  9. Kostal PLENTICORE plus G2 User manual

Kostal PLENTICORE plus G2 User manual

Activate EXTRA YEARS
of FREE WARRANTY!
at shop.kostal-solar-electric.com
Quick Start Guide
PLENTICORE plus G2/PLENTICORE BI G2
Weitere Informationen zum Wechselrichter wie z. B. eine ausführli-
che Betriebsanleitung, freigegebene Energiezähler, Batteriespeicher,
Ländereinstellungen für die Inbetriebnahme, freigegebene Länder
in denen der Wechselrichter betrieben werden kann, Service- und
Garantiebedingungen, EU-Konformitätserklärung und Zertifikate
finden Sie im Internet im Downloadbereich zu Ihrem Produkt unter
www.kostal-solar-electric.com > Download.
Further information on the inverter, such as detailed operating inst-
ructions, approved energy meters, battery storage, country settings
for commissioning, approved countries in which the inverter can be
operated, service and guarantee conditions, EU declaration of con-
formity and certificates can be found on the Internet in the download
area for your product under
www.kostal-solar-electric.com > Download.
DE Gefahr! Lebensgefahr durch Stromschlag und elektrische Entladung. Im Wechselrichter liegen lebensgefährliche Spannungen an. Nur eine Elektrofachkraft
darf das Gerät önen und daran arbeiten. Gerät bei Montage, Wartung und Reparaturen immer spannungsfrei schalten und gegen Wiedereinschalten sichern.
Die PV-Generatoren/-Leitungen können unter Spannung stehen, sobald diese dem Licht ausgesetzt sind. Im laufenden Betrieb dürfen keine DC-Leitungen
an das Gerät angeschlossen oder abgezogen werden, da gefährliche Lichtbögen entstehen können. Die Firma KOSTAL Solar Electric GmbH erklärt hiermit,
dass sich die in diesem Dokument beschriebenen Wechselrichter mit den grundlegenden Anforderungen und anderen relevanten Bestimmungen der unten
genannten Richtlinien in Übereinstimmung befinden.
CZ Nebezpečí! Ohrožení života elektrickým proudem a výbojem. Ve střídači je životu nebezpečné napětí. Přístroj smí otevřít a pracovat na něm pouze kvalifikovaný elektrikář.
Přístroj se musí při montáži a opravách vždy odpojit od napětí a zabezpečit proti opětovnému zapnutí. FV generátory/rozvody mohou být pod napětím, pokud jsou vystaveny
světlu. Za probíhajícího provozu nelze k přístroji připojovat stejnosměrné rozvody ani je odpojovat, protože může vzniknout nebezpečný elektrický oblouk. Firma KOSTAL Solar
Electric GmbH tímto prohlašuje, že střídače popsané v tomto dokumentu vyhovují základním požadavkům a ostatním relevantním ustanovením níže uvedených směrnic.
DA Fare! Livsfare pga. elektrisk stød og elektrisk afladning. Der er påtrykt livsfarlige spændinger i vekselstrømsomformeren. Apparatet må kun åbnes og repareres af en elektriker.
Apparatet skal altid kobles helt fra spændingen og sikres mod genindkobling ved montering, vedligeholdelse og reparation. FV-generatorerne/-ledningerne kan være påtrykt spæn-
ding, så snart disse udsættes for lyset. Under driften må der ikke tilsluttes eller frakobles DC-ledninger til apparatet, da der kan opstå farlige lysbuer. Firmaet KOSTAL Solar Electric
GmbH erklærer hermed, at de vekselstrømsomformere, der beskrives i dette dokument, er i overensstemmelse med de grundlæggende krav og andre relevante bestemmelser i de
nedenstående direktiver.
EL Κίνδυνος! Κίνδυνος θανάτου από ηλεκτροπληξία και ηλεκτρική εκφόρτιση. Στον αντιστροφέα υπάρχουν θανατηφόρες ηλεκτρικές τάσεις. Το άνοιγμα της συσκευής και οι
εργασίες στη συσκευή επιτρέπεται να διενεργούνται μόνο από ηλεκτρολόγο. Πριν από την εγκατάσταση, τη συντήρηση και τις επισκευές θα πρέπει πάντα να διακόπτετε την
ηλεκτρική τροφοδοσία της συσκευής και να την ασφαλίζετε από επανενεργοποίηση. Οι Φ/Β αγωγοί/γεννήτριες μπορεί να βρίσκονται υπό τάση όταν εκτίθενται σε φως. Σε
κατάσταση λειτουργίας δεν επιτρέπεται σε καμία περίπτωση να συνδέονται ή να αποσπώνται αγωγοί DC από τη συσκευή, επειδή μπορεί να προκύψουν επικίνδυνα βολταϊκά
τόξα. Η KOSTAL Solar Electric GmbH δηλώνει με την παρούσα ότι οι αντιστροφείς που περιγράφονται σε αυτό το έντυπο συμφωνούν με τις θεμελιώδεις απαιτήσεις και άλλους
σχετικούς κανονισμούς των ακόλουθων αναφερόμενων Οδηγιών.
EN Danger! Risk of death due to electrical shock and discharge. Life-threatening voltages are present in the inverter. Only a qualified electrician may open and perform work on the
device. Always de-energise the device during installation, maintenance and repairs, and secure it against being switched back on. The PV generators/cables may be live as soon
as they are exposed to light. DC cables must never be connected to or disconnected from the device during operation, as dangerous arcs may form. KOSTAL Solar Electric GmbH
hereby declares that the inverter described in this document complies with the basic requirements and other relevant conditions of the directives listed below.
Legal notice
KOSTAL Solar Electric GmbH
Hanferstraße 6, 79108 Freiburg i. Br., Germany, Phone +49 (0)761 477 44 - 100, www.kostal-solar-electric.com.
Exclusion of liability
All names, trademarks, product names or other designations given in this manual may be legally protected even if this is not labelled
as such (e.g.as a trademark). KOSTAL Solar Electric GmbH accepts no liability and gives no assurance that they can be freely used.
The illustrations and texts have been compiled with great care. However, the possibility of errors cannot be ruled out. The compilation
is made without any guarantee.
General note on gender equality
KOSTAL Solar Electric GmbH is aware of the importance of language with regard to the equality of women and men and always
makes an eort to reflect this in the documentation. Nevertheless, for the sake of readability we are unable to use non-gender-specific
terms throughout and use the masculine form instead.
© 2022 KOSTAL Solar Electric GmbH
All rights reserved by KOSTAL Solar Electric GmbH, including those of reproduction by photocopy and storage in electronic media.
Commercial use or distribution of the texts, displayed models, diagrams and photographs appearing in this product is not permitted.
This manual may not be reproduced, stored, transmitted or translated in any form or by means of any medium – in whole or in part –
without prior written permission.
ES ¡Peligro! Peligro de muerte debido a electrocución y descarga eléctrica. En el inversor existen tensiones que pueden poner en peligro su vida. Únicamente
se permite abrir el equipo y realizar trabajos en el mismo a electricistas profesionales. Durante el montaje, el mantenimiento y reparaciones, desconecte
siempre el equipo de la tensión y protéjalo contra reconexión. Las líneas y los generadores fotovoltaicos pueden estar bajo tensión tan pronto como quedan
expuestos a la luz. Mientras el equipo esté en funcionamiento, queda prohibido conectar o desconectar cables CC del mismo, puesto que pueden producirse
arcos eléctricos peligrosos. La empresa KOSTAL Solar Electric GmbH declara por el presente que los inversores descritos en este documento cumplen los
requisitos básicos y otras disposiciones relevantes de las directivas indicadas abajo.
ET Oht! Eluohtlik elektrilöögi või elektrilahenduse tõttu. Vaheldi sisemuses on eluohtlik pinge. Seadet tohivad avada ja selle juures töid teha ainult elektrikud. Lülitage seade enne
paigaldamist, hooldust ja remonti alati pingevabaks ning kindlustage uuesti sisselülitamise vastu. Päikeseelektrigeneraatorid/-kaablid võivad pingestuda kohe, kui neile langeb
valgus. Töötava seadmega ei tohi ühendada ega töötavast seadmest lahutada alalisvoolukaableid, kuna tekkida võivad ohtlikud elektrikaared. Käesolevaga kinnitab firma KOSTAL
Solar Electric GmbH, et selles dokumendis kirjeldatud vaheldid vastavad allpool nimetatud direktiivide olulistele nõuetele ja teistele asjakohastele sätetele.
FI Vaara! Sähköiskun ja sähköpurkauksen aiheuttama hengenvaara. Invertterissä on hengenvaarallisia jännitteitä. Vain sähköalan ammattilaiset saavat avata laitteen ja tehdä sille
toimenpiteitä. Kytke laite aina jännitteettömäksi ja varmista, ettei sitä voida käynnistää uudelleen, ennen kuin asennat laitteen tai teet sille huolto- tai korjaustöitä. Aurinkopaneelit
/ aurinkosähköjärjestelmän johdot voivat olla jännitteisiä heti kun valo osuu niihin. Laitteeseen ei saa liittää eikä siitä saa irrottaa DC-johtoja käytön aikana, sillä muutoin voi syntyä
vaarallisia valokaaria. KOSTAL Solar Electric GmbH ilmoittaa, että tässä asiakirjassa kuvatut invertterit vastaavat alla mainittujen direktiivien perustavanlaatuisia vaatimuksia sekä
muita asianmukaisia määräyksiä.
FR Danger ! Danger de mort par électrocution et décharge électrique. Des tensions représentant un danger mortel traversent l’onduleur. Seul un électricien est habilité à ouvrir
l’appareil et à y eectuer des travaux. Lors de l’installation, de l’entretien et de la réparation, mettre toujours l’appareil hors tension et le protéger contre toute remise en marche.
Les générateurs ou les câbles photovoltaïques peuvent être sous tension dès qu’ils sont exposés à la lumière. Ne pas brancher ni débrancher les câbles DC de l‘appareil pendant
son fonctionnement au risque de créer des arcs électriques dangereux. La société KOSTAL Solar Electric GmbH certifie par la présente déclaration que les onduleurs décrits dans
le présent document sont conformes aux exigences fondamentales et aux autres dispositions applicables des directives ci-dessous.
IT Pericolo! Pericolo di morte per scossa elettrica e folgorazione. Nell‘inverter si trovano tensioni mortali. Solo un elettricista specializzato può aprire il dispositivo e operare su di
esso. Durante l’installazione, la manutenzione o la riparazione, togliere sempre la tensione al dispositivo e impedirne la riaccensione. I generatori / i cavi dell‘impianto FV possono
essere in tensione quando il campo fotovoltaico è irradiato. Durante il funzionamento, i cavi DC non devono essere collegati o scollegati dal dispositivo, poiché potrebbero verificarsi
pericolosi archi elettrici. La società KOSTAL Solar Electric GmbH dichiara con la presente che gli inverter descritti nel presente documento soddisfano i requisiti fondamentali e le
altre disposizioni rilevanti delle direttive sotto indicate.
NL Gevaar! Levensgevaar door elektrische schok en elektrische ontlading. De omvormer staat onder levensgevaarlijke spanningen. Alleen een elektromonteur mag het toestel
openen en eraan werken. Schakel het toestel bij montage, onderhoud en reparaties altijd spanningsvrij en beveilig het tegen opnieuw inschakelen. De fotovoltaïsche generatoren/
leidingen kunnen onder spanning staan, zodra deze aan licht zijn blootgesteld. Tijdens de werking mogen geen DC-leidingen op het toestel worden aangesloten of uitgetrokken,
aangezien er gevaarlijke vlambogen kunnen ontstaan. De firma KOSTAL Solar Electric GmbH verklaart hiermee dat de in dit document beschreven omvormers in overeenstemming
zijn met de fundamentele vereisten en andere relevante bepalingen van de hieronder genoemde richtlijnen.
PL Niebezpieczeństwo! Zagrożenie życia poprzez porażenie prądem elektrycznym i wyładowanie elektrostatyczne. W falowniku występują niebezpieczne napięcia. Tylko
elektryk może otwierać urządzenie i pracować przy nim. Przed przystąpieniem do montażu, czynności konserwacyjnych i napraw należy odłączyć urządzenie od źródła napięcia
i zabezpieczyć przed ponownym włączeniem. Gdy tylko na generatory/przewody PV pada światło, mogą znajdować się pod napięciem. Podczas pracy do urządzenia nie wolno
podłączać ani odłączać przewodów DC, ponieważ mogłoby to spowodować niebezpieczne wyładowanie łukowe. Firma KOSTAL Solar Electric GmbH oświadcza niniejszym, że
falowniki opisane w niniejszym dokumencie spełniają zasadnicze wymagania i inne istotne postanowienia podanych poniżej dyrektyw.
PT Perigo! Perigo de morte devido a choque elétrico e descarga elétrica. No inversor existem tensões perigosas para a vida. Apenas um eletricista deve abrir o aparelho e
trabalhar no mesmo. Desligue sempre o aparelho da tensão para a montagem, manutenção e reparações e proteja-o contra uma nova ligação. Os geradores/cabos FV podem
ficar sob tensão assim que são sujeitos a radiação. Durante o funcionamento, os cabos CC nunca podem ser ligados ou removidos do aparelho, uma vez que podem resultar
arcos elétricos perigosos. A empresa KOSTAL Solar Electric GmbH declara pela presente que os inversores descritos neste documento estão em conformidade com as exigências
essenciais e outras disposições relevantes das diretivas mencionadas em baixo.
SE Fara! Livsfara på grund av elektriska stötar och elektrisk urladdning. Livsfarlig spänning är aktiv i växelriktaren. Endast en behörig elektriker får öppna och arbeta med appara-
ten. Anslut alltid apparaten i spänningsfritt tillstånd vid montering, underhåll och reparationer och säkra mot återinkoppling. Solcellsgeneratorerna/-kablarna kan stå under spänning
så snart de utsätts för ljus. Under löpande drift får inga DC-kablar anslutas till eller kopplas bort från apparaten, eftersom farliga ljusbågar då kan uppstå. KOSTAL Solar Electric
GmbH intygar härmed att växelriktarna som beskrivs i detta dokument uppfyller de grundläggande kraven och andra relevanta bestämmelser i nedanstående direktiv.
IP65
NH3
-20...60 °C
-4...140 °F
4...100 %
2000 m 90°
90°
200
200
100
100 mm
100 100
141,5 141,5122
405
202,5
202,5 47
200
(mm)
200
563
410
25
128
3 x min. DIN571 A2-70 6 x 50
1.
2.
47
410
122
1 x per DC input
1 x pro DC Eingang
Findthe user manual
Bedienungsanleitungherunterladen
Getyour free monitoring
KostenloseAnlagenüberwachung
KOSTALSolarApp
Android
KOSTALSolarApp
iOS
KOSTAL
SolarPortal
Watchfreevideo tutorials
SehenSie sich kostenlose Video-Tutorialsan
www.kostal-solar-electric.com
Findtheuser manual
Bedienungsanleitungherunterladen
Getyourfree monitoring
KostenloseAnlagenüberwachung
KOSTALSolarApp
Android
KOSTALSolarApp
iOS
KOSTAL
SolarPortal
Watchfreevideo tutorials
SehenSiesich kostenlose Video-Tutorials an
www.kostal-solar-electric.com
Short Manual
L2
L1
L3
N
LAN
DC
COM Smart Communication Board (SCB) KSEM
AC
N PE
RS485
Modbus
LAN
L1 L2 L3
L1 L2 L3 N
LAN
STATUS
NETWORK
SERIALBUS
REST
SmartEnergy Meter
X452
X601
RS485
(Modbus)
X452
B
VCC
GND
A
4321 RS485 (A)
BMS
optional with Code
optional mit Code
PLENTICORE plus
or
X401 X601 X452
A
PLENTICORE plus with batterie / mit Batterie
PLENTICORE BI
PLENTICORE plus
RS485
(Modbus)
X452
B
VCC
GND
A
4321 RS485 (A)
A BGND
L2
L1
L3
N
PE
RS485
Modbus
LAN
L1 L2 L3
L1 L2 L3 N
LAN
STATUS
NETWORK
SERIALBUS
REST
Smart Energy Meter
LAN
LAN LAN
BMS
X601
A
LAN
BMS
X601
PLENTICORE BI
Smart
Communication
Board (SCB)
A
B
GND
WiFi
OFF
ON
OFF
0
L1 L2 L3 N
L1|L2|L3|N|PE
8 Nm
AC max. 10-17 mm
A
A
B
A
B
B
3.0 = 1,5 - 6 mm² 18 mm
4.2 = 1,5 - 6 mm² 18 mm
5.5 = 1,5 - 6 mm² 18 mm
7.0 = 2,5 - 6 mm² 18 mm
8.5 = 2,5 - 6 mm² 18 mm
10 = 4 - 6 mm² 18 mm
NYM-J
NYY-J H05../H07
RN-F
2. System overview | System Übersicht
3. Connect AC | AC anschließen
1. Mounting inverter | Wechselrichter montieren
100%
0%
- KOSTAL Smart Energy Meter
- KOSTAL Energy Meter
- B+G SDM630-Modbus
N PE
Connection via RS485 (Modbus RTU Master)
Sensor position: Grid connection (Position 2)
Verbindung über RS485 (Modbus RTU Master)
Sensorposition: Netzanschlusspunkt (Position 2)
https://www.kostal-solar-electric.com/released-energy-meters-hybrid
L2
L1
L3
N
PE
PLENTICORE plus
Released energy meters / Freigegebene Energiezähler
PLENTICORE BI
- KOSTAL Smart Energy Meter
- KOSTAL Energy Meter
RS485
Modbus
LAN
L1 L2 L3
L1 L2 L3 N
LAN
STATUS
NETWORK
SERIAL BUS
REST
Smart Energy Meter
100%
0%
100%
0%
0,2-1,5 mm²/max. 30 m
100%
0%
A | B | GND
X452
100%
0%
X207
LAN X206
LAN
LAN
LAN
LAN
WWW
WiFi
Cat 6/max. 100 m
BMS
X601
KOSTAL SOLAR WEBSHOP
shop.kostal-solar-electric.com
www.kostal-solar-electric.com
To connect a battery to the DC3 input of the
PLENTICORE plus, an activation code battery
must be purchased.
Um eine Batterie am DC3-Eingang am
PLENTICORE plus anzuschließen, muss ein
Aktivierungscode Batterie gekauft werden.
optional with code
optional mit Code
BMS
DC3
Code required only for PLENTICORE plus
Code erforderlich nur für PLENTICORE plus
DC=
OFF
ON
BMS
Battery only for / Batterie nur mit
PLENTICORE plus (optional with code / optional mit Code)
PLENTICORE BI
Cat.5e / 0,2-1,5 mm² / max. 30 m
Released batteries / Freigegebene Batterien
https://www.kostal-solar-electric.com/plenticore_released_batteries
X601
VDD +12-14V
GND 0V
RS485 B
RS485 A
5. Connect LAN / WiFi communication | LAN / WLAN Kommunikation anschließen
6. Connect battery communication | Batterie Kommunikation anschließen
4. Connect Energy meter in grid position | Energiezähler anschließen am Netzanschlusspunkt
X1401
max. 24V/100mA
out2out1 out3 out4
X1402 X401 X403 X601 X402 X452
Digital-OUT RS485MONBattery com.Digital-IN CEI
REFGen
In1/5
In2/6
In3/7
In4/8
COM
COM
VDD
Hi
Lo
B A
RS485CAN
GND
A
-- -- -- --
B
GND
GND
SPD
LOC
EST
Connection field
SCB board |
Anschlussfeld
SCB Board
UDCmax = 1000 V
DC cable PV according to EN50618 - 6mm²
DC-Kabel PV nach EN50618 - 6mm²
DC cable battery
according to EN50618
6mm²
DC-Kabel Batterie
nach EN50618
6mm²
Battery connection
only on DC3
Batterieanschluss
nur an DC3
DC=
PV only with / PV nur mit
PLENTICORE plus
BMS
DC=
OFF
ON
BMS
Battery only with / Batterie nur mit
PLENTICORE plus (optional + code)
PLENTICORE BI
DC1 DC2 DC3 DC1 DC2 DC3
1,5 Nm
2 Nm
ON
ON
OFF
0
BMS
OFF
ON
BMS
open setup wizard via IP address /
Installationsassistent über IP Adresse aufrufen
xxxxxx
Cancel or back
Abbrechen oder zurück
Enter
Bestätigen
IP address inverter
Status inverter
Event code
IP-Adresse Wechselrichter
Status Wechselrichter
Ereigniscode
Status:
WiFi status
Event notification
Portal access
Update available
Status:
WLAN-Status
Ereignismeldung
Portal-Verbindung
Update verfügbar
Select button
Auswahl Tasten
Settings
Einstellungen
Battery
Batterie
PV
PV
Grid
Netz
Home consumtion
Hausverbrauch
Code
BMS
Not for PLENTICORE plus without battery Not for PLENTICORE BI
Nicht für PLENTICORE plus ohne Batterie Nicht für PLENTICORE BI
Only for
PLENTICORE plus with battery:
Purchase Activation code
Battery and enter during
initial commissioning.
Nur für
PLENTICORE plus mit Batterie:
Aktivierungscode Batterie
kaufen und während der
Erstinbetriebnahme eingeben.
WiFi hotspot /
WLAN-Hotspot
WiFi
connect with inverter hotspot /
verbinden mit Wechselrichter Hotspot
BMS
WiFi
192.168.67.1
Setup wizard
Language
Wellcome
Display Setup
X
SSID: KOSTAL_xxxxxxxxxxxxx
Password: nnnnnnnn
Welcome! Please connect...
http://192.168.67.1
Welcome! Please connect...
7. Close inverter | Wechselrichter schließen
8. Connect DC for PV/Battery | DC anschließen für PV/Batterie
9. Switch on battery/inverter | Batterie/Wechselrichter einschalten
10. Initial commissioning/Operation | Erstinstallation/Bedienung
11/2022 - MA 12156953-0001 - DOC03013376-0001 - This manual is subject to technical changes and printing errors.
You can find current information at www.kostal-solar-electric.com. Manufacturer: KOSTAL Industrie Elektrik GmbH, Hagen, Germany
www.kostal-solar-portal.com
Select / Auswahl
Create a new plant and add the new device to the plant /
Erstellen Sie eine neue Anlage und fügen Sie den
Wechselrichter der neuen Anlage hinzu
xxxxxxxx
<Password>
Plant owner
Forgotten password
Login
xxxxxxxx
<Master key>
<Service code>
Installer
Login
XXXXXXXXXXXXXXXX
Item no.: XXXXXXXX
Hanferstraße 6 – D-79108 Freiburg, +49 (0) 761-47744-100
www.kostal-solar-electric.com
DC input: AC output:DC input: = XXX...XXX V
Vdcmac = XXX V
Idcmax = XX.X A
Iscmax = XX.X A
VBatt_max= XXXV
IBatt_max XX.X A
Protective Class I, IP 55, -20°C...60°C, OVC DC:II / AC:III, VDE V 0126-1-1
Made in Germany
WARNING: dual supply
Isolate on-site generator at:
isolate mains supply at:
Do not work on this equipment until it is isolated from both mains and on-site generation
supplies:
Art. No.: NNNNNNNN
Ser. No.: XXXXXABCXXXXX
SW: XX.XX
Service update: XXXXXXXX
Master key: XXXXXXXXXX
3N~
Vac,r = XXX V
fr = XX Hz
Iacmax = max. XX.X A
Sac,r = XXXXX nVA
cos φ= X.X...1
xxxxxxxxxxxxx
5 min.
Enter IP address of inverter
Die IP Adresse des Wechselrichters eingeben
or / oder
Enter name of inverter
Wechselrichter Name eingeben
xxx.xxx.xxx.xxx
<name of inverter>
Login as Plant owner / Login als Anlagenbetreiber
Enter password / Passwort eingeben
For first login
creat a new
password
Erstellen Sie für die
erste Anmeldung
ein neues Passwort
Login as Installer / Login als Installateur
Enter Service code / Servicecode eingeben
Enter Master key / Master key eingeben
Inverter IP address
Wechselrichter IP Adresse
XXX.XXX.XXX.XXX
11. Login into the Webserver | Am Webserver anmelden
12. KOSTAL Solar Portal registration | KOSTAL Solar Portal Registrierung
www.kostal-solar-electric.com/service-and-support/contact
Contact | Kontakt
Open KOSTAL Solar App
as installer and
activate Smart Warranty.
Scan inverter type plate.
KOSTAL Solar App
als Installateur önen
und Smart Warranty aktivieren.
Wechselrichter Typenschild
einscannen.
Download
KOSTAL Solar App
KOSTAL Solar App
herunterladen
XXXXXXXXXXXXXXXX
Itemno.: XXXXXXXX
XXXXXABCXXXXX
Hanferstraße6–D-79108 Freiburg, +4 9 (0) 7 61-4774 4-100
www.kostal-solar-electric.com
DCinput: ACoutput:Vmpp: =XXX...XXXV
Vdcmac =XXX V
Idcmax = XX.XA
Iscmax =XX.XA
VBatt_max=XXXV
IBatt_maxXX.XA
ProtectiveClassI,IP 55, -20°C...60°C, OVCDC:II / AC:III, VDE V 0126-1-1
MadeinGermany
WARNING:dualsupply
Isolateon-sitegeneratorat:
isolatemainssupplyat:
Donotworkonthisequipmentuntilitisisolatedfrombothmainsandon-sitegeneration
supplies:
Art.No.: NNNNNNNN
Ser.No.:XXXXXABCXXXXX
SW: XX.XX
Serviceupdate:XXXXXXXX
Masterkey:XXXXXXXXXX
Grid =3N~
Vac,r = XXX V
fr =XXHz
Iacmax= XX.X A
Sac,r = XXXXX VA
cosφ=X.X...1
xxxxxxxxxxxxx
5min.
XXXXXXXXXXXXXXXX
Itemno.:XXX XXXXX
XXXXXABCXXXXX
Hanferstraße6–D-79108Freiburg, +4 9 (0) 7 61-4774 4-100
www.kostal-solar-electric.com
DCinput: ACoutput:Vmpp: =XXX...XXX V
Vdcmac = XXX V
Idcmax =XX.XA
Iscmax =XX.XA
VBatt_max=XXXV
IBatt_maxXX.XA
ProtectiveClassI,IP55, -20°C...60°C,OVCDC:II / AC:III, VDE V0126-1-1
MadeinGermany
WARNING:dualsupply
Isolateon-sitegeneratorat:
isolatemainssupplyat:
Donotworkonthisequipmentuntilitisisolatedfrombothmainsandon-sitegeneration
supplies:
Art.No.:NNNNNNNN
Ser.No.:XXXXXABCXXXXX
SW: XX.XX
Serviceupdate:XXXXXXXX
Masterkey:XXXXXXXXXX
Grid =3N~
Vac,r =XXXV
fr =XXHz
Iacmax=XX.X A
Sac,r =XXXXXVA
cosφ=X.X...1
xxxxxxxxxxxxx
5min.
13. Activate free Smart Warranty | Kostenfreie Smart Warranty aktivieren

Other manuals for PLENTICORE plus G2

1

This manual suits for next models

1

Other Kostal Inverter manuals

Kostal PIKO 36 EPC How to use

Kostal

Kostal PIKO 36 EPC How to use

Kostal PIKO 10 User manual

Kostal

Kostal PIKO 10 User manual

Kostal PIKO Series User manual

Kostal

Kostal PIKO Series User manual

Kostal PLENTICORE plus User manual

Kostal

Kostal PLENTICORE plus User manual

Kostal PIKO CI User manual

Kostal

Kostal PIKO CI User manual

Kostal PIKO MP plus series User manual

Kostal

Kostal PIKO MP plus series User manual

Kostal PLENTICORE BI User manual

Kostal

Kostal PLENTICORE BI User manual

Kostal PIKO 10-20 User manual

Kostal

Kostal PIKO 10-20 User manual

Kostal PLENTICORE plus How to use

Kostal

Kostal PLENTICORE plus How to use

Kostal PIKO User manual

Kostal

Kostal PIKO User manual

Kostal PIKO 6.0 BA How to use

Kostal

Kostal PIKO 6.0 BA How to use

Kostal PIKO IQ How to use

Kostal

Kostal PIKO IQ How to use

Kostal PIKO 10 User manual

Kostal

Kostal PIKO 10 User manual

Kostal PLENTICORE BI How to use

Kostal

Kostal PLENTICORE BI How to use

Kostal PIKO MP plus 1.5-1 Manual

Kostal

Kostal PIKO MP plus 1.5-1 Manual

Kostal PIKO MP plus User manual

Kostal

Kostal PIKO MP plus User manual

Kostal PIKO How to use

Kostal

Kostal PIKO How to use

Kostal PIKO Inverter 3.0 How to use

Kostal

Kostal PIKO Inverter 3.0 How to use

Kostal PIKO 1.5 MP User manual

Kostal

Kostal PIKO 1.5 MP User manual

Kostal PLENTICORE plus G2 User manual

Kostal

Kostal PLENTICORE plus G2 User manual

Kostal PIKO 4.2 User manual

Kostal

Kostal PIKO 4.2 User manual

Kostal PLENTICORE plus Instruction Manual

Kostal

Kostal PLENTICORE plus Instruction Manual

Kostal PIKO CI User manual

Kostal

Kostal PIKO CI User manual

Kostal PIKO CI How to use

Kostal

Kostal PIKO CI How to use

Popular Inverter manuals by other brands

ACOPOWER PS 500 user manual

ACOPOWER

ACOPOWER PS 500 user manual

Carrier Aura quick start guide

Carrier

Carrier Aura quick start guide

Grundfos RSI Installation and operating instructions

Grundfos

Grundfos RSI Installation and operating instructions

ETQ TG1200 owner's manual

ETQ

ETQ TG1200 owner's manual

SMA Sunny Boy 3800U installation guide

SMA

SMA Sunny Boy 3800U installation guide

Xantrex HI400 owner's guide

Xantrex

Xantrex HI400 owner's guide

SolaX Power X1 Series user manual

SolaX Power

SolaX Power X1 Series user manual

Qcells Q.HOME CORE A5 user manual

Qcells

Qcells Q.HOME CORE A5 user manual

Solplanet ASW S Series user manual

Solplanet

Solplanet ASW S Series user manual

Whistler Power inverter owner's manual

Whistler

Whistler Power inverter owner's manual

Next Wave CNC SHARK manual

Next Wave CNC

Next Wave CNC SHARK manual

Omron 3G3JX quick start guide

Omron

Omron 3G3JX quick start guide

Kaysun KSEF-22 DN5.0 Owners & installation manual

Kaysun

Kaysun KSEF-22 DN5.0 Owners & installation manual

Patron GI-3500P user manual

Patron

Patron GI-3500P user manual

Siemens SINAMICS V20 Inverter Compact operating instructions

Siemens

Siemens SINAMICS V20 Inverter Compact operating instructions

SOLIS 4G series user manual

SOLIS

SOLIS 4G series user manual

Asterion HYBRID 30K user manual

Asterion

Asterion HYBRID 30K user manual

Samlexpower PSE-24100A owner's manual

Samlexpower

Samlexpower PSE-24100A owner's manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
