Kontron CP6924-1 User manual

www.kontron.com
CP6924-1
Document Revision 1.2
Date: October, 2018
User Guide

www.kontron.com
CP6924-1 User Guide
2
Revision History
Imprint
Kontron Europe GmbH may be contacted via the following:
MAILING ADDRESS TELEPHONE AND E-MAIL
Kontron Europe GmbH +49 (0) 800-SALESKONTRON
Lise-Meitner-Straße 3-5 [email protected]
D - 86156 Augsburg Germany
For further information about other Kontron products, please visit our Internet web site: www.kontron.com.
Disclaimer
Copyright © 2016 Kontron AG. All rights reserved. All data is for information purposes only and not guaranteed for legal purposes. Infor-
mation has been carefully checked and is believed to be accurate; however, no responsibility is assumed for inaccuracies. Kontron and
the Kontron logo and all other trademarks or registered trademarks are the property of their respective owners and are recognized. Spec-
ifications are subject to change without notice.
Publication Title: CP6924-1
Rev. Brief Description of Changes Date of Issue
1.0 Initial Issue 2015-12-15
1.1 Minor changes in chapter 1, 4 and 5 2016-12-07
1.2 Changed Pushbutton Reset description in chapter 4.3.3,
Changed thermal requirements in Table 5.1 2018-10-30

www.kontron.com
CP6924-1 User Guide
3
Contents
Revision History ................................................................................................................. 2
Imprint ............................................................................................................................ 2
Disclaimer ........................................................................................................................ 2
Proprietary Note ................................................................................................................ 8
Trademarks ....................................................................................................................... 8
Environmental Protection Statement ..................................................................................... 8
Advisory Conventions .......................................................................................................... 8
Safety Instructions ............................................................................................................. 9
General Instructions on Usage ............................................................................................ 11
Two Year Warranty ............................................................................................................ 11
1 Introduction .............................................................................................................. 12
1.1 Product Overview .............................................................................................. 12
1.1.1 CP6924-1 Features ........................................................................................ 12
1.1.2 General compliances ..................................................................................... 13
1.2 Technical Specification ....................................................................................... 14
1.2.1 Power Requirements ...................................................................................... 14
1.2.2 Mechanics ................................................................................................... 14
1.2.3 Temperature ................................................................................................ 14
1.2.4 Humidity ..................................................................................................... 14
1.2.5 Altitude ...................................................................................................... 14
1.2.6 Vibration ..................................................................................................... 14
1.2.7 Shock ......................................................................................................... 15
1.2.8 Safety ......................................................................................................... 16
1.2.9 Electromagnetic Compatibility ......................................................................... 16
1.2.10 Reliability ................................................................................................... 16
1.2.11 WEEE .......................................................................................................... 16
1.2.12 RoHS Compliance .......................................................................................... 16
1.2.13 Lead-free .................................................................................................... 16
1.3 Software Support .............................................................................................. 17
2 Installation ............................................................................................................... 19
2.1 Safety Requirements .......................................................................................... 19
2.2 CP6924-1 Initial Installation Procedures ................................................................ 20
2.3 Standard Removal Procedures .............................................................................. 21
2.4 Software Installation ......................................................................................... 21
2.5 Quick Start ....................................................................................................... 22
2.5.1 Out-of-Band CLI Access .................................................................................. 22
2.5.2 In-Band CLI Access ........................................................................................ 23

www.kontron.com
CP6924-1 User Guide
4
3 Functional Description ................................................................................................. 25
3.1 Ethernet Infrastructure ...................................................................................... 26
3.2 Unit Computer and Memory ................................................................................. 27
3.3 IPMI ............................................................................................................... 27
3.3.1 Voltage Sensors ............................................................................................ 28
3.3.2 Current sensors ............................................................................................ 28
3.4 Board Interfaces ............................................................................................... 29
3.4.1 Front Panel Elements ..................................................................................... 29
3.4.2 Front Panel Switches ..................................................................................... 29
3.4.3 Front Panel LEDS .......................................................................................... 30
3.4.4 Front Panel Ports .......................................................................................... 31
3.4.5 Front Panel Management Port RJ45 .................................................................. 32
3.4.6 CompactPCI Connectors ................................................................................. 34
3.5 Write Protection Feature ..................................................................................... 38
4 Software Description ................................................................................................... 39
4.1 Supported RFCs ................................................................................................. 39
4.1.1 FASTPATH Management .................................................................................. 39
4.1.2 FASTPATH Switching ...................................................................................... 40
4.1.3 FASTPATH Routing ........................................................................................ 42
4.1.4 FASTPATH IPv6 Routing .................................................................................. 43
4.1.5 FASTPATH Quality of Service ............................................................................ 44
4.1.6 FASTPATH Multicast ....................................................................................... 45
4.2 Supported MIBs ................................................................................................ 45
4.2.1 Enterprise MIB ............................................................................................. 45
4.2.2 Base Package MIBs ........................................................................................ 45
4.2.3 Switching Package MIBs ................................................................................. 46
4.2.4 Routing Package MIBs ................................................................................... 47
4.2.5 QoS Package MIBs ......................................................................................... 47
4.2.6 Multicast package MIBs .................................................................................. 47
4.2.7 Security MIBs ............................................................................................... 48
4.2.8 Kontron Private MIBs ..................................................................................... 48
4.3 Bootloader ...................................................................................................... 49
4.3.1 Power On Self Test ......................................................................................... 50
4.3.2 Bootloader Shell Options ................................................................................ 51
4.3.3 Bootloader Pushbutton Reset .......................................................................... 53
4.3.4 Bootloader Rollback Control ........................................................................... 53
4.4 IPMI Firmware .................................................................................................. 54
4.4.1 Supported IPMI Commands ............................................................................. 54
4.4.2 Board Sensors .............................................................................................. 60
4.4.3 Board FRU Information .................................................................................. 70
4.5 Software Administration ..................................................................................... 71

www.kontron.com
CP6924-1 User Guide
5
4.5.1 Updating System Software .............................................................................. 72
4.5.2 Updating IPMI Firmware ................................................................................. 73
5 Thermal Considerations ............................................................................................... 74
6 Power Considerations .................................................................................................. 76
6.1 Baseboard ....................................................................................................... 76
6.2 Backplanes ...................................................................................................... 76

www.kontron.com
CP6924-1 User Guide
6
List of Tables
Table 1-1: CP6924-1 Software Specification....................................................................... 17
Table 3-1: Ethernet Port Mapping .................................................................................... 26
Table 3-2: Peripheral Manager AD Input and Voltage Assignment........................................... 28
Table 3-3: SFP Uplink Port Pinout .................................................................................... 31
Table 3-4: Front RJ45 Ethernet Connector ......................................................................... 32
Table 3-5: Front RS232.................................................................................................. 33
Table 3-7: Connector J1 Pinout ....................................................................................... 34
Table 3-8: Connector J2 Pinout ....................................................................................... 35
Table 3-9: Connector J3 Pinout ....................................................................................... 36
Table 3-10: Connector J4 Pinout ....................................................................................... 37
Table 3-11: Connector J5 Pinout ....................................................................................... 38
Table 4-1: POST tests .................................................................................................... 50
Table 4-2: POST routines and error codes .......................................................................... 50
Table 4-3: Bootloader Environment Variables..................................................................... 51
Table 4-4: Standard Commands....................................................................................... 54
Table 4-5: HPM.1 Commands .......................................................................................... 56
Table 4-6: Kontron OEM Commands.................................................................................. 56
Table 4-7: Sensor List.................................................................................................... 61
Table 4-8: IPMB Link (Type C3h) Reading.......................................................................... 63
Table 4-9: IPMB Link (Type C3h) Event Message ................................................................. 64
Table 4-10: MMC Reboot (Type 24h) Reading ....................................................................... 65
Table 4-11: MMC Reboot (Type 24h) Event Message............................................................... 65
Table 4-12: MMC FwUp (Type C7h) Reading.......................................................................... 66
Table 4-13: MMC FwUp (Type C7h) Event Message ................................................................. 66
Table 4-14: POST Fail (Type 0Fh) Reading............................................................................ 67
Table 4-15: POST Fail (Type 0Fh) Event Message ................................................................... 67
Table 4-16: Boot Fail (Sensor Type 1Eh) Reading .................................................................. 68
Table 4-17: Boot Fail (Sensor Type 1Eh) Event Message ......................................................... 68
Table 4-18: Temperature Sensor Thresholds [°C] .................................................................. 69
Table 4-19: Voltage Sensor Thresholds [V] .......................................................................... 69
Table 4-20: Current Sensor Thresholds [I] ........................................................................... 69
Table 4-21: On-board NOR FLASH Partition Scheme (128MB) .................................................. 71
Table 5-1: Thermal Requirements .................................................................................... 75
Table 6-1: Maximum Input Power Voltage Limits................................................................. 76

www.kontron.com
CP6924-1 User Guide
7
List of Figures
Figure 3-1: CP6924-1 Functional Block Diagram 25
Figure 3-2: Front Panel of the CP6924-1-RA-OC 29
Figure 3-3: Front Panel of the CP6924-1-SA-OC-V 29
Figure 3-4: CP6924-1 Front Panel LEDS 30
Figure 5-1: Position of Temperature Sensors, Top Side View 74

www.kontron.com
CP6924-1 User Guide
8
Proprietary Note
This document contains information proprietary to Kontron. It may not be copied or transmitted by any means, disclosed to
others, or stored in any retrieval system or media without the prior written consent of Kontron AG or one of its authorized
agents.
The information contained in this document is, to the best of our knowledge, entirely correct. However, Kontron AG cannot
accept liability for any inaccuracies or the consequences thereof, or for any liability arising from the use or application of
any circuit, product, or example shown in this document.
Kontron AG reserves the right to change, modify, or improve this document or the product described herein, as seen fit by
Kontron AG without further notice.
Trademarks
Kontron AG and the Kontron logo are trade marks owned by Kontron AG, Germany. In addition, this document may include
names, company logos and trademarks, which are registered trademarks and, therefore, proprietary to their respective
owners.
Environmental Protection Statement
This product has been manufactured to satisfy environmental protection requirements where possible. Many of the compo-
nents used (structural parts, printed circuit boards, connectors, batteries, etc.) are capable of being recycled.
Final disposition of this product after its service life must be accomplished in accordance with applicable country, state, or
local laws or regulations.
Advisory Conventions
CAUTION
This symbol and title indicate potential damage and tells you how to avoid
the problem.
Electric Shock
This symbol and title warn of hazards due to electrical shocks (> 60V) when
touching products or parts of them. Failure to observe the precautions indi-
cated and/or prescribed by the law may endanger your life/health and/or
result in damage to your material.
WARNING
This symbol and title emphasize points which, if not fully understood and
taken into consideration by the reader, may endanger your health and/or
result in damage to your material.
ESD Sensitive Device
This symbol and title inform that electronic systems and their components are sensitive
to static electricity. Therefore, care must be taken during all handling operations and
inspections of this product, in order to ensure product integrity at all times.
Please read also the section “Special Handling and Unpacking Instructions”.

www.kontron.com
CP6924-1 User Guide
9
Safety Instructions
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its compliance
with electrical safety requirements. It was also designed for a long fault-free life. However, the life expectancy of your
product can be drastically reduced by improper treatment during unpacking and installation. Therefore, in the interest of
your own safety and of the correct operation of your new Kontron product, you are requested to conform with the following
guidelines.
Temperature and High Voltage Safety Instructions
Note...
This symbol and title emphasize aspects the reader should read through carefully for his
or her own advantage.
CE Conformity
This symbol indicates that the product described in this manual is in compliance
with all applied CE standards. Please refer also to the section „Regulatory cpmpli-
ance Statements“ in this manual.
WARNING
All operations on this device must be carried out by sufficiently skilled per-
sonnel only.
Be careful, this device will heat up during operation, and if touched
may cause burns. The temperature of the product housing may reach up
to approximately 50°C. Allow for sufficient cool down before handling
after power is turned off.
Electric Shock
Before installing your new Kontron product into a system always
ensure that your mains power is switched off. This applies also to the
installation of piggybacks.
Serious electrical shock hazards can exist during all installation,
repair and maintenance operations with this product. Therefore,
always unplug the power cable and any other cables which provide
external voltages before performing work.

www.kontron.com
CP6924-1 User Guide
10
Special Handling and Unpacking Instructions
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is otherwise
protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is not guar-
anteed, it is important for the user to be electrically discharged before touching the product with his/her hands or tools.
This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices, jumper
settings etc. If the product contains batteries for RTC or memory back-up, ensure that the system is not placed on conduc-
tive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage the batteries or conduc-
tive circuits on the system.
Laser Lights
Laser light from fiber-optic transmission cables and components can
damage your eyes. The laser components plugged into the switch are
Class 1 laser components. Class 1 laser is considered incapable of pro-
ducing damaging radiation levels during normal operation or mainte-
nance.
To avoid damaging your eyes and to continue safe operation in case of
abnormal circumstances:
• Never look directly into the outlets of fiber-optic transmission com-
ponents or fiber-optic cables with unprotected eyes.
• Never allow fiber-optic transmission path to operate until all the con-
nections have been made.
• Always fit protective plugs to any unused ports of the switch.
ESD Sensitive Device
Electronic systems and their components are sensitive to static electricity. Therefore,
care must be taken during all handling operations and inspections of this product, in
order to ensure product integrity at all times.
