - Active High
- X Active Low
“X” = Jumper set (short) and “-” = jumper not set (open)
Panel & Backlight Power Selection (JP5)
Jumper 1 Position Description
Pin 1-3 Pin 3-5
X - Backlight Power = +12V
- X Backlight Power = +5V
Jumper 2 Position Description
Pin 2-4 Pin 4-6
X - Panel Power = +3,3V
- X Panel Power = +5V
“X” = Jumper set (short) and “-” = jumper not set (open)
1
2
21
65
21
65

ECX-BYT - Quick Installation Guide - Version 1.0 // www.kontron.com // 5
USB Power Selection (JP6)
Jumper Position Description
Pin 1-2
X USB power is always supply.
- USB power will be cut off in S4 & S5 state.
“X” = Jumper set (short) and “-” = jumper not set (open)
AT / ATX Power Mode Selection (JP7)
Jumper 1 Position Description
Pin 1-2 Pin 2-3
X - ATX Mode
- X AT Mode
“X” = Jumper set (short) and “-” = jumper not set (open)
ME F/W Selection (JP8)
Jumper Position Description
Pin 1-2
X ME F/W Disabled
- Normal Operation
“X” = Jumper set (short) and “-” = jumper not set (open)
2
3
1

ECX-BYT - Quick Installation Guide - Version 1.0 // www.kontron.com // 6
Bottom Side Internal Connector Locations
Item Designation Description
1 CN14 Backlight Power Output Wafer
2 LVDS1 18/24-bit, Single Channel LVDS Panel Connector
Real I/O Panel Connector Locations
Item Designation Description
1 CN7 GbE LAN1 RJ-45 Connector
2 CN8 GbE LAN2 RJ-45 Connector
3 CN6 USB2.0 Port 2,3 Type-A Connector
4 USB1 USB3.0 Port 0 Connector
5 VGA1 VGA Connector
6 HDMI1 HDMI Connector
1
2
1 23 4 56
