Konwin OH907 User manual

OIL-FILLED
RADIATOR HEATER
USER MANUAL
Model No. OH907
KM051318_OH907
WARNING Read and understand this entire user manual, including all safety information,
before
electric shock, or serious personal injuries.
CAUTIONKeep this user manual for future reference.

2
2
Thank you for choosing a KONWIN Product. This user manual
will provide you with valuable information necessary for the proper
care and maintenance of your new product. Thoroughly read the
instructions and familiarize yourself with all the operational aspects
of your new product.
IMPORTANT INSTRUCTIONS
1. Read ALL the instructions before using this unit.
2. CAUTION: Risk of electric shock. DO NOT open or try
to repair the heater yourself.
3. This heater may get hot when in use. To avoid burns,
DO NOT let bare skin touch hot surfaces. If provided, use
the handle(s) when moving this heater. DO NOT place
it against walls, furniture, curtains, etc.
4. Keep combustible materials, such as furniture, pillows,
bedding, paper, clothes, and curtains, at least 3 ft from the
front of the heater and keep them away from the sides,
top, and rear. DO NOT place towels or other objects on
the heater.
5. Extreme caution is necessary when any heater is used
near children or disabled persons, or when it is left running
unattended.
6. DO NOT operate any heater with a damaged cord or
after the heater malfunctions, has been dropped or dam-
aged in any manner. Return the heater to an authorized
service facility for examination, electrical or mechanical
adjust-ment, or repair.
7. This heater is not intended for use in bathrooms, laundry
areas, showers or swimming pools, and similar locations.
NEVER locate the heater where it may fall into a bathtub
or other water container. To protect against electrical
haz-ards, DO NOT immerse in water or other liquids.
8. DO NOT touch the control panel or plug with wet hands.
9. DO NOT run the cord under carpeting. DO NOT cover
the cord with throw rugs, runners, or similar coverings.
Arrange the cord away from traffic areas and where it will
not be tripped over.
When using this electric unit, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and
injuries to persons, including the following:

3
Save these instructions
10. DO NOT insert or allow foreign objects to enter any ven-
tilation or exhaust opening as this may cause an electric
shock or fire, or damage the heater.
11. To prevent a possible fire, DO NOT block the air intakes or
exhaust in any manner. DO NOT use on soft surfaces, like
a bed, where openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. DO
NOT use in areas where gasoline, paint, explosive, and/or
flammable liquids are used or stored. Keep the unit away
from heated surfaces and open flames.
13. Always plug the heater directly into a wall outlet/
receptacle. Never use with an extension cord or relocatable
power tap (outlet/power strip).
14. To avoid fire or shock hazards, plug the unit directly into a
120 V AC electrical outlet.
15. To disconnect the heater, turn controls to OFF and then
remove the plug from the outlet. Pull firmly on the plug,
DO NOT unplug by pulling on the cord.
16. Always unplug the unit before moving or cleaning, or
whenever the heater is not in use.
17. Use only for intended household use as described in this
manual. Any other use not recommended by the manufac-
turer may cause fire, electric shock, or injuries to
persons. The use of attachments not recommended or
sold by unauthorized dealers may cause hazards.
18. Always use on a dry, level surface. Use on floors only.
19. DO NOT use outdoors.
20. WARNING: To reduce the risk of fire or electric shock,
DO NOT use this unit with any solid-state speed control
device.
21. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void your
warranty. The inside of the unit contains no user service-
able parts.
22. Always use the product in an upright position.

9.9 x 13.9 x26 in. (W x D x H)
15 lb
Tip-Over Safety Feature
This heater is equipped with a shut-off safety feature. Once
the heater is tipped over, an internal switch will automatically
shut the heater off. Once the heater is restored to an upright
position, the heater will reset. To continue operation, press
the power button on the control panel or remote control.
Overheat Safety Feature
This heater is equipped with an overheat safety feature. When
the heater’s internal components reach a certain temperature
that could cause overheating ill
automatically shut off.
• A thermal overload protector is built in to prevent over-
heating. When an overheat temperature is reached, the
heater will automatically shut off. Operation can resume
only when the user resets the unit.
• To reset the unit, unplug the heater, ensure the power is
turned off, and wait 15 to 20 minutes for the unit to cool
down.
• Follow the INSTRUCTIONS FOR USE to return the heater
to operating mode.
1,500W

5
IN THE BOX
PART DESCRIPTION QUANTITY
A Heater 1
1
BBolt 2
CNut 4
DPedal
Butterfly nut
2
E 2
F
/
Caster
User manual
4

6
Power Knob
Thermostat Knob
Cord Wrap Housing
Casters
Oil Filled Fins
Pedals
Power Light

6
INSTRUCTIONS FOR ASSEMBLY
1
2
n
in
A
B
D
E
D
B
A
7
butterfly
butterfly nuts (E)

8
4
3. Remove the nuts (C)
preassembled to the casters
(F). Insert the top of casters
into the holes on the pedals
(D). Use the removed nuts to
secure the Casters.
3
FD
C
4. Turn the assembled unit
upright. Ensure the casters
are installed correctly and
level.
Place the heater only on a
the heater on an incline can
cause damage to the heater
and lead to hazardous
situations.
WARNING

9
High
Low Med
+-
The rmo stat
4.
1. Place the product on a rm, level surface.
2. Plug the unit directly into a 120-VAC electrical outlet.
3. Rotate the POWER KNOB clockwise to select
between low heat, medium heat, and high heat .
To maintain energy, the heater operates at 600 W on LOW
position, at 900 W on MEDIUM position, and at a maximum
of 1,500 W on HIGH position.
Turn the THERMOSTAT KNOB clockwise to the highest
setting.
5. When the room reaches a comfortable temperature,
slowly turn the THERMOSTAT KNOB counterclockwise
until the heating element clicks OFF.
6. This is the point where the thermostat setting equals the
room temperature. At this setting, the thermostat will
automatically turn the heater ON and OFF to maintain the
selected temperature.
7. Turn the POWER KNOB to the OFF position and unplug
the heater when finished using.
odour

MAINTENANCE
STORAGE
1. Turn the POWER to the OFF position.
2. Unplug the unit and let it cool down completely.
3. To keep the heater clean, the outer shell may be cleaned
with a soft, damp cloth. A mild detergent can be used if
necessary.
4. After cleaning, dry the unit with a soft cloth.
5. Wait until the unit is completely dry before use.
WARNING
• DO NOT let liquid enter the heater.
• DO NOT use alcohol, gasoline, abrasive powders,
furniture polish, or rough brushes to clean the heater.
This may cause damage or deterioration to the surface
of the heater.
• DO NOT immerse the heater in water.
1. Save the original box for off-season storage.
2. Clean the heater with a soft, damp cloth.
3. Remove the base feet.
4. Place the radiator and base feet in the original box, and store
in a cool and dry place.
5. The heater is stored fully assembled; ensure it is covered to
protect from the dust.
10

11
If the heater will not operate, please check the following:
1. Check if the power cord is plugged into an electrical outlet.
If not, plug the unit into an appropriate outlet.
2. Check if electricity to the outlet is working.
3. Ensure power is turned to the ON position.
4. Make sure the heater is placed on a flat, solid surface.
5. Refer to the SAFETY FEATURES section for additional
information.
6. Turn the THERMOSTAT KNOB clockwise. The heater only
works when the set temperature is higher than room tem-
perature.
protector,
overheating (e.g. of the grilles,

12
LIMITED MANUFACTURER WARRANTY
1-Year Limited Warranty: Konwin warrants this heater against
defects in materials and workmanship on functional parts or a
period of one year from the original date of purchase. Your sales
receipt showing the date of purchase of the product is your
proof of purchase. Keep it in a safe place for future reference.
Manufacturer Warranty
All Konwin products are manufactured with the highest quality
materials and are warranted to be free from defects in material
and workmanship at the time of purchase. This limited warranty
applies to products manufactured or distributed by the Konwin
brand name, are delivered in the continental United States, and
extends to the original purchaser or gift recipient. This warranty
becomes valid at the time of purchase and terminates either by
the speci ed time frame listed above and/or owner transfer
(unless otherwise authorized by Konwin, as the manufacturer).
Any extended warranties (warranties that cover above and be-
yond this manufacturer warranty) that are sold through a retailer
or third party are not directly correlated with this Konwin limited
warranty, and may be redirected to the said retailer or third party
for coverage.
Some States do not allow limitations on how long an implied
warranty lasts, sothe above limitation may not apply to you.
Some Statesdo not allow the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion
may not apply to you.
other rights, which vary from State to State.
The purchaser must present Konwinwith proof of purchase
documents (including the date of purchase) if requested. Any ev-
idence of alteration, erasing, or forgery of proof of purchase doc-
uments will be just cause to VOID this limited warranty. Products,
in which the serial number has been defaced or removed, are not
eligible for warranty coverage.

13
CUSTOMER SERVICE AND SUPPORT
•Model number & serial number (located on the front panel, rear panel,or
box)
•Date of purchase
•Retailer
•Daytime phone number
•Email address
•Copy of receipt
•Detailed description of issue/symptom
Distributed by:
Ningbo Konwin Electrical Appliance Co., Ltd.
Ningbo, China 315315
MADE IN CHINA
Please read the user manual carefully before setting up or
using this product.
For warranty support, please follow these instructions:
Contact Konwin Products Technical Support
Website: www.konwinus.com
Email: [email protected]
Phone: [phone]
Hours: 9 AM – 5 PM (CST), Monday - Friday
Please provide the following information:
