USER MANUAL
Model:
VM-100YC
1:10 s-Video Distribution Amplifier

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
3 Overview 2
4 Your VM-100YC 3
5 Connecting the VM-100YC 4
6 Technical Specifications 5
Figures
Figure 1: VM-100YC 1:10 s-Video Distribution Amplifier 3
Figure 2: Connecting the VM-100YC 1:10 s-Video Distribution Amplifier 4
Tables
Table 1: VM-100YC 1:10 s-Video Distribution Amplifier Features 3
Table 2: Technical Specifications of the VM-100YC 1:10 s-Video Distribution Amplifier 5

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly
defined by function.
Congratulations on purchasing your Kramer VM-100YC, which is ideal for
the following typical applications:
Production and duplication facilities
Schools and boardrooms
Retail stores, point-of-sale systems, CCTV and security applications
The package includes the following items:
VM-100YC 1:10 s-Video Distribution Amplifier
Power supply (12V DC Input)
This user manual
2
2 Getting Started
We recommend that you:
Review the contents of this user manual
Use Kramer high performance high resolution cables
3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Twisted-Pair Solutions; GROUP 6: Specialty AV Products; GROUP 7: Scan
Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and
Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
2
3 Overview
The VM-100YC is a high quality 1:10 s-Video Distribution Amplifier for
s-Video (Y/C) signals. It accepts one input, provides correct buffering and
isolation, and distributes the signal to 10 identical outputs using 4-pin
connectors. The looping connector can be used to connect to a local display or
other Y/C acceptor, or to create larger systems (for example, connecting three
VM-100YC units to make a 1:30 s-Video Distribution Amplifier).
In addition, the VM-100YC features:
Bandwidth (Y) - 275MHz (-3dB)
Level (gain) controls - Y and C (on the underside)
Selectable input signal termination
A compact desktop size. Two units can be rack mounted side-by-side in
a 1U rack space with the optional RK-1 adapter
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated
noise-levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your VM-100YC away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
1
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 For example: model number AD2512C, part number 2535-000251

Your VM-100YC
3
4 Your VM-100YC
Figure 1 and Table 1 define the VM-100YC.
Figure 1: VM-100YC 1:10 s-Video Distribution Amplifier
Table 1: VM-100YC 1:10 s-Video Distribution Amplifier Features
#
Feature Function
1 POWER Switch Illuminated switch for turning the unit ON or OFF
2 INPUT 4-pin Connector Connects to the s-Video source
3 LOOP 4-pin Connector For looping (if required) to increase the number of outputs
4 TERM Button Pushing in selects 75; releasing selects Hi-Z
1
5 OUT 4-pin Connector Connects to the s-Video acceptors (from 1 to 10)
6 12 VDC +12V DC connector for powering the unit
1 For looping select Hi-Z

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the VM-100YC
4
5 Connecting the VM-100YC
To connect the VM-100YC 1:10 s-Video Distribution Amplifier,as the
example in Figure 2 illustrates, do the following
1
:
1. Connect the s-Video source (for example, an s-Video player) to the
INPUT 4-pin connector.
2. Connect the OUT 4-pin connectors to up to 10 s-Video acceptors (for
example, s-Video recorders).
3. If required, connect the LOOP 4-pin connector, when looping units and
release the TERM switch on first unit (selecting Hi-Z). Push in the
TERM switch on the second unit (selecting 75).
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2).
5. Switch on the VM-100YC.
The s-Video source distributes to the s-Video acceptors.
Figure 2: Connecting the VM-100YC 1:10 s-Video Distribution Amplifier
1 Switch OFF the power on each device before connecting it to your VM-100YC. After connecting your VM-100YC,
switch on its power and then switch on the power on each device

Technical Specifications
5
6 Technical Specifications
Table 2 defines the technical specifications:
Table 2: Technical Specifications
1
of the VM-100YC 1:10 s-Video Distribution Amplifier
INPUT: 1 s-Video: 1Vpp/75(Y), 0.3Vpp/75(C), on a 4-pin connector with a termination
switch
OUTPUT: 10 s-Video: 1Vpp/75(Y), 0.3Vpp/75(C), on 4-pin connectors; 1 s-Video loop
on a 4-pin connector
MAX. OUTPUT LEVEL: 1.9Vpp/75(Y)
BANDWIDTH (-3dB): 275MHz
DIFF. GAIN: 0.03%
DIFF. PHASE: 0.03 Deg.
K-FACTOR: < 0.05%
S/N RATIO: 81.4dB
CONTROLS: Trimmers for "Y" level: -1.4 to +6dB; "C" level: -1 to +6.3dB
COUPLING: AC
POWER SOURCE: 12 VDC, 80mA
DIMENSIONS: 22cm x 18cm x 4.5cm (8.7" x 7" x 1.7") W, D, H.
WEIGHT: 0.93kg (2lbs) approx.
ACCESSORIES: 12 VDC power supply
OPTIONS: RK-1 19" rack adapter
1 Specifications are subject to change without notice
