KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
106
Mic Amplifier/DA
P/N: 2900-000074 Rev 2

106 – Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3Overview 4
3.1 Defining the 106 Mic Amplifier/DA 5
4Connecting the 106 6
5Technical Specifications 7
Figures
Figure 1: 106 Mic Amplifier/DA 5
Figure 2: Connecting the 106 Mic Amplifier/DA 6

106 - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer 106 Mic Amplifier/DA, which is ideal
for the following typical applications:
Public address systems
Presentation and multimedia audio distribution

2
106 - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer 106 away from moisture, excessive sunlight and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!

106 - Getting Started
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
!

4
106 - Overview
3 Overview
The 106 Mic Amplifier / DA is a high−quality distribution amplifier for balanced
mono microphone signals. It takes one dynamic or condenser microphone input
and distributes the signal to two high-level balanced mono line outputs, reaching
27Vpp (22dB).
The 106 features:
Three trimmers to adjust the LINE OUT audio level
A switch for selecting the type of microphone (condenser or dynamic)
Two balanced mono line outputs for power amplifiers

106 - Overview
5
3.1 Defining the 106 Mic Amplifier/DA
This section defines the 106.
Figure 1: 106 Mic Amplifier/DA
#
Feature
Function
1
LEVEL
LINE OUT 2 Trimmer
Adjusts the LINE OUT 2 audio level
Insert a screwdriver into the small hole and
carefully rotate it to adjust the audio level
2
LINE OUT 1 Trimmer
Adjusts the LINE OUT 1 audio level
3
MASTER Trimmer
Adjusts both the LINE OUT 1 and LINE OUT 2
audio levels
4
ON LED
Illuminates when receiving power
5
MIC IN Terminal Block
Connector
Connects to the microphone
6
TYPE COND./DYN Selector
Switch
Push to select the condenser microphone,
release to select the dynamic microphone
7
LINE OUT 1 Terminal Block
Connector
Connects to acceptor 1
8
LINE OUT 2 Terminal Block
Connector
Connects to acceptor 2
9
12V DC
+12V DC connector for powering the unit

6
106 - Connecting the 106
4 Connecting the 106
Always switch off the power to each device before connecting it to your
106. After connecting your 106, connect its power and then switch on
the power to each device.
To connect the 106 as illustrated in the example in Figure 2:
1. Connect a mono balanced microphone to the MIC IN terminal block
connector.
2. Connect the LINE OUT 1 terminal block connector to a power amplifier
and/or the LINE OUT 2 terminal block connector to a power amplifier.
3. Connect each power amplifier to a loudspeaker.
4. Connect the 12V DC power adapter to the power socket, and connect the
adapter to the mains electricity.
5. Adjust the audio level via LEVEL Trimmers, if required.
Use the LINE OUT 1 trimmer to adjust the line 1 output, use the LINE OUT 2 trimmer to
adjust the line 2 output, and use the MASTER trimmer to adjust both line outputs.
Figure 2: Connecting the 106 Mic Amplifier/DA
i

106 - Technical Specifications
7
5 Technical Specifications
INPUT:
1 microphone mono balanced on 3 pin terminal block
connector
OUTPUTS:
2 mono balanced line outputs on 3 pin terminal block
connectors
MAX. OUTPUT LEVEL:
27Vpp (22dBm)
BANDWIDTH:
>40kHz
S/N RATIO:
81dB
CONTROLS:
Mic. Type selector pushbutton, -14dB to +68dB LINE
OUT trimmers (MASTER trimmer at max.), +37dB to
+68dB master (LINE OUT trimmer at max.)
COUPLING:
Input: AC, Output: DC
AUDIO THD +NOISE:
0.18%
AUDIO 2nd HARMONIC:
0.16%
POWER CONSUMPTION:
12V DC, 132mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12 cm x 7.5 cm x 2.5 cm (4.7" x 2.95" x 0.98", W, D, H)
WEIGHT:
0.3 kg (0.66lbs.) approx.
ACCESSORIES:
Power supply (12V, 500mA), mounting bracket
OPTIONS:
RK-3T 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N:
2900-000074
Rev:
2
!
